Rockford Fosgate M1D2-8B Bruksanvisning

Rockford Fosgate Subwoofer M1D2-8B

Läs nedan 📖 manual på svenska för Rockford Fosgate M1D2-8B (32 sidor) i kategorin Subwoofer. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/32
M1D2-8
M1D2-8B
M1D4-8
M1D4-8B
M1D2-10
M1D2-10B
M1D4-10
M1D4-10B
M1D2-12
M1D2-12B
M1D4-12
M1D4-12B
Installation & Operation
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
rockfordfosgate.com
02262020 1230-730797-01-D Printed In China
Installation assistance available at:
ELEMENT READY™ SUBWOOFERS
2
Introduction
©2019 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE, PUNCH® and associated logos where applicable are registered trademarks
of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications
subject to change without notice.
2 Introduction
3-4 Specifications
5-6 Enclosures
7-9 Wiring
10-29 Additional Languages
French
Spanish
German
Italian
32 Limited Warranty Information
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered auto sound systems
may produce sound pressure levels well over 130dB. Use common
sense and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique
upérieurs à 100 dB peut causer une perte d’acuité auditive
permanente. Les systèmes audio de forte puissance pour auto
peuvent produire des niveaux de pression acoustique bien au-delà
de 130 dB. Faites preuve de bon sens et pratiquez une écoute sans
risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores
a 100 dB puede causar la pérdida permanente de la audición. Los
sistemas de sonido de alta potencia para automóviles pueden
producir niveles de presión de sonido superiores a los 130 dB. Aplique
el sentido común y practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit
über 130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an
und praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica
ben superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle
regole del suono senza pericoli
Dear Customer,
Congratulations on your purchase of the world’s finest brand of
audio products. At Rockford Fosgate we are fanatics about musical
reproduction at its best, and we are pleased you chose our product.
Through years of engineering expertise, hand crasmanship and
critical testing procedures, we have created a wide range of products
that reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new
Rockford Fosgate product installed by an Authorized Rockford Fosgate
Dealer. Please read your warranty and retain your receipt and original
carton for possible future use.
Great product and competent installations are only a piece of the
puzzle when it comes to your system. Make sure that your installer is
using 100% authentic installation accessories from Rockford Fosgate in
your installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! Aer
all, your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image, order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all
other countries, call +001-480-967-3565 or FAX +001-480-966-
3983.
Table of Content
If, aer reading your manual, you still have questions regarding
this product, we recommend that you see your Rockford Fosgate
dealer. If you need further assistance, you can call us direct at
1-800-669-9899. Be sure to have your serial number, model
number and date of purchase available when you call.
Safety
This symbol with “WARNING” is
intended to alert the user to the
presence of important instructions.
Failure to heed the instructions could
result in severe injury or death.
This symbol with “CAUTION” is
intended to alert the user to the
presence of important instructions.
Failure to heed the instructions could
result in injury or unit damage.
• To prevent injury and damage to the unit, please read and
follow the instructions in this manual.
• If you feel unsure about installing this system yourself, have
it installed by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-)
terminal to prevent damage to the unit, fire and/or possible
injury.
3
Specifications
* All measurements taken with voice coils wired in series
Model M1D2-8/B
M1D4-8/B
M1D2-10/B
M1D4-10/B
M1D2-12/B
M1D4-12/B
Nominal Size 8”
(203.2mm)
10”
(254mm)
12”
(304.8mm)
Description Subwoofer Subwoofer Subwoofer
Nominal Impedance (Ohms) 2 or 4 Ω DVC 2 or 4 Ω DVC 2 or 4 Ω DVC
Frequency Response (Hz)* 28-750 28-750 28-750
Voice Coil Diameter - inch (mm) 1.5” (4-Layer)
(38.6mm)
1.95” (4-Layer)
(49.5mm)
1.95” (4-Layer)
(49.5mm)
Power Handling - Watts (RMS/Peak) 150/600 300/1200 300/1200
Fs - Free Air Resonance (Hz) 44.5 34 26
Qts 0.9 0.44 0.53
Vas - cu. . (Liter) 0.553
(15.7L)
1.563
(44.2L
4.03³
(114.2L)
Displacment -cu. fl.
(Liter)
0.053
(1.41L)
0.13
(2.8L)
0.123
(3.49L)
Sensitivity (2.83V/1M) 87.5dB 91.5dB 92dB
Xmax - inch (mm) 0.28”
(7mm)
0.28”
(7mm)
0.28”
(7mm)
Grille/Trim Ring YES YES YES
LED Current Draw 0.25 Amps 0.25 Amps 0.25 Amps
Recommended Fused Rating For
LED’s (not included) 1 Amp 1 Amp 1 Amp
LED Voltage Range 9-16 Volts 9-16 Volts 9-16 Volts
*Rockford Fosgate determines its rated frequency response range at -6 dB below its nominal sensitivity at upper and lower extents of a
speaker’s output.
VERIFIED WITH KLIPPEL
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be trained
and certified by Klippel prior to using the three separate Klippel systems to design, develop and test. Rockford Fosgate
has made the investment in Klippel to deliver the best possible speakers and subwoofers to their customers.

Produktspecifikationer

Varumärke: Rockford Fosgate
Kategori: Subwoofer
Modell: M1D2-8B
