[en] Instruction manual

Extractor hood ATS6S220, ATS6S260,

ATS6S250

Ú Table of contents

[en]Instruction manual

Important safety information .................................................... 2

Environmental protection ......................................................... 4

Saving energy......................................................................................4

Environmentally-friendly disposal.....................................................4

Operating modes ....................................................................... 4

Exhaust air mode................................................................................4

Circulating-air mode ...........................................................................4

Operating the appliance............................................................ 5

Filter drawer .........................................................................................5

Lighting .................................................................................................5

Cleaning and maintenance ....................................................... 5

Trouble shooting........................................................................ 7

After-sales service ..................................................................... 7

Accessories for circulated air mode ........................................ 8

: Important safety information

Read these instructions carefully. Only then

will you be able to operate your appliance

safely and correctly. Retain the instruction

manual and installation instructions for

future use or for subsequent owners.

The appliance can only be used safely if it

is correctly installed according to the safety

instructions. The installer is responsible for

ensuring that the appliance works perfectly

at its installation location.

This appliance is intended for domestic use

and the household environment only. The

appliance is not intended for use outside.

Do not leave the appliance unattended

during operation. The manufacturer is not

liable for damage which is caused by

improper use or incorrect operation.

This appliance is intended for use up to a

maximum height of 2000 metres above sea

level.

This appliance may be used by children

over the age of 8 years old and by persons

with reduced physical, sensory or mental

capabilities or by persons with a lack of

experience or knowledge if they are

supervised or are instructed by a person

responsible for their safety how to use the

appliance safely and have understood the

associated hazards.

Children must not play with, on, or around

the appliance. Children must not clean the

appliance or carry out general maintenance

unless they are at least 8 years old and are

being supervised.

Keep children below the age of 8 years old

at a safe distance from the appliance and

power cable.

Check the appliance for damage after

unpacking it. Do not connect the appliance

if it has been damaged in transport.

Only a licensed professional may connect

appliances without plugs. Damage caused

by incorrect connection is not covered

under warranty.

Danger of suffocation!

Packaging material is dangerous to

children. Never allow children to play with

packaging material.

Danger of death!

Risk of poisoning from flue gases that are

drawn back in.

Always ensure adequate fresh air in the

room if the appliance is being operated in

exhaust air mode at the same time as room

air-dependent heat-producing appliance is

being operated.

Room air-dependent heat-producing

appliances (e.g. gas, oil, wood or coal-

operated heaters, continuous flow heaters

or water heaters) obtain combustion air

from the room in which they are installed

and discharge the exhaust gases into the

open air through an exhaust gas system

(e.g. a chimney).

In combination with an activated vapour

extractor hood, room air is extracted from

the kitchen and neighbouring rooms - a

partial vacuum is produced if not enough

fresh air is supplied. Toxic gases from the

chimney or the extraction shaft are sucked

back into the living space.

■Adequate incoming air must therefore

always be ensured.

■An incoming/exhaust air wall box alone

will not ensure compliance with the limit.

Safe operation is possible only when the

partial vacuum in the place where the heat-

producing appliance is installed does not

exceed 4 Pa (0.04 mbar).

This can be achieved when the air needed

for combustion is able to enter through

openings that cannot be sealed, for

example in doors, windows, incoming/

exhaust air wall boxes or by other technical

means.

In any case, consult your responsible

Master Chimney Sweep. He is able to

assess the house's entire ventilation setup

and will suggest the suitable ventilation

measures to you.

Unrestricted operation is possible if the

vapour extractor hood is operated

exclusively in the circulating-air mode.

Risk of fire!

■Grease deposits in the grease filter may

catch fire.

Clean the grease filter at least every

2 months.

Never operate the appliance without the

grease filter.

Risk of fire!

■Grease deposits in the grease filter may

catch fire. Never work with naked flames

close to the appliance (e.g. flambéing). Do

not install the appliance near a heat-

producing appliance for solid fuel (e.g.

wood or coal) unless a closed, non-

removable cover is available. There must

be no flying sparks.

Risk of fire!

■Hot oil and fat can ignite very quickly.

Never leave hot fat or oil unattended.

Never use water to put out burning oil or

fat. Switch off the hotplate. Extinguish

flames carefully using a lid, fire blanket or

something similar.

Risk of fire!

■When gas burners are in operation without

any cookware placed on them, they can

build up a lot of heat. A ventilation

appliance installed above the cooker may

become damaged or catch fire. Only

operate the gas burners with cookware on

them.

Risk of fire!

■Operating several gas burners at the

same time gives rise to a great deal of

heat. A ventilation appliance installed

above the cooker may become damaged

or catch fire. Never operate two gas

burners simultaneously on the highest

flame for longer than 15 minutes. One

large burner of more than 5 kW (wok) is

equivalent to the power of two gas

burners.

Risk of burns!

The accessible parts become very hot when

in operation. Never touch hot parts. Keep

children at a safe distance.

Risk of injury!

■Components inside the appliance may

have sharp edges. Wear protective gloves.

Risk of injury!

■Items placed on the appliance may fall

down. Do not place any objects on the

appliance.

Risk of electric shock!

■A defective appliance may cause electric

shock. Never switch on a defective

appliance. Unplug the appliance from the

mains or switch off the circuit breaker in

the fuse box. Contact the after-sales

service.

Risk of electric shock!

■Incorrect repairs are dangerous. Repairs

may only be carried out and damaged

power cables replaced by one of our

trained after-sales technicians. If the

appliance is defective, unplug the

appliance from the mains or switch off the

circuit breaker in the fuse box. Contact the

after-sales service.

Risk of electric shock!

■Do not use any high-pressure cleaners or

steam cleaners, which can result in an

electric shock.

Causes of damage

Caution!

Risk of damage due to corrosion. Always switch on the

appliance while cooking to avoid condensation. Condensate

can produce corrosion damage.

Always replace faulty bulbs to prevent the remaining bulbs from

overloading.

Risk of damage due to ingress of humidity into the electronic

circuitry. Never clean operator controls with a wet cloth.

Surface damage due to incorrect cleaning. Clean stainless

steel surfaces in the direction of the grain only. Do not use any

stainless steel cleaners for operator controls.

Surface damage due to strong or abrasive cleaning agents.

Never use strong and abrasive cleaning agents.

Risk of damage from returning condensate. Install the exhaust

duct in such a way that it falls away from the appliance slightly

(1° slope).
