SM-UHO SERIES
Single-Head HDMI KVM Switch with USB 2.0 Support and OSD
USER MANUAL
Designed and Manufactured in the USA
1-800-284-2131
www.smartavi.com
SM-UHO-8P Single-Head 8-Port HDMI KVM Switch with USB 2.0 Support and OSD
SM-UHO-16P Single-Head 16-Port HDMI KVM Switch with USB 2.0 Support and OSD
HDMI KVM Switch with USB 2.0 Support and OSD 2
OVERVIEW
TECHNICAL SPECIFICATIONS_________________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________________
FRONT AND BACK___________________________________________________________________________
INSTALLATION_______________________________________________________________________________
SYSTEM OPERATION_________________________________________________________________________
FRONT PANEL CONTROL_____________________________________________________________________
HOTKEY AND RS232 SERIAL CONTROL_______________________________________________________
CUSTOM HOTKEY TRIGGERS_________________________________________________________________
OSD MENU___________________________________________________________________________________
TROUBLESHOOTING_________________________________________________________________________
TECHNICAL SUPPORT________________________________________________________________________
LIMITED WARRANTY STATEMENT____________________________________________________________
3
4
4
5-6
7
7
7
8
8
9
9
10
HDMI KVM Switch with USB 2.0 Support and OSD 3
Technical Specifications
VIDEO
Format HDMI2.1
Maximum Pixel Clock 165 MHz
Input Interface SM-UHO-8P (8) HDMI
SM-UHO-16P (16) HDMI
Output Interface (1) HDMI
Resoluon Up to 4K (3840 x 2160 @ 30 Hz)
DDC 5 volts p-p (TTL)
Input Equalizaon Automac
Input Cable Length Up to 20 
Output Cable Length Up to 20 
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Input Interface SM-UHO-8P (8) USB Type B
SM-UHO-16P (16) USB Type B
Output Interface (2) USB 1.1 Type A for KVM Devices; (2) USB 2.0 Type A Transparent
CONTROL
Front Panel Push Buons with LED Indicators
RS-232 DB9 Female - 115200 N,8,1, No ow control
Hot Keys Via Keyboard
OSD Via KM arrow keys
OTHER
Power Adapter External 100-240 VAC/12VDC3A @ 24W
Approvals UL, CE, ROHS Compliant
Operang Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (No Condensaon)
Emulaon Keyboard and Mouse
