Soundcraft Notepad User Guide
USER GUIDE
2Soundcraft Notepad User Guide
© Harman International Industries Ltd. 2009
All rights reserved
Parts of the design of this product may be protected by worldwide patents.
Part No. BD10.534000 Issue 1109
Soundcraft is a trading division of Harman International Industries Ltd. Informa-
tion in this manual is subject to change without notice and does not represent
a commitment on the part of the vendor. Soundcraft shall not be liable for any
loss or damage whatsoever arising from the use of information or any error
contained in this manual.
No part of this manual may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, electrical, mechanical,
optical, chemical, including photocopying and recording, for any purpose without
the express written permission of Soundcraft.
Harman International Industries Limited
Cranborne House
Cranborne Road
POTTERS BAR
Hertfordshire
EN6 3JN
UK
Tel: +44 (0)1707 665000
Fax: +44 (0)1707 660742
http://www.soundcraft.com
soundcraft@harman.com
This equipment complies
with the EMC Directive
2004/108/EC and LVD
2006/95/EC
IMPORTANT
Please read this manual carefully before using
your mixer for the rst time.
3
Soundcraft Notepad User Guide
Contents
IMPORTANT SAFETY INSTRUCTIONS 4
SAFETY SYMBOL GUIDE 5
INTRODUCTION 8
THE 60-SECOND GUIDE 10
WIRING UP 12
BLOCK DIAGRAMS 16
MONO INPUT CHANNELS 18
STEREO INPUT CHANNELS 20
MASTER SECTION 22
FX PROCESSOR OVERVIEW 24
FX OPERATION 25
REVERBS 25
DELAYS 26
MODULATED EFFECTS 26
EFFECTS DATA CHART 27
USING YOUR NOTEPAD 124/124FX CONSOLE 28
MARK-UP SHEETS 30
DIMENSIONS 32
APPLICATIONS 33
TYPICAL CONNECTING LEADS 34
TYPICAL SPECIFICATIONS 36
WARRANTY 37
GLOSSARY 38
