Industrial 4-/8-port 10/100TX + 2-port 1000X SFP
Ring Ethernet Switch
IFGS-620TF/IFGS-624PTF/IFGS-1222TF
User's Manual
Table of Contents
1. Package Contents ..........................................................................................3
2. Hardware Introduction ...................................................................................4
2.1 Switch Front Panel ...................................................................................4
2.2 LEDDenition ........................................................................................8
2.3 Switch Upper Panel ............................................................................... 10
2.4 Wiring the Power Inputs ........................................................................ 11
2.5 Wiring the Faulty Alarm Contact ............................................................. 12
2.6 Grounding the Device ............................................................................ 12
3. Installation .................................................................................................. 13
3.1 DIN-rail Mounting Installation................................................................. 13
3.2 Wall-mount Plate Mounting .................................................................... 14
3.3 Side Wall-mount Plate Mounting ............................................................. 14
4.ProductSpecications .................................................................................. 15
5. Customer Support ....................................................................................... 19
3
1. Package Contents
Thank you for purchasing PLANET Industrial 4-/8-port 10/100TX + 2-port 1000X
SFP Ring Ethernet Switch, IFGS-620TF, IFGS-624PTF or IFGS-1222TF. The table
below shows the models with the number of ports:
Model Name 10/100TX
Copper Ports
802.3at PoE
Ports
10/100/100T
Copper Ports
1000X SFP
Ports
IFGS-620TF 4 - - 2
IFGS-624PTF 4 4 - 2
IFGS-1222TF 8 - 2 2
In the following sections, the term means the “Industrial Ring Ethernet Switch”
IFGS-620TF, IFGS-624PTF or IFGS-1222TF.
Open the box of the Industrial Ring Ethernet Switch and carefully unpack it. The box
should contain the following items:
Industrial Ring Ethernet Switch x 1 QR Code Sheet x 1 Wall-mount Kit
Let’s get started with your PLANET product
IFGS-620TF
EN Please scan the QR code to browse our online User’s Manual or Quick
Installation Guide and follow the instructions to complete the setup.
User's Manual
DE
Bitte scannen Sie den QR Code sie werden per Browser zur
Bedienungsanleitung oder Schnellanleitung weiter geleitet. Folgen Sie den
Anweisungen um die Installation abzuschließen.
FR
Veuillez scanner le code QR pour obtenir notre Notice d’Utilisation en
ligne ou notre Guide d’Installation Rapide et suivez les instructions pour
compléter la conguration
ES
Escanee el código QR para encontrar el Manual del Usuario en línea o
la Guía de Instalación Rápida y siga las instrucciones para completar la
conguración.
IT Scansiona il codice QR per consultare online il Manuale utente o la Guida di
installazione rapida e segui le istruzioni per completare la congurazione.
PT Por favor, escaneie o QR code para navegar no Manual do Usuário ou Guia
de Instalação Rápida. Siga as instruções para completar a conguração.
PL
Zeskanuj kod QR, aby otworzyć naszą internetową instrukcję obsługi
lub instrukcję szybkiej instalacji. Postępuj zgodnie z instrukcjami, aby
zakończyć poprawną kongurację.
RU
One word modify: Отсканируйте QR-код, чтобы просмотреть наше
онлайн-руководствопользователя или руководство по б ыстрой
настройке, и следуйте инструкциям для завершения настройки
RO Te rugam sa scanezi codul QR, pentru a descarca User’s Manual sau Quick
Installation Guide si a urmari instructiunile necesare in nalizarea instalarii
AR
Need more help?
PLANET online FAQs:
http://www.planet.com.tw/en/support/faq
Technical Su pport: support@planet.com.tw
Copyright © PLANET Technology Corp. 2024.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
Part No. 2360-AH7090-000
RJ45 Dust Cap SFP Dust Cap x 2 DIN-rail Kit
IFGS-620TF x 4
IFGS-624PTF x 4
IFGS-1222TF x 8
IFGS-620TF IFGS-624PTF/
IFGS-1222TF
If any of these are missing or damaged, please contact your dealer immediately;
if possible, retain the carton including the original packing material, and use them
again to repack the product in case there is a need to return it to us for repair.
