OWNER’S MANUAL

XMP300

OSD Audio

775 Columbia St.,

Brea. CA92821

www.osdaudio.com XMP300 Owner’s Manual 51115

Congratulations on your purchase of the OSD Audio XMP300.

Please take a few moments to read this entire manual, and be sure to

retain this document for future reference. Please read and observe all

safety instructions detailed on page 2.

NOTE: If any part of this product is damaged or missing, please call your

dealer or OSD Audio directly at 562-697-2600.

Please read your warranty and retain your receipt and original carton

for possible future use.

For more information about OSD Audio electronics, speakers and

accessories please visit www.osdaudio.com

XMP300

Digital Stereo Power Amplifier

FEATURES:

MAIN / INTERRUPT priority input switching

MAIN auxiliary output

Speaker A/B switching

Front panel Balance and Volume controls

Signal sensing “Power On” and Trigger mode

SPECIFICATIONS

Stereo (8 ohm): N150W x 2, <1% THD+

Stereo (4 ohm): N300W x 2, <1% THD+

Bridged Mono (8 ohm): 450W, 1kHz, <1% THD+N

Frequency Response: 10Hz ~ 30kHz, -2dB/ +1dB

Signal to Noise Ratio: 100dB below 150W output into 8 ohms

w/20kHz Lowpass filter

Channel Separation: 65dB @ 1kHz, referred to 150W output

into 8 ohms

Input Sensitivity: 700mV input for rated 150W output

into 8 ohms

AC Power Consumption: 450W maximum

Net Weight: 7.9lbs / 3.7kgs

Gross Weight: 10.7lbs / 5kgs

2.15”

(55mm)

16.9” (430mm)

11”

(280mm)

Rear mounted treble and bass controls

Bass/Treble Control: +/- 12dB @ 100Hz and 10kHz

13. Unplug the apparatus during lightning storms or when unused for long periods

of time.

14. Refer all servicing to qualified personnel. Servicing is required when the

apparatus has been damaged in any way, such as power supply cord or

plug is damaged, liquid has been spilled or objects have fallen into the

apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. WARNING: To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture. The apparatus shall not be exposed to

dripping or splashing and that objects filled with liquids, such as vases,

shall not be placed on apparatus.

16. WARNING: The mains plug/appliance coupler is used as disconnect device,

the disconnect device shall remain readily operable.

17. This equipment is a Class II or double insulated electrical appliance. It

is designed in such a way that it does not require a safety connection

to electrical earth.

18.

- This lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of non-insulated “dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to constitute

a risk of electric shock.

- Warning: to reduce the risk of electric shock, do not remove cover (or back) as

there are no user-serviceable parts inside. Refer servicing to qualified personne

- The exclamation point within an equilateral triangle is intended to alert the use

to the presence of important operating and maintenance instructions in the

literature accompanying the appliance.

XMP300

OWNER’S MANUAL

CAUTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER. NO

USER SE R VICABLE P A R TS INSIDE. REFER SE R VICING TO QUALIFIED PERSONNEL!

IMPOR T ANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. The ventilation should not be impeded

by covering the ventilation openings with items such as newspaper, table-

cloths, curtains etc. Install in accordance with the manufacturer’s instructions.

8. Do not install near heat sources such as radiators, heat registers, stoves,

or other apparatus (including amplifiers) that produce heat. No open flame

sources, such as lighted candles, should be placed on the apparatus.

9. Do not defeat the safety purpose of the polarized or grounding type plug.

A polarized plug has two blades with one wider than the other. A grounding

type plug has two blades and a third grounding prong. The wide blade or

third prong is provided for your safety. If the provided plug does not fit into

your outlet, consult an electrician for replacement of the obsolete outlet.

MAGNETIC FIELD: !!CAUTION!! Do not locate sensitive high-gain equipment such as p r eampliﬁers or tape decks di r ectly above or below the unit. Because

this ampliﬁer has a high power densit y , it has a st r ong magnetic ﬁeld, which can induce hum into unshielded devices that a r e located nearb y . The ﬁeld is

st r ongest just above and below the unit. If an equipment rack is used, we r ecommend locating the ampliﬁer(s) in the bottom of the rack and the p r eampliﬁer

or other sensitive equipment at the top.

EXPLAN A TION OF

SAFETY SYMBOLS

The exclamation point within an equ i lateral triangle is intended to alert the user of the p r esence of important

operating and maintenance (servicing) instructions in the literatur e accompanying the appliance.

The lightning ﬂash with the ar r owhead symbol within an equilateral triangle is intended to alert the user to the

p r esence of uninsulated “dange r ous voltage” within the p r oducts’ enclosu r e that may be of sufﬁcient magnitude

to constitute a risk of electric shock to persons.

10. Protect the power cord from being walked on or pinched particularly at the

plugs, convenience receptacles, and at the point of exit from the apparatus.

11. Only use attacheements/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart or rack is used, use

caution when moving the cart/apparatus

combination to avoid injury from tip-over.

• W ARNING: T O PREVEN T FIRE OR SHOCK HAZARD, DO NO T EXPOSE THIS APPLIANCE T O RAIN OR MOISTURE. THE AP P AR A TUS SHAL L NO T

BE EXPOSED T O DRIPPING OR SPLASHING AND TH A T OBJECTS FILLED WITH LIQUIDS, SUCH AS V ASES, SHAL L NO T BE PLACED

ON AP P AR A TUS .

• WARNING: TO PREVENT FIRE OF SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET

UNLESS THE BLADES CAN BE FUL L Y INSE R TED T O PREVEN T BLADE EXPOSURE .

• W ARNING: THE MAINS PLUG IS USED AS DISCONNEC T DEVICE. THE DISCONNEC T DEVICE SHAL L REMAIN READI L Y AV AILABLE .

• W ARNING: ON L Y USE A T T ACHMENTS OR ACCESSORIES SPECIFIED OR PROVIDED B Y THE MANU F ACTURER .

775 Columbia St.,Brea. CA 92821

XMP300

OWNER’S MANUAL

1. Power Switch

Switches the XMP300 on or o f f. A red LED indicates connection to AC power

while in standby mode. Turns green indicating audio signal is present.

2. Speaker Selector

Selects speaker zone A or B. For A + B zones push both buttons in.

3. Balance

Fades speaker output between the Right and Left Channels

4. V olume

Adjusts ampliﬁer volume.

FRONT P ANEL CONTROLS

7. Interupting Line Input

This is the secondary input, use MAIN IN for your main input.

INTERRUPTING INPUT can be used if a second source is desired and

takes over when signal is present and has at least a 5mV level.

When there is no signal, or a signal with less than 5mV level, the amp

switches back to MAIN IN after a brief delay.

10.

Main Input/Output

11.

12.

Mode Select Switch

Switches the ampliﬁer from Stereo mode to Bridged mode.

13.

14.

AUTO ON Select Switch

Power can be turned on and off manually via the switch on the front panel

or automatically by signal sensing. Set it to NORMAL for manual power on/off.

Set to AUTO for signal sensing; the amp will turn on when audio signal is

detected at the inputs. NOTE: The front panel power switch must be in the

ON position (pushed in) for the AUTO ON featu

e to operate.

Speaker Zone A Output

Speaker output terminals for zone A. Minimum impedance: 8 ohm bridged

or 4 ohm stereo.

Speaker Zone B Output

Speaker output terminals for zone B. Minimum impedance: 8 ohm bridged

or 4 ohm stereo.

Power Cord

This ampliﬁer is conﬁgured for operation at 115V (North America). A fuse

located internally protection from fault conditions. Refer to qualified

service personel should this need to be replaced.

REAR PANEL CONTROLS

Figu r e 1. F r ont Panel

6 9

Figu r e 2. Rear Panel

Connect

Receiver

Here

MAIN IN should be used as the “primary” or main input for the ampliﬁer.

Connect your receiver or main source to this input. Use MAIN OUT to pass

MAIN IN signal to another amplifier.

If you will be connecting one or two pair of speakers to the ampliﬁer, place

the switch in the “Stereo” position. NOTE: For playing 2 pairs of speakers

(A plus B), make sure each speaker has an impedance of 8 ohms or greater.

When set to “Bridged” mode, the ampliﬁer is a single channel mono amplifier.

NOTE: The XMP300 supplies 450W in bridged mode, Please verify that your

speakers are capable of handling such power to avoid possible damage!

For stereo output connect the speaker’s positive (red) terminal to the ampliﬁer’s

positive (red) terminal, and the speaker’s negative (black) terminal to the

ampliﬁer’s negative (black) terminal for each Right and Left speaker.

NOTE: To prevent sonic degradation in your speaker installation, total speaker

wire resistance should be kept below 0.5 ohms. This table lists recommended

speaker wire gauge versus wire run length.

Place the “MODE” switch in the “BRIDGED” position and use both red

terminals to connect to the speaker. Connect the speaker’s positive (red)

terminal to the ampliﬁer’s red (+) terminal noted next to the bridging mark, and

the speaker’s negative (black) terminal to the ampliﬁer’s unmarked positive

NOTE: Only one zone (A or B) can be bridged. Do not attempt to bridge both

A and B speaker terminals! This may result in a lower impedance than the

ampliﬁer is designed for and may damage your ampliﬁer. The minimum

impedance for the total load connected in bridged mode is 8 ohms.

STEREO MODE

BRIDGED MODE

BRIDGED MODE- MONO APPLICATION

For bridged mode, playing Right and Left together as mono output, plug

RCA cables in to Right and Left RCA at MAIN input.

Set the MODE switch to BRIDGED and follow the instructions

for bridged speaker connection in the SPEAKER TERMINALS section of

this manual.

50’ or less - 16 Gauge 2-Cond. CL3 Rated

50’ - 150’ - 12 Gauge 2-Cond. CL3 Rated

150’ - 200’ - 10 Gauge 2-Cond. CL3 Rated

SPEAKER TERMINALS - STEREO MODE

SPEAKER TERMINALS - BRIDGED MODE

6. Bass and Treble Controls

These controls can adjust bass and treble frequencies +/- 12dB at 100Hz

and 10kHz.

9. 12V Trigger

Allows the XMP300 to be powered on by other electronics or to power

on other electronics via a 3.5mm mini phone plug cable.

(red) terminal.

NOTE: Use Class 2 wiring for speaker connections.

To wire the output connector: 1. Strip the insulation off each speaker wire to

expose 3/8" (10 mm) of bare conductor. 2. Unscrew the output terminal bindin

post several twists, insert each wire into the correct terminal. 3. Tighten bindin

post by twisting clock-wise until it is firmly clamping the speaker wire.

Warning: While the amplifier does self-protect under most improper output

conditions, misconfiguration of loudspeaker mode and incorrect connection o

loudspeakers could damage connected loudspeakers and/or amplifier.

Please refer installation to a qualified installation professional, and always

check state and local electrical codes when installing.
