MIXCAB- 15
15” Portable Mixer PA
MIXCAB- 178.971UK 15:
XCAB-15
15” Extension Cabinet
XCAB-15: 178.972UK
VERSION 1 1.
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
MIXCAB- XCAB-15 User Manual15
Introduction
Thank you for choosing MIXCAB- portable PA unit. This versatile portable PA unit offers a a 15
full set of PA features in a rugged and portable enclosure. Operated as a standalone unit or
with the passive XCAB-15, this portable PA delivers an output power normally only possible
from mains powered speakers and has inputs for multiple performers as a band PA system.
Package Contents
Please check the contents to ensure that the product has been received in good condition.
If you find any accessory is missing or the product has arrived with any problems, please
contact your retailer at once.
• MIXCAB- mixer PA unit 15
• Media player remote control
• IEC power lead(s)
(all above not applicable to XCAB-1 5)
This product contains no user-serviceable parts so make no attempt to try to fix or modify this
item yourself as this will invalidate the warranty. We recommend you keep the original
package and proof of purchase for any possible replacement or returned demand.
Warning
To prevent the risk of fire or electric shock, do not expose this appliance to rain or moisture.
To prevent electric shock do not remove the cover. No user serviceable parts inside. Refer
servicing to qualified service personnel.
Safety
Prior to connecting mains, check the supply voltage is correct and the IEC mains lead is OK.
Avoid ingress of water or particles into the enclosure.
If the internal IEC fuse blows, refer the unit to qualified service personnel
If the UHF microphones are to be unused for a long period of time, remove the batteries and
store for later use.
Placement
Keep the unit out of direct sunlight and away from heat sources.
Place the unit in an upright position during use and storage.
Keep the unit away from moisture or dusty environments.
Cleaning
Use a soft cloth with a neutral detergent to clean the cabinet, rear panel and controls.
To avoid damage, do not use solvents to clean this equipment.
MIXCAB- , XCAB-15 User Manual15
MIXCAB- Rear Panel 15
Power connection and internal battery
Your new MIXCAB- unit may arrive with you with t internal battery charged. 15 he
Before connecting to the mains, turn down all volume controls ( , 20 23) a switch the unit 17 , nd
on ( and check the battery level indicators (25). If the battery level is low or if no LEDs 26)
light at all, you will need to charge the battery befor operating away from mains power. e
Connect the MIXCAB- unit to the mains (27) using the appro iate mains IEC lead supplied. 15 pr
You may otherwise opt to connect the DC input at the rear ( to an external 12- Vdc 14) 15
supply car battery) or use the internal battery if charged. (e.g
If the POWER switch is in the off position ilst the unit is connected to the mai , the “ ” wh ns
internal battery will be re-charged from the mains supply. The battery status LEDs will be off
and the CHA LED will light red when charging or green when fully charged. “RGING”
Note: it is recommended to store the PA unit at an ambient temperature and not with the
battery fully discharged.
1.
SD card slot
2.
USB port
3.
CH.1 input XLR/jack
4.
CH.1 Mic/Line level select or
5.
C 2 input XLR/jack H.
6.
C 2 Mic/Line level select H. or
7.
C 3 input XLR/jack H.
8.
C 3 Mic/Line level select H. or
9.
CH.4 line input L+R RCA
10.
CH.4 input stereo 3.5mm jack
11.
Line output L+R RCA
12.
Echo effect on/off selector
13.
Echo effect master volume
14.
12Vdc power input safety fuse &
15.
Speaker output (XCAB- ) 15
16.
Media player display
17.
Media player volume
18.
Media player controls
19.
CH.1-4 echo effect controls
20.
CH.1-4 volume controls
21.
CH.1-4 treble EQ controls
22.
CH.1-4 bass EQ controls
2 3.
Master volume
2 4.
Master mono/stereo switch
25.
Battery charging/level indicators
26.
Power on ff switch /o
27.
IEC mains inlet & fuse holder
