U-SHAPED WINDOW AIR CONDITIONER
ENGLISH
USER’S MANUAL
Models
1PACU8000
1PACU10000
1PACU12000
Important Safety Instructions .....................................................................................................
Installation Instructions ..............................................................................................................
Normal Sounds ..........................................................................................................................
Air Conditioner Features .............................................................................................................
Care and Cleaning .....................................................................................................................
Troubleshooting Tips ..................................................................................................................
3
14
IMPORTANT NOTE:
Before using your air conditioner, please read this manual carefully and keep it for future reference.
CONTENTS
20
21
26
27
3
Inside you will nd many helpful hints on how to use and maintain your air conditioner properly. Just a little
preventive care on your part can save you a great deal of time and money over the life of your air conditioner.
You’ll nd many answers to common problems in the chart of Troubleshooting Tips. If you review our chart of
Troubleshooting Tipsrst, you may not need to call for service at all.
To prevent injury to the user or other people and property damage, the following instructions must be followed.
Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classied by
the following indications.
READ THIS MANUAL
This symbol indicates the possibility of death or serious injury.
• Plug in power plug properly. Otherwise, it may cause electric shock or re due to excess heat generation.
Do not operate or stop the unit by inserting or pulling out the power plug. It may cause electric shock or re
due to heat generation. Do not damage or use an unspecied power cord. It may cause electric shock or
re. If the power cord is damaged, it must be replaced by the manufacturer or an authorized service center
or a similarly qualied person in order to avoid a hazard. .
• Always install circuit breaker and a dedicated power circuit. Incorrect may cause re and electric installation
shock. Do not operate with wet hands or in damp environment. It may cause electric shock. Do not direct
airow at room occupants only. This could damage your health. Always ensure eective grounding. Incorrect
grounding may cause electric shock. Do not allow water to run into electric parts. It may cause failure of
machine of electric shock. Do not modify power cord length or share the outlet with other appliances. It may
cause electric shock or re due to heat generation.
• Unplug the unit if strange sounds, smell, or smoke come from it. It may cause re and electric shock.
Do not use the socket if it is loose or damaged. It may cause re and electric shock. Do not open the unit
during operation. It may cause electric shock.
• Keep rearms away. It may re. Do not use the power cord close to heating appliances.cause
• It may re and electric shock. Do not use the power cord near ammable gas or combustibles, cause
such as gasoline, benzene, thinner, etc. It may cause an explosion or re. Ventilate the room before
operating air conditioner if there is a gas leakage from another appliance. It may cause explosion, re and,
burns. Do not disassemble or modify unit. It may cause failure and electric shock.
This symbol indicates the possibility of injury or dame to property.
WARNING
WARNING
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS CONTINUED
6
Operation of GFCI Device
WARNING (For using R290/R32 refrigerant only)
This air conditioner is designed to be operated under condition as follows:
The power supply cord contains a ground fault circuit interrupter (GFCI) device that senses damage
to the power cord. To test your power supply cord, do the following:
1. Plug in the Air Conditioner.
2. The power supply cord will have TWO buttons on the plug head. Press the TEST button,
you will notice a click as the RESET button pops out.
3. Press the RESET button, again you will notice a click as the button engages.
4. The power supply cord is now supplying electricity to the unit.
(On some products this is also indicated by a light on the plug head.)
Note
Please Note
Do not use this device to turn the unit on or o. Always make sure the RESET button is pushed in for correct
operation. The power supply must be replaced if it fails reset when either the button is pushed, or it TEST
cannot be reset. A new one can be obtained from the product manufacturer. If power supply cord is damaged,
it cannot be repaired. It MUST be replaced by one obtained from the product manufacturer.
Performance may be reduced outside of these operating temperatures.
Cooling Operation
Outdoor Temperature 64 - 109°F / 18 - 43°C (64 - 125°F / 18 - 52°C for special tropical models)
Indoor Temperature 60 - 90°F / 16 - 32°C
• Do not use means to accelerate the defrosting process or to clean, other than those recommended
by the manufacturer.
• The appliance shall be stored in a room without continuously operating ignition sources
• (for example: openames, an operating gas appliance) and ignition sources or (for example: an operating
electric heater) close to the appliance. The appliance shall be stored in a room without continuously operating
ignition sources (for example: open ames, an operating gas appliance or an operating electric heater).
• Do not pierce or burn.
• Be aware that the refrigerants may not contain an odor.
• Compliance with national gas regulations shall be observed.
• Keep ventilation openings clear of obstruction.
• The appliance shall be stored so as to prevent mechanical damage from occurring.
• A warning the appliance shall be stored in a well-ventilated area where the room size corresponds that
to the room area as specied for operation.
7
IMPORTANT SAFETY INSTRUCTIONS
• Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid
certicate from an industry-accredited assessment authority, which authorizes their competence to handle
refrigerants safely in accordance with an industry recognized assessment specication.
• Servicing should only be performed as recommended by the equipment manufacturer. Maintenance
and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of ammable refrigerants.
• DO NOT modify the of the power cord or use an extension cord to power the unit.length
• DO NOT share a single outlet with other electrical appliances. Improper power supply can cause re
or electrical shock.
• Please follow the instructions carefully to , install, clear, service the air conditioner to avoid any damage handle
or hazard. Flammable Refrigerant R32 is used within the air conditioner. When maintaining or disposing the air
conditioner, the refrigerant (R32 or R290) should be recovered properly and should not be discharged into the
air directly.
• DO NOT have any open or device-like switch which may generate a spark/arcing around the air conditioner re
to avoid causing ignition of the ammable refrigerant used.
• Please follow the instructions carefully to store or maintain the air conditioner to prevent mechanical damage
from occurring.
• refrigerant - R32 is used in air conditioner. Please follow the instructions carefully to avoid Flammable
any hazard.
CAUTION: Risk ofre/ammable materials (Required for R32/R290 units only
IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit.
Make sure to save this manual for future reference.
Explanation of symbols displayed on the unit (For units with R32/R290 Refrigerant only)
WARNING This symbol shows that this appliance used a ammable refrigerant. If the refrigerant
is leaked and exposed to an external ignition source, there is a risk of re.
CAUTION This symbol shows that the operation manual should be read carefully.
CAUTION This symbol shows that a service professional should be handling this equipment
with reference to the installation manual.
CAUTION This symbol shows that information is available such as the operation manual
installation manual.
CONTINUED
IMPORTANT SAFETY INSTRUCTIONS
8
CONTINUED
WARNING
Transport of equipment containingammable refrigerants
• See transport regulations.
Marking of using signsequipment
• See local regulations.
Disposal of equipment using refrigerantsammable
• See national regulations.
Storage of equipment/appliances
• The storage of equipment should be in accordance with the manufacturer’s instructions.
Storage of packed (unsold) equipment
• Storage package protection should be constructed such that mechanical damage to the equipment inside
the package will not cause a leak of the refrigerant charge.
• The maximum number of pieces of equipment permitted to be stored together will be determined
by local regulations.
Information on servicing
1. Checking the area
• Prior to beginning work on systems containing ammable refrigerants, safety checks are
necessary to ensure that the risk of ignition is minimized. For repair to the refrigerating system,
the following precautions shall be complied with prior to conducting work on the system.
2. Work procedure
• Work shall be undertaken under a controlled procedure so as to minimize the risk of a ammable
gas or vapor being present while the work is being performed.
3. General work area
• All maintenance sta and others working in the local area shall be instructed on the nature
of work being carried out. Work in conned spaces shall be avoided. The area around the
workspace shall be sectioned o. Ensure that the conditions within the area have been made
safe by control of ammable material.
4. Checking for presence of refrigerant
• The area should be checked with an appropriate detector prior to and during work,refrigerant
to ensure the technician is aware of potentially ammable atmospheres. Ensure that the leak
detection equipment being used is suitable for use with ammable refrigerants, i.e. non-sparking,
adequately sealed or intrinsically safe.
5. Presence of a re extinguisher
• If any hot work is to be conducted on the refrigeration equipment or any associated parts,
appropriate re extinguishing equipment shall be available to hand. Have a dry powder or CO 2
re extinguisher adjacent to the charging area.
6. No ignition sources
• No person carrying out work in relation to a refrigeration system which involves exposing any
pipe work that contains or has contained ammable refrigerant shall use any sources of ignition
in such a manner that it may lead to the risk of re or explosion. All possible ignition sources,
including cigarette smoking, should be kept suciently far away from the site of installation,
repairing, removing and disposal, during which ammable refrigerant can possibly be released
to the surrounding space. Prior to work taking place, the area around the equipment is to be
surveyed to make sure that there are no ammable hazards or ignition risks. No Smoking signs
shall be displayed.
(For using R290/R32 refrigerant only)
CONTINUED
IMPORTANT SAFETY INSTRUCTIONS
10
10. Repairs to sealed components
• During repairs to sealed components, all electrical supplies shall be disconnected from
the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely
necessary to have an electrical supply to equipment during servicing, then a permanently
operating form of leak detection shall be located at the most critical point to warn of a potentially
hazardous situation.
• Particular shall be paid to the following to ensure that by working on electricalattention
components, the casing is not altered in such a way that the level of protection is aected.
This shall include damage to cables, excessive number of connections, terminals not made
to original specication, damage to seals, incorrect tting of glands, etc.
• Ensure that seals or materials have not degraded such that they no longer serve sealing
the purpose of preventing the ingress of ammable atmospheres. Replacement parts should
be in accordance with the manufacturer’s specications.
11. Repair to intrinsically safe components
• Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that
this will not exceed the permissible voltage and current permitted for the equipment in use.
Intrinsically safe components are the only types that can be worked on while live in the presence
of a ammable atmosphere. The test apparatus shall be at the correct rating.
• Replace components only with parts specied by the manufacturer. Other parts may result
in the ignition of refrigerant in the atmosphere from a leak.
12. Cabling
• Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp
edges or any other adverse environmental eects. The check shall also take into account the
eects of aging or continual vibration from sources such as compressors or fans.
13. Detection of ammable refrigerants
• Under no circumstances, should potential sources of ignition be used in the searching
for or detection of refrigerant leaks. A halide torch (or any other detector using a naked ame)
should not be used.
Note
The use of silicon sealant may inhibit the eectiveness of some types of leak detection equipment. Intrinsically
safe components do not have to be isolated prior to working on them.
WARNING
(For using R290/R32 refrigerant only)
IMPORTANT SAFETY INSTRUCTIONS CONTINUED
11
14. Leak detection methods
• The following leak detection methods are deemed acceptable for systems containing ammable
refrigerants. Electronic leak detectors shall be used to detect ammable refrigerants, but the
sensitivity may not be adequate, or may need re-calibration. (Detection equipment should
be calibrated in a refrigerant-free area.) Ensure that the detector is not a potential source of
ignition and is suitable for the refrigerant used. Leak detection equipment should be set at a
percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant employed and
the appropriate percentage of gas (25 % maximum) is conrmed.
• Leak detection uids are suitable for use with most refrigerants but the use of detergents
containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode
the copper pipework.
• If a leak is suspected, all naked ames should be removed/ extinguished. If a leakage
of refrigerant is found which requires brazing, all of the refrigerant should be recovered from the
system, or isolated (by means of shut o valves) in a part of the system remote from the leak.
Oxygen free nitrogen (OFN) should then be purged through the system both before and during
the brazing process.
15. Removal and evacuation
• When breaking into the refrigerant circuit to make repairs or for any other purpose conventional
procedures shall be used. However, it is important that best practice is followed since
ammability is a consideration. Opening of the refrigeration systems should not be done
by brazing.
• The following procedure shall be adhered to:
• Remove refrigerant
• Purge the circuit with inert gas
• Evacuate
• Purge again with inert gas
• Open the circuit by cutting or brazing.
• The refrigerant charge should be recovered into the correct recovery cylinders. The system
should be ushed with OFN to render the unit safe. This process may need to be repeated
several times. Compressed air or oxygen shall not be used for this task.
• Flushing should be achieved by breaking the vacuum in the system with OFN and continuing
to ll until the working pressure is achieved, then venting to atmosphere, and nally pulling down
to a vacuum. This process shall be repeated until no refrigerant is within the system.
• When the nal OFN charge is used, the system shall be vented down to atmospheric
pressure to enable work to take place. This operation is absolutely vital if brazing operations
on the pipework are to take place.
• Ensure that the outlet for the vacuum pump is not close to any ignition sources and
there is ventilation available.
WARNING
(For using R290/R32 refrigerant only)
IMPORTANT SAFETY INSTRUCTIONS CONTINUED
13
18. Labelling
• Equipment should be labelled stating that it has been de-commissioned and emptied of
refrigerant. The label should be dated and signed. Ensure that there are labels on the equipment
stating the equipment contains ammable refrigerant.
19. Recovery
• When removing refrigerant from a system, either for servicing or decommissioning,
it is recommended good practice that all refrigerants are removed safely.
• When transferring into cylinders, ensure that only appropriate refrigerant recovery refrigerant
cylinders are employed. Ensure that the correct number of cylinders for holding the total system
charge is available. All cylinders to be used are designated for the recovered refrigerant and
labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall
be complete with pressure relief valve and associated shut-o valves in good working order.
Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs.
• The recovery be in good working order with a set of instructions concerning equipment shall
the equipment that is at hand and shall be suitable for the recovery of ammable refrigerants.
In addition, a set of calibrated weighing scales shall be available and in good working order.
• Hoses shall be complete with leak-free disconnect couplings and in good condition. Before
using the recovery machine, check that it is in satisfactory working order, has been properly
maintained and that any associated electrical components are sealed to prevent ignition in the
event of a refrigerant release. Consult manufacturer if in doubt.
• The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery
cylinder, and the relevant Waste Transfer Note arranged. Do not mix refrigerants in recovery units
and especially not in cylinders. If compressors or compressor oils are to be removed, ensure that
they have been evacuated to an acceptable level to make certain that ammable refrigerant does
not remain within the lubricant. The evacuation process shall be carried out prior to returning the
compressor to the suppliers. Only electric heating to the compressor body should be employed
to accelerate this process. When oil is drained from a system, it should be carried out safely.
WARNING
(For using R290/R32 refrigerant only)
14
INSTALLATION INSTRUCTIONS
Note
The unit you purchased may look like the following. All the illustrations in this manual are for explanation
purposes only. The air conditioner you have may be slightly dierent.
BEFORE YOU BEGIN
WINDOW REQUIREMENTS
15
• Read these instructions completely and carefully.
• IMPORTANT - Save these instructions for local inspector’s use.
• IMPORTANT - Observe all governing codes and ordinances.
• Note to Installer - Be sure to leave these instructions with the Consumer.
• Note to Consumer - Keep these instructions for future reference.
• Skill level - Installation of this appliance requires basic mechanical skills.
• Completion time - Approximately 1 hour.
• We recommend that two people install this product.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under the warranty.
• You MUST use all supplied parts and use proper installation procedures as described
in these instructions when installing this air conditioner.
Your air conditioner is designed to install in standard double hung windows with opening widths
of 20 to 38 inches (508mm to 965mm).
20" to 38"
508mm to 965mm
Wooden Windows
• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
• Do not change the plug on the power cord of the air conditioner.
• Aluminum house wiring may present special problems - consult a qualied electrician.
• When handling unit, be careful to avoid cuts from sharp metal edges and aluminum ns on front
and rear coils.
CAUTION
Note
If there is interference between the shaft and the window, seal it with a sponge.
INSTALLATION INSTRUCTIONS CONTINUED
INSTALLATION INSTRUCTIONS
16
CONTINUED
TOOLS YOU WILL NEED TOOLS YOU MAY USE
Phillips Screwdriver
Level
Flathead Screwdriver
Pencil
Ruler or Tape Measure
Scissors or Knife
1. PREPARE THE WINDOW
2. PREPARE THE AIR CONDITIONER
Lower sash must open suciently to allow a clear vertical opening of 13 inches (330mm). Side louvers and
the rear of the AC must have clear air space to allow enough air ow through the condenser, for heat removal.
The rear of the unit must be outdoors, not inside a building or garage.
Remove the air conditioner and hardware from the carton and place on a at surface.
Note
Save the carton and these Installation Instructions for future reference.
6Self-tapping Screw (ST3.9 x 10)
Self-tapping Screw (ST3.9 x 6.5) 4
Flat Head Bolt and Locknut 2
Snap Ring 2
Support Bracket 1
Sealed Sponge 2
17
INSTALLATION INSTRUCTIONS CONTINUED
3. ASSEMBLE THE SUPPORT BRACKET
Connect the retaining plate and support rail via snaps. Fix the horizontal support plate to the main support
connection plate with screws. See Figure 1.
Attach Legs: Slide leg into support rail while pressing BOTH spring button. Release the button so that
it extends out from the inner or outer hole of support rail. Repeat for second leg. See Figure 2.
Figure 1
Retaining Plate
Horizontal Support Plate
Leg
Figure 2
Prepare Sill Stop Wings: Slide wings (left and right) onto frame. See Figure 3.
Sill Stop Wings
Figure 3
18
INSTALLATION INSTRUCTIONS CONTINUED
Figure 4A
Figure 4B
4. INSTALL THE SUPPORT BRACKET
• Adjust the bracket until the sliding leg is rmly secure against exterior surface.
• Place in window.
• Rest bracket on the bottom sill. Adjust each sill stop wing until it reaches the outermost side
of the window frame.
• Connect the horizontal support plate and the sill stop wings by bolts. See Figure 4.
21
AIR CONDITIONER FEATURES
WARNING
CAUTION
To reduce the risk of re, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS
before operating this appliance.
Please always wait 3 minutes when turning unit o then on again, and when changing from cool to fan and back
to cool. This prevents compressor from overheating & possible circuit breaker tripping.
Air Directional Louvers
The louvers will allow you to direct the airow Up or Down (on some models) and Left or Right throughout
the room as needed. Pivot horizontal louvers until the desired Up/Down direction is obtained. Move the
lever(s) from side to side until the desired Left/Right direction is obtained.
To begin operating the air conditioner, follow these steps:
1. Set the thermostat to the highest number (coldest or cooler setting).
2. Set the selector control to the highest COOL setting.
3. Adjust the louver for comfortable air ow (see Air Directional Louvers).
4. Once the room has cooled, adjust the thermostat to the setting you nd most comfortable.
5. Make sure that the air ow inside and outside are not obstructed by anything.
Air Direction
Lever
Lever
Lever
22
AIR CONDITIONER FEATURES CONTINUED
ELECTRONIC CONTROL OPERATING INSTRUCTIONS
Note
Dierent models have dierent control buttons and indicator lights. Not all the control buttons and
indicator lights describing below are available for the unit you purchased. Please check the control panel
of the unit you purchased. The unit can be controlled by the unit control alone or with the remote.
2 3 4 5 6 7 8 9 1
# ITEM DESCRIPTION
1ON/OFF
Button
• Press ON/OFF button to turn unit on or o. The unit will initiateNote:
automatically the Energy Saver function under and modes.Cool, Dry Auto
2CONNECT
Button
• For the rst time to use WLAN function, press the button for 3 seconds to
initiate the WLAN connection mode. The LED DISPLAY shows ‘AP’ to
indicate you can set WLAN connection. If connection (router) is successful
within 8 minutes, the unit will exit WLAN connection mode automatically
and the indicator illuminates. If connection is failure within 8 CONNECT
minutes, the unit exits WLAN connection mode automatically. After WLAN
connection is successful, you can press and hold and CONNECT DOWN
buttons at the same time for 3 seconds to turn o WLAN function and
the LED DISPLAY shows ‘OFF’ for 3 seconds, press and CONNECT UP
buttons at the same time to turn on WLAN function and the LED
DISPLAY shows ‘ ’ for 3 seconds.ON
3TIMER
Button
• Press Timer button, the or TIMER ON TIMER OFF indicator light will
illuminate. lt indicates the Auto Start or Auto Stop program is initiated. For
some units, keep pressing the Timer button will cancel the timer settings.
• Press or hold the or UP DOWN button to change the time by 0.5-hour Auto
increments, up to 10 hours, then at 1-hour increments up to 24 hours. The
control will count down the time remaining until start.
• The selected time will register in 5 seconds, and the system will
automatically revert back to display the previous temperature setting or room
temperature when the unit is on. (when the unit is o, there is no display.)
• Turning the unit ON OFF or at any time or adjusting the timer setting to 0.0
will cancel the Auto Start/Stop timed program.
AIR CONDITIONER FEATURES
Displays
Error Codes
ADDITIONAL THINGS YOU SHOULD KNOW
Shows the set temperature in “ ℃” or “ ℉” and the Auto-timer settings. While on Fan only mode, it shows
the room temperature. If the room temperature is too high or low, it will display “ HI” or “ LO”.
• The unit may stop operation or continue to run safely. If the error codes appear, wait for about 10 minutes.
• The problem may resolve itself. If not, disconnect the power, then connect it again. Turn the unit on.
• If the problem persists, disconnect the power and contact your nearest customer service center.
• Error code appears and begins with the letters as the following in the window display of indoor unit:
EH(xx), EL(xx), EC(xx) , PH(xx), PL(xx), PC(xx)
Now that you have mastered the operating procedure, here are more features in your
control that you should become familiar with.
• The Cool circuit has an automatic 3 minutes time delayed start if the unit is o and on quickly. turned
This prevents overheating of the compressor and possible circuit breaker tripping. The fan will continue to
run during this time.
• The control is capable of displaying temperature in degrees Fahrenheit or Celsius. To convert degrees
from one to the other, press and hold the Up and Down buttons at the same time for 3 seconds.
25
Note
If the unit breaks o unexpectedly due to a power outage, it will restart with the previous function setting
automatically when the power resumes.
Display
CONTINUED

Produktspecifikationer

Varumärke: Perfect Aire
Kategori: Luftkonditionering
Modell: 1PACU8000

Behöver du hjälp?

Om du behöver hjälp med Perfect Aire 1PACU8000 ställ en fråga nedan och andra användare kommer att svara dig


Luftkonditionering Perfect Aire Manualer

Perfect Aire

Perfect Aire 1PNC18000 Bruksanvisning

6 Januari 2025
Perfect Aire

Perfect Aire 4PACH12000 Bruksanvisning

6 Januari 2025
Perfect Aire

Perfect Aire 3PAMSH36B-SYS Bruksanvisning

25 September 2024
Perfect Aire

Perfect Aire 3PAMSHH09-SYS Bruksanvisning

25 September 2024
Perfect Aire

Perfect Aire 3PAMSHQCW18-U230 Bruksanvisning

25 September 2024
Perfect Aire

Perfect Aire 3PATW14002 Bruksanvisning

25 September 2024
Perfect Aire

Perfect Aire 1PAWFC10000 Bruksanvisning

25 September 2024
Perfect Aire

Perfect Aire 3PASC10000 Bruksanvisning

25 September 2024
Perfect Aire

Perfect Aire 1PAWFC12000 Bruksanvisning

25 September 2024
Perfect Aire

Perfect Aire 3PAMSHH12-SYS Bruksanvisning

25 September 2024

Luftkonditionering Manualer

Nyaste Luftkonditionering Manualer

Vox

Vox PMF09CH Bruksanvisning

18 Mars 2025
Vox

Vox PQF12CH Bruksanvisning

18 Mars 2025
Vox

Vox PQA12C Bruksanvisning

18 Mars 2025
Vox

Vox PMJ09C Bruksanvisning

18 Mars 2025
Toshiba

Toshiba RAC-WK1011ESCWU Bruksanvisning

18 Mars 2025
Toshiba

Toshiba RAC-WK0812ESCWRU1 Bruksanvisning

18 Mars 2025
Midea

Midea AG16Black-24NXD0-I Bruksanvisning

12 Mars 2025
Midea

Midea MSX-12NXD0 Bruksanvisning

12 Mars 2025
Midea

Midea AEP2-12NXD6-I Bruksanvisning

12 Mars 2025
Midea

Midea AEP2-09NXD6-I Bruksanvisning

12 Mars 2025
