QR12 PAPABT, QR15 BT
Portable PA
Item ref: 178.8 , 178.847UK 48UK
User Manual
Version 1.2
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
178.8 , 178.8 User Manual 47UK 48UK
Introduction
Thank you for choosing the QRPABT portable PA unit. Please read this manual prior to use to avoid damage to the item.
This versatile portable PA unit is pa d with features in a compact, manageable enclosure and is suitable for a wide cke
array of applications ranging from public address for presentations to outdoor karaoke.
• 15Vdc power adapter with IEC input
• Internal 12V rechargeable battery
• 2 x VHF handheld microphones included
• Guitar / Microphone inputs (6.3mm jack)
• Master 2 band EQ and Echo effect for microphones
• Internal USB/SD/FM/BT media player with record function
• Bluetooth pairing with TWS function
• VCV mic override function
• I.R. remote control for media player
• Integral 35mm pole mount
• AUX line input
Please check the contents to ensure that the product has been received in good condition.
• QRPABT portable PA unit
• 2 x VHF handheld microphone transmitters
• 4 x AA batteries
• IEC mains power lead(s)
• IR Remote control for media player
• User manual
If you find any accessory is missing or the product has arrived with any problems, please contact your retailer at once.
This product contains no user-serviceable parts so make no attempt to try to fix or modify this item yourself as this will
invalidate the warranty. We recommend you keep the original package and proof of purchase for any possible
replacement or returned demand.
Warning
To prevent the risk of fire or electric shock, do not expose this appliance to rain or moisture. To prevent electric shock do
not remove the cover. No user serviceable parts inside. Refer servicing to qualified service personnel.
Safety
Prior to connectin the mains adapter, ensure that the supply voltage is correct and the mains lead is in good condition. g
Avoid ingress of water or particles into the enclosure.
If the internal fuse blows, refer the unit to qualified service personnel
If the VHF microphone transmitter is to be unused for a long period of time, remove the batteries and store for later use.
Placement
Keep the unit out of direct sunlight and away from heat sources.
Place the unit in an upright position during use and storage.
Keep the unit away from moisture or dusty environments.
Cleaning
Use a soft cloth with a neutral detergent to clean the cabinet, panel and controls.
To avoid damage, do not use solvents to clean this equipment.
178.8 , 178.8 User Manual 47UK 48UK
Control panel
Powering up
Your n QRPABT unit may arrive with you with the internal battery charged. Before connecting to the mains with the ew
supplied power adaptor, switch the it on and check the POWER LED (18). If it is green, there is charge in the battery. un
If it is red, then you will need to charge the battery before using away from a mains supply.
Connect the QRPABT unit to the mains using the supplied IEC mains lead (22). You may otherwise opt to connect the DC
input jack (21) to an external 12- Vdc supply, such as a car battery, or use the internal battery if charged. 15
When not in use but connected to the mains, if the POWER switch is in the
off
position, the internal battery will be re-
charged from the mains supply. This can be observed by the CHARGE LED (18) which will light orange when charging. ,
When fully charged, the CHARGE LED will change to green.
Note: it is recommended to store the PA unit at an ambient temperature and not with the battery fully discharged.
Initial setup
Turn all VOLUME & ECHO controls down (anti-clockwise) and turn the POWER itch on (the power LED should light). sw
BASS and TREBLE controls should remain pointing vertically (12-o-clock position).
Turn up the main VOLUME control part way and switch VCV off. Your QRPABT unit should now be ready to operate.
VHF Microphone
Ins t the supplied AA batteries into each of the handheld microphones by carefully unscrewing the base and connecting er
the “+” and “ ” terminals o- f the battery to the corresponding contacts inside the microphone body, taking care to observe
the correct polarity. Turn on the VHF receiver (16) and turn the VHF VOL controls (6) up (clockwise) part way.
Switch on each wireless mic in turn the rear panel RF LEDs should light as a result. If the LED on the transmitter lights –
dimly, change the battery. Gradually increase the VHF VOL controls (6), testing each microphone for output through the
speaker. Take care not to incur “feedback” (howling or screeching sound through the speaker) by keeping the
microphone a sensible distance from the speaker and pointing away from the speaker so that it doesn’t
hear
the speaker.
Turning the ECHO control (4) clockwise introduces a pre-set echo function for singing and special effects.
BASS and TREBLE (15, 3) can be cut by turning anti-clockwise or boosted by turning clockwise.
When not in use, switch the handheld transmitters off and remove the batteries if not being used for long periods.
1
USB port
2
SD/MMC card slot
3
TREBLE EQ
4
ECHO level
5
Wired MIC / guitar volume
6
VHF Mic volumes A and B
7
LINE IN 2 x RCA
8
Wired MIC.1 / guitar and MIC.2 input 6.3mm jacks
9
Smart phone / aux input stereo 3.5mm jack
10
Antenna connection - VHF A Mic
11
Media player LCD display & IR receiver
12
Media player mode & transport controls
13
Main volume
14
VCV talkover on/off
15
BASS EQ
16
VHF wireless receiver on/off
17
MIX OUT line output 2 x RCA
18
Battery charge & power LEDs
19
Power on/off
20
Antenna connection - VHF B Mic
21
DC power input jack
22
IEC power inlet & fuse holder
