Sida 1/35
INSTRUCTION MANUAL
RD700
RD701
DIGITAL MULTIMETER
CONTENTS
[1] SAFETY PRECAUTIONS
*Before use, read the following safety precautions.
1-1 Explanation of Warning Symbols 1…………………………00
1-2 Warning Instruction for Safe Use 1…………………………00
1-3 Overload protections 2………………………………………00
[2] APPLICATION AND FEATURES……………………………003
[3] NAME OF FUNCTION ………………………………………004
[4] DESCRIPTION OF FUNCTIONS
4-1 Function Switch 5……………………………………………00
4-2 Auto Power Off ……………………………………………005
4-3 Low Battery Indication 5……………………………………00
4-4 Measurement Function Select: SELECT 5………………00
4-5 Range Hold: RANGE 6………………………………………00
4-6 Data Hold: HOLD …………………………………………006
4-7 Max Hold: MAX 6…………………………………………00
4-8 Relative Mode: REL 6……………………………………00
4-9 Mis-insertion alarm for current function: ALARM 6………00
4-10 Words 6………………………………………………………00
[5] MEASUREMENT PROCEDURE
5-1 Start-Up Inspection 9…………………………………………00
5-2 Voltage measurement / Frequency measurement 10……0
5-3 Adapter measurement 12……………………………………0
5-4 Resistance measurement and Capacitance measurement /
Testing Diode / Checking Continuity 14……………………0
5-5 Temperature Measurement 18………………………………0
5-6 Current Measurement 19……………………………………0
[6] MAINTENANCE
6-1 Maintenance and Inspection 21………………………………0
6-2 Calibration …………………………………………………021
6-3 Battery and Fuse Replacement 21…………………………0
6-4 Storage 22………………………………………………………0
H
[7] AFTER-SALE SERVICE
7-1 Warranty and Provision 23……………………………………0
7-2 Repair 23………………………………………………………0
7-3 Sanwa web site 24……………………………………………0
[8] SPECIFICATIONS
8-1 General Specification 25………………………………………0
8-2 Measurement Range and Accuracy 28………………………0
