Samsung UA49M5523AK Bruksanvisning

Samsung Tv UA49M5523AK

Läs nedan 📖 manual på svenska för Samsung UA49M5523AK (153 sidor) i kategorin Tv. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Sida 1/153
E-MANUAL
Thank you for purchasing this Samsung product.
To receive more complete service, please register your
product at
www.samsung.com/register
Model______________ Serial No.______________
Contents
Quick Guides
Connecting the to the TVSamsung Smart Remote
Using Smart Hub
Using Voice Interaction
3 Running Voice Interaction
5 Read Before Using Voice Interaction
Updating the TV’s Software
6 Updating the TV’s software to the latest version
6 Updating the TV automatically
Getting Support
7 Getting support through Remote Management
8 Finding the contact information for service
8 Requesting service
Connections
Connection Guide
Connecting an Antenna (Aerial)
Connecting to the Internet
11 Connecting to your Internet network
Connecting to a Network via a Mobile Dongle
Troubleshooting Internet Connectivity Issues
15 Troubleshooting wired Internet connectivity issues
16 Troubleshooting wireless Internet connectivity issues
Connecting Video Devices
17 HDMIConnecting with an cable
18 Connecting with a component cable (Only for models with
COMPONENT IN / AV IN)
19 Connecting with a composite cable (Only for models with
COMPONENT IN / AV IN)
Audio Input and Output Connections
20 HDMI ( )Connecting with an ARC cable
20 Connecting with a digital audio (optical) cable
20 Connecting through a wireless network
21 Connecting Bluetooth Devices
Connecting a Computer
21 Connecting through the HDMI port ― Screen Sharing (HDMI)
Connecting a Mobile Device
22 Connecting to a Network
22 Viewing the screen of a mobile device on your TV (Screen
Sharing)
23 Managing a Mobile Device
Switching between external devices connected to the TV
23 Changing the input signal
24 Editing the name and icon of an external device
25 Using additional functions
Connection Notes
25 Connection notes for HDMI
26 Connection notes for audio devices
27 Connection notes for computers
27 Connection notes for mobile devices
Remote Control and Peripherals
About the Samsung Smart Remote
Connecting to the Samsung Smart Remote
Controlling External Devices with the Samsung Smart Remote
- Using the Universal Remote
Using Anynet+ (HDMI-CEC)
31 Connecting an external device through Anynet+ and using
their menus
Controlling the TV with a Keyboard
32 Connecting a USB keyboard
32 Connecting a Bluetooth keyboard
32 Using the keyboard
Entering Text using the On-Screen QWERTY Keyboard
34 Using additional functions
34 Entering Text using the remote control's microphone and the
on-screen QWERTY keyboard
Smart Features
Smart Hub
36 Displaying the Home Screen
38 Launching Smart Hub automatically
38 Launching the last used app automatically
39 Testing Smart Hub connections
39 Resetting Smart Hub
Using a Samsung account
39 Creating and managing your Samsung account
40 Signing in to a Samsung account
Using the Apps Service
43 Installing and running an app
44 Managing purchased or installed apps
Using the e-Manual
46 Launching the e-Manual
46 Using the buttons in the e-Manual
Using the Internet
Playing pictures/video/music
48 Playing media content
Using Voice Interaction
49 Running Voice Interaction
50 Read Before Using Voice Interaction
TV Viewing
Viewing Digital Broadcast Information at a Glance
52 Using the guide
Recording Programmes
54 Recording programmes
55 Managing the schedule recording list
55 Viewing recorded programmes
Setting Up a Schedule Viewing
56 Setting up a schedule viewing for a channel
57 Editing a schedule viewing
57 Setting the Schedule Viewing Time
Using Timeshift
58 Buttons and functions available while recording a programme
or Timeshift
Using the Channel List
Editing channels
60 Removing registered channels
60 Editing registered channels
Creating a Personal Favourites List
61 Registering channels as favourites
61 Viewing and selecting channels on Favourites lists only
Editing a Favourites List
62 Adding channels to favourites list
62 Removing channels from a favourites list
62 Rearranging a favourites list
62 Renaming a favourites list
TV-Viewing Support Functions
63 Changing the broadcast signal
63 Scanning for available channels
63 Restricting Viewing to Specific Channels
64 Selecting the broadcasting audio option
64 Using Programme Rating Lock
64 Configuring advanced broadcasting settings
65 Selecting the broadcast audio language
66 Tuning broadcast signals manually
66 Fine-tuning analogue broadcasts
67 Deleting CAM operator profile
67 Setting satellite system
67 Changing teletext language
68 Showing common interface menu
Picture and Sound
Adjusting the Picture Quality
69 Choosing a picture mode
70 Configuring advanced picture settings
Setting the Viewing Environment for External Devices
72 Playing games on an optimised screen
72 Using HDMI black level
73 Registering the TV as a DivX-certified device (watching for pay
DivX movies)
Picture Support Functions
73 Changing the picture size
74 Changing the picture size automatically
74 Changing the picture size in 4:3 or Screen Fit mode
Adjusting the Sound Quality
75 Choosing a sound mode
75 Configuring advanced sound settings
Using the Sound Support Functions
76 Selecting speakers
76 Listening to the TV through Bluetooth devices
77 Listening to the TV through a Multiroom speaker
System and Support
Setting the Time and Using the Timer
78 Setting the current time
79 Using the timers
Using the Screen Burn Protection and Energy Saving Functions
80 Preventing screen burn
80 Reducing the energy consumption of the TV
Updating the TV’s Software
81 Updating the TV’s software to the latest version
81 Updating the TV automatically
Protecting the TV from Hacking and Malicious Code
82 Scanning the TV and connected storage for malicious code
Using Other Functions
82 Running the accessibility functions
83 Enabling voice guides for the visually impaired
83 Audio Description
84 Watching TV broadcasts with subtitles
85 White text on black background (high contrast)
85 Enlarging the font (for the visually impaired)
85 Learning about the remote control (for the visually impaired)
85 Learning about the TV menu
85 Listening to the TV through Bluetooth devices (for the hearing
impaired)
86 Configuring advanced system settings
87 Checking digital channel signal info and strength
87 Restoring the TV to the factory settings
HbbTV
Using a TV Viewing Card (“CI or CI+ Card”)
89 Connecting the “CI or CI+ Card” via COMMON INTERFACE slot
with the CI CARD Adapter
90 Using the “CI or CI+ Card”
Teletext Feature
92 Typical Teletext page
Troubleshooting
Getting Support
93 Getting support through Remote Management
94 Finding the contact information for service
94 Requesting service
Diagnosing TV operational issues
There Is a Problem with the Picture
95 Testing the picture
I Can't Hear the Sound Clearly
97 Testing the sound
There Is a Problem with the Broadcast
My Computer Won't Connect
The TV Won't Connect to the Internet
The Schedule Recording/Timeshift Function Isn't Working
Anynet+ (HDMI-CEC) Isn't Working
I Have Trouble Launching/Using Apps
My File Won't Play
I Want to Reset the TV
Other Issues
Precautions and Notes
Before Using the Recording and Timeshift Functions
105 Before using the recording and schedule recording functions
107 Before using the timeshift function
Supported broadcasting audio options
Read Before Using Apps
Read Before Using the Internet
Read Before Playing Photo, Video, or Music Files
111 Limitations on use of photo, video, and music files
112 Supported external subtitles
112 Supported internal subtitles
113 Supported image formats and resolutions
113 Supported music formats and codecs
114 Supported video codecs
Read After Installing the TV
116 Picture sizes and input signals
117 Installing an anti-theft lock
117 Read before setting up a wireless Internet connection
Read Before Connecting a Computer (Supported Resolutions)
118 IBM
118 MAC
119 VESA DMT
Supported Resolutions for Video Signals
120 CEA-861
Read Before Using Bluetooth Devices
121 Restrictions on using Bluetooth
Buttons and Functions
122 Buttons and functions available while playing multimedia
content
Licence
Accessibility Guidance
Using the Remote control
125 Samsung Smart RemoteOrientation of the
125 Samsung Smart RemoteDescription of the
Using the accessibility menu
127 Accessibility short cut menu
128 Step by Step instructions to.
130 Setting accessibility settings using Voice Interaction
Using the TV with Voice Guide on
131 Watching TV
Using the guide
Setting Up a Schedule Viewing
Using the Channel List
138 Creating a Personal Favourites List
Recording
140 Using the instant and schedule recording options from the
guide screen:
141 Using the Instant and Schedule Recording options from
programme info window
141 Recording a programme you are currently watching directly
from live TV
141 Changing the recording time
142 Viewing recorded programmes
142 Deleting a recorded programme
Using Smart Hub
143 Smart Hub
144 Displaying the Home Screen in the Smart Hub
Using the e-Manual
146 e-ManualLaunching the
Using Voice Interaction
147 Running Voice Interaction
- 1 -
Quick Guides
You can learn quickly how to run and use the frequently used functions.
Connecting the Samsung Smart Remote to the TV
Connect the to your TV to operate the TV.Samsung Smart Remote
When you turn on the TV for the first time, the Samsung Smart Remote pairs to the TV automatically. If the Samsung
Smart Remote does not pair to the TV automatically, point it at the remote control sensor of the TV, and then press
and and buttons simultaneously for 3 seconds or more. hold the
"The images, buttons, and functions of the Samsung Smart Remote may differ by model.
"For more information, refer to "About the Samsung Smart Remote."
"Availability depends on the specific model.
- 4 -
If you say voice commands like "Channel number 11 Volume 10," and " " you can set the channel and volume.
If you say an accessibility-related command such as "Subtitle" or "Voice Guide," the command is applied
directly and you will see a notification that the function is operating.
When playing back media content, you can execute commands such as "Play, Pause, Rewind," " " "Stop," " " and
"Fast Forward."
"The function does not operate for all apps.
You can set the timer with the command "Sleep reservation in 30 minutes."
To change the source, say " " " " or " "HDMI, TV, USB.
To change the picture mode, say "Movie Picture Mode" or "Set Picture Mode to Standard."
To search, say "Search ****" or "Search **** in YouTube."
To view Help, say " " "Help, What can I say" or "User guide."
"The supported language may differ by geographical region.
"When you press the button once, the Help Guide is displayed. Use the Voice Interaction function as instructed in
the Guide.
- 5 -
Read Before Using Voice Interaction
Precautions for voice interaction
To use Voice Interaction, you must have a Samsung account. For more information, refer to "Using a Samsung
account."
The supported voice interaction languages and features may differ by geographical region.
If the language set differs from the language of your country, some features are not available.
The function is available only when the TV is connected to the Internet.
Voice interaction is available only on TVs that support it and come with remote controls that have a
microphone.
Symbols including "-" and special characters are not supported. Consequently, if a word or sentence contains
numeric values or symbols, the function may not operate properly.
Searched results may not provide complete results.
You may be required to pay for some apps. Consequently, you may encounter a service application or contract.
To change the current channel by saying channel names as voice commands, you must finish Set Up Service
Provider Settings General Start Setup. ( )
To use the voice text input function and Smart search function, you must consent to provisions allowing third
parties to collect and use your voice data.
To use the interactive voice interaction function, you must.
Agree to Smart Hub's Terms of Use
Agree to a guidance regarding the collection and use of personal information for the Smart Hub service.
Consent to the collection and use of personal information for the voice interaction-based service.
Requirements for using voice interaction
The voice interaction rate differs with the volume/tone, pronunciation, and ambient sound environment (TV
sound and ambient noise).
The optimal volume for voice commands is between 75 dB and 80 dB.
- 6 -
Updating the TV’s Software
View your TV's software version and update it if necessary.
Settings Support Software Update
Updating the TVs software to the latest version
[ DO NOT turn off the TV’s power until the update is complete. The TV will turn off and on automatically after
completing the software update. Video and audio settings will be reset to their defaults after a software
update.
Updating through the Internet
Settings Support Software Update Update Now
"Updating from the Internet requires an active Internet connection.
Updating through a USB device
Settings Support Software Update Update Now
After downloading the update file from the Samsung website and storing it on a USB device, connect the USB device
to the TV to update.
"To update using a USB flash drive, download the update package from Samsung.com to your computer. Then, save the
update package in the USB device's top-level folder. Otherwise, the TV will not be able to locate the update package.
Updating the TV automatically
Settings Support Software Update Auto update
If the TV is connected to the Internet, you can have the TV update its software automatically while you are watching
the TV. When the background update is completed, it is applied the next time the TV is turned on.
If you agree to the Smart Hub terms and conditions, Auto update On is set to automatically. If you want this function
disabled, use the Select button to turn it off.
"This function may take a longer time if another network function is running concurrently.
"This function requires an Internet connection.
- 7 -
Getting Support
Get help directly from Samsung if you have a problem with your TV.
Getting support through Remote Management
Settings Support Remote Management
After consenting to our service agreement, you can use to access Remote Support and have Remote Management
a Samsung service technician diagnose your TV, correct problems, and update your TV's software, remotely, via the
web. You can also turn Remote Management on and off.
"This function requires an Internet connection.
What is Remote Support?
Samsung Remote Support service offers you one-on-one support with a Samsung Technician who can remotely:
Diagnose your TV
Adjust the TV settings for you
Perform a factory reset on your TV
Install recommended firmware updates
How does Remote Support Work?
You can easily have a Samsung Tech service your TV remotely:
1.
Call the Samsung Contact Centre and ask for remote support.
2.
Open the menu on your TV and go to the section.Support
3.
Select Remote Management, then read and agree to the service agreements. When the PIN screen appears,
provide the PIN number to the agent.
4.
The agent will then access your TV.
- 8 -
Finding the contact information for service
Settings Support About This TV
You can view the address of the Samsung website, the call centre phone number, your TV's model number, your TV's
software version, Open Source Licence and other information you may need to get service support from a Samsung
call agent or the Samsung website.
"You can also view information by scanning the QR code of your TV.
"You can also start this function by pressing and holding the button for 5 or more seconds.
"This function is not available on certain models in specific geographical areas.
Requesting service
Settings Support Request Support
You can request service when you encounter a problem with the TV. Select the item matching the problem that
you encountered, and then select Request Now or Schedule Appointment Send. Your service request will be
registered. The Samsung Contact Centre will contact you to set up or confirm your service appointment.
"This function is not available in specific geographical areas.
"You must agree to the terms and conditions for the service request.
"This function requires an Internet connection.
- 9 -
Connections
You can watch live broadcasts by connecting an antenna and antenna cable to your TV and can get access to the
Internet by using a LAN cable or wireless router. Using various connectors, you can also connect external devices.
Connection Guide
You can view detailed information about external devices that can be connected to the TV.
Source Connection Guide
It guides you the way to connect various external devices such as the cable box, game console, and PC through
pictures. If you select the connection method to an external device, the information details appear.
Connection Guide
Cable Box/Disc Player HDMI
Game Console AV
PC Component
Audio device
Mobile Device
External Storage
Accessory
"The image on your TV may differ from the image above depending on your model and geographical area.
- 11 -
Connecting to the Internet
You can get access to the Internet through your TV.
Connecting to your Internet network
Settings General Network Open Network Settings Try Now
Connect to an available network.
Establishing a wired Internet connection
Settings General Network Open Network Settings Wired
If you connect a LAN cable, the TV automatically accesses the Internet.
"Use a CAT 7 (*STP type) cable for the connection.
* Shielded Twist Pair
"The TV will not be able to connect to the Internet if your network speed is below 10 Mbps.
- 13 -
Checking the Internet connection status
Settings General Network Network Status Try Now
View the current network and Internet status.
Turning on the TV with a Mobile Device
Settings General Network Power On with Mobile
By using a mobile device on the same network, you can turn on the TV.
Changing the name of the TV on a network
Settings General System Manager Device Name
You can change the name of the TV on the network. Select User Input at the bottom of the list and change the name.
- 15 -
Troubleshooting Internet Connectivity Issues
If your TV won't connect to the Internet, try the solutions below.
Troubleshooting wired Internet connectivity issues
After reading the following content, troubleshoot the wired Internet connection issue. If the problem persists,
contact your Internet Service Provider.
No network cable found
Make sure that the LAN cable is plugged in on both ends. If it is plugged in, make sure that the router is turned on. If
the router is on, try turning it off and then on.
IP auto setting failed
1.
Configure the settings in IP Settings.
2.
Make sure that the DHCP server is enabled on the router, and then reset the router.
Unable to connect to the network
1.
Check all IP Settings.
2.
After checking the DHCP server status (must be active) on the router, remove the LAN cable, and then connect
it again.
- 16 -
Connected to a local network, but not to the Internet
1.
Make sure that the Internet LAN cable is connected to the router's external LAN port.
2.
Check the DNS values in IP Settings.
Network setup is complete, but unable to connect to the Internet
If the problem persists, contact your Internet Service Provider.
Troubleshooting wireless Internet connectivity issues
After reading the following content, troubleshoot the wireless Internet connection issue. If the problem persists,
contact your Internet Service Provider.
Wireless network connection failed
If a selected wireless router is not found, go to , and then select the correct router.Open Network Settings
Unable to connect to a wireless router
1.
Check if the router is turned on. If it is, turn it off and then on.
2.
Enter the correct password if required.
IP auto setting failed
1.
Configure the settings in IP Settings.
2.
Make sure that the DHCP server is enabled on the router. Then, unplug the router and plug it back in.
3.
Enter the correct password if required.
- 17 -
Unable to connect to the network
1.
Check all IP Settings.
2.
Enter the correct password if required.
Connected to a local network, but not to the Internet
1.
Make sure that the Internet LAN cable is connected to the router's external LAN port.
2.
Check the DNS values in IP Settings.
Network setup is complete, but unable to connect to the Internet
If the problem persists, contact your Internet Service Provider.
Connecting Video Devices
Make the correct video connections between your TV and your external devices.
Connecting with an HDMI cable
HDMI IN
- 19 -
Connecting with a composite cable (Only for models with COMPONENT IN /
AV IN)
Through the Composite connection, you can enjoy the resolution up to 576i.
Review the illustration below, and then connect AV IN on the TV to AV OUT on the external device using the provided
AV adapter and composite cable. When connecting the cables, be sure to match the colours of the cables to the
colours of the ports.
COMPONENT IN / AV IN
COMPONENT IN
AV IN
"Connect AV (composite) equipment to AV In only. Do not connect to Component In.
- 20 -
Audio Input and Output Connections
Make the correct audio connections between your TV and your external devices.
" For more information about how to select external speakers, refer to "Selecting speakers."
Connecting with an HDMI ( )ARC cable
HDMI IN
(ARC)
Connecting with a digital audio (optical) cable
DIGITAL
AUDIO OUT
(OPTICAL)
Connecting through a wireless network
You can connect the TV to a Samsung wireless audio device through your wireless network. The two devices must be
connected to the same network. For more information about the connection and its use, refer to the user manual of
the audio device.
- 21 -
Connecting Bluetooth Devices
For more information about how to connect and use external speakers, refer to the Connection Guide (
Source Connection Guide ) and their user manuals.
"This function is not available on certain models in specific geographical areas.
Connecting a Computer
Use the TV as a computer monitor or connect the TV to a computer via your network and access the computer's
content.
Connecting through the HDMI port ― Screen Sharing (HDMI)
HDMI IN
HDMI
DVI
HDMI IN
"When your PC is connected, select PC for the . For more information about the port settings, refer to "Device Icon Editing the
name and icon of an external device."
- 22 -
Connecting a Mobile Device
View a mobile device's screen and multi-media content by connecting the mobile device to your TV or network.
After you connect a mobile device that supports screen mirroring to your TV, you can use screen mirroring to view
the screen of the mobile device on your TV wirelessly and play the video, audio, or photo files currently playing on the
mobile device on your TV.
Connecting to a Network
Connecting to the Same Wireless Network
Connect the mobile device and TV to the same wireless network.
"For more information about the wireless network connection, refer to "Establishing a wireless Internet connection."
"For more information about the wireless network connection from a mobile device, refer to its user guide.
"When a mobile device is connected to the TV using the Wi-Fi direct function, you can enjoy the photos, videos, and music
stored on the mobile device through the TV.
Viewing the screen of a mobile device on your TV (Screen Sharing)
When you run the Smart View on a mobile device, you can view the screen of the mobile device on the TV.
1.
Run the Smart View on your mobile device. The device searches for TVs that can be connected.
2.
Select the desired TV from the searched result. The TV and the mobile device are connected.
If there is no TV found, try again after turning both off and on.
If you have multiple TVs, assign a different name to each TV in Settings General System
Manager Device Name to make selection easy.

Produktspecifikationer

Varumärke: Samsung
Kategori: Tv
Modell: UA49M5523AK

Behöver du hjälp?

Om du behöver hjälp med Samsung UA49M5523AK ställ en fråga nedan och andra användare kommer att svara dig




Tv Samsung Manualer

Tv Manualer

Nyaste Tv Manualer
