HDX-XT SERIES
4K Video and USB 2.0 KVM Extender
USER MANUAL
Designed and Manufactured in the USA
1-800-284-2131
www.smartavi.com
HDX-XT Single Head HDMI, USB 2.0 and Audio KVM CAT5/6 Extender
Advanced HDMI Extender with Audio and USB 2.0 Support 2
OVERVIEW
TECHNICAL SPECIFICATIONS_________________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________________
FRONT AND BACK___________________________________________________________________________
INSTALLATION_______________________________________________________________________________
LED’S BEHAVIOUR___________________________________________________________________________
TROUBLESHOOTING_________________________________________________________________________
TECHNICAL SUPPORT________________________________________________________________________
LIMITED WARRANTY STATEMENT____________________________________________________________
3
4
4
5
6
7
7
8
Advanced HDMI Extender with Audio and USB 2.0 Support 3
Technical Specifications
VIDEO
Format HDMI2.0
Maximum Pixel Clock Single-link 340 MHz (10.2 Gbps)
Input Interface (TX) (1) HDMI, (1) LAN, (1) USB-H, (1) IR-IN, (1) RS-232, (1) Opcal (Spdif in), (1) Audio In
Output Interface (TX) (1) IR Out, (1) Opcal (Spdif out), (1) Extender Out, (2) USB-D
Input Interface (RX) (1) IR In, (1) Opcal (Spdif In), (1) Extender, (1) USB-H
Output Interface (RX) (1) HDMI, (1) LAN, (2) USB, (1) IR Out, (1) Audio Out, (1) RS-232, (1) Opcal (Spdif out)
Resoluon 480p, 720p, 1080i, 1080p/60Hz, 4K/30Hz
Max Output Distance 1080p@60 100m (330) [CAT5/5e/6]; 4K2K (4:2:0 8bit) 45m (148) [CAT5/5e/6]
DDC 5 Volts [peak-to-peak, TTL]
Input Equalizaon Automac
Data Rate 1.65 Gbps per color
AUDIO
Format HDMI
Input Interface 3.5 mm Jack Socket (Female)
Output Interface 3.5 mm Jack Socket (Female)
USB
Input Interface (TX) (1) USB Type B
Output Interface (RX) (2) USB 1.1 Type A for KM Devices; (2) USB 2.0 Type A Transparent
Keyboard and mouse Keyboard and mouse emulaon
RS-232
Format Full duplex TXD, RXD signal
SYSTEM
Interface RJ-45
Cable Requirements CAT5/5e/6
Maximum Length 330  (100 m)
OTHER
Power Adapter External 100-240 VAC/5VDC3A @ 15W
Dimensions 6.3” W x 3.8” H x 1.1” D
Weight 1.0 lb (per unit)
Approvals UL, CE, ROHS Compliant
Operang Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 95% (No Condensaon)
Compliance EMC FCC (Class A), CE (Class A), ICES-003
Envr. Compliance RoHS2 (CE)
Support Warranty 1-year
