✩Some models have a screw down crown instead of a standard crown.

• How to unlock the crown:

Unscrew the crown by turning it counterclockwise. Then, pull it out for time/calendar setting.

• How to lock the crown:

Push the crown back to the normal position. Then, turn it clockwise while pressing it until it

locks in place.

• When using the watch in water:

Before using the watch in water, make sure the crown is screwed in completely. Do not

operate the crown when the watch is wet or in water.

Calibre No.

■Calibre number of your watch

Please check the case back of your watch to find the calibre number inscribed on it,

and read the instructions pertaining to your watch calibre number. It is a 4-digit

number to the left of the hyphen mark.

MECHANICAL WATCHES : Cal. 4206, 4207, 4217, 7002, 7009, 7019, 4S15, 7S25, 7S26, 7S35, 7S36, 7S55

ANALOGUE QUARTZ WATCHES : All other calibres

Second hand

[DISPLAY AND HANDS]

Minute hand

Hour hand

Day

Crown

✩

Date

INSTRUCTIONS FOR ANALOGUE QUARTZ AND MECHANICAL WATCHES

Your watch is one of the following six types of analogue quartz and mechanical watches.

Before using your new watch, please read the instructions pertaining to your watch type; they

will help you to get the best out of the watch.

D Three hands without calendar

E Three hands with date calendar

F Three hands with

day and date calendar

A Two hands without calendar

B Two hands with date calendar

C Two hands with

day and date calendar

Note:

When setting the minute hand of a quartz watch, advance it to a few minutes ahead

of the time and then turn it back to the exact time.

●For models with date calendar

✩

The date will change gradually between 9:00 P.M. and 4:00 A.M. (See note 1 on

calendar setting.) For some models, however, it will change instantly when the

hands pass the 12 o’clock marker at midnight.

1. Pull out the crown to the first click.

2. Turn the crown until the previous day’s date appears in the calendar frame.

3. Pull out the crown to the second click, and advance the hour and minute hands until the

desired date appears.

* If your watch has three hands, pull out the crown when the second hand is pointing to 12 o’clock.

4. Adjust the time by turning the crown in the desired direction.

5. Push the crown back in to the normal position.

* If your watch has three hands, push the crown back in to the normal position in accordance with a

time signal for “00” seconds.

TIME/CALENDAR SETTING FOR MODELS WITH CALENDAR

B E

■How to start a mechanical watch

●Cal. 4206, 4207, 4217, 7002, 7009, 7019, 4S15, 7S25, 7S26, 7S35, 7S36, 7S55

To initially start your watch, swing it from side to side in a horizontal arc for about 30 seconds.

●Cal. 4206, 4207, 4217, 4S15

These watches can also be started by winding the crown.

Note:

If the watch is worn daily, SEIKO’s automatic mechanism will wind the mainspring

automatically through normal wrist movements.

1. Pull out the crown all the way.

* If your watch has three hands, pull out the crown when the second hand is pointing to 12 o’clock.

2. Adjust the time by turning the crown in the desired direction.

3. Push the crown back in to the normal position.

* If your watch has three hands, push the crown back in to the normal position in accordance with a

time signal for “00” seconds.

TIME SETTING FOR MODELS WITHOUT CALENDAR

Set the time/calendar following the instruction pertaining to your watch type.

HOW TO USE THE WATCH

3 When setting the hour hand, check that AM/PM is correctly set. The watch is so

designed that the calendar changes once every 24 hours.

Turn the hands past the 12 o’clock marker to determine whether the time is set for the

A.M. or P.M. period. If the calendar changes, the time is set for the A.M. period. If it

does not change, the time is set for the P.M. period.

Loss/gain (monthly rate) is less than 15 seconds (20 seconds for some calibres) in the

normal temperature range (5 C ~ 35 C or 41 F ~ 95° ° ° °F).

LOSS/GAIN OF THE ANALOGUE QUARTZ WATCH

Because the battery is inserted at the factory to check the function and performance of

the watch, its actual service life once in your possession may be less than the specified

period. When the battery expires, make sure to replace it as soon as possible to prevent

any malfunction. For battery replacement, we recommend that you contact an AUTHOR-

IZED SEIKO DEALER and request they only use a genuine SEIKO battery.

●Battery life indicator

If your analogue quartz watch has a second hand, the battery needs to be replaced

when you see the second hand moving in two-second increments instead of the normal

one-second increments. (Some calibres do not have this function.) The watch will,

however, remain accurate while the second hand is moving in two-second increments.

CHANGING BATTERY IN ANALOGUE QUARTZ WATCH

●For models with day and date calendar

1. Pull out the crown to the first click.

2. Turn the crown until the previous day’s date appears in the calendar frame.

3. Turn the crown in the opposite direction until the desired language (bilingual) for the day

before the desired day appears in the calendar frame.

* For Cal. 7009 and 7019, push the crown back in to the normal position and then push it repeatedly

to set the day.

4. Pull out the crown to the second click, and advance the hour and minute hands until the

desired date and day appears.

* If your watch has three hands, pull out the crown when the second hand is pointing to 12 o’clock.

5. Adjust the time by turning the crown in the desired direction.

6. Push the crown back in to the normal position.

* If your watch has three hands, push the crown back in to the normal position in accordance with a

time signal for “00” seconds.

Notes on calendar setting:

1 Do not change the calendar between 9:00 P.M. and 4:00 A.M, as it may not change

properly. If it is necessary to set the calendar during that time period, first change the

time to any time outside those hours, set the calendar and then reset the correct time.

2 When the day shifts automatically to the next day, the other language will temporarily

appear.
