Universal Ultra Slim Flat Wall Mount

For 37" to 50" Ultra-thin Displays*

One of the world’s slimmest mounts at only 0.33" (8mm) thin, this near-invisible mount is the beauty

that supports the modern style of the latest ultra-thin displays. Its all-steel, clean-line, high-gloss

modeling features universal compatibility with virtually any ultra-thin display innovation. This

unmatched solution delivers space-saving, ultra-sleek looks and brings the display ultra-close

to the wall.

Easy InstallatIon

Simple hook-on design makes

installation quick and easy

Ultra slIm

dEsIgn

The mount

virtually

disappears

behind the

display

VIEwIng FlExIbIlIty

Horizontal adjustment up to 6"

(152mm) for perfect display

positioning

Display size: 37"-50" Max load: 150lb (68kg)

SUF640P

 Ultra-thin design holds

display only 0.33" (8mm)

from the wall for a

near-invisible application

 Universal mount compatible

with ultra-thin displays

with mounting patterns

up to 450 x 402mm

(17.73" W x 15.82" H)

 Universal brackets easily

hook onto wall plate for an

easy installation

 Industrial-strength Velcro®

latching system secures

display adaptors to wall

plate in a single step,

making installation fast

and secure

 Lateral shift adjustment

of up to 6" (152mm)

(depending on display

model) for perfect display

placement

 Mounts to wood studs,

concrete, cinder block or

metal studs (metal stud

accessory required)

 Comes with fastener pack

with all necessary display

attachment hardware

FEatUrEs

sEcUrE InstallatIon

Industrial strength Velcro®

latching system holds the

display in place preventing

accidental bump-off

or unwanted horizontal

adjustment

Specially designed safety

tabs for secure support

Easy hook-on design

* Designed exclusively for use with ultra-

thin displays 2" (51mm) deep or less

clIcK: call: Fax: peerless-av.com 800.865.2112 800.359.6500

Patented. Design Patent No. D679,571. Utility Panent No. 8,154,855.

15.82.81

PACKAGE SIZE (W x H x D) PACKAGE SHIP WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE

SUF640P 22.375" x 2.375" x 5.25"

(568 x 60 x 133mm) 4.7lb (2.2kg) 735029258353

Wall plate, universal

display adaptors,

mounting and display

attachment hardware

Package Speciﬁcations

Accessories

DImENSIONS (W x H x D) LOAD CAPACITy FINISH AVAILABLE COLORSPRODUCT WEIGHT

SUF640P 20.69" x 17.95" x .33"

(526 x 456 x 8mm) 4.1lb (1.9kg) 150lb (68kg)

Scratch

resistant

fused

epoxy

Gloss Black

Product Speciﬁcations

Model Numbers WARRANTY: Limited 5-year

A R C H I T E C T S S P E C I F I C A T I O N S

The Ultra-Thin Universal Flat Wall Mount shall be a Peerless-AV model SUF640P and shall be located where indicated on the plans. It shall be constructed

of cold rolled steel and feature scratch resistant gloss black fused epoxy nish. Assembly and installation shall be done according to instructions provided.

Metal Stud Accessory KitACC215:

All dimensions = (mm)inch

Universal Ultra Slim Flat Wall Mount for 37" to 50" Ultra-thin DisplaysSUF640P:

LIT-0387 rev.4

NOTE: Display Compatibility Requirements

Designed exclusively for use with ultra-thin displays 2” (51mm) deep or less

The display does not require any additional heat ventilation room than 0.33” (8mm). Please refer to the manufacturer’s requirements for mounting your display on the wall.

The display must have a at mounting surface, or the mounting holes need to be on the furthest back surface of the display.

 Input/Output connection must be properly orientated to accommodate mounting 0.33” (8mm) from the wall.

20.69"

(526 mm)

17.73"

(450 mm)

17.95"

(456 mm)

(401 mm)

.88"

(22 mm)

MAX

16"

(406 mm)

FRONT VIEW

.33"

(8 mm)

SIDE VIEW

.85"

(22 mm)

1.11"

(28 mm)

2.81"

(71 mm)

17.83"

(453 mm)

FRONT VIEW BRACKET DETAIL

Visit peerless-av.com to see the complete line of AV solutions from Peerless-AV, including at panel mounts, projector mounts, carts/stands, furniture, cables, screen cleaners and a full assortment of accessories.
