Sida 1/18

www.segway.com CE.00.0043.84-D

YT01

Ninebot KickScooter

Product Manual

Manuel du Produit

Produkt-Handbuch

Manuale del prodotto

Manual del producto

Instrukcja produktu

The manufacturer reserves the right to make changes to the product, release ﬁrmware updates, and update this manual at any

time. Visit www.segway.com or check the Segway-Ninebot app to download the latest user materials. You must install the app,

activate your KickScooter, and obtain the latest updates and safety instructions.

Le fabricant se réserve le droit d'apporter des modiﬁcations au produit, de publier des mises à jour du microprogramme et de

réviser ce manuel à tout moment. Visitez www.segway.com ou consultez l'application Segway-Ninebot pour télécharger les

derniers contenus utilisateur. Vous devez installer l'application, activer votre trottinette et obtenir les dernières mises à jour et

consignes de sécurité.

Der Hersteller behält sich jederzeit das Recht von Produktänderungen, der Herausgabe von Firmware-Updates und der

Aktualisierung dieses Handbuches vor. Besuchen Sie www.segway.com oder schauen Sie auf der Segway-Ninebot App nach, um

sich die neuesten Benutzermaterialien herunterzuladen. Sie müssen die Segway-Ninebot App installieren und Ihren KickScooter

aktivieren, um die neuesten Updates und Sicherheitshinweise zu erhalten.

Il produttore si riserva il diritto di apportare modiﬁche al prodotto, aggiornare gli aggiornamenti del ﬁrmware e aggiornare questo

manuale in qualsiasi momento. Visitare www.segway.com o controllare l'app Segway-Ninebot per scaricare l'ultimo manuale

utente e materiali. È necessario installare l'App, attivare il proprio KickScooter e ottenere gli ultimi aggiornamenti e le istruzioni di

sicurezza.

El fabricante se reserva el derecho a realizar cambios en el producto, actualizaciones del ﬁrmware y modiﬁcaciones de este

manual en cualquier momento. Visita www.segway.com o revisa la app para descargar los materiales de usuario más recientes.

Debes instalar la aplicación Segway-Ninebot, activar tu KickScooter y obtener las actualizaciones e instrucciones de seguridad

más recientes.

Producent zastrzega sobie prawo do wprowadzania zmian w produkcie, aktualizacji oprogramowania i aktualizacji tej instrukcji

obsługi w dowolnym momencie. Odwied stron www.segway.com lub sprawd aplikacj Segway-Ninebot, aby pobra najnowsze

materiały uytkownika. Musisz zainstalowa aplikacj, aktywowa swojego KickScootera i uzyska najnowsze aktualizacje i zasady

bezpieczestwa.

I T

P L

EN The pictures shown are for illustration purposes only. The actual product may vary.

FR La photo est pour référence seulement. Veuillez vous référer au produit réel pour plus de détails.

DE Das Bild dient nur als Referenz. Das tatsächliche Produkt kann abweichen. Bitte beziehen Sie sich auf das aktuelle Produkt für

weitere Details.

I T La ﬁgura è da considerarsi solo come riferimento. Si prega di far riferimento al prodotto attuale per maggiori dettagli.

ES La imagen es solo de referencia. Remítase al producto en sí para ver más detalles.

PL Rysunek jest tylko poglądowy. Szczegóły znajdują się w faktycznym produkcie.

Diagram

Bell

Handlebar Throttle

Snap Hook

Left Direction Indicator

Dashboard & Power Button

Safety Button

Brake Lever

Reﬂector

Headlight

Stem

Folding Mechanism

Quick-release Lever

Front Fork

Front Fender

Drum Brake Hub Motor

Rear Direction

Indicator

Charge Port

Footboard

Buckle

Rear Fender

Tail light

& Brake Light

& Reﬂector

Insurance

Plate Area

Kickstand

Battery Compartment

Direction Indicator Button

Right Direction Indicator

Power Button: Press the button to power on; press and hold the button for 3 seconds to power off. When the KickScooter is on, press the

button to turn on/off the headlight and the tail light; and press twice to switch between the speed modes.

Speedometer: It displays the current speed of the scooter, as well as error codes.

Left Direction Indicator Icon: When this icon blinks, it indicates that the direction indicators on the left side are turned on.

Right Direction Indicator Icon: When this icon blinks, it indicates that the direction indicators on the right side are turned on.

Walk Mode: Max. speed is 5 km/h (3.1 mph).

F65I: The headlight and tail light keep flashing and can't be turned off.

F65D: The headlight and tail light are always on and can't be turned off.

* How to enable in the Segway-Ninebot app: > Settings Walk Mode.

Speed Mode: There are three modes available. The top speed is as follows:

Error Notiﬁcation: It indicates that the scooter has detected an error.

Temperature Warning: It indicates that the battery temperature has reached 55°C (131°F) or is below 0°C (32°F).

* At this point, the KickScooter cannot accelerate normally and may not be charged. DO NOT use until the temperature has reverted to the

normal range.

Bluetooth: It indicates that the scooter has been successfully connected to the mobile device.

Battery Level: The total battery level equals 5 bars.

* The battery power is very low when the first battery bar is red. Please charge your KickScooter immediately.

Specications

Dashboard & Power Button

Speedometer

Bluetooth

Headlight

Temperature Warning

Speed Mode

Walk Mode

Battery Level

Power Button

Left Direction Indicator Icon Right Direction Indicator Icon

Model

Mode F65DF65I

15 km/h (9.3 mph)

20 km/h (12.4 mph)

15 km/h (9.3 mph)

20 km/h (12.4 mph)

25 km/h (15.5 mph)

ECO (Energy-saving mode)

D (Standard mode)

S (Sport mode)

Approx. 25 km/h (15.5 mph)

Approx. 65 km (40.4 miles)

Approx. 20%

-10–40°C (14–104°F)

-10–50°C (14–122°F)

IPX5

Approx. 5 h

Bicycle lanes, parks, campuses and most of the flat road conditions and

typical Belgian roads

Energy-saving mode, Standard mode and Sport mode

Features

Tire

Approx. 1196 × 569 × 1237 mm (47 × 22.4 × 48.7 in)

Approx. 1196 × 569 × 540 mm (47 × 22.4 × 21.3 in)

Approx. 21.8 kg (48 lbs)

Product

Rider

Machine

Battery

Motor

Charger

Ninebot KickScooter

F65I

Approx. 20 km/h (12.4 mph)

Item Parameter

Name

Model

Length × Width × Height

Folded: Length × Width × Height

Net Weight

Payload

Recommended Age

Required Height

Max. Speed

Typical Range[1]

Max. Slope

Traversable Terrain

Operating Temperature

Storage Temperature

IP Rating

Duration of Charging

Nominal Voltage

Max. Charging Voltage

Charging Temperature

Nominal Capacity

Nominal Energy

Battery Management System

Output Power

Input Voltage

Max. Output Voltage

Rated Output

Brake Light

Speed Modes

Tire Pressure 40–45 psi

Tires 10-inch Pneumatic tire

0.16 kW, 160 W

100–240 V ~ 50–60 Hz, 2.0 A MAX.

54.6 V

53.5 V , 3 A

Nominal Power

Max. Power

Model

0.4 kW, 400 W

0.7 kW, 700 W

NBW54D603D0D

Type Built-in

46.8 V

54.6 V

0–45°C (32–113°F)

12 Ah

561 Wh

Over-heating, short circuit, over-current, over-discharge and

over-charge protection

30–120 kg (66–265 lbs)

14–60 years

130–200 cm (4’3”–6’6”)

F65D

[1] Typical Range: tested while riding with a full battery, 75 kg (165 lbs) load, 25°C (77°F), at the speed of 18 km/h (11.2 mph) on average on pavement.

* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
