AMPLIFIERS
Installation & Operation
R2-200X2
R2-300X4
R2-500X4
R2-750X5
R2-250X1
R2-500X1
R2-750X1
R2-1200X1
Installation assistance available at:
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
rockfordfosgate.com
010820 1230-72210-02-C Printed In China
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of
audio products. At Rockford Fosgate we are fanatics about musical
reproduction at its best, and we are pleased you chose our product.
Through years of engineering expertise, hand crasmanship and
critical testing procedures, we have created a wide range of products
that reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new
Rockford Fosgate product installed by an Authorized Rockford Fosgate
Dealer. Please read your warranty and retain your receipt and original
carton for possible future use.
Great product and competent installations are only a piece of the
puzzle when it comes to your system. Make sure that your installer is
using 100% authentic installation accessories from Rockford Fosgate in
your installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! Aer
all, your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com or, in the U.S. call 1-800-669-9899 or FAX
1-800-398-3985. For all other countries, call +001-480-967-3565 or FAX
+001-480-966-3983.
Table of Contents
If, aer reading your manual, you still have questions regarding this
product, we recommend that you see your Rockford Fosgate dealer.
If you need further assistance, you can call us direct at 1-800-669-
9899. Be sure to have your serial number, model number and date of
purchase available when you call.
Safety
This symbol with “WARNING” is
intended to alert the user to the
presence of important instructions.
Failure to heed the instructions could
result in severe injury or death.
This symbol with “CAUTION” is
intended to alert the user to the
presence of important instructions.
Failure to heed the instructions could
result in injury or unit damage.
To prevent injury and damage to the unit, please read and follow the
instructions in this manual.
If you feel unsure about installing this system yourself, have it installed
by a qualified Rockford Fosgate technician.
Before installation, disconnect the battery negative (-) terminal to
prevent damage to the unit, fire and/or possible injury.
Introduction
©2019 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered trademarks
of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.
Specifications subject to change without notice.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered auto sound systems
may produce sound pressure levels well over 130dB. Use common
sense and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique
upérieurs à 100 dB peut causer une perte d’acuité auditive
permanente. Les systèmes audio de forte puissance pour auto peuvent
produire des niveaux de pression acoustique bien au-delà de 130 dB.
Faites preuve de bon sens et pratiquez une écoute sans risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores
a 100 dB puede causar la pérdida permanente de la audición. Los
sistemas de sonido de alta potencia para automóviles pueden
producir niveles de presión de sonido superiores a los 130 dB. Aplique
el sentido común y practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit
über 130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an
und praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica
ben superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle
regole del suono senza pericoli
2 Introduction
3-4 Specifications
5-7 Design Features
8-10 Installation
Installation Considerations
Mounting Locations
Battery and Charging
Wiring the System
11 Operation
Adjusting Crossover Frequency
Input Switch
C.L.E.A.N.
Punch EQ
Remote Punch Level Control
12 Troubleshooting
13-44 Additional Languages
French
Spanish
German
Italian
48 Limited Warranty Information
3
Specifications
CEA 2006
Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry
standards. These guidelines mean your amplifier’s output power ratings are
REAL POWER numbers, not inflated marketing ratings.
Mode R2-200X2 R2-300X4 R2-500X4 R2-750X5 R2-250X1 R2-500X1 R2-750X1 R2-1200X1
Rated Power -
Continuous
Power Rating
(RMS) Measured
@ 14.4V
50x2 @ 4 ohms
100x2 @ 2 ohms
200x1 @ 4 ohms*
50x4 @ 4 ohms
75x4 @ 2 ohms
150x2 @ 4 ohms*
75x4 @ 4 ohms
125x4 @ 2 ohms
250x2 @ 4 ohms*
50x4 @ 4 ohms
100x4 @ 2 ohms
200x2 @ 4 ohms*
Sub: 200x1 @ 4 ohms
Sub: 350x1 @ 2 ohms
150x1 @ 4 ohms
250x1 @ 2 ohms
300x1 @ 4 ohms
500x1 @ 2 ohms
250x1 @ 4 ohms
500x1 @ 2 ohms
750x1 @ 1 ohm
400x1 @ 4 ohms
800x1 @ 2 ohms
1200x1 @ 1 ohm
Crossover
Slope
12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct
Crossover
Frequency
Variable 50Hz-250Hz
LP/AP/HP
Variable 50Hz-250Hz
LP/AP/HP
Variable 50Hz-250Hz
LP/AP/HP
Variable 50Hz-250Hz
LP/AP/HP
IF: 15Hz-40Hz
Variable LP 50Hz-
250Hz
IF: 15Hz-40Hz
Variable LP 50Hz-
250Hz
IF: 15Hz-40Hz
Variable LP 50Hz-
250Hz
IF: 15Hz-40Hz
Variable LP
50Hz-250Hz
IF: 15Hz-40Hz
Punch EQ N/A N/A N/A Mono Channel Only
Variable 0 -+18dB
@ 45Hz
Variable 0 -+18dB
@ 45Hz
Variable 0 -+18dB
@ 45Hz
Variable 0 -+18dB
@ 45Hz
Variable 0 -+18dB
@ 45Hz
Operating
Voltage
9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC
Frequency
Response
20Hz-20kHz 20Hz-20kHz 20Hz-20kHz F/R: 20Hz-20kHz
Sub: 20Hz-250Hz
20Hz-250Hz 20Hz-250Hz 20Hz-250Hz 20Hz-250Hz
Battery Fuse
Rating (not
supplied)
30A 60A 80A 120A 50A 80A 120A 200A
Input
Sensitivity
150mV-4V Low Level
450mV-12V High
Level
150mV-4V Low Level
450mV-12V High
Level
150mV-4V Low Level
450mV-12V High
Level
150mV-4V Low Level
450mV-12V High
Level
150mV-4V Low
Level
450mV-12V High
Level
150mV-4V Low
Level
450mV-12V High
Level
150mV-4V Low
Level
450mV-12V High
Level
150mV-4V Low
Level
450mV-12V High
Level
S/N Ratio CEA
2006
>80dB >70dB >80dB F/R: > 80dB
Sub: >75dB
>80dB >75dB >70dB >75dB
Overall
Length(See Pg 4)
7.3”
186mm
7.3”
186mm
7.3”
186mm
7.3”
186mm
7.3”
186mm
7.3”
186mm
7.3”
186mm
7.3”
186mm
Length (See Pg 4) 6.8”
173mm
6.8”
173mm
6.8”
173mm
6.8”
173mm
6.8”
173mm
6.8”
173mm
6.8”
173mm
6.8”
173mm
Width 8.0” (See Pg 4)
205mm
10.0”
255mm
10.0”
255mm
11.2”
285mm
8.0”
205mm
8.4”
215mm
10.0”
255mm
11.2”
285mm
Height 1.9” (See Pg 4)
49mm
1.9”
49mm
1.9”
49mm
1.9”
49mm
1.9”
49mm
1.9”
49mm
1.9”
49mm
1.9”
49mm
* Rated power when amplifier is wired in a bridged configuration.
