Sida 1/25
Printed in Japan
BSJ9SCCG -2002
Thank you very much for choosing a Grand Seiko watch.
For proper and safe use of your Grand Seiko watch, please
read the instructions carefully in this booklet before using it.
Keep this manual handy for easy reference.
Bracelet sizing is available at the retailer from whom the watch was purchased. If you cannot
have your watch band sized by the retailer from whom the watch was purchased because you
received the watch as a gift, or you moved to a distant place, please contact Grand Seiko
international service network mentioned on CERTIFICATE OF GUARANTEE or our website.
The service may also be available on a chargeable basis at other retailers, however, some
retailers may not undertake the service.
If your watch has a protective film for preventing scratches, make sure to peel it off before using
the watch. If the watch is used with the film on it, dirt, sweat, dust, or moisture may be attached
to the film and may cause rust.
CONTENTS
■ INTRODUCTION ............................................................. 2-About mechanical watch-
• Characteristics of a mechanical watch .............................................................. 3
• For lifelong use of your mechanical watch ......................................................... 5
■ CAUTIONS FOR ACCURACY ............................................................................. 8
■ HANDLING CAUTIONS ....................................................................................... 9
■ CHECK THE CALIBER NUMBER AND WATER-RESISTANT LEVEL ............. 10
■ CAUTIONS ON WATER RESISTANCE ............................................................ 11
■ NAMES OF THE PARTS .................................................................................... 15
■ HOW TO USE ..................................................................................................... 18
• Crown .............................................................................................................. 18
• Power reserve indicator ................................................................................... 19
• HOW TO USE (FOR CAL. 9S85, 9S68, 9S65, 9S27) ...................................... 20
• HOW TO USE (FOR CAL. 9S86, 9S66) .......................................................... 22
※List of time zone differences in major regions of the world ........................... 29
• HOW TO USE (FOR CAL. 9S64, 9S63) .......................................................... 30
• HOW TO USE (FOR CAL. 9S61) .................................................................... 32
■ FUNCTIONS OF DIVER’S MODEL .................................................................... 33
• Unidirectional rotating bezel ............................................................................ 33
• Slide adjuster ................................................................................................... 34
■ THE GRAND SEIKO STANDARD ..................................................................... 35
• The Grand Seiko Standard Inspection Certificate ............................................ 37
• Cautions for accuracy of mechanical watch .................................................... 38
■ TO PRESERVE THE QUALITY OF YOUR WATCH .......................................... 39
• After-sale service ............................................................................................. 39
• Guarantee ....................................................................................................... 40
• Daily care ........................................................................................................ 41
• Band ................................................................................................................ 42
• Magnetic resistance (Magnetic influence) ....................................................... 43
• Lumibrite ......................................................................................................... 44
• Troubleshooting .............................................................................................. 45
■ SPECIFICATIONS (Movement) ........................................................................ 46
1
English
■
INTRODUCTION -About mechanical watch-
Thank you very much for purchasing the Grand Seiko mechanical watch.
Take hold of your watch softly.
Hear the watch ticking,
tick tock, tick tock, tick tock,
soft and faint, a dignified sound can be heard.
The sound can be called
the crystal of the craftsmen’s spirit and skill.
Handpicked parts assembled one by one,
carefully, with craftsmanship,
giving life to a mechanical watch.
This is proven by the sound.
Talking about accuracy,
mechanical watches cannot be compared to
quartz watches, that is for certain.
However, the accuracy of a mechanical watch
is pursued by human hands.
Full of spirit and know-how of craftsmen.
A mechanical watch - complicated, sensitive,
and having a human touch.
We would like to let all of you know
the charm of a mechanical watch, which has no bounds.
So we made this handbook, mainly detailing the accuracy.
Wishing you will have a nice time
with your Grand Seiko for a long, long time.
2
Quartz watches and mechanical watches - what
is the difference?
We will explain by example
Quartz watches that you have come to be
familiar with.
These are just like airplanes, controlled by
computers.
A battery, IC, and crystal make quartz
watches work accurately, electrically.
Some loss or gain may occur while the watch
is worn.
However, this will be too small to notice in your
daily life.
If a quartz watch resembles an airplane, a
mechanical watch is like a bicycle.
All watch parts work together mechanically to
make it tick.
Thus, a mechanical watch is easily affected
by the outside environment.
If it is hot, the watch tends to lose time. When
power driving the watch becomes short (when
the amount the spring is wound is short),
accuracy becomes unstable.
If the resting position of the watch is changed,
accuracy is also affected.
The rate of loss/gain could be significant that
you will notice in your daily life.
The accuracy is shown by the daily rate
The measured loss/gain of the watch per day
This is called the daily rate.
The accuracy of a mechanical watch is usually shown in
this daily rate.
The accuracy of a mechanical watch changes delicately
day by day,
depending on the condition in which the watch is used or
the outside environment.
Thus,
By only observing loss/gain in one day, you cannot judge
how accurate the watch works.
If you check the average of the daily loss/gain rate, you
can judge the accuracy of the watch.
In the case of quartz watches, the accuracy is usually
shown by the monthly/yearly rate.
Total losses/gains for a month/year are called the loss/
gain rate of quartz watches.
3INTRODUCTION -About mechanical watch-Characteristics of a mechanical watch
English
