Sida 1/5
English -4
Connecting a AV device
WY R
WYR
RG B
WR
W R
R GB
HD connection
DVD / Blu-Ray player / Cable Box
/ Satellite receiver (STB)
Using a DVI Cable
AUDIO OUTDVI OUT
HD connection
DVD / Blu-Ray player / HD Cable
Box / HD Satellite receiver (STB)
Using an HDMI Cable
HDMI OUT
Audio/Video connection
VCR
Using an Audio/Video Cable
AUDIO OUTVIDEO OUT
Component connection
DVD / Blu-Ray player / Cable
Box / Satellite receiver
Using a Component Cable
AUDIO OUT COMPONENT OUT
HDMI/DVI
PC/COMPONENT
EXT/VIDEO
BestNormal
VCR / DVD
Using a Scart Cable
EXT
The Supplied Accessories
(M4 X L16)
Remote Control & Batteries (AAA x 2) Power Cord Stand Screw X 4
(Depending on the model)
Cleaning Cloth Cover-Bottom Holder-Wire Cable
(Depending on the model)
User Manual
Installing Batteries in the Remote Control
LCD TV
QUICK SETUP GUIDE
English - 1
BN68-01894F-01
Installing the Stand
Preset: Place the Guide Stand and Cover Neck onto the stand and fasten it using the screws. Applicable to models (Depending on
the model)
Step 1. Attach your LCD TV to the stand.
Two or more people should carry the TV.
Make sure to distinguish between the front and back of the stand when assembling them.
To make sure the TV is installed on the stand at a proper level, do not apply excess downward pressure to the upper left
of right sides of the TV.
Step 2. Fasten two screws at position 1 and then fasten two screw at position 2.
Stand the product up and fasten the screws. If you fasten the screws with the LCD TV placed down, it may lean to one
side.
Assembling the Cables
Enclose the cables in the Holder-Wire Cable so that the cables are not visible through the
transparent stand.
Using the remote control buttons
MENU Button
Display the main on-screen menu.
ENTER
E
/ DIRECTION Buttons
Move the cursor and select an item.
Select the currently selected item.
Confirm the setting.
RETURN Button
Return to the previous menu.
EXIT
Exit the on-screen menu.
N
N
N
N
N
English - 2
Back
Front
Front
Back
2
1
Preset Step 1 Step 2
