IMPORTANT! These speakers are designed for use in pre-construction applications with
professional installation. They must be installed into the corresponding Paradigm®Backbox
(sold separately)
. They are NOT recommended for a retrofit application.
BACKBOX AND SPEAKER
INSTAL LATI ON MANUAL IN-608
Paradigm Electronics Inc. In Canada: 205 Annagem Blvd., Mississauga, ON L5T 2V1 •In the U.S.: MPO Box 2410, Niagara Falls, NY 14302
IN-WALL LCR SPEAKERS
Thank you for choosing award-winning Paradigm®Reference
speakers and congratulations. You are about to hear the difference these
state-of-the-art high-end speakers make in your audio/home-theater system.
They are the product of countless hours of comprehensive research and development
and will deliver superior sound for many years. To achieve all of the exceptional
high-end sound these speakers are designed to provide requires professional
installation of backbox and speakers.
If you have further questions, contact an Authorized Paradigm®Reference Dealer
or visit the Q&A page on our website at www.paradigm.com.
The New Speakers . . . . . . . . . . . . 3
Backbox Parts List . . . . . . . . . . . . . 3
Speaker Assembly Parts List . . . . 3
The Listening Room . . . . . . . . . . . 3
Placement Guidelines . . . . . . . . . . 3
Installing the Backbox . . . . . . . . . . 4
How to Avoid Speaker Damage . . 5
Pre-Wiring the Backbox . . . . . . . . 5
Speaker Installation . . . . . . . . . . . 6
Speaker Connection . . . . . . . . . . . 6
Color-Match Painting . . . . . . . . . . 6
PICTORIAL GUIDE TO
INSTALLING AND CONNECTING
Placement Guidelines . . . . . . . . . 6
Installing BX-LCR 3 Backbox . . . . 7
Installing BX-LCR 5 Backbox . . . . 8
Rotating Tweeter/Midrange
Assembly . . . . . . . . . . . . . . . . . . . . 9
Pre-Wiring the Backbox . . . . . . . . 9
Connecting the Speakers . . . . . . . 9
Installing Speaker Vertically . . . . .10
Installing Speaker Horizontally . . .11
Color-Match Painting . . . . . . . . . . 12
Troubleshooting Guide . . . . . . . . 12
Limited Warranty . . . . . . . . . . . . . 13
Adhere to all local fire, safety and building codes
during the installation process.
Professional installation is required due to the need
for a pre-construction “window-frame-style” rough-in
when installing backbox BX-LCR 3 horizontally or
backbox BX-LCR 5 horizontally and vertically.
Paradigm DOES NOT supply screws for attaching
backbox to wall studs.
Choose screws appropriate for wall composition and
weight of the backbox with speaker. Dimensions and
weights of backboxes and speakers are provided later in
this Manual.
TABLE OF CONTENTS
RECYCLING AND REUSE GUIDELINES FOR EUROPE
In accordance with the European Union WEEE (Waste Electrical and Electronic Equipment) directive effective
August 13, 2005, we would like to notify you that this product may contain regulated materials which, upon
disposal, according to the WEEE directive, require special reuse and recycling processing. For this reason Paradigm
Electronics Inc. (manufacturers of Paradigm®speakers and Anthem®electronics) has arranged with our distributors
in European Union member nations to collect and recycle this product at no cost to you. To find your local distributor
please contact the dealer from whom you purchased this product or go to our website at www.paradigm.com.
Please note that the product only falls under the WEEE directive. When disposing of packaging and other shipping
material we encourage you to recycle through the normal channels.
DIRECTIVES EUROPEENNES SUR LE RECYCLAGE ET LE TRAITEMENT DES DECHETS
Dans le respect de la directive WEEE (Waste Electrical & Electronic Equipment) mise en place par les institutions
Européennes à compter du 13 Août 2005, nous souhaitons vous informer que ce produit peut contenir des matières
devant faire l’objet d’une procédure de recyclage ou de traitement approprié des déchets. Dans cette optique,
Paradigm Electronics Inc (fabricant des enceintes ParadigmMD et des électroniques AnthemMD
) avec ses Distributeurs
agréés dans l’Union Européenne, ont mis en place une procédure de collecte et de retraitement gratuite. Pour en
savoir davantage sur cette procédure veuillez contacter votre revendeur, ou notre Distributeur dans votre pays vous
en obtiendrez les coordonnées sur simple demande ou en consultant notre site internet www.paradigm.com.
Notez que seul le produit fini est concerné par cette directive et ses obligations. S’agissant de son emballage et
de ses accessoires de transport nous vous recommandons de les recycler selon les procédures mises en place par
votre commune ou votre département.
2
IMPORTANT! READ BEFORE COMMENCING INSTALLATION
3
Although Paradigm®Reference in-wall LCR speakers sound great out of
the carton, they will sound even better once they are broken in. Operate
them for several hours before listening critically.
High-frquency drivers use ferro-fluid that can thicken at temperatures
below 10° C (50° F). If the speakers have been transported or stored in the
cold, let them warm to room temperature before use.
Clean speaker housing with a soft, damp cloth, Do not use a strong or
abrasive cleaner or get any part of the speaker wet.
THE NEW SPEAKERS
BX-LCR 3
• 1 Backbox
• 2 Mounting brackets
• 1 Masonite cover (pre-attached)
Required, not included:
• 16 Drywall screws (8 to attach brackets to backbox;
8 to attach brackets to wall stud)
BX-LCR 5
• 1 Backbox
• 4 Mounting brackets
• 1 Masonite cover (pre-attached)
Required, not included:
• 20 Drywall screws (12 to attach brackets to backbox;
8 to attach brackets to wall stud)
NOTE: Depending upon wall composition, additional drywall screws may be required.
BACKBOX PARTS LIST
• 1 Speaker with removable frame
• Screws to install speaker into backbox (quantity varies by model)
• 1 Wire tie
• 1 Piece of fine sandpaper
SPEAKER ASSEMBLY PARTS LIST
(each speaker)
Paradigm®Reference in-wall LCR speakers are suitable for use in a wide
variety of listening environments. Note, however, that room construction,
dimensions and furnishings all play a part in the quality of sound you
ultimately achieve. The extra care taken in installation will result in
greater listening enjoyment. Try to follow these guidelines:
a) Strong, rigid walls and ceilings are preferred for best bass balance.
b) Midrange and high frequencies are affected by room furnishings. For
best sound, the listening room should contain an average amount of
curtains, carpets, sofas, etc.
THE LISTENING ROOM
LOCATION
Guidelines for placement throughout this section refer to placement of the
backbox enclosure.
IMPORTANT! At the pre-construction stage, it is important to establish
the location of the main listening area in order to identify and mark the
exact location on the wall where the display or screen will be mounted.
This will allow speakers to be positioned in the wall for optimal sound.
A NOTE OF CAUTION! This is a pre-construction application. Once framing
and dry-wall are complete, it is a difficult and costly procedure to change the
location of the backbox enclosures. Before commencing installation, re-check
to ensure you have measured and planned your wall construction correctly.
Remember the adage: Measure twice! Cut once!
PLACEMENT GUIDELINES
