Installation & Operation

RFX3-K4 • RFX3-K8

CAN-AM A 3® M VERICK X

AMPLIFIER

IN ALST LA TTION KI

R O F O F O S G A T C O MC K R D E .

600 South Rockford Drive • Tempe, Arizona 85281 United States

Direct: (480) 967-3565 • Toll Free: (800) 669-9899

Installation assistance available at:

Dear Customer,

Congratulations on your purchase of the world’s finest brand of

audio products. At Rockford Fosgate we are fanatics about musical

reproduction at its best, and we are pleased you chose our product.

Through years of engineering expertise, hand crasmanship and critical

testing procedures, we have created a wide range of products that

reproduce music with all the clarity and richness you deserve.

For maximum performance we recommend you have your new

Rockford Fosgate product installed by an Authorized Rockford Fosgate

Dealer, as we provide specialized training through Rockford Technical

Training Institute (RTTI). Please read your warranty and retain your

receipt and original carton for possible future use.

Great product and competent installations are only a piece of the puzzle

when it comes to your system. Make sure that your installer is using

100% authentic installation accessories from Rockford Fosgate in your

installation. Rockford Fosgate has everything from RCA cables and

speaker wire to power wire and battery connectors. Insist on it! Aer all,

your new system deserves nothing but the best.

To add the finishing touch to your new Rockford Fosgate image order

your Rockford accessories, which include everything from T-shirts to

hats.

Visit our web site for the latest information on all Rockford products;

www.rockfordfosgate.com

or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other

countries, call +001-480-967-3565 or FAX +001-480-966-3983.

Table of Contents

If, aer reading your manual, you still have questions regarding this

product, we recommend that you see your Rockford Fosgate dealer.

If you need further assistance, you can call us direct at 1-800-669-

9899. Be sure to have your serial number, model number and date of

purchase available when you call.

Safety

This symbol with “WARNING” is intended to

alert the user to the presence of important

instructions. Failure to heed the instructions

will result in severe injury or death.

This symbol with “CAUTION” is intended to

alert the user to the presence of important

instructions. Failure to heed the instructions

can result in injury or unit damage.

• To prevent injury and damage to the unit, please read and

follow the instructions in this manual. We want you to enjoy

this system, not get a headache.

• If you feel unsure about installing this system yourself, have

it installed by a qualiﬁed Rockford Fosgate technician.

• Before installation, disconnect the battery negative (-)

terminal to prevent damage to the unit, ﬁre and/or possible

injury.

Contents

Installation Tools

The following is a list of suggested tools needed for installation:

Introduction

trademarks of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective

owners. Speciﬁcations subject to change without notice.

2Introduction

3Installation

4Warranty

• Small Flat Blade Screwdriver

• Large Ratchet

• Metric Sockets

• Metric Nutdrivers

• Metric Wrenches

• Torx Driver

• 2.5 mm Allen Driver

• Wire Cutters

• Panel Tool

• (1) Amplifier Bracket

• (2) Bracket Clamp Halves

• (1) Wire Harnesses

• Mounting Hardware

• Plastic Wire Tie Wraps

PRACTICE SAFE SOUND

Continuous exposure to sound pressure levels over 100dB

may cause permanent hearing loss. High powered auto

sound systems may produce sound pressure levels well

over 130dB. Use common sense and practice safe sound.

Installation Considerations

This section focuses on some considerations for installing your Can-Am

Maverick X3 amplifier installation kit. This kit is designed to work in

conjunction with Rockford’s other X3 specific audio kits and parts.

If you feel unsure about installing this system yourself, have it installed

by a qualified technician.

When drilling holes, make sure what is on the other side. Be sure that

any electrical, fuel lines or any other important components are free

and clear from the area.

Before installation, disconnect the battery

negative (-) terminal to prevent damage to

the unit, fire and/or possible injury.

Before beginning any installation, follow

these simple rules:

Be sure to carefully read and understand the

instructions before attempting to install this

wiring kit.

• Consult your UTV’s service manual for model specific information.

• This amplifier installation kit is specifically designed to work with

Rockford Fosgate’s compact chassis amplifiers.

• With the addition of an amplifier or source unit, be sure that your

current charging system is in proper working order.

• Visit rockfordfosgate.com for more comprehensive product

information.

• Visit our YouTube channel for comprehensive installation videos

demonstrating complete installation guides and install tips.

Installation

Applicable Models:

Can-Am Maverick X3 (2 & 4 seat models)

This amplifier installation kit is designed to work with Rockford

Fosgate’s Maverick X3 specific enclosures and dash kits. The amp kit

steering column.

Step 1. Remove the driver side top dash panel using your Torx tool.

Step 2.

the front of the panel.

Step 3. Remove the seat(s) on the passenger side of the vehicle using

a ratchet and socket.

NOTE: On 4 seat models, both passenger side seats will need removed.

Step 4. Remove the access panels on the passenger side of the center

console.

NOTE: 2 seat models will have 3 panels to remove and the 4 seat models

will have 4.

Step 5. Mount the amplifier bracket to the vehicle’s chassis tube just

steering unit. The bracket will be secured with the supplied

clamp system.

Step 6. Mount the amplifier to the bracket once the bracket is secured

to the vehicle.

TM400X4ad mounting shown above.

TM1000X5ad mounting shown above.

Step 7. Connect the power and ground to the battery terminals and

route the wire harness down the center console toward the

front of the vehicle.

NOTE: The connectors for the radio input will get routed through the

fuse cover opening while the power and amplifier harness get routed

toward the drivers side. Be sure to secure all wiring with the supplied

plastic wire ties.

Step 8. Plug the power/ground and input/output harnesses into the

amplifier.

Step 9. Connect input connector(s) from the radio.

Step 10. Once all connections have been made, be sure to test the

system and reassemble vehicle.
