Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols 4
Important safety precautions 5
Critical installation warnings 8
Installation cautions 9
Critical usage warnings 10
Usage cautions 11
Critical cleaning warnings 14
Instructions about the WEEE 14
Installation 15
What’s included 15
Installation requirements 17
Step-by-step installation 19
Before you start 28
Initial setup 28
Laundry guidelines 29
Detergent drawer guidelines 32
Operations 35
Control panel 35
Operating a cycle 37
Cycle overview 38
Additional Functions 42
System Functions 45
Special features 47
SmartThings 50
Open Source Announcement 51
Maintenance 52
Drum Clean+ 52
Emergency drain 53
Cleaning 54
Detergent drawer 57
Defrosting your washing machine 58
Care against an extended time of disuse 58
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 2 2021/1/16 10:27:29
English
English 3
Troubleshooting 59
Checkpoints 59
Information codes 63
Specifications 66
Fabric care chart 66
Protecting the environment 67
Spare parts guarantee 67
Specification sheet 68
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 3 2021/1/16 10:27:29
English
English4
Safety information
Congratulations on your new Samsung washing machine. This manual contains important information
on the installation, use and care of your appliance. Please take some time to read this manual to take full
advantage of your washing machine’s many benefits and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efficiently operate the
extensive features and functions of your new appliance. Please store the manual in a safe location close
to the appliance for future reference. Use this appliance only for its intended purpose as described in this
instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution and care when installing,
maintaining and operating your washing machine.
Because the following operating instructions cover various models, the characteristics of your washing
machine may differ slightly from those described in this manual and not all warning signs may be
applicable. If you have any questions or concerns, contact your nearest service centre or find help and
information online at www.samsung.com.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Indicates that a risk of personal injury or material damage exists.
Read the instructions
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
Read all instructions before using the appliance.
As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate
this appliance, familiarize yourself with its operation and exercise care when using it.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 4 2021/1/16 10:27:29
English
English 5
Important safety precautions
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using
your appliance, follow basic precautions, including the following:
1. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
2. For use in Europe: This appliance can be used by children aged from
8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
3. Children should be supervised to ensure that they do not play with
the appliance.
4. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
5. The new hose-sets supplied with the appliance are to be used and
that old hose-sets should not be reused.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 5 2021/1/16 10:27:30
English
Safety information
English6
6. For appliances with ventilation openings in the base, that a carpet
must not obstruct the openings;
7. For use in Europe: Children of less than 3 years should be kept away
unless continuously supervised.
8. CAUTION: In order to avoid a hazard due to inadvertent resetting of
the thermal cut-out, this appliance must not be supplied through an
external switching device, such as a timer, or connected to a circuit
that is regularly switched on and off by the utility.
9. The tumble dryer is not to be used if industrial chemicals have been
used for cleaning.
10. The lint trap has to be cleaned frequently, if applicable.
11. Lint must not to be allowed to accumulate around the tumble dryer.
(not applicable for appliances intended to be vented to the exterior of
the building)
12. Adequate ventilation has to be provided to avoid the back flow of
gases into the room from appliances burning other fuels, including
open fires.
13. Do not dry unwashed items in the tumble dryer.
14. Items that have been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes
and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the tumble dryer.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 6 2021/1/16 10:27:30
English
English 7
15. Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the tumble dryer.
16. Fabric softeners, or similar products, should be used as specified by
the fabric softener instructions.
17. The final part of a tumble dryer cycle occurs without heat (cool down
cycle) to ensure that the items are left at a temperature that ensures
that the items will not be damaged.
18. Remove all objects from pockets such as lighters and matches.
19. WARNING: Never stop a tumble dryer before the end of the drying
cycle unless all items are quickly removed and spread out so that the
heat is dissipated.
20. Exhaust air must not be discharged into a flue which is used for
exhausting fumes from appliances burning gas or other fuels.
21. The appliance must not be installed behind a lockable door, a sliding
door or a door with a hinge on the opposite side to that of the tumble
dryer, in such a way that a full opening of the tumble dryer door is
restricted.
22. WARNING: The appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is
regularly switched on and off by a utility.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 7 2021/1/16 10:27:30
English
Safety information
English8
23. This appliance is intended to be used in household only and it is not
intended to be used such as:
–staff kitchen areas in shops, offices and other working
environments;
–farm houses;
–by clients in hotels, motels and other residential type
environments;
–bed and breakfast type environments;
–areas for communal use in blocks of flats or in launderettes.
Critical installation warnings
WARNING
The installation of this appliance must be performed by a qualified technician or service company.
• Failure to do so may result in electric shock, fire, an explosion, problems with the appliance, or injury.
The appliance is heavy, therefore take care when lifting it.
Plug the power cord firmly into a wall socket that meets local electrical specifications. Use the socket for
this appliance only, and do not use an extension cord.
• Sharing a wall socket with other appliances using a power strip or extending the power cord may result
in electric shock or fire.
• Ensure that the power voltage, frequency, and current are the same as those of the product
specifications. Failure to do so may result in electric shock or fire.
Remove all foreign substances such as dust or water from the power plug terminals and contact points
using a dry cloth on a regular basis.
• Unplug the power plug and clean it with a dry cloth.
• Failure to do so may result in electric shock or fire.
Plug the power plug into the wall socket so that the cord is running towards the floor.
• If you plug the power plug into the socket in the opposite direction, the electric wires within the cable
may be damaged and this may result in electric shock or fire.
Keep all packaging materials out of the reach of children as these may be dangerous.
• If a child places a bag over its head, it may suffocate.
When the appliance, power plug or power cord is damaged, contact your nearest service centre.
This appliance must be properly grounded.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 8 2021/1/16 10:27:30
English
English 9
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
• This may result in electric shock, fire, an explosion, or problems with the appliance.
• Never plug the power cord into a socket that is not grounded correctly and make sure that it is in
accordance with local and national regulations.
Do not install this appliance near a heater or any inflammable material.
Do not install this appliance in a humid, oily or dusty location, or in a location exposed to direct sunlight or
water (rain drops).
Do not install this appliance in a location exposed to low temperatures.
• Frost may cause the tubes to burst.
Do not install this appliance in a location where gas may leak.
• This may result in electric shock or fire.
Do not use an electric transformer.
• This may result in electric shock or fire.
Do not use a damaged power plug, damaged power cord, or loose wall socket.
• This may result in electric shock or fire.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power
cord between objects, or push the power cord into the space behind the appliance.
• This may result in electric shock or fire.
Do not pull the power cord when unplugging the power plug.
• Unplug the power plug by holding the plug.
• Failure to do so may result in electric shock or fire.
This appliance should be positioned so that the power plug, the water supply taps, and the drain pipes are
accessible.
Following the repair by a non-authorized service provider, self-repair or non-professional repair of the
product, Samsung is not liable for any damage to the product, any injury or any other product safety issue
caused by any attempt to repair the product which does not carefully follow these repair and maintenance
instructions. Any damage to the product caused by an attempt to repair the product by any person other
than a Samsung certified service provider will not be covered by the warranty.
Installation cautions
CAUTION
This appliance should be positioned in such a way that the power plug is easily accessible.
• Failure to do so may result in electric shock or fire due to electric leakage.
Install your appliance on a solid, level floor that can support its weight.
• Failure to do so may result in abnormal vibrations, movement, noise, or problems with the appliance.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 9 2021/1/16 10:27:30
English
Safety information
English10
Critical usage warnings
WARNING
If the appliance is flooded, turn off the water & power supplies immediately and contact your nearest
service centre.
• Do not touch the power plug with wet hands.
• Failure to do so may result in electric shock.
If the appliance generates a strange noise, a burning smell, or smoke, unplug the power cord immediately
and contact your nearest service centre.
• Failure to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the
power plug. Do not touch the appliance or power cord.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
Remove the washing machine door lever before disposing the appliance.
• If trapped inside the appliance, children may suffocate to death.
Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the washing machine
before using it.
Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or other
inflammable or explosive substances.
• This may result in electric shock, fire, or an explosion.
Do not open the washing machine door by force while it is operating (high-temperature washing/drying/
spinning).
• Water flowing out of the washing machine may result in burns or cause the floor to be slippery. This may
result in injury.
• Opening the door by force may result in damage to the appliance or injury.
Do not touch the power plug with wet hands.
• This may result in electric shock.
Do not turn the appliance off by unplugging the power cord while an operation is in progress.
• Plugging the power cord into the wall socket again may cause a spark and result in electric shock or fire.
Do not let children climb in or onto the appliance.
• This may result in electric shock, burns or injury.
Do not insert your hand or a metal object under the washing machine while it is operating.
• This may result in injury.
Do not unplug the appliance by pulling the power cord. Always grip the plug firmly and pull it straight out
of the outlet.
• Damage to the power cord may cause a short-circuit, fire and/or electric shock.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 10 2021/1/16 10:27:30
English
English 11
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use a fuse (such as copper, steel wire, etc.) other than a standard fuse.
• When the appliance needs to be repaired or reinstalled, contact your nearest service centre.
• Failure to do so may result in electric shock, fire, problems with the appliance, or injury.
If the water supply hose comes loose from the water tap and floods the appliance, unplug the power cord.
• Failure to do so may result in electric shock or fire.
Unplug the power cord when the appliance is not being used for long periods of time or during a thunder or
lightning storm.
• Failure to do so may result in electric shock or fire.
If any foreign substance enters into the appliance, unplug the power cord and contact your nearest
Samsung Customer Service.
• This may result in electric shock or fire.
Do not let children (or pets) play in or on your washing machine. The washing machine door does not open
easily from the inside and children may be seriously injured if trapped inside.
Usage cautions
CAUTION
When the washing machine is contaminated by a foreign substance such as detergent, dirt, food waste,
etc., unplug the power cord and clean the washing machine using a damp, soft cloth.
• Failure to do so may result in discolouration, deformation, damage, or rust.
The front glass may be broken by a strong impact. Take care when using the washing machine.
• If the glass is broken, it may result in injury.
Open the water tap slowly after a long period of non-use, water supply failure, or when reconnecting the
water supply hose.
• The air pressure in the water supply hose or the water pipe may damage a part of the appliance or result
in a water leak.
If a draining error occurs during an operation, check if there is a draining problem.
• If the washing machine is used when it is flooded because of a draining problem, it may result in electric
shock or fire.
Insert the laundry into the washing machine completely so that the laundry does not get caught in the
door.
• If laundry gets caught in the door, it may result in damage to the laundry or the washing machine, or
result in a water leak.
Turn the water supply off when the washing machine is not being used.
• Ensure that the screws on the water supply hose connector are properly tightened.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 11 2021/1/16 10:27:30
English
Safety information
English12
Ensure that the rubber seal and front door glass are not contaminated by a foreign substance (e.g. waste,
thread, hair, etc.).
• If a foreign substance is caught in the door or the door is not completely closed, it may cause a water
leak.
Open the water tap and check if the water supply hose connector is firmly tightened and that there is no
water leak before using the appliance.
• If the screws on the water supply hose connector are loose, it may result in a water leak.
The appliance you have purchased is designed for domestic use only.
Using the appliance for business purposes qualifies as an appliance misuse. In this case, the appliance will
not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to
Samsung for malfunctions or damages resulting from such misuse.
Do not stand on the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance.
• This may result in electric shock, fire, problems with the appliance, or injury.
Do not spray volatile material such as insecticide onto the surface of the appliance.
• As well as being harmful to humans, this may result in electric shock, fire or problems with the
appliance.
Do not place objects that generate electromagnetic fields near the washing machine.
• This may result in injury due to a malfunction.
Water drained during a high-temperature wash or drying cycle is hot. Do not touch the water.
• This may result in burns or injury.
Draining time may vary depending on the water temperature. If the water temperature is too high, the
draining process starts after the water cools down.
Do not wash, spin, or dry water-proof seats, mats, or clothing (*) unless your appliance has a special cycle
for washing these items.
(*): Woollen bedding, rain covers, fishing vests, ski pants, sleeping bags, diaper covers, sweat suits, and
bicycle, motor cycle and car covers, etc.
• Do not wash thick or hard mats even if the washing machine mark is on the care label. This may result in
injury or damage to the washing machine, walls, floor, or clothing due to abnormal vibrations.
• Do not wash throw rugs or doormats with rubber backing. The rubber backing may come off and stick to
inside the drum, and this may result in malfunction such as a drainage error.
Do not operate the washing machine when the detergent drawer is removed.
• This may result in electric shock or injury due to a water leak.
Do not touch the insides of the drum during or just after drying as it is hot.
• This may result in burns.
The door glass becomes hot during washing and drying. Therefore, do not touch the door glass.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 12 2021/1/16 10:27:30
English
English 13
Also, do not allow children to play around the washing machine or touch the door glass.
• This may result in burns.
Do not insert your hand into the detergent drawer.
• This may result in injury as your hand may be caught by the detergent input device.
Remove the liquid detergent guide (applicable models only) when using powdered detergent.
• If not, water may leak through the front of the detergent drawer.
Do not place any objects (such as shoes, food waste, animals) other than laundry into the washing machine.
• This may result in damage to the washing machine, or injury and death in the case of pets due to the
abnormal vibrations.
Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.
• This may result in electric shock or injury.
Do not wash laundry contaminated by oils, creams or lotions usually found in skincare shops or massage
clinics.
• This may cause the rubber seal to become deformed and result in a water leak.
Do not leave metal objects such as safety pins, hair pins or bleach in the drum for long periods of time.
• This may cause the drum to rust.
• If rust starts appearing on the surface of the drum, apply a (neutral) cleansing agent to the surface and
use a sponge to clean it. Never use a metal brush.
Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry contaminated by dry
cleaning detergent.
• This may result in spontaneous combustion or ignition due to the heat from the oxidation of the oil.
Do not use water from water cooling/heating devices.
• This may result in problems with the washing machine.
Do not use natural hand-washing soap for the washing machine.
• If it hardens and accumulates inside the washing machine, it may result in problems with the appliance,
discolouration, rust, or bad odours.
Place socks and brassieres in a washing net and wash them with the other laundry.
Do not wash large laundry items such as bedding in the washing net.
• Failure to do so may result in injury due to abnormal vibrations.
Do not use hardened detergent.
• If it accumulates inside the washing machine, it may result in a water leak.
Make sure that the pockets of all the clothing items to be washed are empty.
• Hard, sharp objects such as coins, safety pins, nails, screws, or stones can cause extensive damage to
the appliance.
Do not wash clothing with large buckles, buttons or other heavy metal objects.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 13 2021/1/16 10:27:30
English
Safety information
English14
Sort the laundry by colour on the basis of its colorfastness and select the recommended cycle, water
temperature and additional functions.
• This may result in discolouration or fabric damage.
Take care that children’s fingers are not caught in the door when you close it.
• Failure to do so may result in injury.
To prevent odours and mould, leave the door open after a wash cycle to allow the drum to dry.
To prevent limescale build up, leave the detergent drawer open after a wash cycle and dry inside it.
Critical cleaning warnings
WARNING
Do not clean the appliance by spraying water directly onto it.
Do not use a strong acidic cleaning agent.
Do not use benzene, thinner or alcohol to clean the appliance.
• This may result in discolouration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, unplug the appliance from the wall socket.
• Failure to do so may result in electric shock or fire.
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories (e. g. charger, headset, and USB cable) should not be disposed of
with other household waste at the end of their working life. To prevent possible harm to
the environment or the human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
For more information on safe disposal and recycling visit our website.
www.samsung.com/in/support or contact our Helpline numbers-1800 40
SAMSUNG(7267864).
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 14 2021/1/16 10:27:30
English
English 15
Installation
Follow these instructions carefully to ensure proper installation of the washing machine and to prevent
accidents when doing laundry.
What’s included
Make sure all the parts are included in the product package. If you have a problem with the washing
machine or the parts, contact a local Samsung customer centre or the retailer.
13
07
09
08
02
03
04
05
06
10
12
11
01
01 02 Manual dispenser Release lever Detergent drawer03
04 05 06 Control panel Door Drum
07 Debris filter Emergency drain tube08 09 Filter cover
10 Worktop Power plug Drain hose11 12
13 Levelling feet
* The design of the drawer and/or the lever differs with the model.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 15 2021/1/16 10:27:31
English
Installation
English16
Spanner Bolt caps Hose guide
Cold water hose Hot water hose Liquid detergent guide
(applicable models only)
Cap Fixer
(applicable models only)
Accessories (not supplied)
• Stacking kit : SK-DH
-Staking kit is required to stack a dryer on a washing machine.
NOTE
• Spanner: For removing the shipping bolts and levelling the washing machine.
• Bolt caps: For covering the holes after removing the shipping bolts. The provided number of bolt caps (3
to 6) depends on the model.
• Hose guide: For hanging the drain hose in the drainpipe or wash-basin.
• Cold/Hot water hose: For supplying water to the washing machine. (Hot water hoses is for applicable
models only.)
• Liquid detergent guide: Insert it in the detergent compartment to use liquid detergent.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 16 2021/1/16 10:27:32
English
English 17
Installation requirements
Electrical supply and grounding
• AC 220-240 V / 50 Hz fuse or circuit breaker is
required.
• Use an individual branch circuit specific to the
washing machine.
To ensure proper grounding, the washing machine
comes with a power cord featuring a three-prong
grounding plug for use in a properly installed and
grounded outlet.
Check with a qualified electrician or service
person if you are not sure about the grounding.
Do not modify the provided plug. If it does not fit
the outlet, call a qualified electrician to install a
suitable outlet.
WARNING
• Do NOT use an extension cord.
• Use only the power cord that comes with the
washing machine.
• Do NOT connect the ground wire to plastic
plumbing, gas lines, or hot water pipes.
• Improperly connected grounding conductors
may cause electric shock.
Water supply
A proper water pressure for this washing machine
is between 50 kPa and 800 kPa. Water pressure
less than 50 kPa may cause the water valve to not
close completely, or it may take longer to fill the
drum, causing the washing machine to turn off.
Water taps must be within 120 cm from the rear
of the washing machine so that the provided inlet
hoses reach the washing machine.
To reduce the risk of leaks:
• Make sure water taps are easily accessible.
• Turn off the taps when the washing machine is
not in use.
• Check for any leaks at the water inlet hose
fittings on a regular basis.
CAUTION
Before using the washing machine for the first
time, check all connections at the water valve and
taps for any leaks.
Drain
Samsung recommends a standpipe 60-90 cm
high. The drain hose must be connected through
the hose clip to the standpipe, and the standpipe
must fully cover the drain hose.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 17 2021/1/16 10:27:32
English
Installation
English18
Flooring
For best performance, the washing machine must
be installed on a solid floor. Wood floors may need
to be reinforced to minimise vibration and/or
unbalanced loads. Carpeting and soft tile surfaces
do not resist vibration well and may cause the
washing machine to move slightly during the spin
cycle.
CAUTION
Do NOT install the washing machine on a platform
or a poorly supported structure.
Water temperature
Do not install the washing machine in areas where
water may freeze as the washing machine always
retains some water in its water valves, pumps,
and/or hoses. Frozen water left in the connection
parts may cause damage to belts, the pump, and
other components of the washing machine.
Alcove installation
Minimum clearance for stable operation:
Sides 25 mm
Top 25 mm
Rear 50 mm
Front 550 mm
If both the washing machine and a dryer are
installed in the same location, the front of the
alcove must have at least a 550 mm unobstructed
air opening. Your washing machine alone does not
require a specific air opening.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 18 2021/1/16 10:27:32
English
English 19
Step-by-step installation
STEP 1 Select a location
Location requirements:
• Solid, level surface without carpeting or flooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room for ventilation and wiring
• The ambient temperature is always higher than the freezing point (0 °C)
• Away from a heat source
NOTE
• To prevent excessive vibration while operating the washing machine, consider stability before anything
else.
• Install your washing machine on a solid and level floor.
• Do not install your washing machine on soft floors or floor coverings.
• If you install your washing machine on a wood floor, install a water-resistance wooden panel (min 1.18 in.
/ 30 mm thick) to the floor. Also, we recommend installing your washing machine on the corner of the
wood floor.
STEP 2 Remove the shipping bolts
Unpack the product package and remove all shipping bolts.
NOTE
Number of shipping bolts may differ depending on the model.
WARNING
• Packaging materials can be dangerous to children. Dispose all packaging material (plastic bags,
polystyrene, etc.) out of children’s reach.
• To avoid injury, cover the holes with bolt caps after removing the shipping bolts. Do not move the
washing machine without the shipping bolts in place. Assemble the shipping bolts before moving the
washing machine to another location. Keep the shipping bolts in a safe place for future use.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 19 2021/1/16 10:27:32
English
Installation
English20
A
1. Locate the shipping bolts (marked with circle in the
figure) on the rear side of the washing machine.
CAUTION
Do not remove the screw (A) that fixes the hose clip.
2. Using the supplied spanner, loosen all the shipping
bolts by turning them anticlockwise.
NOTE
You must keep the shipping bolts for future use.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 20 2021/1/16 10:27:33
English
English 21
B
3. Insert the to the holes (marked with bolt caps (B)
circle in the figure).
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 21 2021/1/16 10:27:33
English
Installation
English22
STEP 3 Adjust the levelling feet
1. Gently slide the washing machine into position.
Excessive force may damage the levelling feet.
2. Level the washing machine by manually adjusting the
levelling feet.
3. When levelling is complete, tighten the nuts using
the spanner.
CAUTION
When installing the product make sure the levelling feet
is not pressing the power cord.
CAUTION
Make sure all the levelling feet are seating on the floor surface to avoid the washing machine from moving
or generating noise due to vibration. Then, check if the washing machine is rocking. If the washing machine
is not rocking, tighten the nuts.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 22 2021/1/16 10:27:34
English
English 23
STEP 4 Connect the water hose
The provided water hose may differ depending on the model. Please follow the instruction according to the
provided water hose.
Connecting to a threaded water tap
A
B
1. Remove the adaptor (A) from the water hose (B).
2. Use a Phillips screwdriver to loosen four screws on
the adaptor.
C
3. Hold the adaptor and turn part (C) in the arrow
direction to loosen it by 5 mm (*).
C
4. Insert the adaptor onto the water tap, and then
tighten the screws while lifting the adaptor.
5. Turn part (C) in the arrow direction to tighten it.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 23 2021/1/16 10:27:34
English
Installation
English24
E
6. While pulling down on the water hose, part (E)
connect the water hose to the adaptor. Then, release
part (E). The hose fits into the adaptor with a clicking
sound.
7. If you are using a screw type of water tap, use the
provided screw-type adaptor to connect to the water
tap as shown.
8. Connect the other end of the water hose to the inlet
valve on the back of the washing machine. Turn the
hose clockwise to tighten.
9. Open the water tap and check if there are any leaks
around the connection areas. If there are water leaks,
repeat the steps above.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 24 2021/1/16 10:27:35
English
English 25
WARNING
Stop using the washing machine if there is a water leak, and contact a local Samsung service centre.
Otherwise, this may cause electric shock.
CAUTION
Do not stretch the water hose by force. If the hose is too short, replace the hose with a longer, high-
pressure hose.
NOTE
• After connecting the water hose to the adaptor, pull the water hose down to check if it is connected
properly.
• Use a popular type of water taps. If the tap is square-shaped or too big, remove the spacer ring before
inserting the tap into the adaptor.
For models with an additional hot water inlet:
1. Connect the red end of the hot water hose to the hot
water inlet on the back of the machine.
2. Connect the other end of the hot water hose to the
hot water tap.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 25 2021/1/16 10:27:35
English
Installation
English26
STEP 5 Position the drain hose
The drain hose can be positioned in three ways:
A
Over the edge of a wash basin
The drain hose must be placed between 60 cm and 90
cm (*) above from the floor. To keep the spout of the
drain hose bent, use the supplied plastic hose guide
(A). Secure the guide to the wall using a hook to ensure
stable drainage.
In a drain pipe
The drain pipe should be between 60 cm and 90 cm high
(*). It is advisable to use a 65 cm high vertical pipe.
• To ensure the drain hose stays in position, use the
plastic hose guide provided (see the figure).
• To prevent the siphoning of water flow during
drainage, make sure to insert the drain hose 15 cm in
the drain pipe.
• To prevent the drain hose from moving around,
secure the hose guide to the wall.
Drain standpipe requirements:
• Minimum diameter of 5 cm
• Minimum carry-away capacity of 60 litres per minute
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 26 2021/1/16 10:27:36
English
English 27
In a sink drain pipe branch
The drain pipe branch must be above the sink siphon
so that the end of the hose is at least 60 cm above the
ground.
(*) : 60 cm
CAUTION
Remove the lid on the sink drain pipe branch before
connecting the drain pipe to it.
STEP 6 Power on
Plug the power cord into a wall socket that is correctly rated, grounded, and protected by a fuse or circuit
breaker. Then, tap to turn on the washing machine.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 27 2021/1/16 10:27:36
English
English28
Before you start
Initial setup
• When you turn on the washing machine for the first time, the screen shows the initial setup process.
Follow the on-screen instructions to complete it.
• Initial setup will not repeat after you’ve completed it.
• The initial setup includes language selection, calibration, and a brief tutorial.
• Tap or turn the to skip to the next screen.Navigation dial
Run Calibration
• Initial setup includes the calibration process which comes after the language selection. You must
proceed calibration before using the washing machine.
• Empty the drum, and then tap and hold to start calibration.
• When calibration is complete, power turns off and then turns on automatically.
• If you want to proceed calibration again, tap and hold for 3 seconds to enter the system function and
select Calibration.
01 02 03 Language selection Calibration Welcome screen
Turn dial & Tap O
English(US)
Empty drum before calibrating
[Tap to skip]OWelcome!
04 Tutorial
Let’s explore your new washer!
[Tap to skip]O
Turn the dial to explore cycles
[Tap to skip]O
Now hold to start a cycle
[Tap ]O to skip
Tap to see
additional functions
[Tap ]O to skip
Try saving favorites
in My Cycles
A washer that knows you!
All Done!
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 28 2021/1/16 10:27:38
English
English 29
Laundry guidelines
STEP 1 Sort
Sort the laundry according to these criteria:
• Care Label: Sort the laundry into cottons, mixed fibres, synthetics, silks, wools, and rayon.
• colour: Separate whites from colours.
• Size: Mixing different sized items together in the drum improves the washing performance.
• Sensitivity: Wash delicate items separately, such as pure, new woollen items, curtains, and silk items.
Check the labels on the items.
NOTE
Make sure to check the care label on the clothing, and sort them accordingly before starting the wash.
STEP 2 Empty pockets
Empty all the pockets of your laundry items
• Metal objects such as coins, pins, and buckles on clothing may damage other laundry items as well as
the drum.
Turn clothing with buttons and embroideries inside out
• If trousers or jacket zippers are open while washing, the drum may be damaged. Zippers should be
closed and fixed with a string.
• Clothing with long strings may become entangled with other clothes. Make sure to tie the strings
before starting the wash.
STEP 3 Use a laundry net
• Brassieres (machine washable) must be placed in a laundry net. Metal parts of the brassieres may break
through and tear other laundry items.
• Small, light clothing such as socks, gloves, stockings, and handkerchiefs may become caught around
the door. Place them inside a fine laundry net.
• Do not wash the laundry net by itself without other laundry. This may cause abnormal vibrations that
could move the washing machine and result in injury.
STEP 4 Prewash (if necessary)
Select the Prewash option for the selected cycle if the laundry is heavily soiled. Do not use the Prewash
option when detergent is manually added into the drum.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 29 2021/1/16 10:27:38
English
Before you start
English30
STEP 5 Determine the load capacity
Do not overload the washing machine. Overloading may cause the washing machine to not wash properly.
For the load capacity for the type of clothing, see page 38.
NOTE
When washing bedding or bedding covers, the wash time may be lengthened or the spin efficiency may be
reduced. For bedding or bedding covers, the recommended maximum spin cycle speed is 800 rpm, and the
load capacity is 2.0 kg or less.
CAUTION
• Unbalanced laundry may reduce the spinning performance.
• Make sure the laundry is fully inserted in the drum and not caught in the door.
• Do not slam the door. Close the door gently. Otherwise, the door may not be closed properly.
STEP 6 Apply a proper detergent type
The type of detergent depends on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash
temperature, and degree of soiling. Make sure to use the laundry detergent that is designed for automatic
washing machines.
NOTE
• Follow the detergent manufacturer’s recommendations based on the weight of the laundry, the degree
of soiling, and the hardness of the water in your local area. If you are not sure about the water hardness,
contact a local water authority.
• Do not use detergent that tends to be hardened or solidified. This detergent may remain after the rinse
cycle, blocking the drain outlet.
CAUTION
When washing wool using the Wool cycle, use a detergent dedicated to wool items. If used with the Wool
cycle, powder detergent may remain on the laundry and discolour the laundry.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 30 2021/1/16 10:27:38
English
English 31
Laundry capsules
To get the best results from using laundry capsules, please follow these instructions.
1. Put the capsule in the bottom of the empty drum
towards the rear.
2. Put the laundry in the drum on top of the capsule.
CAUTION
For cycles using cold water or cycles that complete in less than one hour, the capsule may not dissolve
completely.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 31 2021/1/16 10:27:38
English
Before you start
English32
Detergent drawer guidelines
The manual dispenser models provide a three-compartment dispenser: the left compartment for the main
wash, the centre for fabric softeners, and the right for the preliminary wash.
A
1. Prewash compartment: Apply prewash detergent.
2. Main-wash compartment: Apply main-wash
detergent, water softener, soaking detergent, bleach,
and/or stain removers.
3. Softener compartment: Apply additives such as
fabric softener. Do not exceed the max line (A).
CAUTION
Do not use the following types of detergent in the drawer:
• Tablet, capsule, ball, or net types.
To apply washing agents to the manual dispenser
1. Slide open the detergent drawer.
2. Apply laundry detergent to the main-wash
compartment as instructed or recommended by the
manufacturer. To use liquid detergent, see page 34.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 32 2021/1/16 10:27:40
English
English 33
3. Apply fabric softener to the softener
compartment. Do not exceed the max line.
4. If you want to prewash, apply prewash detergent
to the prewash compartment as instructed or
recommended by the manufacturer.
5. Close the detergent drawer.
CAUTION
• Do not apply powder detergent to the liquid
detergent container.
• Concentrated fabric softener must be diluted with
water before applied.
• Do not apply main-wash detergent to the softener
compartment.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 33 2021/1/16 10:27:41
English
Before you start
English34
To use liquid detergent manually (applicable models only)
A
First insert the provided liquid detergent container in
the main-wash compartment. Then, apply liquid
detergent to the container below the marked max line
(A).
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 34 2021/1/16 10:27:41
English
English 35
Operations
Control panel
01 03
02
04
10
05 06 07 08 09
01 Power
Tap to turn the washing machine on or off.
• If you do not manipulate the control panel for 10 minutes after the
washing machine is turned on, the washing machine automatically
turns off.
• The washing machine automatically turns off when the cycle
completes.
CAUTION
Do not tap to turn the washing machine off while the wash cycle is in
progress. Tap and hold to pause the cycle first, and then tap to turn
the washing machine off.
02 Navigation dial
Turn the navigation dial left or right to navigate through cycles and
functions.
When you turn the navigation dial, LCD displays your selection (such as
cycle, additional functions, and system functions).
03 Start/Pause Tap and hold to start or pause an operation.
04 Display The display shows current cycle information and estimated time
remaining, or an information message when a problem occurs.
05 OK Tap to confirm your selection of function or setting.
06 Temp.
Tap to change the water temperature for the selected cycle.
• The indicator above the button indicates the default or selected
setting.
07 Rinse
Tap to change the rinse count for the selected cycle.
• The indicator above the button indicates the default or selected
setting.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 35 2021/1/16 10:27:42
English
Operations
English36
08 Spin
Tap to change the spin speed for the selected cycle.
• The indicator above the button indicates the default or selected
setting.
09 Additional function Tap to enter the additional functions menu.
Tap and hold for 3 seconds to enter the system functions menu.
10 Smart Control
Tap to activate or deactivate the Smart Control function.
Tap and hold to enter pairing mode to connect to the SmartThings app.
• When the Smart Control function is activated, you can control your
washing machine remotely using the SmartThings app on your
smartphone or tablet (Android or iOS).
Icon descriptions
Wi-Fi • This icon indicates that the washing machine is connected to Wi-Fi.
Smart Control • This icon indicates that Smart Control is on.
• For more information on Smart Control, see page 50.
Door Lock
• This icon indicates the door is locked and cannot be opened.
• The door locks automatically during a cycle and this indicator turns on.
• You can open the door when this icon disappears.
Child Lock • This icon indicates that Child Lock is on.
• For more information on Child Lock, see page 44.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 36 2021/1/16 10:27:44
English
English 37
Operating a cycle
2
5 3 4
61
1. Tap turn on the washing machine.
2. Turn the Navigation dial to select the cycle you want.
-For more information on Cycle overview, see page 38.
3. Tap , , or to change the default cycle settings.
4. Tap , and then turn the to select additional function.Navigation dial
-For more information on , see page Additional functions 42.
5. Tap to change the settings for selected additional function.
-Not all cycles have additional functions available.
6. Tap and hold to start operation.
-Once you set the cycle you want, the screen displays a brief cycle description, maximum laundry
load, and cycle time. You can also check the cycle progress, remaining cycle time, and information
codes.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 37 2021/1/16 10:27:44
English
Operations
English38
Cycle overview
Cycle Description
Max load (kg)
WD1*T******
WD9*T******
WD8*T******
Cotton
• For cottons, bed linens, table linens, underwear, towels,
or shirts. The washing time and the rinse count are
automatically adjusted according to the load.
• For cleaning lightly soiled cotton items at a nominal
temperature of 20 °C.
Max
AI Wash
(WD**T98*****,
WD**T93*****
model only)
• Adjusts the amount of detergent and the cycle according
to the load and the soil severity. This cycle is best used
with the Auto Dispense function.
Max
15' Quick Wash
For lightly soiled items in less than 2.0 kg that you want to
wash quickly.
• Use less than 20 g of detergent. Using more than 20 g of
detergent may leave detergent residue.
• For liquid detergent, use a max of 20 ml of liquid
detergent.
2
Super Speed
(WD**T9*****,
WD**T7*****,
WD**T6*****
models only)
• Fast completion for everyday items such as underwear
and shirts.
• The cycle time will differ depending on the water supply
conditions, load, and type of laundry.
5
Super Eco Wash • Low temperature ecobubble cycle helps reduce power
consumption. 4
E Cotton
• Optimal performance with lower energy for cotton
fabrics, bed linens, table linens, underwear, towels, or
shirts.
• For energy saving, the actual washing temperature may
be lower than specified.
Max
Synthetics • For fabrics that are made of polyester (diolen, trevira),
polyamide (perlon, nylon), or the like. 4
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 38 2021/1/16 10:27:44
English
English 39
Cycle Description
Max load (kg)
WD1*T******
WD9*T******
WD8*T******
Delicates
• For sheer fabrics, bras, lingerie (silk), and other
handwash-only fabrics.
• For best performance, use liquid detergent.
2
Towels • For bath towels, washcloths, and mats. 4
Bedding
• For bed spreads, bed sheets, bedding covers, etc.
• For best results, wash only 1 type of bedding and make
sure the load weighs less than 2.0 kg.
2
Shirts • For shirts, blouses that are made of cotton, synthetic
fiber. 2
Hygiene Steam
• Cotton and linen fabric which have been in direct contact
with the skin, such as underwear.
• For optimum hygiene results select a temperature of 60 °C
or above.
• Steam cycles feature allergy care and bacteria
elimination (sterilize).
4
Wool
• Specific for machine-washable wool for loads less than
2.0 kg.
• The Wool cycle features fine pulsating and soaking to
protect the wool fibres from shrinkage/distortion.
• A neutral detergent is recommended.
2
Outdoor
• For outdoor clothes, skiwear, and sportswear that are
made of functional materials such as spandex, stretch,
and micro-fibre.
2
Activewear
• For exercise wear such as sports jerseys, training pants,
shirts/tops and other performance clothing. This cycle
provides effective soil removal with controlled drum
rotation for special fabric care.
2
Colors
• Featuring additional rinses and reduced spinning to
ensure that the laundry is washed gently and rinsed
thoroughly.
4
Silent Wash • For reducing operating noise and vibration. 4
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 39 2021/1/16 10:27:44
English
Operations
English40
Cycle Description
Max load (kg)
WD1*T******
WD9*T******
WD8*T******
Daily Wash
(WD**T5*****
models only)
• For everyday items such as underwear and shirts. 4
Cloudy Day • For optimum spin drying at high humid condition. Max
Rinse+Spin • Featuring an additional rinse process after applying
fabric softener to the laundry. Max
Drain/Spin
• For draining the water inside the drum and running an
additional spin process to effectively remove moisture
from laundry.
Max
Drum Clean+
(WD**T9*****,
WD**T7*****,
WD**T6*****
models only)
• Cleans the drum by removing dirt and bacteria from it.
• Cleans the rubber door gasket by removing dirt from the
gasket.
• Perform once every 40 washes with no detergent or
bleach applied. Notification message appears after every
40 washes.
• Make sure the drum is empty.
• Do not use any cleaning agents for cleaning the drum.
-
Drum Clean
(WD**T5*****
models only)
• Cleans the drum by removing dirt and bacteria from it.
• Perform once every 40 washes with no detergent or
bleach applied. Notification message appears after every
40 washes.
• Make sure the drum is empty.
• Do not use any cleaning agents for cleaning the drum.
-
Dry cycle
Wash+Dry
• For cleaning normally soiled cotton items which are
declared to be washable at 40 °C or 60 °C, together in the
same cycle, and to dry them in such a way that it can be
immediately stored in a cupboard.
7 6 6
Cotton Dry • For general drying.
7 6 6
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 40 2021/1/16 10:27:44
English
English 41
Cycle Description
Max load (kg)
WD1*T******
WD9*T******
WD8*T******
Synthetics Dry • A low temperature drying cycle for heat-sensitive
garments.
3
Air Wash • This cycle is useful for removing bad odours. 1
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 41 2021/1/16 10:27:44
English
Operations
English42
Additional Functions
Using Additional Functions
1. Tap .
2. Turn the to select the desired additional function.Navigation dial
3. Tap to change the selected function’s settings or start the function.
NOTE
• To return to the main screen, tap again or turn the to select and tap Navigation dial Back .
• If the selected function is not supported, the “Currently not supported” message is displayed, and the
button is not activated.
• When you select an additional function, a brief help message appears for the first ten times of use.
Dry
You can add a drying process at the end of a wash cycle.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select , and then tap Navigation dial Dry .
4. Turn the or tap Navigation dial repeatedly to select the desired drying time.
-You can select from Off, Auto, , 30min 1hr 00min 1hr 30min 2hr 00min 3hr 00min, , , , or 4hr 00min.
5. Tap and hold .
Quick Drive (WD**T7***** models only)
You can reduce the overall washing time of the selected cycle settings.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select , and then tap Navigation dial Quick Drive .
4. Tap and hold .
Prewash
You can add a preliminary washing cycle before the main wash cycle.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select Navigation dial Prewash, and then tap .
4. Tap and hold .
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 42 2021/1/16 10:27:44
English
English 43
Intensive
For badly soiled laundry. The operation time for each cycle is longer than normal.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select , and then tap Navigation dial Intensive .
4. Tap and hold .
Bubble Soak
This function helps remove a wide variety of stubborn stains. With Bubble Soak selected, laundry is
thoroughly soaked in water bubbles for effective washing.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select , and then tap Navigation dial Bubble Soak .
-Bubble Soak is available with and adds up to 30 minutes to these cycles: Cotton, Synthetics,
Bedding, and Super Speed.
4. Tap and hold .
My Cycles
Add or remove cycles to create a personal cycle list.
1. Tap .
2. Turn the to select Navigation dial My Cycles, and then tap .
-You can only edit a cycle to create a personal cycle when the washing machine is not operating.
3. Turn the Navigation dial to select a desired cycle.
4. Tap to add or remove the selected cycle.
-Addition and removal of the course is saved automatically.
5. Once you finish creating My Cycles, tap to return to the cycles screen.
NOTE
• The E Cotton and Drum Clean+ cycles cannot be removed from the cycles list.
• You can also edit My Cycles in the SmartThings app.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 43 2021/1/16 10:27:44
English
Operations
English44
Delay End
You can set the washing machine to finish your wash automatically at a later time, choosing a delay of
between 1 to 24 hours (in 1 hour increments). The hour displayed indicates the time the wash will finish.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select Navigation dial Delay End, and then tap .
4. Turn the to select the desired time, and then tap Navigation dial .
5. Tap and hold .
-Status shows in the display and the washing machine tumbles the drum to sense the weight of the
load (if load sensing is preset for the selected cycle). When load sensing is complete, the display
shows the remaining time until the end of the wash cycle.
-To cancel Delay End, tap to restart the washing machine.
Child Lock
To prevent children or infants from accidentally starting or setting the washing machine, Child Lock locks
all buttons except for and .
1. Tap .
2. Turn the to select , and then tap Navigation dial Child Lock .
3. Tap to select On or Off.
-The Child Lock icon turns on when the function is on.
NOTE
• When Child Lock is on, all buttons are disabled except for and . The washing machine door also
locks.
• Tapping a button while Child Lock is on triggers an alarm with the “Child Lock On” message.
• You cannot open the door after a wash cycle when the Child Lock is on. Turn the function off before
opening the door to take out the laundry.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 44 2021/1/16 10:27:44
English
English 45
System Functions
Using System Functions
1. Tap and hold for 3 seconds.
2. Turn the Navigation dial and select the desired system function, and then tap .
3. Tap to change the selected function’s settings or start the function.
NOTE
To return to the main screen, tap again or turn the to select and tap Navigation dial Back .
AI Pattern
This function saves frequently used cycles and settings. When you turn the function on, the washing
machine remembers the cycles you use most and their settings (Temp., Rinse, Spin) and displays them in
frequency order.
1. Tap and hold for 3 seconds.
2. Turn the to select , and then tap Navigation dial AI Pattern .
3. Tap to select On or Off.
-The default setting is On. Set it to Off if you do not want to use this function.
-When you turn off the function, all the saved data resets.
Alarm
You can turn on or off the sound from the washing machine. When this function is set to Off, the AddWash
alarm, the melody of cycle completion, and the power-off beep does not sound. However, the other sounds
stay active.
1. Tap and hold for 3 seconds.
2. Turn the to select , and then tap Navigation dial Alarm .
3. Tap to select On or Off.
-The default setting is On.
NOTE
The setting remains unchained even if you restart the washing machine.
Calibration
You can run calibration again for accurate weight detection.
1. Tap and hold for 3 seconds.
2. Turn the to select , and then tap Navigation dial Calibration .
-Calibration does not start if the door is not closed properly.
-The drum rotates clockwise and anticlockwise for about 3 minutes.
3. When calibration is complete, the “Calibration complete” message appears on the display and the
washing machine turns off automatically.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 45 2021/1/16 10:27:45
English
Operations
English46
Wi-Fi
You can turn the washing machine's Wi-Fi on or off.
1. Tap and hold for 3 seconds.
2. Turn the to select , and then tap Navigation dial Wi-Fi .
3. Tap to select On or Off.
-The washing machine's Wi-Fi is off as a factory default setting. However, the washing machine's
Wi-Fi turns on automatically when you turn on the washing machine for the first time. Then, the final
Wi-Fi setting maintains regardless of the washing machine power status.
-Once you turn on the washing machine's Wi-Fi and connect to a network, the washing machine
remains connected to the network even when you turn off the power.
-The Wi-Fi indicates that the washing machine is connected to the router through the Wi-Fi
connection.
Language
You can change the system language.
1. Tap and hold for 3 seconds.
2. Turn the to select , and then tap Navigation dial Language .
3. Turn the to select the desired language, and then tap Navigation dial .
Factory Reset
You can reset the washing machine.
1. Tap and hold for 3 seconds.
2. Turn the to select Navigation dial Factory Reset, and then tap .
-Your washing machine resets to the factory setting.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 46 2021/1/16 10:27:45
English
English 47
Special features
AddWash (applicable models only)
To add laundry after the wash starts, use the AddWash door.
1. Tap and hold to stop the wash cycle.
2. Press the upper area of the AddWash door to unlock
the door. The door will move inward slightly when
you press it and then open.
3. Open the AddWash door fully, and then insert
additional laundry through the AddWash door into
the drum.
4. Lift the AddWash door back into position, and then
lock the door by pushing the upper area of the door
until you hear a click. Then, tap and hold again to
resume the wash cycle.
CAUTION
Do not put excessive force on the AddWash door. It may
break.
NOTE
The water inside the drum does not leak if the AddWash door is closed properly. Water drops may form
around the AddWash door, but water will not leak from inside the drum. This is normal.
CAUTION
• Do not open the AddWash door if suds have formed inside the drum that rise above the level of the
Addwash door.
• Do not attempt to open the AddWash door while the machine is operating without first tapping and
holding . Please note that the AddWash door can be opened unintentionally (without tapping and
holding ) when the wash is complete.
• Do not add an excessive load through the AddWash door. Performance may be degraded.
• Do not use the lower area of the AddWash door as a handle. Your fingers may be caught.
• Make sure that no laundry is caught in the AddWash door.
• Keep your pets out of the washing machine, especially the AddWash door.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 47 2021/1/16 10:27:45
English
Operations
English48
• When using hot water for the wash, the AddWash door may appear to leak water after opening and
closing the AddWash door. This is normal, simply because steam emerging from the open AddWash
door has cooled and formed water drops on the surface.
• When the AddWash door closes, the door seals up and no water can leak. However, you may encounter
what appears to be water leak around the door - some residual water remaining around the AddWash
door may form water drops. This is normal.
• Neither the main door nor the AddWash door can be opened when the water temperature is over 50 °C.
If the water level inside the drum is over a certain point, the main door cannot be opened.
• If an information code of ‘AddWash door is open’ appears on the display, see the Information codes
section for further actions.
• Keep the AddWash door and its surroundings clean at all times. Debris or detergent on or around the
seals of the AddWash door may cause a leak.
Adding laundry for non-AddWash models (applicable models only)
1. Tap and hold to stop the wash cycle.
2. Open the door and add the laundry into the drum.
3. Close the door, and then tap and hold again to resume the wash cycle.
Smart control (applicable models only)
You can connect to the SmartThings app and control your washing machine remotely.
Connecting your washing machine
1. Download and open the SmartThings app on your smartphone or tablet (Android & iOS).
2. Tap to turn on the washing machine.
3. Tap and hold .
a. The washing machine enters AP mode and connects to your smartphone or tablet.
b. Tap to authenticate your washing machine.
c. Once the authentication process is complete, your washing machine is successfully connected to the
app.
-You can use various features available in the SmartThings app.
NOTE
• If your washing machine fails to connect with the SmartThings app, try again.
• Check your router if you experience any Internet connection problem after connecting your washing
machine with the SmartThings app.
• If the Wi-Fi is off, tap and hold for 3 seconds to enter the System functions menu, and select Wi-Fi to
turn it on.
• Turning the washing machine's Wi-Fi on allows you connect to the washing machine via SmartThings
app on your smartphone or tablet, regardless of the power status of the washing machine. However, the
washing machine appears offline on the SmartThings app if the washing machine's Wi-Fi is off.
• Close the door before starting the Smart Control function.
• If you use your washing machine for a while without connecting it to the SmartThings app, a pop-up
message about Smart Control will show for 3 seconds.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 48 2021/1/16 10:27:45
English
English 49
• If the washing machine's Wi-Fi is not connected to an AP (access point), the Wi-Fi will turn off when you
turn of the power.
Stay Connect
Set up the Stay Connect function in your SmartThings app to keep Smart Control turned on at the end of a
cycle. Your washing machine stays connected to the app so you can send additional instructions, whether
you are at home or away.
1. If you turn on the Stay Connect function on the SmartThings app, the washing machine will stay in
standby power saving mode after completing a cycle.
-The Stay Connect function will remain active for up to 7 days if the door remains closed.
2. When the Stay Connect function is active, the Smart Control, Door Lock, and Wi-Fi icons are illuminated
on your washing machine display.
3. You can conveniently control your washing machine, adding rinse, spin or dry cycles using the
SmartThings app.
NOTE
• The washing machine switches to standby power saving mode when operation is paused even if the
machine is not connected to the SmartThings app.
• In some circumstances, only the Door Lock icon may be illuminated.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 49 2021/1/16 10:27:46
English
Operations
English50
SmartThings
Wi-Fi connection
On your smartphone or tablet, go to and turn on the wireless connection and select an AP (Access Settings
Point).
• This appliance supports the Wi-Fi 2.4 GHz protocols.
Download
On an app market (Google Play Store, Apple App Store, Samsung Galaxy Apps), find the SmartThings app
with a search term of “SmartThings”. Download and install the app on your device.
NOTE
The app is subject to change without notice for improved performance.
Log in
You must first log into SmartThings with your Samsung account. To create a new Samsung account, follow
the instructions on the app. You don’t need a separate app to create your account.
NOTE
If you have a Samsung account, use the account to log in. A registered Samsung smartphone or tablet user
automatically logs in.
To register your appliance to SmartThings
1. Make sure your smartphone or tablet is connected to a wireless network. If not, go to Settings and turn
on the wireless connection and select an AP (Access Point).
2. SmartThingsOpen on your smartphone or tablet.
3. If a message of “A new device is found.”, select Add.
4. If no message appears, select and select your appliance in a list of devices available. If your appliance +
is not listed, select Device Type Specific Device Model > , and then add your appliance manually.
5. Register your appliance to the SmartThings app as follows.
a. Add your appliance to SmartThings. Make sure your appliance is connected to SmartThings.
b. When registration is complete, your appliance appears on your smartphone or tablet.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 50 2021/1/16 10:27:46
English
English 51
Open Source Announcement
The software included in this product contains open source software. You may obtain the complete
corresponding source code for a period of three years after the last shipment of this product by contacting
our support team via http://opensource.samsung.com (Please use the “Inquiry” menu.)
It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-
ROM; a minimal charge will be required.
The following URL http://opensource.samsung.com/opensource/SMART_AT_051/seq/0 leads to the
open source license information as related to this product. This offer is valid to anyone in receipt of this
information.
NOTE
Hereby, Samsung Electronics, declares that the radio equipment type appliance is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet
address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support >
Search Product Support and enter the model name.
Wi-Fi max transmitter power : 20 dBm at 2.412 GHz – 2.472 GHz
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 51 2021/1/16 10:27:46
English
English52
Maintenance
Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle.
Drum Clean+
Perform this cycle regularly to clean the drum by removing bacteria from it. This cycle heats the water
between 60 °C and 70 °C, and it also removes accumulated dirt from the rubber door gasket.
1. Tap .
2. Turn the to select Navigation dial Drum Clean+.
3. Tap and hold .
CAUTION
• Do not use any cleaning agents for cleaning the drum. Chemical residue in the drum may cause damage
to the laundry or the drum of the washing machine.
• To prevent limescale, add the proper amount of detergent according to your local water hardness or add
a water softener additive together with the detergent.
Drum Clean+ reminder
Depending on the model, the Drum Clean+ reminder is either an icon or an LED.
For icons, the icon lights up on the control panel.
For LEDs, the LED lights up next to , or on the option area of the control panel. Drum Clean+
• The Drum Clean+ reminder blinks on the control panel once every 40 washes. It is advisable to perform
Drum Clean+ regularly.
• When you first see this reminder blinking, you can ignore the reminder for 6 consecutive washes. From
the 7 th wash, the reminder no longer appears. However, it appears again on the second 40 th wash.
• Even after the last process is terminated, the “ ” message may remain.0
• You can record the running count of the cycle by tapping Drum Clean+ . This does not stop or turn off
the machine but marks your cycle count.
• Even if “0” does not disappear, the machine operates normally.
• It is recommended to run the cycle regularly for hygienic purposes.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 52 2021/1/16 10:27:46
English
Maintenance
English54
Cleaning
Surface of the washing machine
Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the washing machine.
AddWash door (applicable models only)
A
1. Open the AddWash door.
2. Use a wet cloth to clean the AddWash door.
-Do not use cleaning agents. Discolouration
may occur.
-Use caution when cleaning the rubber packing
and the locking mechanism (A).
-Dust off the door area regularly.
3. Wipe up and close the AddWash door until you
hear a clicking sound.
CAUTION
• Do not apply force on the AddWash door. It may break.
• Do not leave the AddWash door open while the machine is operating.
• Do not put heavy objects on the AddWash door at any time.
• To prevent physical injury, do not touch the AddWash door while the drum is rotating.
• Do not open the AddWash door while the machine is operating. This may cause physical injury.
• Do not manipulate the feature panel while the AddWash door is open. This may cause physical injury or
system failure.
• Do not input objects other than laundry.
• Do not input bulky items to the drum through the AddWash door.
• Do not pull out the rubber packing of the AddWash door when cleaning. This may cause damage.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 54 2021/1/16 10:27:47
English
English 55
Mesh filter
Clean the mesh filter of the water hose once or twice a year.
1. Turn off the washing machine, and unplug the
power cord.
2. Close the water tap.
3. Loosen and disconnect the water hose from the
back of the washing machine. Cover the hose
with a cloth to prevent water from gushing out.
4. Use pliers to pull out the mesh filter from the
inlet valve.
5. Submerge the mesh filter deeply in water so that
the threaded connector is also submerged.
6. Dry the mesh filter completely in the shade.
7. Reinsert the mesh filter into the inlet valve, and
reconnect the water hose to the inlet valve.
8. Open the water tap.
NOTE
If the mesh filter is clogged, an information code of “Check water supply” appears on the screen.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 55 2021/1/16 10:27:48
English
Maintenance
English56
Debris filter
It is advisable to clean the debris filter every 2 months to prevent its clogging. A clogged debris filter may
reduce the bubble effect.
1. Turn off the washing machine, and unplug the
power cord.
2. Drain the remaining water inside the drum. See
the Emergency drain section.
3. Gently press the top area of the filter cover to
open.
4. Turn the debris filter knob to the left, and drain
off the remaining water.
5. Clean the debris filter using soft brushes. Make
sure the drain pump propeller inside the filter is
unclogged.
6. Reinsert the debris filter, and turn the filter knob
to the right.
NOTE
• Some debris filters feature a safety knob that
is designed to prevent accidents by children. To
open the safety knob of the debris filter, push in
and turn it anticlockwise. The spring mechanism
of the safety knob helps open the filter.
• To close the safety knob of the debris filter, turn
it clockwise. The spring makes a rattling sound,
which is normal.
NOTE
If the pump filter is clogged, an information code of “Check drainage” appears on the screen.
CAUTION
• Make sure the filter knob is closed properly after cleaning the filter. Otherwise, this may cause a leak.
• Make sure the filter is inserted properly after cleaning it. Otherwise, this may cause an operational
failure or a leak.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 56 2021/1/16 10:27:49
English
English 57
Detergent drawer
1. While holding down the release lever inside the
drawer, slide open the drawer.
2. Clean the drawer components in flowing water using
a soft brush.
3. Clean the drawer recess using a soft brush.
4. Reinsert the liquid detergent container to the drawer.
5. Slide the drawer inward to close it.
NOTE
Make sure the drawer recess is completely dry before
inserting the detergent drawer.
NOTE
To remove remaining detergent, perform the cycle with the drum being empty.Rinse+Spin
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 57 2021/1/16 10:27:50
English
Maintenance
English58
Defrosting your washing machine
The washing machine may freeze when it drops below 0 °C.
1. Turn off the washing machine, and unplug the power cord.
2. Pour warm water over the water tap to loosen the water hose.
3. Disconnect the water hose, and soak it in warm water.
4. Pour warm water into the drum and leave it for about 10 minutes.
5. Reconnect the water hose to the water tap.
NOTE
If the washing machine still doesn’t operate normally, repeat the above steps until it operates normally.
Care against an extended time of disuse
Avoid leaving the washing machine unused for an extended time. If this is the case, drain the washing
machine and unplug the power cord.
1. Turn the to select Navigation dial Rinse+Spin.
2. Empty the drum, and then tap and hold .
3. When the cycle is complete, close the water tap and disconnect the water hose.
4. Turn off the washing machine, and unplug the power cord.
5. Open the door to let air circulate through the drum.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 58 2021/1/16 10:27:50
English
English 59
Troubleshooting
If there is any problem, check the information message on the LCD screen and follow the on-screen
instructions.
If the problem persists, please contact the service center.
Checkpoints
If you encounter a problem with the washing machine, first check the table below and try these
suggestions.
Problem Action
Does not start.
• Make sure the washing machine is plugged in.
• Make sure the door is properly closed.
• Make sure the water taps are open.
• Tap and hold to start the washing machine.
• Make sure Child Lock is not activated.
• Before the washing machine starts to fill, it will make a series of clicking
noises to check the door lock and will do quick drain.
• Check the fuse or reset the circuit breaker.
• Check if power is supplied properly.
• Low voltage detected.
-Check if the power cord is plugged in.
• Make sure laundry is not caught in the door.
• The “AddWash door is open” message appears when you open the
AddWash door without tapping and holding . If this happens, do one of
the following:
• Press the AddWash door to close properly. Then, tap and hold and try
again.
• To add laundry, open the AddWash door and put in laundry. close the
AddWash door completely. Then, tap and hold to resume operation.
Water supply is
insufficient, or no water
is supplied.
• Fully open the water tap.
• Make sure the door is properly closed.
• Make sure the water supply hose is not frozen.
• Make sure the water supply hose is not kinked or clogged.
• Make sure there is sufficient water pressure.
• Make sure that the cold water tap and the hot water tap are properly
connected.
• Clean the mesh filter as it may be clogged.
After a cycle, detergent
remains in the
detergent drawer.
• Make sure the washing machine is running with sufficient water pressure.
• Make sure the detergent is added to the centre of the detergent drawer.
• Make sure the rinse cap is inserted properly.
• If using granular detergent, make sure the detergent selector is in the
upper position.
• Remove the rinse cap and clean the detergent drawer.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 59 2021/1/16 10:27:50
English
Troubleshooting
English60
Problem Action
Excessive vibrations or
makes noise.
• Make sure the washing machine is installed on a level, solid floor that is
not slippery. If the floor is not level, use the levelling feet to adjust the
height of the washing machine.
• Make sure the shipping bolts are removed.
• Make sure the washing machine is not in contact with any other object.
• Make sure the laundry load is balanced.
• The motor can cause noise during normal operation.
• Overalls or clothes with metallic decorations can cause noise while being
washed. This is normal.
• Metal objects such as coins can cause noise. After washing, remove these
objects from the drum or filter case.
• Redistribute the load. If only one item of clothing needs washing, such as
a bathrobe or pair of jeans, the final spin result might be unsatisfactory,
and a “Unbalanced laundry detected” check message will be shown in the
display.
Does not drain and/
or spin.
• Make sure the drain hose is straightened all the way to the drain system. If
you encounter a drain problem, call for service.
• Make sure the debris filter is not clogged.
• Close the door and tap and hold .
For your safety, the washing machine will not tumble or spin unless the
door is closed.
• Make sure the drain hose is not frozen or clogged.
• Make sure the drain hose is connected to a drain system that is not
clogged.
• If the washing machine is not supplied with sufficient power, the washing
machine will temporarily not drain or spin. As soon as the washing
machine regains sufficient power, it will operate normally.
• Make sure the drain hose is positioned correctly, depending on the
connection type.
• Clean the debris filter as it may be clogged.
The door does not
open.
• Tap and hold to stop the washing machine.
• It may take a few moments for the door lock mechanism to disengage.
• The door will not open until 3 minutes after the washing machine has
stopped or the power has been off.
• Make sure all the water in the drum is drained.
• The door may not open if water remains in the drum. Drain the drum and
open the door manually.
• Make sure the door lock light is off. The door lock light turns off after the
washing machine has drained.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 60 2021/1/16 10:27:50
English
English 61
Problem Action
Excessive suds.
• Make sure you use the recommended types of detergent as appropriate.
• Use high efficiency (HE) detergent to prevent oversudsing.
• Reduce the detergent amount for soft water, small loads, or lightly soiled
loads.
• Non-HE detergent is not recommended.
Cannot add additional
detergent.
• Make sure the remaining amount of detergent and fabric softener is not
over the limit.
Stops.
• Plug the power cord into a live electrical outlet.
• Check the fuse or reset the circuit breaker.
• Close the door, and tap and hold to start the washing machine. For your
safety, the washing machine will not tumble or spin unless the door is
closed.
• Before the washing machine starts to fill, it will make a series of clicking
noises to check the door lock and will do quick drain.
• There may be a pause or soak period in the cycle. Wait briefly, and the
washing machine may start.
• Make sure the mesh filter of the water supply hose at the water taps is not
clogged. Periodically clean the mesh filter.
• If the washing machine is not supplied with sufficient power, the washing
machine will temporarily not drain or spin. As soon as the washing
machine regains sufficient power, it will operate normally.
Fills with the wrong
water temperature.
• Fully open both taps.
• Make sure the temperature selection is correct.
• Make sure the hoses are connected to the correct taps. Flush water lines.
• Make sure the water heater is set to supply a minimum of 49 °C hot water
at the tap. Also, check the water heater capacity and recovery rate.
• Disconnect the hoses and clean the mesh filter. The mesh filter may be
clogged.
• While the washing machine fills, the water temperature may change
as the automatic temperature control feature checks incoming water
temperature. This is normal.
• While the washing machine fills, you may notice just hot and/or just cold
water going through the dispenser when cold or warm temperatures are
selected. This is a normal function of the automatic temperature control
feature as the washing machine determines the water temperature.
Load is wet at the end
of a cycle.
• Use the High or Extra High spin speed.
• Use high efficiency (HE) detergent to reduce oversudsing.
• Load is too small. Small loads (one or two items) may become unbalanced
and not spin completely.
• Make sure the drain hose is not kinked or clogged.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 61 2021/1/16 10:27:50
English
Troubleshooting
English62
Problem Action
Leaks water.
• Make sure the door is properly closed.
• Make sure all hose connections are tight.
• Make sure the end of the drain hose is correctly inserted and secured to
the drain system.
• Avoid overloading.
• Use high efficiency (HE) detergent to prevent oversudsing.
• Check the drain hose.
- Make sure the end of the drain hose is not placed on the floor.
- Make sure the drain hose is not clogged.
Has odours.
• Excessive suds collect in recesses and can cause foul odours.
• Run cleansing cycles to sanitise periodically.
• Clean the door seal (diaphragm).
• Dry the washing machine interior after a cycle has finished.
No bubbles are seen
(Bubble models only).
• You may not be able to see bubbles if there is too much items in the drum.
• Severely contaminated laundry may not generate bubbles.
Can I open the
AddWash door at any
time?
• The AddWash door can be opened only when the indicator appears.
However, it does not open in the following cases:
- When the boiling or drying process is running and the internal
temperature becomes high
- If you set the Child Lock for safety reasons
- When the drum wash or drum drying cycle that does not involve
additional laundry is running.
A message appears on
the display to alert that
dispenser is open.
• Check if the detergent drawer is closed properly.
- Open the detergent drawer and close it again. Make sure it’s closed
properly.
If a problem persists, contact a service center. The number of the service center is on the label attached to
the product.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 62 2021/1/16 10:27:50
English
English 63
Information codes
If the washing machine fails to operate, you may see an information code on the screen. Check the table
below and try the suggestions.
Code Action
Check drainage
Water is not draining.
• Make sure the drain hose is not frozen or clogged.
• Make sure the drain hose is positioned correctly, depending on the
connection type.
• Clean the debris filter as it may be clogged.
• Make sure the drain hose is straightened all the way to the drain system.
• If the information code remains, contact a customer service centre
Check water supply
Water is not supplied.
• Make sure the water taps are open.
• Make sure the water hoses are not clogged.
• Make sure the water taps are not frozen.
• Make sure the washing machine is operating with sufficient water
pressure.
• Make sure that the cold water tap and the hot water tap are properly
connected.
• Clean the mesh filter as it may be clogged.
• All buttons will be disabled for 3 minutes after the information code
appears.
• When the "Check water supply" message appears, the machine drains
water for 3 minutes. In the meantime, the Power button will be disabled.
Check water lines
• Make sure the cold water supply hose is firmly connected to the cold water
tap. If it is connected to the hot water tap, the laundry may be deformed
with some cycles.
Unbalanced laundry
detected
Spinning does not work.
• Make sure laundry is spread out evenly.
• Make sure the washing machine is on a flat, stable surface.
• Redistribute the load. If only one item of clothing needs washing, such as
a bathrobe or pair of jeans, the final spin result might be unsatisfactory,
and an “Unbalanced laundry detected” check message will be shown in
the display.
Door is open
Operating the washing machine with the door open.
• Make sure the door is properly closed.
• Make sure laundry is not caught in the door.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 63 2021/1/16 10:27:50
English
Troubleshooting
English64
Code Action
Addwash door is open
(applicable models
only)
This message appears when you open the Add Door without pressing Start/
Pause (Hold to Start). If this happens, do one of the following:
• Press the Add Door to close properly. Then, press and hold Start/Pause
(Hold to Start) and try again.
• To add laundry, open the Add Door and input laundry. Close the Add Door
properly. Then, press and hold Start/Pause (Hold to Start) to resume
operation.
OC
Water has overflowed.
• Restart after spinning.
• If the information code remains on the display, contact a local Samsung
service centre.
LC LC1,
Check the drain hose.
• Make sure the end of the drain hose is not placed on the floor.
• Make sure the drain hose is not clogged.
• If the information code remains, contact a customer service centre.
3C
Check the drum motor for operation.
• Try restarting the cycle.
• If the information code remains, contact a customer service centre.
3CP
The electronic control needs to be checked.
• Try restarting the cycle.
• If the information code remains, contact a customer service centre.
UC
Check the pulsator motor for operation.
• Check if power is supplied properly.
• If the information code remains, contact a customer service centre.
Low voltage detected.
• Check if the power cord is plugged in.
• If the information code remains, contact a customer service centre.
HC High temperature heating check.
• If the information code remains, contact a customer service centre.
1C
The Water Level sensor is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service centre.
AC
Check communications between main and sub PBAs.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service centre.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 64 2021/1/16 10:27:50
English
English 65
Code Action
8C
The MEMS sensor is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service centre.
AC6
Check communications between the main and the inverter PBAs.
• Depending on the state, the machine may automatically returns to normal
operation.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service centre.
DC1
The Main Door lock/unlock is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service centre.
DC3
The Add Door lock/unlock is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service centre.
FC
The drying fan motor is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a local Samsung service centre.
HC2
The drying heater is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a local Samsung service centre.
If any information code keeps appearing on the screen, contact a local Samsung service centre.
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 65 2021/1/16 10:27:50
English
English66
Specifications
Fabric care chart
The following symbols provide garment care directions. The care labels include four symbols in this order:
washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures
consistency among garment manufacturers of domestic and imported items. Follow the care label
directions to maximise garment life and reduce laundry problems.
Resistant material Do not iron
Delicate fabric Can be dry cleaned using any solvent
Item can be washed at 95 °C Dry clean
Item can be washed at 60 °C Dry clean with perchloride, lighter
fuel, pure alcohol or R113 only
Item can be washed at 40 °C Dry clean with aviation fuel, pure
alcohol or R113 only
Item can be washed at 30 °C Do not dry clean
Hand wash only Dry flat
Dry clean only Can be hung to dry
Can be bleached in cold water Dry on clothes hanger
Do not bleach Tumble dry, normal heat
Can be ironed at 200 °C max Tumble dry, reduced heat
Can be ironed at 150 °C max Do not tumble dry
Can be ironed at 100 °C max
U-PJT_COMBO-MD_SimpleUX_DC68-04199U-00_EN.indd 66 2021/1/16 10:27:57
Produktspecifikationer
| Varumärke: | Samsung |
| Kategori: | tvättmaskin |
| Modell: | WD90T654DBX |
| Färg på produkten: | Zwart |
| Bredd: | 139.7 mm |
| Djup: | 122.174 mm |
| Höjd: | 55.118 mm |
| Snäll: | Digitale wekker |
| Kraftkälla: | USB |
| Antal USB 2.0-portar: | 1 |
| Antal per paket: | 1 stuk(s) |
| USB-laddningsport: | Ja |
| Färgskärm: | Nee |
| Laddning via USB: | Ja |
Behöver du hjälp?
Om du behöver hjälp med Samsung WD90T654DBX ställ en fråga nedan och andra användare kommer att svara dig
tvättmaskin Samsung Manualer
5 April 2025
5 April 2025
5 April 2025
5 April 2025
4 April 2025
4 April 2025
4 April 2025
3 April 2025
2 April 2025
2 April 2025
tvättmaskin Manualer
- tvättmaskin Candy
- tvättmaskin Electrolux
- tvättmaskin LG
- tvättmaskin Bosch
- tvättmaskin AEG
- tvättmaskin IKEA
- tvättmaskin Panasonic
- tvättmaskin AEG Electrolux
- tvättmaskin Bauknecht
- tvättmaskin BEKO
- tvättmaskin Delonghi
- tvättmaskin Daewoo
- tvättmaskin Etna
- tvättmaskin Grundig
- tvättmaskin Indesit
- tvättmaskin Inventum
- tvättmaskin Kenwood
- tvättmaskin Miele
- tvättmaskin Medion
- tvättmaskin Quigg
- tvättmaskin Siemens
- tvättmaskin Toshiba
- tvättmaskin Whirlpool
- tvättmaskin Zanussi
- tvättmaskin Zanker
- tvättmaskin Acec
- tvättmaskin Adler
- tvättmaskin Alpina
- tvättmaskin Amica
- tvättmaskin Akai
- tvättmaskin Aldi
- tvättmaskin Amana
- tvättmaskin Ardo
- tvättmaskin Ariston
- tvättmaskin Arcelik
- tvättmaskin Aristona
- tvättmaskin Asko
- tvättmaskin Ahma
- tvättmaskin OneConcept
- tvättmaskin Eurom
- tvättmaskin GE
- tvättmaskin Sharp
- tvättmaskin Techwood
- tvättmaskin Fisher And Paykel
- tvättmaskin Bertazzoni
- tvättmaskin Lamona
- tvättmaskin Fagor
- tvättmaskin Brandt
- tvättmaskin Omega
- tvättmaskin Smeg
- tvättmaskin Telefunken
- tvättmaskin Gorenje
- tvättmaskin Neff
- tvättmaskin Palsonic
- tvättmaskin Baumatic
- tvättmaskin Hitachi
- tvättmaskin Nedis
- tvättmaskin Thomson
- tvättmaskin Hoover
- tvättmaskin Saturn
- tvättmaskin Black And Decker
- tvättmaskin KitchenAid
- tvättmaskin Domo
- tvättmaskin Teka
- tvättmaskin Nordland
- tvättmaskin Cata
- tvättmaskin Pyle
- tvättmaskin Gaggenau
- tvättmaskin Hotpoint-Ariston
- tvättmaskin Zanussi-electrolux
- tvättmaskin Ignis
- tvättmaskin Calor
- tvättmaskin Tomado
- tvättmaskin Kernau
- tvättmaskin Maytag
- tvättmaskin Manta
- tvättmaskin Hisense
- tvättmaskin Hyundai
- tvättmaskin Hanseatic
- tvättmaskin Vox
- tvättmaskin Cylinda
- tvättmaskin Dyson
- tvättmaskin Avanti
- tvättmaskin Westinghouse
- tvättmaskin Vestel
- tvättmaskin ECG
- tvättmaskin Pelgrim
- tvättmaskin Blomberg
- tvättmaskin Bush
- tvättmaskin Magic Chef
- tvättmaskin Swan
- tvättmaskin RCA
- tvättmaskin Clatronic
- tvättmaskin Russell Hobbs
- tvättmaskin Constructa
- tvättmaskin John Lewis
- tvättmaskin Summit
- tvättmaskin Hotpoint
- tvättmaskin Midea
- tvättmaskin Prima
- tvättmaskin De Dietrich
- tvättmaskin Mabe
- tvättmaskin Concept
- tvättmaskin Gram
- tvättmaskin Monogram
- tvättmaskin Frigidaire
- tvättmaskin Iberna
- tvättmaskin Svan
- tvättmaskin Logik
- tvättmaskin Danby
- tvättmaskin Balay
- tvättmaskin Stirling
- tvättmaskin PKM
- tvättmaskin Carson
- tvättmaskin Frilec
- tvättmaskin Rosieres
- tvättmaskin Mesko
- tvättmaskin Salora
- tvättmaskin Scholtes
- tvättmaskin Profilo
- tvättmaskin CDA
- tvättmaskin Finlux
- tvättmaskin Castor
- tvättmaskin Intex
- tvättmaskin Heinner
- tvättmaskin Sanyo
- tvättmaskin Kenmore
- tvättmaskin Hoover-Helkama
- tvättmaskin Philco
- tvättmaskin TCL
- tvättmaskin Juno
- tvättmaskin Nabo
- tvättmaskin Defy
- tvättmaskin Schulthess
- tvättmaskin Infiniton
- tvättmaskin Otsein-Hoover
- tvättmaskin Aspes
- tvättmaskin Premium
- tvättmaskin White Knight
- tvättmaskin Sunny
- tvättmaskin Easymaxx
- tvättmaskin Blanco
- tvättmaskin Orima
- tvättmaskin Trebs
- tvättmaskin Luxor
- tvättmaskin Nordmende
- tvättmaskin Husqvarna
- tvättmaskin Koenic
- tvättmaskin Haier
- tvättmaskin Friac
- tvättmaskin Ariston Thermo
- tvättmaskin Viking
- tvättmaskin Dexter
- tvättmaskin Wolkenstein
- tvättmaskin Hansa
- tvättmaskin Polar
- tvättmaskin Thor
- tvättmaskin Kubo
- tvättmaskin Benavent
- tvättmaskin Exquisit
- tvättmaskin Elba
- tvättmaskin Proline
- tvättmaskin Euromaid
- tvättmaskin Corberó
- tvättmaskin Crosley
- tvättmaskin WLA
- tvättmaskin New Pol
- tvättmaskin Ansonic
- tvättmaskin Laden
- tvättmaskin Kelvinator
- tvättmaskin Element
- tvättmaskin Olympia
- tvättmaskin Everglades
- tvättmaskin Bomann
- tvättmaskin Zerowatt
- tvättmaskin Kuppersbusch
- tvättmaskin Continental Edison
- tvättmaskin Freggia
- tvättmaskin Insignia
- tvättmaskin Listo
- tvättmaskin Edesa
- tvättmaskin Milectric
- tvättmaskin Lloyd
- tvättmaskin Franke
- tvättmaskin New World
- tvättmaskin AYA
- tvättmaskin Camry
- tvättmaskin Nodor
- tvättmaskin Speed Queen
- tvättmaskin WhiteLine
- tvättmaskin Bompani
- tvättmaskin Jocel
- tvättmaskin Viva
- tvättmaskin Koblenz
- tvättmaskin Electra
- tvättmaskin Rex
- tvättmaskin Creda
- tvättmaskin Comfee
- tvättmaskin Atlantic
- tvättmaskin Meireles
- tvättmaskin Technika
- tvättmaskin Scandomestic
- tvättmaskin Aurora
- tvättmaskin V-Zug
- tvättmaskin Godrej
- tvättmaskin Sauber
- tvättmaskin Chiq
- tvättmaskin MPM
- tvättmaskin Zenith
- tvättmaskin Becken
- tvättmaskin Esatto
- tvättmaskin Belling
- tvättmaskin Tesla
- tvättmaskin Mx Onda
- tvättmaskin Orion
- tvättmaskin Kleenmaid
- tvättmaskin Hilton
- tvättmaskin Essentiel B
- tvättmaskin Mestic
- tvättmaskin Bendix
- tvättmaskin Privileg
- tvättmaskin Vivax
- tvättmaskin Edy
- tvättmaskin Nevir
- tvättmaskin Zoppas
- tvättmaskin Edgestar
- tvättmaskin Simpson
- tvättmaskin Parmco
- tvättmaskin Caple
- tvättmaskin Eurotech
- tvättmaskin Carrefour Home
- tvättmaskin Equator
- tvättmaskin Triumph
- tvättmaskin Vestfrost
- tvättmaskin Kunft
- tvättmaskin Integra
- tvättmaskin Upo
- tvättmaskin Hestan
- tvättmaskin Rommer
- tvättmaskin ZLine
- tvättmaskin Belion
- tvättmaskin SIBIR
- tvättmaskin Calex
- tvättmaskin Trieste
- tvättmaskin Veripart
- tvättmaskin Butler
- tvättmaskin DEXP
- tvättmaskin Lynx
- tvättmaskin Flavel
- tvättmaskin Teco
- tvättmaskin Cecotec
- tvättmaskin Bluesky
- tvättmaskin Videocon
- tvättmaskin Arctic Cooling
- tvättmaskin Otsein
- tvättmaskin Tisira
- tvättmaskin Wasco
- tvättmaskin Icecool
- tvättmaskin Cobal
- tvättmaskin Premier
- tvättmaskin Atlas
- tvättmaskin Kalorik
- tvättmaskin Marynen
- tvättmaskin Morris
- tvättmaskin Galanz
- tvättmaskin Khind
- tvättmaskin Laurus
- tvättmaskin Eudora
- tvättmaskin Thomas
- tvättmaskin Linetech
- tvättmaskin Kogan
- tvättmaskin PolyJohn
- tvättmaskin Signature
- tvättmaskin ZWF81443W
- tvättmaskin Romo
- tvättmaskin T&S
- tvättmaskin Consul
- tvättmaskin Cambro
- tvättmaskin LERAN
- tvättmaskin Fensa
- tvättmaskin Ursus Trotter
- tvättmaskin Simplicity
- tvättmaskin Elin
- tvättmaskin High One
- tvättmaskin Companion
- tvättmaskin Codini
- tvättmaskin Curtiss
- tvättmaskin Vedette
- tvättmaskin Winia
- tvättmaskin Artusi
- tvättmaskin Robinhood
- tvättmaskin Ocean
- tvättmaskin IPSO
- tvättmaskin Imesa
- tvättmaskin Sôlt
- tvättmaskin Ravanson
- tvättmaskin Fisher Paykel
- tvättmaskin Arda
- tvättmaskin Camec
- tvättmaskin Hiberg
- tvättmaskin Americana
- tvättmaskin Horn
- tvättmaskin MegaMove
- tvättmaskin Lemair
- tvättmaskin ARC
- tvättmaskin FAURE
- tvättmaskin Novamatic
- tvättmaskin KIN
- tvättmaskin Emilia
- tvättmaskin BSK
- tvättmaskin Miele Professional
- tvättmaskin Mio Star
- tvättmaskin IFB
- tvättmaskin Germanica
- tvättmaskin Adora
- tvättmaskin Newpol
- tvättmaskin Samus
- tvättmaskin Dexter Laundry
- tvättmaskin SEIKI
- tvättmaskin Haden
- tvättmaskin Howdens
- tvättmaskin Drean
- tvättmaskin Euro Appliances
- tvättmaskin Dishlex
- tvättmaskin Arthur Martin-Electrolux
- tvättmaskin Elektra Bregenz
- tvättmaskin Tuscany
- tvättmaskin Porter & Charles
- tvättmaskin Café
- tvättmaskin Patriot
- tvättmaskin Classique
- tvättmaskin Smart Brand
- tvättmaskin Wisberg
- tvättmaskin Waltham
- tvättmaskin DAYA
- tvättmaskin Sangiorgio
- tvättmaskin Kluge
- tvättmaskin Imarflex
- tvättmaskin Pitsos
- tvättmaskin Helkama
- tvättmaskin Foron
- tvättmaskin Cove
- tvättmaskin EBD
Nyaste tvättmaskin Manualer
9 April 2025
9 April 2025
9 April 2025
8 April 2025
8 April 2025
8 April 2025
8 April 2025
8 April 2025
8 April 2025
7 April 2025
