OPERATOR’S MANUAL
6-1/2 in. CIRCULAR SAW
MANUEL D’UTILISATION
SCIE CIRCULAIRE DE 165 mm (6-1/2 po)
MANUAL DEL OPERADOR
SIERRA CIRCULAR DE 165 mm (6-1/2 pulg.)
R3204
To register your RIDGID
product, please visit:
http://register.RIDGID.com
Pour enregistrer votre
produit de RIDGID,
s’il vous plaît la visite:
http://register.RIDGID.com
Para registrar su producto
de RIDGID, por favor visita:
http://register.RIDGID.com
TABLE OF CONTENTS
****************
General Power Tool Safety
Warnings 2-3 .........................................
Circular Saw Safety Rules 3-4 ...............
Symbols 5 ..............................................
Electrical .............................................6
Features ..............................................7
Assembly .........................................7-8
Operation .......................................8-12
Adjustments ................................12-13
Maintenance .....................................13
Accessories ......................................14
Illustrations ..................................15-17
Parts Ordering and
Service Back page ................................
TABLE DES MATIÈRES
****************
Règles de sécurité relatives
aux outils electriques 2-3 ......................
Avertissements de sécurité
relatifs scie circulaire 3-4 .......................
Symboles 5 ............................................
Caractéristiques électriques 6 ...............
Caractéristiques .................................7
Assemblage .....................................7-8
Utilisation .......................................8-12
Réglages 12-13 ......................................
Entretien ...........................................13
Accessoires 14 ......................................
Illustrations ..................................15-17
Commande de pièces et
dépannage Page arrière ........................
ÍNDICE DE CONTENIDO
****************
Advertencias de seguridad
para herramientas eléctricas 2-3 .........
Advertencias de seguridad
sierra circular 3-4 .................................
Símbolos 5 ............................................
Aspectos eléctricos 6 ...........................
Características ...................................7
Armado .......................................... 7-8
Funcionamiento ........................... 8-12
Ajustes ....................................... 12-13
Mantenimiento .................................13
Accesorios .......................................14
Ilustraciones .............................. 15-17
Pedidos de piezas y
servicio Pág. posterior .........................
Includes: Circular saw, blade, hex key,
Operator’s Manual
Inclut : Scie circulaire, lam e, clé
hexagonale, manuel d’utilisation
Incluye: Sierra circular, hoja, llave
hexagonal, manual del operador
SAVE THIS MANUAL
FOR FUTURE REFERENCE
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS
WARNING:
To reduce the risk of injury, the
user must read and understand
the operator’s manual before
using this product.
AVERTISSEMENT :
Pour réduire les risques de
blessures, l’utilisateur doit lire
et veiller à bien comprendre
le manuel d’utilisation avant
d’utiliser ce produit.
ADVERTENCIA:
Para reducir el riesgo de
lesiones, el usuario debe leer
y comprender el manual del
operador antes de usar este
producto.
2 - English
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of a GFCI reduces the
risk of electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal
injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites
accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught
in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
Do not wear loose clothing or jewelry. Contain long
hair. Loose clothes, jewelry, or long hair can be drawn
into air vents.
Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
power tool in unexpected situations.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
3 - English
CUTTING PROCEDURES
DANGER:
Keep hands away from cutting area and the
blade. Keep your second hand on auxiliary
handle, or motor housing. If both hands are
holding the saw, they cannot be cut by the blade.
Do not reach underneath the workpiece. The guard
can not protect you from the blade below the workpiece.
Adjust the cutting depth to the thickness of the
workpiece. Less than a full tooth of the blade teeth
should be visible below the workpiece.
Never hold piece being cut in your hands or across
your leg. Secure the workpiece to a stable platform.
It is important to support the work properly to minimize
body exposure, blade binding, or loss of control.
Hold the power tool by insulated gripping surfaces only,
when performing an operation where the cutting tool
may contact hidden wiring or its own cord.
Contact with
a “live” wire will also make exposed metal parts of the
power tool “live” and could give the operator an electric
shock.
When ripping, always use a rip fence or straight edge
guide. This improves the accuracy of cut and reduces
the chance of blade binding.
Always use blades with correct size and shape
(diamond versus round) of arbour holes. Blades that
do not match the mounting hardware of the saw will run
eccentrically, causing loss of control.
Never use damaged or incorrect blade washers or
bolt. The blade washers and bolt were specially designed
for your saw, for optimum performance and safety of
operation.
KICKBACK CAUSES AND RELATED WARNINGS
Kickback is a sudden reaction to a pinched, bound or
misaligned saw blade, causing an uncontrolled saw to
lift up and out of the workpiece toward the operator;
When the blade is pinched or bound tightly by the kerf
closing down, the blade stalls and the motor reaction
drives the unit rapidly back toward the operator;
If the blade becomes twisted or misaligned in the cut,
the teeth at the back edge of the blade can dig into the
top surface of the wood causing the blade to climb out
of the kerf and jump back toward the operator.
Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below:
Maintain a firm grip with both hands on the saw and
position your arms to resist kickback forces. Position
your body to either side of the blade, but not in line
with the blade. Kickback could cause the saw to jump
backwards, but kickback forces can be controlled by the
operator, if proper precautions are taken.
When blade is binding, or when interrupting a cut
for any reason, release the trigger and hold the saw
motionless in the material until the blade comes to a
complete stop. Never attempt to remove the saw from
the work or pull the saw backward while the blade is
in motion or kickback may occur. Investigate and take
corrective actions to eliminate the cause of blade binding.
When restarting a saw in the workpiece, centre the
saw blade in the kerf and check that saw teeth are
not engaged into the material. If saw blade is binding,
it may walk up or kickback from the workpiece as the
saw is restarted.
Support large panels to minimise the risk of blade
pinching and kickback. Large panels tend to sag under
their own weight. Supports must be placed under the
panel on both sides, near the line of cut and near the
edge of the panel.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
GENERAL POWER TOOL SAFETY WARNINGS
CIRCULAR SAW SAFETY WARNINGS
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
When servicing a power tool, use only identical
replacement parts. Follow instructions in the
Maintenance section of this manual. Use of unauthorized
parts or failure to follow Maintenance instructions may
create a risk of shock or injury.
Produktspecifikationer
| Varumärke: | RIDGID |
| Kategori: | Sågmaskin |
| Modell: | R3204 |
Behöver du hjälp?
Om du behöver hjälp med RIDGID R3204 ställ en fråga nedan och andra användare kommer att svara dig
Sågmaskin RIDGID Manualer
20 September 2024
16 September 2024
9 September 2024
8 September 2024
7 September 2024
4 September 2024
1 September 2024
1 September 2024
31 Augusti 2024
29 Augusti 2024
Sågmaskin Manualer
- Sågmaskin Bosch
- Sågmaskin AEG
- Sågmaskin DeWalt
- Sågmaskin Ford
- Sågmaskin Al-ko
- Sågmaskin Silverline
- Sågmaskin Brennenstuhl
- Sågmaskin Ferm
- Sågmaskin Workzone
- Sågmaskin Clarke
- Sågmaskin Ozito
- Sågmaskin Gude
- Sågmaskin Makita
- Sågmaskin Draper
- Sågmaskin Tryton
- Sågmaskin Hitachi
- Sågmaskin Black And Decker
- Sågmaskin Vonroc
- Sågmaskin Remington
- Sågmaskin ACG
- Sågmaskin Maestro
- Sågmaskin Stanley
- Sågmaskin Skil
- Sågmaskin Hyundai
- Sågmaskin Yato
- Sågmaskin Hilti
- Sågmaskin Ryobi
- Sågmaskin Florabest
- Sågmaskin Festool
- Sågmaskin Metabo
- Sågmaskin Parkside
- Sågmaskin Worx
- Sågmaskin Meec Tools
- Sågmaskin Milwaukee
- Sågmaskin Hikoki
- Sågmaskin Sun Joe
- Sågmaskin Dremel
- Sågmaskin Sovereign
- Sågmaskin Tacklife
- Sågmaskin Hazet
- Sågmaskin Einhell
- Sågmaskin Gardena
- Sågmaskin Baumr-AG
- Sågmaskin Yard Force
- Sågmaskin Ferrex
- Sågmaskin Luxor
- Sågmaskin Husqvarna
- Sågmaskin Maktec
- Sågmaskin Bort
- Sågmaskin Tanaka
- Sågmaskin Ideal
- Sågmaskin Craftsman
- Sågmaskin Power Craft
- Sågmaskin Snow Joe
- Sågmaskin Powerplus
- Sågmaskin Stiga
- Sågmaskin Porter-Cable
- Sågmaskin Cotech
- Sågmaskin Genesis
- Sågmaskin Trotec
- Sågmaskin Troy-Bilt
- Sågmaskin Cobra
- Sågmaskin Hammer
- Sågmaskin Challenge
- Sågmaskin Topcraft
- Sågmaskin Texas
- Sågmaskin Martha Stewart
- Sågmaskin Spear & Jackson
- Sågmaskin Scheppach
- Sågmaskin Atika
- Sågmaskin Gamma
- Sågmaskin McCulloch
- Sågmaskin Sterwins
- Sågmaskin Powerfix
- Sågmaskin Matrix
- Sågmaskin Kress
- Sågmaskin Stihl
- Sågmaskin Bavaria
- Sågmaskin Dolmar
- Sågmaskin Shindaiwa
- Sågmaskin Hobart
- Sågmaskin Lionelo
- Sågmaskin Flex
- Sågmaskin Powerworks
- Sågmaskin Duro
- Sågmaskin Prime3
- Sågmaskin Zipper
- Sågmaskin Mafell
- Sågmaskin Greenworks
- Sågmaskin Fieldmann
- Sågmaskin Qualcast
- Sågmaskin Pattfield
- Sågmaskin Defort
- Sågmaskin Fuxtec
- Sågmaskin IKRA
- Sågmaskin Truper
- Sågmaskin Masport
- Sågmaskin Grizzly
- Sågmaskin Echo
- Sågmaskin Solo
- Sågmaskin Bruder Mannesmann
- Sågmaskin Cocraft
- Sågmaskin Powerblade
- Sågmaskin Maruyama
- Sågmaskin Herkules
- Sågmaskin Meister Craft
- Sågmaskin Toolcraft
- Sågmaskin Łucznik
- Sågmaskin Batavia
- Sågmaskin Proxxon
- Sågmaskin Gardenline
- Sågmaskin Westfalia
- Sågmaskin Holzmann
- Sågmaskin Fein
- Sågmaskin Oregon Scientific
- Sågmaskin Huvema
- Sågmaskin Black Decker
- Sågmaskin Elu
- Sågmaskin Blucave
- Sågmaskin Max Bahr
- Sågmaskin Plantiflor
- Sågmaskin Lux Tools
- Sågmaskin Kompernass
- Sågmaskin Goon
- Sågmaskin Triton
- Sågmaskin BGU
- Sågmaskin Avantco
- Sågmaskin Wolfcraft
- Sågmaskin Dedra
- Sågmaskin Kreg
- Sågmaskin Sthor
- Sågmaskin Verto
- Sågmaskin Vulcan
- Sågmaskin Germania
- Sågmaskin FOM
- Sågmaskin Anova
- Sågmaskin Hurricane
- Sågmaskin Budget
- Sågmaskin Ergofix
- Sågmaskin Challenge Xtreme
- Sågmaskin Global
- Sågmaskin King Craft
- Sågmaskin EGO
- Sågmaskin Maxx
- Sågmaskin Pro-Cut
- Sågmaskin Graphite
- Sågmaskin Narex
- Sågmaskin Rikon
- Sågmaskin Elektra Beckum
- Sågmaskin Duro Pro
- Sågmaskin Alpha Tools
- Sågmaskin Toolson
- Sågmaskin Felisatti
- Sågmaskin Power Smart
- Sågmaskin Backyard Pro Butcher Series
- Sågmaskin Toledo
- Sågmaskin EFA
- Sågmaskin Erbauer
- Sågmaskin Exakt
- Sågmaskin Jonsered
- Sågmaskin Gude Pro
- Sågmaskin MSW
- Sågmaskin Backyard Pro
- Sågmaskin Royal Catering
- Sågmaskin Robust
- Sågmaskin Ultranatura
- Sågmaskin FIXIT
- Sågmaskin Einhell Bavaria
- Sågmaskin Ergotools Pattfield
- Sågmaskin MyTool
- Sågmaskin McKenzie
- Sågmaskin Proviel
- Sågmaskin Morrison
- Sågmaskin Garland
- Sågmaskin Bavaria By Einhell
- Sågmaskin Prowork
- Sågmaskin Donau Elektronik
- Sågmaskin Chicago Pneumatic
- Sågmaskin Rona
- Sågmaskin Bestgreen
- Sågmaskin CMI
- Sågmaskin MacAllister
- Sågmaskin TAURUS Titanium
- Sågmaskin Maxbear
- Sågmaskin Evolution
- Sågmaskin Extralink
- Sågmaskin Yellow Garden Line
- Sågmaskin Stalco
- Sågmaskin Total
- Sågmaskin Turbo-Silent
Nyaste Sågmaskin Manualer
10 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
7 Januari 2025
7 Januari 2025
