Sida 1/20
Installation & Operation
AMPLIFIERS
TM400X2ad TM400X4ad TM500X1br• •
TM750X1bd TM1000X5ad•
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of car
audio products. At Rockford Fosgate we are fanatics about musical
reproduction at its best, and we are pleased you chose our product.
Through years of engineering expertise, hand craftsmanship and criti-
cal testing procedures, we have created a wide range of products that
reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new
Rockford Fosgate product installed by an Authorized Rockford Fosgate
Dealer, as we provide specialized training through Rockford Technical
Training Institute (RTTI). Please read your warranty and retain your
receipt and original carton for possible future use.
Great product and competent installations are only a piece of the
puzzle when it comes to your system. Make sure that your installer is
using 100% authentic installation accessories from Rockford Fosgate
in your installation. Rockford Fosgate has everything from RCA cables
and speaker wire to power wire and battery connectors. Insist on it!
After all, your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
jackets.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Content
If, after reading your manual, you still have questions regarding this prod-
uct, we recommend that you see your Rockford Fosgate dealer. If you need
further assistance, you can call us direct at . Be sure to 1-800-669-9899
have your serial number, model number and date of purchase available
when you call.
Safety
This symbol with “WARNING” is intended
to alert the user to the presence of important
instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with “CAUTION” is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
can result in injury or unit damage.
• To prevent injury and damage to the unit, please read and follow the
instructions in this manual. We want you to enjoy this system, not get
a headache.
• If you feel unsure about installing this system yourself, have it installed
by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-) terminal to
prevent damage to the unit, fire and/or possible injury.
Introduction
©2014 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered trademarks of Rockford Corporation
in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
2 Introduction
3 Specifications
4-5 Design Features
6-13 Installation
Installation Considerations
Mounting Locations
Battery and Charging
Wiring the System
14-15 Operation
Clip Indicator Setup
Adjusting Crossover Frequency
2/4 Channel Switch
Punch EQ
16 Troubleshooting
17 Limited Warranty Information
3
Specications
CEA 2006
Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines
mean your amplifier’s output power ratings are REAL POWER numbers, not inflated marketing ratings.
Mode TM400X2ad TM400X4ad TM500X1br TM750X1bd TM1000X5ad
Rated Power -
Continuous Power
Rating (RMS) Mea-
sured @ 14.4V
200x2 @ 4 ohm
200x2 @ 2 ohm
400x1 @ 4 ohm*
100x4 @ 4 ohm
100x4 @ 2 ohm
200x2 @ 4 ohm*
175x1 @ 4 ohm
300x1 @ 2 ohm
500x1 @ 1 ohm
500x1 @ 4 ohm
750x1 @ 2 ohm
750x1 @ 1 ohm
100x4 @ 4 ohm
100x4 @ 2 ohm
200x2 @ 4 ohm
Sub:
400x1 @ 4 ohm
600x1 @ 2 ohm
600x1 @ 1 ohm
Crossover Slope 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct
Crossover Frequency Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz
Sub: 28Hz
Punch EQ Variable 0 -+14dB @
12.5kHz and 0-+18dB
@ 45Hz
Variable 0 -+14dB @
12.5kHz and 0-+18dB
@ 45Hz
Variable 0-+18dB @
45Hz
Variable 0-+18dB @
45Hz
Variable 0-+14dB @
45Hz and 0-+18dB @
45Hz and
Operating Voltage 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC
Frequency Response 20Hz-20kHz 20Hz-20kHz 20Hz-250Hz 20Hz-230Hz 20Hz-20kHz
Battery Fuse Rating
(not supplied)
60A 60A 60A 100A 100A
THD+N @ Rated
Power
<1.0% @ 4 ohm
<1.0% @ 2 ohm
<1.0% @ 4 ohm
<1.0% @ 2 ohm
<1.0% @ 4 ohm
<1.0% @ 2 ohm
<1.0% @ 1 ohm
<1.0% @ 4 ohm
<1.0% @ 2 ohm
<1.0% @ 1 ohm
F/R:
<1.0% @ 4 ohm
<1.0% @ 2 ohm
Sub:
<1.0% @ 4 ohm
<1.0% @ 2 ohm
<1.0% @ 1 ohm
Input Sensitivity 150mV-12V 150mV-12V 150mV-12V 150mV-12V 150mV-12V
Input Impedance 20k 20k 20k 20k 20k
S/N Ratio CEA 2006 >90dB >90dB >90dB >80dB F/R: >80dB
Sub: >75dB
S/N Ratio @ Rated
Power
>110dB >110dB >110dB >105dB F/R: >100dB
Sub: >95dB
Channel Separation >60dB >60dB N/A N/A >50dB
Common Mode
Rejection Ratio
>60dB >60dB >60dB >70dB >55dB
Dimensions (LxWxH) 7” x 4.3” x 1.6”
(17.8cm x 10.8cm x 4.1 cm)
8.3” x 4.3” x 1.6”
(21.1cm x 10.8cm x 4.1 cm)
8.3” x 4.3” x
1.6”
(21.1cm x 10.8cm x 4.1 cm)
8.3” x 4.3” x
1.6”
(21.1cm x 10.8cm x 4.1 cm)
12” x 4.3” x 1.6”
(30.5cm x 10.8cm x 4.1 cm)
* Rated power when amplifier is wired in a bridged configuration.
