PRE CAU T IONS
• Please read and follow these instructions and
keep this manual in a safe place.
• Keep this product away from water and all
flammable gasses or liquids.
• Do not attempt to disassemble or repair this
product.
• Make sure that this product is intact and that
there are no missing parts.
• All photos are for illustrative purposes only.
CON T ENT S INCLU D E
S D C- 2 15 0
• SDC-2150 microphone
• Mic clip
• Product manual
S D C- 2 15 0 -MP
• SDC-2150 microphone (×2)
• Mic clip (×2)
• Carrying case
• Product manual
2150
CONDENSER
MICROPHONE
SMALL DIAPHRAGM
PRODUCT
MANUAL
ONE -YE AR L I MIT ED WAR RANT Y
This Polsen product is warranted to the original purchaser to be free from defects in materials and workmanship
under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after
replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall
be limited solely to repair or replacement, at the provider’s discretion, of any product that fails during normal use of
this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be
determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right
to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper
installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS
WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights,
and you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Polsen Customer Service Department to obtain a return merchandise
authorization (“RMA”) number, and return the defective product to Polsen along with the RMA number and proof of
purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.polsenaudio.com or call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Polsen is a registered trademark of the Gradus Group. 2015 Gradus Group LLC. All Rights Reserved.©GG1
SP ECIFICAT I ONS
T R A N S D U CE R Back electret condenser
POL AR P A T T ERN Cardioid
FR E QU ENC Y RESPO NS E 50 Hz – 18 kHz
SE NS IT I V IT Y -42 dB 3 dB (0 dB ± = 1 V/Pa at 1 kHz
OUT P UT IM P ED A NC E 200Ω ± % 30 (at 1 kHz)
LOA D IM PE D ANCE ≥ 1000Ω
MAX IM U M I NPU T SPL 130 dB (THD ≤ 1.0 at 1 kHz)%
POW E R R E QU IRE M EN T 9 – 52 V DC phantom power
CABLE CO NN ECT OR XLR male
DIM EN SI ONS ( , L)Ø 0.8” (21 mm), 6.1” (15.6 cm)
W E IG H T 0.35 lb. (159 g)
-70
-60
-40
-30
-50
50 2K 20K10K1K 5K50020010020
FREQUENCY (Hz)
RELATIVE RESPONSE (dB)
POLAR PAT T E R N FRE Q U E NCY RE SPONSE G R APH
0°30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
UNI-DIRECTIONAL
(at 1kHz)
SDC-2150
SMALL DIAPHRAGM
CONDENSER MICROPHONE
T HANK Y OU FOR CHOOSING POLSEN.
The Polsen SDC-2150 microphone is a small diaphragm cardioid
condenser microphone designed for recording high-quality audio
in a professional or project studio. Its high sensitivity and tailored
frequency response make it ideal for acoustic instruments and
drum overheads. The high sound pressure level (SPL) handling
capability enables close mic placement to snares, cymbals, pianos,
guitars, and other acoustic instruments while capturing detailed
and accurate sound. As a matched pair, they are an excellent
choice to use as stereo room mics or for stereo recordings of live
performances. The cardioid polar pattern is less susceptible to
recording reflections than shotgun microphones, making the
SDC-2150 a superb option for boompole use while recording
speech or dialog in the studio or on location.
