Ph Sf Cpny r eac n s gurte
FIRST OPENING ON FACTORY DEFAULT CODE
Factory code is 1 2 3 4 5 6
1. Touch the screen, to activate (1 bleep and screen illuminates).
2. Enter the user code (1st time usage 123456).
3. Touch , a melodic tone will sound and the display will OPEN
show .OPEnd
4. Turn handle counter clockwise and open the door while the
tone is sounding.
CAUTION
I. If an incorrect code is entered, Error will appear in the display
panel and a short warning tone will sound.
II. If a wrong code is entered 5 times the lock will cease to oper-
ate for 5 minutes. During which a warning tone will sound and
the display will indicate deLAY.
SETTING A NEW USER CODE
Set a new code with the door open and test the new code before
closing the door.
1. Touch the screen to activate
2. Touch ENTER
3. Type in the present code
4. Touch ENTER
5. Type in the new 4 – 16 digit code
6. Touch , a melodic tone will sound and the display will ENTER
show EntErd
For example:
If the present code is 1 2 3 4 5 6 and a new four digit code is
decided as 4 2 4 2 enter the following –
ENTER 1 2 3 4 5 6 ENTER 4 2 4 2 ENTER> > > >
EntErd will show in the display and a short tone will sound to
conrm the change to 4 2 4 2
INTRODUCING A FINGERPRINT
Open the door using the user code. Keep the door open while
carrying out this process.
1. Press the button on the back of door, the screen will be M
activated
2. Press on the screen3
3. Press ENTER
4. Enter the user code and press ENTER
5. Scan in the ngerprint twice
consecutively, by placing the
nger on the sensor. The screen
will show a melody will EntErd
sound.
NOTE: Check the nger print had
been set correctly following -
How to open with a ngerprint.
• A total of 128 nger prints can be
introduced into the lock.
HOW TO OPEN WITH A FINGERPRINT
1. Touch the screen to activate
2. Scan the ngerprint on the sensor, the screen will show
OPEnd and a melody will sound.
3. Turn the handle counter clockwise and open the door while the
tone is sounding.
CAUTION
I. will appear in the If an incorrect ngerprint is scanned, ErrOr
display and a short warning tone will sound.
II. If a wrong ngerprint is scanned 5 times the lock will cease to
operate for 5 minutes. During which a warning tone will sound
and the display will indicate deLAY.
V1 JUL 2018
Battery Case
Hold the upper part and turn it counter-clockwise to
disassemble (1,5V AA Alkaline 4 pcs)
Upper part Lower part
Reset Button
Upper
part
Lower
part
Securing
Hole
Memory Button
Door back or Top drawer back
Put Finger-print twice
While red lamp flickering,
put user’s finger on sensor.
1
2After Bi- sound,
repeat the above 1
SS1160F OPERATING INSTRUCTIONS
& GUARANTEE REGISTRATION
Ph Sf Cpny r eac n s gurte
HOW TO DELETE REGISTERED FINGERPRINTS
1. Press the button on the back of the door, the screen will be M
activated.
2. Press ENTER
3. Press 3
4. Press , the display will show and a melody will ENTER CLEAr
sound.
NOTE: All ngerprints are deleted
DUAL LOCKING (2 CODES REQUIRED TO OPEN THE
SAFE)
Set up a 2nd user code
Press the button, touch number 2, touch , type in the M ENTER
numbers required for the code and touch . The screen will ENTER
show EntErd
M 2 Enter 2nd Code Enter> > > >
Activate / Deactivate Dual Locking
Press the button touch number 9, touch M ENTER. The screen
will show – to indicate dual locking has been activated or dUAL
5in9LE to indicate the lock has been reverted to single locking.
M Enter > > 9
To Open While in Dual Mode
1. Touch the screen to activate
2. Type in the 1st user code
3. Touch OPEN
4. Type in the 2nd user code
5. Touch OPEN
6. The screen will show OPEnd
NOTE: In dual mode it is not possible to open using a nger-
print.
TO HIDE CODE IN THE DISPLAY AND TURNOFF
KEYPAD SOUND
To activate and deactivate –
Press memory button on the back of the door touch number , M 7
touch . The display will show or ENTER hidE CLEAr
M > 7 > Enter
SCRAMBLE NUMBERS
The code can be disguised by inserting random numbers either
before, after, or both before and after, the user code. This feature
can also be used with the hidden code display and silent keypad
as above.
For example – personal code has been set as 4 2 4 2
1. Touch the screen to activate
2. Enter the user code as 61 4 2 4 2 75391
3. Touch OPEN
The display will show OPEnd
ALARM SETTING
The alarm can be set before closing the door and will automati-
cally be deactivated when the personal code is entered.
TO SET THE ALARM
Press the button on the back of the door touch number , touch M 8
ENTER ALErT. The display will show
M 8 Enter > >
If the safe is tilted over 45° or impacted, the alarm will sound if it
has been activated.
RESET
If the display does not respond, press the reset button on the
inside of the display casing to reset the lock. The registered codes
and nger prints will not be deleted.
BATTERY LIFE
6 months if the lock is accessed 3 times a day.
The batteries must be replaced if –
1. When touching the screen, appears on the display.LobAtt
2. The battery icon appears in the display.
3. Correct code or ngerprint entered but the door will not open.
* Even if the batteries are completely exhausted, the codes
are not lost.
BATTERIES
4 X 1.5v AA Alkaline Batteries (supplied) are required
to activate the lock. Used batteries should not be
disposed of with normal domestic waste. These should
be disposed of at approved collection points. You may
also return used batteries to your Retailer at their expense (where
applicable).
SS1160F OPERATING INSTRUCTIONS
& GUARANTEE REGISTRATION
Ph Sf Cpny r eac n s gurte
BASE FIXING FOR THE SS1160F SERIES
Thank you for purchasing a Phoenix Safe. Your safe is ready
prepared for base xing / rear xing (dependent on the model
purchased), with xing bolts for concrete supplied.
To x your safe, follow the instructions to the below, using the
dimensions in the table.
DIMENSION OF
THE ANCHOR
BOLT
LENGTH OF
THE ANCHOR
BOLT (L), MM
DIAMETER
OF THE DRILL
BIT (D), MM
DEPTH TO
DRILL (M), MM
MINIMUM
DEPTH TO
INSERT THE
BOLT (H), MM
M12/180mm 180 12 150 81
Drill the hole according to the dimensions (C&D)
Insert the anchor bolt through the base of the safe
and tap down using with the help of a hammer.
Screw the anchor bolt until it will tighten no further.
Clean the hole with a brush to remove debris.
GUARANTEE REGISTRATION
Please submit your guarantee registration by visiting our website
www.phoenixsafe.com and clicking on guarantee registration.
For further assistance or information
please contact us on 0151 944 6444.
APEX HOUSE, 1 ORRELL MOUNT, LIVERPOOL, L20 6NS,
UNITED KINGDOM | +44 (0)151 944 6444
SS1160F OPERATING INSTRUCTIONS
& GUARANTEE REGISTRATION
