Flat Panel Cart
The SRM Flat Panel Cart has been redesigned to include all of the features you may
need, making it perfect for any application. Mobility, appealing design, display height
adjustment, pre-assembled base and UL® certication ensure quick assembly while
providing a ridged, but attractive, structure that ts into any cor. The " castors make
it easy to move from room to room while the UL® certication ensures you that it can
be done with safety in mind.
Display size
32"-75"
Max load
150lb (68.2kg)
display
25lb (11.4kg)
per shelf
Display and component shelf can
be located anywhere along the
column for perfect component
placement and viewing height
(up to " at center)
Integrated cable management
protects, contains and conceals
cables for a clean, professional
installation
Maneuvers easily on " (mm)
swivel casters, two locking
Pre-assembled base provides
rigidity, stability and quick assembly
Textured black powder coat nish
helps hide nger prints and dust
Open frame display adaptor helps
prevent display input interference
Universal mount ts displays
with mounting patterns from
 x mm up to  x mm
Designed to meet UL certications, the
SR560M incorporates safety and security,
ensuring you get the job done correctly.
Additional Features
FOR " TO " DISPLAYS
SR560M
SR560M-AB
SR560M-AW
info@peerless-av.com
peerless-av.com
VERTICAL ADJUSTMENT
Display and component shelf
can be located anywhere along
the column (up to " at center)
SAFE AND EASY
MANEUVERABILITY
" (mm) swivel casters
meet UL/CUL requirements
WELDED BASE
Provides rigidity, stability
and quick assembly
UL/CUL CERTIFIED
Provides the highest
level of safety
PLUMB ADJUSTMENT
 degrees of negative
adjustment keeps even the
heaviest of displays level
OPEN FRAME ADAPTOR
Helps prevent display input
interference
COMPONENT PLACEMENT
Metal shelf can be located
anywhere along the
column assembly
Cable management allows
cables to enter or exit
anywhere along the column
*Antimicrobial protection is limited to the treated article and does not protect a user against disease
causing bacteria. Always clean products thoroughly after each use. Visit agion-tech.com for more details.
Nature’s antimicrobial
SRM-AB/AW:
The Flat Panel Cart shall be a Peerless-AV model SR560M(-AB)(-AW) and shall be located where indicated on the plans..
Assembly and installation shall be done according to instructions provided by the manufacturer.
LIT-0767 rev.5
PACKAGE SIZE
W x H x D
PACKAGE
SHIP WEIGHT
PACKAGE
UPC CODE PACKAGE CONTENTS UNITS
IN PACKAGE
SRMABAW 47.50" x 7.25" x 38.50”
(1207 x 184 x 978mm) 79lb (35.9kg)
SR560M:
SR560M-AB:
SR560M-AW:
735029247715
735029281771
735029281788
Assembled base, Aluminum column,
Universal display adaptor, Metal component
shelf, (2) swivel casters, (2) locking swivel
casters, hardware & instructions
1
Package Specications
Architect Specications
Accessories
DIMENSIONS W X H X D PRODUCT WEIGHT LOAD CAPACITY FINISH AVAILABLE COLORS
SRMABAW 34.95" x 68.38" x 29.00"
(888 x 1736 x 737mm) 66lb (30kg) 150lb (68.2kg) display
25lb (11.4kg) per shelf
Textured
Powder
Coat
SR560M:
SR560M-AB:
SR560M-AW:
Black
Antimicrobial* Black
Antimicrobial* White
Product Specications
Model Numbers
WARRANTY: Limited -year
All dimensions = (mm)inch
SRMABAW Flat Panel Cart for 32" to 75" Displays
() -
() -
Fax: () -
Peerless-AV
2300 White Oak Circle
Aurora, IL 60502 USA
Visit peerless-av.com to see the
complete line of AV solutions from
Peerless-AV, including outdoor displays,
wireless, kiosks, digital audio, display
mounts, projector mounts, carts/stands,
and a full assortment of accessories.
© 2014 Peerless Industries, Inc. Peerless-AV ® is a registered trademark of Peerless Industries, Inc. All rights reserved.
 ()  
Fax:  ()  
Peerless-AV Europe
Unit 3 Watford Interchange
Colonial Way, Watford
Herts, WD24 4WP
United Kingdom
 () -
Fax:  () -
Peerless-AV de México
Ave de las Industrias 413
Parque Industrial Escobedo
Escobedo, N.L.,
Mexico 66050
ACC: Feet Accessory
ACC: Safety Belt
ACC: Electrical Outlet Strip with Cord Wrap
ACC-BPR: Bumper Accessory for legs
ACC-GS: Tempered Glass Shelf
ACC-LA: Laptop Arm
ACC-MS: Metal Shelf
Video Conferencing ShelfACC-VCS:
DSX: Media Player Storage
*Antimicrobial protection is limited to the treated article and does not protect a user against disease
causing bacteria. Always clean products thoroughly after each use. Visit agion-tech.com for more details.
