Installation & Operation
P300-8P
P300-10
P300-10T
P300-12
P300-12T
P500-12P
POWERED ENCLOSURE
Serial Number:
Date of Purchase:
R O C K F O R D F O S G AT E . C O M
600 South Rockford Drive • Tempe, Arizona 85281
United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
Installation assistance available at:
www.rockfordfosgate.com/rech
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of car
audio amplifiers. At Rockford Fosgate we are fanatics about musical
reproduction at its best, and we are pleased you chose our product.
Through years of engineering expertise, hand crasmanship
and critical testing procedures, we have created a wide range of
products that reproduce music with all the clarity and richness you
deserve.
For maximum performance we recommend you have your new
Rockford Fosgate product installed by an Authorized Rockford Fosgate
Dealer, as we provide specialized training through Rockford Technical
Training Institute (RTTI). Please read your warranty and retain your
receipt and original carton for possible future use.
Great product and competent installations are only a piece of the
puzzle when it comes to your system. Make sure that your installer is
using 100% authentic installation accessories from Rockford Fosgate in
your installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! Aer all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
jackets.
Visit our web site for the latest information on all
Rockford products; www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all
other countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Content
If, after reading your manual, you still have questions regarding
this product, we recommend that you see your Rockford
Fosgate dealer. If you need further assistance, you can call us
direct at . Be sure to have your serial number, 1-800-669-9899
model number and date of purchase available when you call.
Safety
This symbol with “WARNING” is intended to alert the
user to the presence of important
instructions. Failure to heed the
instructions will result in severe injury
or death.
This symbol with “CAUTION” is
intended to alert the user to the
presence of important instructions.
Failure to heed the instructions can
result in injury or unit damage.
• To prevent injury and damage to the unit, please read
and follow the instructions in this manual. We want you to
enjoy this system, not get a headache.
• If you feel unsure about installing this system yourself, have
it installed by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-)
terminal to prevent damage to the unit, fire and/or possible
injury.
Introduction
©2012 Rockford Corporation. All Rights Reversed. ROCKFORD FOSGATE and associated logos where applicable are registered
trademarks of Rockford Corporation in the United States and/or other
countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique upérieurs à
100 dB peut causer une perte d’acuité auditive permanente. Les systèmes
audio de forte puissance pour auto peuvent produire des niveaux de
pression acoustique bien au-delà de 130 dB. Faites preuve de bon sens et
pratiquez une écoute sans risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores a 100
dB puede causar la pérdida permanente de la audición. Los sistemas de
sonido de alta potencia para automóviles pueden producir niveles de
presión de sonido superiores a los 130 dB. Aplique el sentido común y
practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit über
130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an und
praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica ben
superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle regole
del suono senza pericoli
2 Introduction
3-5 Specifications
6 Design Features
7-8 Installation
Installation Considerations
Battery and Charging
Wiring the System
9 Operation
Adjusting Gain / Crossover
Phase Switch
Input Level
Auto Turn-on
Punch Bass / Remote Punch Level
10-21 Additional Languages
French
Spanish
German
Italian
22 Limited Warranty Information
3
Specifications
Model P300-10 P300-12 P300-8P
Description 10” Powered Subwoofer 12” Powered Subwoofer 8” Powered Subwoofer
Power Rating
(RMS/Peak) 300W / 600W 300W / 600W 300W / 600W
Crossover Slope 12dB/Oct 12dB/Oct 12dB/Oct
Crossover
Frequency
Variable 50Hz-200Hz Variable 50Hz-200Hz Variable 50Hz-200Hz
Punch Bass Variable 0 - +12dB @ 45Hz Variable 0 - +12dB @ 45Hz Variable 0 - +12dB @ 45Hz
Frequency
Response
35Hz - 200Hz 35Hz - 200Hz 35Hz - 200Hz
Input Sensitivity 100mV - 3V 100mV - 3V 100mV - 3V
Fuse Rating 20A (2 X 10A) 20A (2 X 10A) 20A (2 X 10A)
Overall
Dimensions
(HxWxD)
13.3” x 18.0” x 8.9”/5.9”
(33.7cm x 45.7cm x
22.6/15cm)
15.0” x 19.8” x 11.0”/7.0”
(38.1cm x 50.3cm x
28/17.8cm)
11.38” x 17.6” x 4.84”/3.69”
(28.9cm x 44.8cm x
14.1/9.36cm)
See illus.-1.1 for additional dimensions
CEA 2006
Power ratings on Rockford Fosgate amplifiers conform
to CEA-2006 industry standards. These guidelines
mean your amplifier’s output power ratings are REAL
POWER numbers, not inflated marketing ratings.
CEA 2031
Power handling on Rockford Fosgate speakers
conform to CEA-2031 industry standards. This means
your speaker has the capacity to handle power under
continuous demand, not instantaneous power handling,
that over time can damage voice coils.
Model P300-10T P300-12T P500-12P
Description 10” Powered Subwoofer 12” Powered Subwoofer 12” Powered Subwoofer
Power Rating
(RMS/Peak) 300W / 600W 300W / 600W 500W / 1000W
Crossover Slope 12dB/Oct 12dB/Oct 12dB/Oct
Crossover Frequency Variable 50Hz-200Hz Variable 50Hz-200Hz Variable 50Hz-200Hz
Punch Bass Variable 0 - +12dB @ 45Hz Variable 0 - +12dB @ 45Hz Variable 0 - +12dB @ 45Hz
Frequency Response 35Hz - 200Hz 35Hz - 200Hz 20Hz - 200Hz
Input Sensitivity 100mV - 3V 100mV - 3V 130mV - 5V
Fuse Rating 20A (2 X 10A) 20A (2 X 10A) 30A (2 X 15A)
Overall Dimensions
(HxWxD)
13.31” x 21.73” x
11.0”/7.0”
(33.8cm x 55.2cm x
20.1/12.2cm)
14.96” x 25.83.” x
8.46”/4.8”
(38cm x 65.6cm x
21.5/12.2cm)
12.88” x 24.76.” x
”10.91/7.71”
(32.7cm x 62.9cm x
27.7/189.2cm)
See illus.-1.1 for additional dimensions
