The DSToers a "single-box" solution to digital signage and public space at panel
installations. This versatile solution enables ceiling or wall mounting, providing plenty
of space for a computer or media box storage. Designed for easy-assembly, this mount
incorporates step-by-step installation instructions and a security option ensuring the
display stays in place. Enhancing eectiveness of the mounted display, this product,
when installed in a ceiling mounted application, incorporates a built-in
swivel degrees that positions the display at the perfect angle.
Additional Features
Flat/Tilt Wall or Ceiling Mount
with Media Device Storage
FOR " TO " DISPLAYS
DST360
info@peerless-av.com
peerless-av.com
Display size
26"-60"
Max load
150lb (68kg)
DST360’s accessible design provides quick
serviceability to your media device without
removing the display.
•Ideal for wall or ceiling mounted
applications
•Universal mounting in either portrait or
landscape orientation
•Built-in swivel up to º allows for
optimum viewing angle for ceiling mount
applications only
•Flat and tilt wall mount functionality (up
to º tilt)
•Available area within mount for housing a
computer or media controller device ”
x ” x ” ( x  x mm)
•Access panel opens to a full º for
serviceability, replacement, repair or
maintenance
•Clean prole design hides wiring and
mount within enclosed wall plate
•Built in adaptor plate supports VESA®
 x ,  x ,  x  and
 x mm
•Works with all PLP-style VESA ®
mounting hole adaptor plates
•Includes hardware for installation to
wood*** and metal**** studs, concrete or
cinder block
***Mounts to single stud or " stud centers
(wall application)
****Rated to lb (kg) display max using
dual metal stud, or lb (.kg) display max
using single metal studs
•Security screws prevent tampering and
theft
Back view Front view
(display attachment side)
Media controller storage
area within mount
Ceiling mounted side
view with forward tilt
Built-in ventilation and
cable management
MEDIA CONTROLLER
HOUSING
Available area within mount for
housing a computer or media
controller device
UNIVERSAL MOUNTING OPTIONS
Ideal for wall or ceiling installations
SERVICE ACCESSIBILITY
Mount folds open ° from the
bottom for computer or media
controller service access without
removing the display
CLEAN APPLICATION
Internal cable management delivers
a clean, clutter-free side prole and
rear view
FLEXIBLE
VIEWING
Ceiling mounted:
built-in swivel,
up to º, allows
for optimum
viewing angle
Wall mounted:
at and tilt options
with up to º tilt
The Flat/Tilt Wall or Ceiling Mount with Media Device Storage shall be Peerless-AV model DST360 and shall be located where indicated on the plans. It shall be
constructed of heavy gauge steel. The nish shall be scratch resistant black fused epoxy. Assembly and installation shall be done according to instructions provided by the
manufacturer.
LIT-0449 rev.4
Architect Specications
WARRANTY: Limited -year
Flat/Tilt Wall or Ceiling Mount with Media Device Storage DST
() -
() -
Fax: () -
Peerless-AV
2300 White Oak Circle
Aurora, IL 60502 USA
Visit peerless-av.com to see the
complete line of AV solutions from
Peerless-AV, including outdoor displays,
wireless, kiosks, digital audio, display
mounts, projector mounts, carts/stands,
and a full assortment of accessories.
© 2014 Peerless Industries, Inc. Peerless-AV ® and are registered trademarks of Peerless Industries, Inc. All rights reserved.
 ()  
Fax:  ()  
Peerless-AV Europe
Unit 3 Watford Interchange
Colonial Way, Watford
Herts, WD24 4WP
United Kingdom
 () -
Fax:  () -
Peerless-AV de México
Ave de las Industrias 413
Parque Industrial Escobedo
Escobedo, N.L.,
Mexico 66050
Model Number
PACKAGE SIZE W x H x D PACKAGE SHIP
WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE
DST 24.5" x 12.25" x 27.75"
(622 x 311 x 705mm) 40.5lb (18.37kg) 735029264521
Computer/media player
holder box, access plate,
adaptor plate, fastener
packet
1
Package Specications
Accessories
DIMENSIONS W X H X D PRODUCT WEIGHT LOAD CAPACITY FINISH AVAILABLE COLORS
DST 18.63" x 15.27" x 4.28"
(473 x 388 x 109mm) 31.5lb (14.29kg) 150lb (68kg)
Scratch
resistant
fused
epoxy
Black
Product Specications
Works with all PLP-style VESA® mounting hole adaptor plates
Works with any standard EXT, ADD, or ADJ extension columns and ceiling mounts (sold separately)
All dimensions = (mm)inch
12.00"
(305 mm)
16.00"
(406 mm)
6.00"
(152 mm) 7.87"
(200 mm)
3.24"
( )82 mm
2.69"
( )68 mm
3.94"
( )100 mm
8.49"
(216 mm)
7.87"
(200 mm)
4.28"
( )109 mm
3.60"
(92 mm)
16.67"
(423 mm)
18.63"
(473 mm)
2.00"
( )51 mm
15.27"
( )388 mm 12.22"
( )311 mm
14.52"
( )369 mm
(7 mm) (14 mm )
( )49 mm
V ®ESA
VESA®
Ø
(6 PLCS)
Ø
(8 PLCS)
VESA®
Ø .28" X .56" SLOT
(9 PLCS)
20°
15°
10°
5°
INSIDE
INSIDE
Ø 1.93 HOLE
HOLE FOR CEILING
MOUNT POLE
INSIDE
11.81"
(300 mm)
11.81"
(300 mm)
FRONT ISO VIEW
ACCESS ISO VIEW
TOP VIEW
BACK VIEW FRONT VIEW RIGHT VIEW TILTS RANGES VIEW
