SHARED FEATURES
Suspension
The Reverb Series suspension consists of
an internal HDPE contoured framesheet and
a layered Snowshed™ backpanel designed
to deliver the utmost in carry
and performance.
Harness
A fixed EVA foam padded harness featuring
an adjustable sternum strap with safety
whistle buckle and an insulated hydration
sleeve come standard on every Reverb
Series pack.
ErgoPull™ Waiststrap
A removable nylon waiststrap featuring
our modified straight ErgoPull™ closure
system is featured on every Reverb Series
pack. To operate the ErgoPull™, loosen the
webbing enough so you can connect the
center buckle. Then grasp the loose ends
of the webbing on either side, and pull in
and across evenly with both hands at the
same time.
Diagonal Ski Carry
Diagonal ski carry utilizes the right side
of the bottom front panel webbing and
secures on the opposite side of the top
front panel webbing. To utilize, loosen A)
lower webbing via the slider buckle,
slip ski tails into position beneath the
reinforced area of the strap and re-
tension strap securely around ski tails.
B) Locate the hidden nylon carry strap
beneath the hook and loop tab at the top
of the left harness, unclip the buckle and
thread the nylon strap through the slider
to extend the strap. Re-clip the buckle C)
around the upper portion of the skis
creating a loop and tension the strap for
stable, secure carry. Reverse to remove.
REVERB 18
The Reverb 18 is a low profile, lift accessed/sidecountry riding pack featuring sharp
styling and practical utility for those seeking sidecountry adventure.
Unique Features
• Externalquickaccessprobeandshovel
handle sleeves
• Zipperedbackpanelaccesstoavalanche
safety kit compartment featuring sleeves for
probe/shovel handle/skins and a front panel
zippered pocket with internal key clip
• Topzipperedgogglepocketlinedwithprotective
heat embossed fabric for scratch free carry
Key Fabrics
• 420Ddobbypoly
• 420HDnylon
Size Capacity Weight
OS 1098cu.in./18l 2lb1oz/0.94kg
REVERB 10
TheReverb10isalowprole,liftaccessed/sidecountryridingpackfeaturingsharp
styling and practical utility for those seeking shorter duration sidecountry adventure.
Unique Features
• Backpanelmaincompartmentaccessto
avalanche safety kit featuring sleeves for
probe/shovel handle/skins and spare layers etc.
• Topzipperedgogglepocketlinedwith
protective heat embossed fabric for
scratch free carry with internal zippered
slash pocket and key clip
Key Fabrics
• 420Ddobbypoly
• 420HDnylon
Size Capacity Weight
OS 610cu.in./10l 1lb14oz/0.85kg
Updated02/13/13Printed on recycled content paper
Reverb Series
Owner’s Manual
Congratulations on your purchase of an Osprey Reverb
Series pack. Our obsession with detail rewards you
with a truly full-featured pack and we want to be
sure that you understand and utilize your new Osprey
completely. Here’s a full tour of your pack from the
ground up.
WWW.OSPREYEUROPE.COM
GUARANTEE
At Osprey, sustainability is
designed into
our packs, which
are built to last a lifetime and backed by a superb guarantee,
no matter how hard you are on your gear. Visit www.ospreypacks.com for details.
QUESTIONS?
Contact Osprey Customer Service. Real help from
real people. Scroll over the customer service tab at
www.ospreypacks.com.
OSPREY PACKS, INC.
115 PROGRESS CIRCLE
CORTEZ, CO 81321 USA
866-284-7830
PACK YOUR PACK
Loading your pack correctly
optimizes comfort while you
are carrying it. For complete
information visit:
www.ospreypacks.com/
PackTech/HowToPackYourPack
Heavy Light
PACK CARE
Osprey recommends Nikwax
®
products for pack care.
For complete instructions on cleaning your pack, visit :
www.ospreypacks.com/PackTech/PackCare
Your pack is an extremely durable product built for years
of use and abuse. However, some basic procedures will
ensure that your pack holds up optimally.
• Aftereachtripbesuretocleanoutyourpackthoroughly.
• Ifit’swet,hangittodry.
• Loosenallthestraps.
• Washyourpackeverynowandthen.(Donotimmerse
travel packs with our High Road™WheeledChassis.)
OSPREY ADDONS™
Customize and protect your pack with Osprey’s
full line of AddOns.™ For the full lineup, please visit
your local Osprey retailer or visit our web site
www.ospreypacks.com.
A
B
C
Reverb 18Reverb10
REVERB 10
REVERB 10: Backpanel Access
TheReverb10featuresbackpanelmain
compartment access to an avalanche safety
kit featuring sleeves for probe/shovel handle/
skins and spare layers etc.
REVERB 10: Goggle Pocket
TheReverb10topzipperedgogglepocket
features a protective heat embossed fabric
for scratch free carry with an internal
zippered slash pocket and key clip.
Hydraulics™ Reservoir
AddanOspreyHydraulics™2or3liter
hydration reservoir to your pack for stable,
efficient, on-the-go water management.
For more information, please visit your local
Osprey retailer or visit www.ospreypacks.com.
Backpanel Access
Dual zippered backpanel entry into the main
compartment provides access to gear and
hydration when carrying skis or snowboards
–and keeps the backpanel, harness and
hipbelt out of the snow while gaining access.
Once inside you will find you will find a large
mouth space for your gear and a zippered
hydration compartment.
Hydration
An internal zippered backpanel hydration
compartment with reservoir hanger and a
fully insulated dual zippered harness router
provide for hassle and ice free hydration.
A) Slip your reservoir into the zippered
compartment utilizing the reservoir hanger
if needed and route the hydration hose B)
through the right harness strap for on the go
water management.
Reinforced Front Panel
Each Reverb Series pack features a
reinforced, padded front panel for protection
while carrying skis and snowboards.
Glove Friendly Buckles
Quick release glove friendly buckles release
quicklywiththumbandforengerproviding
easy access to retained items.
Vertical Frontpanel Snowboard Carry
Reverb vertical snowboard carry utilizes a
reinforced lower strap on the front panel
of the pack and a stowable strap on the
left shoulder harness that extends across
the snowboard to the right side harness.
To use, Undo lower webbing strap A)
completely via the slider buckle and thread
the webbing from beneath the fabric overlay
to extend. Place the snowboard bindings B)
up into position and reattach the strap
over the snowboard beneath the bindings,
rethreading the webbing through the slider
buckle and tensioning to secure. Locate C)
the hidden nylon carry strap beneath the
hook and loop tab at the top of the left
harness, unclip the buckle extending the
strap to its full length over the top of the
snowboard and connect it to the female
buckle found on the right shoulder harness,
tensioning to secure. Reverse to remove.
* Snowboard carry can also be utilized to
carry snowshoes
Horizontal Backpanel Snowboard Carry
Areinforcedhipbeltwingprovidesquick
horizontal snowboard carry across the
backpanel of the pack. To use, place A)
the pack backpanel up on the ground and
position snowboard base up horizontally
across the pack’s backpanel, resting it on the
reinforced hipbelt wings with the bindings on
either side of the pack. Load the board and B)
pack onto your back tensioning the hipbelt
and harness to secure the board horizontally
between the pack’s backpanel and your pack.
Reverse to remove.
REVERB 18
REVERB 18: External Probe/
Shovel Handle Sleeves
TheReverb18featuresexternalquickaccess
probe and shovel handle sleeves. To use the
shovel handle sleeve, locate the shovel A)
handle icon at the top of the sleeve on the
left side of the pack, unclip the retention
strap via the glove friendly buckle and insert
shovel handle into sleeve shaft first. Re-clip B)
the retention strap over the shovel grip and
tension for stable, secure carry. To use the
probe sleeve , locate the probe icon at the A)
top of the sleeve on the right side of the pack,
lift up the fabric flap and insert probe into
sleeve. B) Tension the elasticized cord lock
loop around the probe and tension to secure.
Reverse to remove.
REVERB 18: Front Panel Access
The Reverb 18 features zippered front
panel access to an avalanche safety kit
compartment featuring sleeves for probe/
shovel handle/skins and a front zippered
pocket with internal key clip for the utmost
in organizational features.
REVERB 18: Zippered Goggle Pocket
The Reverb 18’s top zippered goggle pocket
is lined with a protective heat embossed
fabric for scratch free carry.
A
B
A
B
B
C
C
A
*
A
B
A
A
B
B
UNIQUE FEATURES EXPLAINED
