Instructions Manual
WARNING!
•Read the instructions carefully before installing and/or using the hood.
•Before connecting, make sure that the mains voltage corresponds to the voltage on
the rating plate inside the hood. (see fig. 7)
•Once you remove the appliance from its packaging make sure it is intact. If the
product is damaged, do not use it and contact the Smeg assistance network.
•It is recommended that a qualified technician performs installation and adjustment
operations .
•Before carrying out any kind of maintenance or cleaning, disconnect the hood from
the mains supply.
•Inspect and clean the filters thoroughly and in accordance with the intervals
suggested by the manufacturer.
•Do not cook or fry in a way that could result in flames being sucked into the hood and
causing a fire.
•The hood surface can be cleaned with a damp cloth and a non-bleach liquid
detergent.
•THE MANUFACTURER CANNOT BE HELD RESPONSIBLE IF THE ABOVE
INSTRUCTIONS ARE NOT FOLLOWED
There shall be adequate ventilation of the room when the range hood is used at the same time
as appliances burning gas or other fuels. (Not applicable to appliances that only discharge the
air back into the room).
There is a risk of fire if cleaning is not carried out in accordance with the instructions.
Do not flambé under the range hood.
Caution: accessible parts may become hot when used with a cooking appliance.
The appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervised or instruction concerning use of the appliance by a responsible person for
their safely.
Young children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
The exhaust air must not be discharged into a flue which is used for exhausting fumes from
other appliances burning gas or other fuels. (Not applicable for appliances which only discharge
air back into the room)
The minimum distance between the supporting surface for the cooking vessels on the hob and
the lowest part of the range hood:
When the range hood is located above a gas appliance, this distance shall be 65cm. If the
instructions for the installation for the gas hob specify a greater distance, this must be taken
into account. (the distance of 65 cm can be reduced for non-combustible parts of range hood
and part operating at safety extra low voltage provided these parts do not give access to live
parts. Distance may be reduced to 60cm to align with the AGA code.
Regulation concerning the discharge of air have to be fulfilled.
WARNING: Failure to install the screws or fixing device in accordance with the instructions may
result in electrical hazards.
EN 01
OPERATION
This appliance has been designed to work as a DUCTING hood (evacuation of the
air) or RECYCLING hood (recycling of the filtered air).
•DUCTED MODE: In order to use the hood in the ducted mode, connect the motor
intake, by means of a suitable ducting hose not less than 120mm diameter, directly to
the external fumes outlet.
Note: Remove any carbon filters.
•RECIRCULATION MODE: If it is not possible to discharge fumes outside, the hood
can be used to filter and recycle the air. This way, air and fumes are filtered by the
anti-odour carbon filters and recirculated through the aerating grids on the sides of
chimney.
EN 02
