Addendum

Addendum EN 1

Addendum FR 2

Apéndice ES 3

Adendo PT 4

Addendum NL 5

Nachtrag DE 6

Aggiunte IT 7

приложение RU 8

Ek TR 9

补遗 ZH 10

補遺 JA 11

Addendum SV 12

Liite FI 13

Tillæg DA 14

Dodatek CZ 15

Załącznik PL 16

Dodatak HR 17

Instrucţiuni suplimentare RO 18

Függelék HU 19

Tillegg NO 20

Προσάρτημα EL 21

Addendum SR 22

Dodatok k zariadeniu SK 23

Dodatek SL 24

microReel Addendum

After seating the drum into the case, use both hands to

guide the push cable into the drum . Ensure (See Figure 3)

the drum rotates in the case as the push cable rewinds.

Figure 3 – Rotate drum to properly wind the push

cable

To avoid damaging the push cable, keep one hand close to

the drum when rewinding the push cable to ensure that the

drum rotates freely .(See Figure 4)

Figure 4 – Guiding the push cable into the drum

After rewinding the push cable back into the drum, gently

thread the camera head through the push cable guide. To

avoid bending and breaking the push cable when replacing

the camera head, only pull up on the portion of the cable

that contains the spring .(See Figure 5)

Figure 5 – Routing the camera head

WARNING

If the push cable is not secured inside the

drum, the push cable can unwind itself if the

drum is removed from the case or if the case

is left open with the drum inside. If the push

cable unwinds, do not manually twist or force

the push cable back into the non-rotating

drum. The inevitable twisting and bending of the push cable

that results from forcing it into the drum without the use of

the outer case to rotate it will damage the push cable.

If the push cable has unwound from the drum, place the

drum back into the case before reinserting the push cable

(See Figure 1).

Figure 1 – Drum properly seated in casing

If space permits and if the entire drum has unspooled, uncoil

and straighten the push cable on the ground (See Figure 2).

When the push cable is not housed in the drum, the push

cable can be easily bent, kinked, and damaged. Straighten-

ing and laying the push cable out before rewinding it back

into the drum can prevent further damage.

Figure 2 – Straightening the push cable

If the push cable cannot be laid out straight, use extreme

care when rewinding the push cable. Ensure the push cable

does not bend or get caught under or on objects. If the push

cable becomes twisted or bent, stop rewinding and untwist

it before continuing.

English 1 –
