DE | Sicherheitshinweise

Laser – Die ROCCAT™ Nyth Maus verwendet einen Lasersensor der Klas-

se 1. Das Licht dieses Sensors erfüllt die Anforderungen der EN/IEC 60825-

1:2007 bezüglich der Augensicherheit. Trotzdem ist es unter bestimmten

Umständen möglich, dass direkter Kontakt des Auges mit dem Laser Seh-

schäden verursachen kann. Schaue niemals direkt in den Laserstrahl und

richte den Strahl niemals auf andere Personen oder reﬂ ektierende Oberﬂ ä-

chen wie z.B. Spiegel. Schaue niemals durch vergrößernde Geräte wie Lu-

pen, Mikroskope oder ähnliche Geräte in den Laserstrahl.

EN | Safet y Instructions

Laser – The ROCCAT™ mouse uses a Class 1 laser sensor. The light Nyth

emitted by this sensor meets EN/IEC 60825-1:2007 requirements with re-

gard to eye safety. Despite this, under certain circumstances pointing the

laser directly at the eyes may cause blindness. Never look directly at the

laser beam and never point it at other people or reﬂ ective objects such as

mirrors, for instance. Never look at the laser beam with magnifying devices

such as magnifying glasses, microscopes or similar devices.

ES | Medidas de seguridad

Láser – El ratón ROCCAT™ utiliza un sensor láser clase 1. La luz de este Nyth

sensor cumple los requisitos de la norma EN/IEC 60825-1:2007 en lo referen-

te a seguridad ocular. Aun así, dadas ciertas circunstancias, el contacto direc-

to de la vista con el láser puede ser causa de daños oculares. No mires nunca

directamente en el rayo láser, ni lo dirijas tampoco nunca hacia otras personas

o superﬁ cies que lo reﬂ ejen, p. ej. espejos. No mires tampoco el láser a través

de aparatos de aumento como lupas y microscopios o similares.

JP | 安全指示

Laser – The ROCCAT™ Nyth マウスはクラス1のレーザーセンサー

を使用しています。このセンサーが放出する光は、目の安全に関

するEN/IEC 60825-1:2007要件を満たしています。これにも関わら

ず、目に直接レーザーが当たる特定の環境下では失明を引き起

こすこともあります。レーザービームを直接のぞき込んだり、人

や鏡などの反射物体にレーザーを当てたりすることとは絶対に

おやめください。拡大鏡、顕微鏡など拡大装置でレーザービーム

を絶対に見ないでください。

KO | 안전 지침

레이저 – ROCCAT™ Nyth 마우스는 클래스 1 레이저 센서를

사용합니다. 이 센서에서 방출되는 빛은 시력 보호에 대한

EN/IEC 60825-1:2007 요구 사항을 충족합니다. 그럼에도 불구하고

특정 환경에서 레이저를 눈에 직접 비추면 실명할 수 있습

니다.

레이저 광선을 직접 쳐다보지 말고 다른 사람이나 예를 들어

거울과 같은 반사체에 레이저 광선을 비추지 마십시오.

돋보기, 현미경이나 이와 유사한 장치와 같은 확대 장치를

가지고 레이저 광선을 쳐다보지 마십시오.

RU | Указания по безопасности

Лазер – В мышке ROCCAT™ Nyth используется лазерный датчик класса

1. Свет этого датчика отвечает требованиям EN/IEC 60825-1:2007 отно-

сительно безопасности глаз. Несмотря на это при определенных обсто-

ятельствах прямой контакт глаза с лазером может привести к ущербу

для зрения. Никогда не смотрите прямо на луч лазера и никогда не на-

правляйте луч на других людей или отражающие поверхности, напри-

мер, зеркала. Никогда не смотрите на луч лазера через увеличивающие

приспособления, такие как лупы, микроскопы и похожие приборы.

SC | 安全说明

激光 – ROCCAT™ Nyth 鼠标使用 Class 1（1 类）激光传感器。此传

感器发射的激光符合在眼睛安全方面的要EN/IEC 60825-1:2007

求。尽管如此，在有些情况下，激光直射眼睛可能会造成失明。因

此，切勿直视激光束，严禁将激光指向他人或反射物体，如镜

子。切勿通过放大设备，如放大镜、显微镜或类似设备，

观看激光束。

TC |

注意事項

雷射– ROCCAT™ Nyth 滑鼠採用雷射感應器。此感應器發Class 1

出的光線符合 EN/IEC 60825-1:2007 的眼睛安全防護規定。然而在

特定情況下，將雷射直接對準眼睛仍有可能會造成失明的危

險。切勿直視雷射光線，或將雷射光線指向他人或鏡子等反射

物體；切勿用放大鏡、顯微鏡等放大裝置觀看雷射光線。

TH | ขั้นตอนเพื่อความปลอดภัย

เลเซอร์ – เมาส์ ROCCAT™ Nyth 1 ใช้เซนเซอร์เลเซอร์คลาส . แสงที่

ปล่อยออกมาโดยเซนเซอร์นี้สอดคล้องกับข้อกําหนด EN/IEC 60825-

1:2007 ในด้านความปลอดภัยต่อดวงตา ถึงแม้ว่าจะมีความสอดคล้อง แต่

ในบางสถานการณ์ การชี้เลเซอร์เข้าไปที่ดวงตาโดยตรงอาจทําให้เกิดการ

ตาบอด ห้ามมองเข้าไปที่ลําแสงเลเซอร์โดยตรง และห้ามชี้ลําแสงไปที่

บุคคลอื่น หรือวัตถุที่มีการสะท้อนได้ เช่น กระจกเงา ห้ามมองที่ลําแสง

เลเซอร์ด้วยอุปกรณ์การขยายต่างๆ เช่น แว่นขยาย กล้องจุลทรรศน์ หรือ

อุปกรณ์ที่มีลักษณะเดียวกัน

VN |

Hướng dẫn an toàn

Laser – Chuột

ROCCAT™ Nyth

sử dụng bộ cảm biến laser Nhóm 1. Đèn

bật sáng qua bộ cảm biến đã đáp ứng các quy định

EN/IEC 60825-1:2007

về an toàn cho mắt. Mặc dù vậy, trong một số trường hợp nhất định, chĩa

thẳng tia laser vào mắt có thể gây mù mắt. Đừng bao giờ nhìn thẳng vào

tia laser cũng như không chĩa tia laser vào người khác hay vào các vật

phản chiếu như gương chẳng hạn. Đừng bao giờ nhìn tia laser bằng các

thiết bị phóng đại như kính lúp, kính hiển vi hay các thiết bị tương tự.

Complies with FDA performance standards for laser products except

for deviations pursuant t o Laser Notice No. 50, dated June 24, 2007.

QUICK-INSTALL ATION GUIDE

IMPOR TA NT DOCUMENT

or registered trademarks and are the property of their respective owners. Information contained herein is

subject to change without notice. ROCCAT GmbH shall not be made liable for any errors that may appear in this

manual. This publication or parts of it may not be repr oduced without the express consent of the publisher.

ROCCAT GmbH

Otto von Bahrenpark, Paul-Dessau-Str. 3G, 22761 Hamburg, Germany

T36145MSIP-REM-ROA-NYTH

PLEASE USE YOUR PRODUCT’S SERIAL NUMBER

(LOCATED ON THE BOTTOM LABEL

) FOR

REGISTRATION. SIGN IN AT:

WWW.ROCCAT.ORG/SUPPORT/AUT HENTICIT Y-CHECK

S U P P O R T

3D PRINT

Should you need assistance …

Our suppor t team is ready to help with any technical questions.

Just send an e-mail to support@roccat.org. Or visit our website at:

WWW.ROCCAT.ORG/SUPPORT

SPECIFICATIONS

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are

entitled to a replacement or refund for a major failure and for compensation for any other reasonably

foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods

fail to be of acceptable quality and the failure does not amount to a major failure.

PACKAGE CONTAINS

ROCCAT™ Nyth BLK –

Modular MMO Gaming Mouse

Quick-Installation Guide

Accessory Carry Case

2 Sidegrips; 33 Buttons

ROCCAT™ Sticker

SYSTEM REQUIREMENTS

Windows® 7 32/64 bit

Windows® 8

Windows® 10

USB 2.0 port

Internet connection

(for driver installation)

TECH SPECS

Twin-Tech Laser Sensor R1

with up to 12000dpi

1000Hz polling rate

1ms response time

50G acceleration

3.8m/s (150ips) single axis

5.4m/s (212ips) both axes

16-bit data channel

Adjustable lift-off distance

(200 - 1000µm)

Adjustable click accuracy to mitigate

against miniscule movments

Tracking & Distance Control Unit

72MHz Turbo Core V2

32-bit ARM based MCU

576kB onboard memory

Zero angle snapping/predicton

1.8m Braided USB cable

CONGRATULATIONS!

You are now the proud owner of a ROCCAT™ Nyth! The Nyth is a truly evolutionary mouse with a unique design that arms

you with a powerful weapon for the games of today and tomorrow. With its boundless customization options, the Nyth can

seamlessly transition from genre to genre and gaming style to gaming style.

Enjoy it, and get out there and win!

MODULAR

THUMB ZONE

The modular thumb zone on the Nyth is a unique

button area completely adaptable to your style.

Flexible and interchanable, it allows you to individually

place up to 12 tactile mechanical buttons to suit

the game you’re playing the way you play it.

ERGONOMIC

SIDEGRIPS

The Nyth’s hotswappable sidegrips cater both

to gamers who play with an aggressive claw grip

and gamers who favor a more relaxed palm grip.

The ergonomic grips can be changed quickly and

easily, and are kept securely in place by magnets.

ROCCAT TM

SWARM

Swarm is ROCCAT’s integrated driver system

that brings your hardware to the next level. It’ll

cover you for all relevant gaming platforms and

devices, it’s your go-to place for control over all

your ROCCAT products as well as games and apps.

1. ROCCAT™ 의 USB 커넥터를 비어 있는 Nyth USB

포트에 연결하십시오.

2. 컴퓨터를 부팅하여 인터넷에 연결하십시오.

3. 웹사이트 www.roccat.org/roccat-swarm으로 가서

최신 버전을 다운로드하십시오.Swarm

4. 소프트웨어 설치 과정을 시작하고 화면상 지침을 따르십시오.

1. Cắm đầu cắm USB của chuột ROCCAT™ Nyth vào

bất cứ cổng USB nào trống trên máy tính.

2. Khởi động máy và kết nối internet.

3. Truy cập và tải về www.roccat.org/roccat-swarm

phiên bản Swarm mới nhất.

4. Khởi động quá trình cài đặt phần mềm và thực hiện

theo các hướng dẫn trên màn hình.

HƯỚNG DẪN

지시사항

1. Verbinde deine ROCCAT™ Nyth mit einem freien

USB Steckplatz deines Computers.

2. Starte deinen Computer neu und stelle eine

Verbindung zum Internet her.

3. Rufe www.roccat.org/roccat-swarm auf und lade

dir die neuste Swarm Version herunter.

4. Starte die Software Installation und folge den

Anweisungen.

ANLEITUNG

1. Вставьте USB-коннектор ROCCAT™ Nyth

в любой свободный USB-порт.

2. Включите компьютер и выйдите в Интернет.

3. Зайдите на www.roccat.org/roccat-swarm и

загрузите самую новую версию Swarm.

4. Начните процесс установки программного

обеспечения и следуйте указаниям на экране.

ИНСТРУКЦИИ

1. Plug the USB connector on your ROCCAT™ Nyth

into any free USB port.

2. Boot your computer and connect to the internet.

3. Navigate to www.roccat.org/roccat-swarm and

download the latest version of Swarm.

4. Start the software installation process and follow

the on-screen instructions.

INSTRUCTIONS

1. 将ROCCAT™ Nyth上的USB接头插入任意空闲的USB端口。

2. 启动计算机并连接网络。

3. 访问，下载最新版本 www.roccat.org/roccat-swarm

的Swarm。

4. 启动软件安装过程，按照屏幕上的说明操作。

说明

1. Enchufe el conector USB en un puerto USB libre

del ROCCAT™ Nyth.

2. Reinicie el ordenador y conéctese a internet.

3. Acceda a la página www.roccat.org/roccat-swarm

y descárguese la última versión swarm.

4. Inicie el proceso de instalación de software y siga las

instrucciones de la pantalla.

INSTRUCCIONES

1. 將上的 USB 連接器插入任何可用的 ROCCAT™ Nyth

USB 連接埠。

2. 開啟電腦並連接至網際網路。

3. 前往 www.roccat.org/roccat-swarm 並下載最新版本

的。Swarm

4. 開始軟體安裝程序，然後依畫面說明操作。

使用說明

1. 空きUSBポートにお使いのROCCAT™ Nyth上のUSB

 コネクタを差し込みます。

2. コンピュータを起動し、インターネットに接続します。

3. www.roccat.org/roccat-swarmにナビゲート 

 し、Swarmの最新バージョンをダウンロードします。

4. ソフトウェアインストール処理を開始し、画面上の指示に 

 従います。

使用説明

1. เสียบขั้วต่อ USB บน ROCCAT ™ Nyth ของคุณเข้ากับพอร์ต

USB ใดๆ ที่ว่าง

2. บูทเครื่องคอมพิวเตอร์ของคุณแล้วเชื่อมต่อกับอินเทอร์เน็ต

3. นําทางไปที่ www.roccat.org/roccat-swarm

และดาวน์โหลด Swarm เวอร์ชันล่าสุด

4. เริ่มต้นกระบวนการติดตั้งซอฟต์แวร์และปฏิบัติตามคําแนะนํา

บนหน้าจอ

คําแนะนํา

ERGONOMIC SIDEGRIPS

Attach grip by lining up screws with relevant holes

Remove grip by pulling away from mouse

BUTTON PLACEMENT

Take care to insert buttons correctly

Double buttons cannot be placed in the middle

BUILD YOUR VICTORY

RELEASE SWITCH

Slide and hold switch on underside of mouse to release thumb buttons

Buttons can be removed one by one or all together

1 = Left mouse button

2= Right mouse button

3= Universal scroll

4 = Scroll down

5= Scroll up

6= Easy-Shift[+]™ button

7 = Tilt left

8= Tilt right

9= 1

10 = 2

11 = 3

12 = 4

13 = 5

14 = 6

15 = 7

16 = 8

17 = 9

18 = 10

19 = 11

20 = 12

6 + 1 = Disabled

6 + 2 = Disabled

6 + 3 = Mute

6 + 4 = Volume down

6 + 5 = Volume up

6 + 6 = Disabled

6 + 7 = End

6 + 8 = Pos1

6 + 9 = Right shift + 1

6 + 10 = Right shift + 2

6 + 11 = Right shift + 3

6 + 12 = Right shift + 4

6 + 13 = Right shift + 5

6 + 14 = Right shift + 6

6 + 15 = Right shift + 7

6 + 16 = Right shift + 8

6 + 17 = Right shift + 9

6 + 18 = Right shift + 10

6 + 19 = Right shift + 11

6 + 20 = Right shift + 12

9-20

(no driver installed)

DEFAULT BUTTON ASSIGNMENT

(no driver installed)

DEFAULT BUTTON ASSIGNMENT: EASY-SHIFT[+]™

Produktspecifikationer

Varumärke:	Roccat
Kategori:	gå
Modell:	Nyth
Färg på produkten:	Black, White
Bredd:	700 mm
Djup:	700 mm
Förpackningens vikt:	17499 g
Förpackningens bredd:	795 mm
Djuppackning:	1290 mm
Förpackningshöjd:	153 mm
Höjd (max):	1900 mm
Justerbar i höjdled:	Ja
Monteringsmetod:	Vrijstaand
Modell:	Portret
Rammaterial:	Aluminium
Rep tålig:	Ja
Linjal:	Ja
Frame:	Ja
Magnetisk:	Ja
Installatietype:	Draagbaar
Oppervlaktekleur:	Staal
Pennfack ingår:	Ja
Justerbara krokar:	Ja
