200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
DIMENSIONS
FEATURES
Intensifier T® Series HD-TVI 1080p 2MP Indoor Dome Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
CVC6246T – 2.8~12mm auto iris varifocal lens, black housing
CVC6246TW – 2.8~12mm auto iris varifocal lens, white housing
SPECIFICATIONS
Image Sensor.................. 1/3” Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.001 lux (Sens-up X32)
Effective Pixels................ 1984 (H) x 1105 (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
Day / Night....................... Auto / Color / BW / External
Test Monitor Output......... CVBS (BNC out in Yellow)
Communication............... UTC (up the coax)
Power............................. 12VDC / 24VAC
Power Consumption........ 150mA (DC), 2W (AC)
Operating Temperature.... -4 F – 122 F ° °
Unit Dimensions.............. 3.82” (H) x 5.47” (Dia.)
Unit Weight...................... 1.54 lbs
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Superior low-light performance
• Amplify existing light with no distance limitation
• PRESET (Indoor/Outdoor/Lowlight/Hallway/Lobby/Elevator)
• 3-axis for wall and ceiling mounting
• Full OSD operation thru on-board control and UTC (up the coax)
• Additional 960H analog output ( )BNC out in Yellow
• Signal distance up to 1600 feet*
• 12VDC/24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
EXPOSURE
• •B/W EXTERN
• • •LOW MIDDLE HIGH
• • •SHARPNESS GAMMA MIRROR •FLIP
DAY / NIGHT
WHITE BAL.
SPECO DNR
EXIT
•BRIGHTNESS •SHUTTER
BACKLIGHT
•HLC•BLC•WDR
•AUTO
• •AWB COLOR GAIN
• •ACE DEFOG
SYSTEM
• •COM. IMAGE RANGE
•COLOR SPACE
•FRAME RATE
• •INTENSIFY AGC
•COLOR
•PRIVACY
LENS
MOTION
•OUTPUT
•LANGUAGE
• •COLOR BAR RESET
•CAMERA TITLE
•FREQ
LENS : as this item uses DC lens, please stay with ‘DC’ mode.
EXPOSURE : Adjusts exposure settings.
BRIGHTNESS : Adjusts image brightness. (0~ 20)
SHUTTER : Auto / Manual Shutter can be selectable
- AUTO : Shutter can be selectable automatically.
- FLICKER(Flicker Less) : Selects this when picture flickering.
- Manual : Controls the shutter speed manually from 1/30 ~1/30000
INTENSIFY : Sets the desired multiple of the digital exposure length.
(OFF/x2 ~ x32)
AGC(Auto Gain Control): Adjusts the AGC level. (0~10)
OSD MENU Details
Side View
Top View Optional Accessories
DFM1
(Tile Ceiling Flush Mount)
CVCWMINDT
(Indoor Wall Mount)
Unit : mm
PRESET MODE
• INDOOR • OUTDOOR • LOW LIGHT • LOBBY• HALLWAY • ELEVATOR
MAIN SETUP
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without
notice and without incurring any obligation. Rev. 160726
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
OSD MENU Details
DAY / NIGHT : Adjust Day / Night options.
COLOR : Always Color mode.
B/W : Always B/W mode.
- ANTI-SAT. : Adjusts the Anti Saturation level (0~20)
EXT : please do not use this mode for this item
AUTO : Day / Night is switching automatically by AGC level.
- ANTI-SAT. : Adjusts the Anti Saturation level (0~20)
- AGC THRES : Adjusts AGC THRES (0~20)
- AGC MARGIN : Adjusts AGC margin (0~20)
- DELAY : Adjusts the changing delay time (LOW/MIDDLE/HIGH)
WHITE BAL. : Adjusts white balancing options.
AWB : it goes to optimized color level automatically.
COLOR GAIN : Sets the desired Color Gain value (0~20)
SPECO DNR : Uses to reduce the background noise in a low luminance
environment with 2D + 3D filtering system.
BACKLIGHT : Adjusts backlight options.
WDR : WDR illuminates darker areas of an image while retaining the
same light level for brighter areas to even out the overall brightness
of images with high contrast between bright and dark area
- Adjusts the WDR Weight (LOW/MIDDLE/HIGH)
* CVBS out cannot adjust this function.
BLC : Produces a clearer image of an object darkened by strong backlighting.
- H-POS : Adjusts the horizontal position(0~20)
- V-POS : Adjusts the Vertical position(0~20)
- H-SIZE : Adjusts the horizontal block size (0~20)
- V-SIZE : Adjusts the vertical block size (0~20)
HLC : Uses to contain extremely bright areas such as from car headlight,
the light can be masked out much of the on-screen details.
IMAGE : Adjusts various image options.
SHARPNESS: Adjusts sharpness level. Increasing this value, the picture
outline becomes stronger and clear. (0~10)
GAMMA : Sets the desired Gamma value. (0.45 ~ 0.75)
MIRROR : Change the video direction horizontally.
FLIP: Change the video direction perpendicularly.
ACE (D-WDR) : Uses a digital wide dynamic range to balance dark and over
saturated areas within the image.
DEFOG : Activated this mode when the video or the weather is foggy.
PRIVACY : Used to hide regions of the image.
- ZONE NUM : Selects the zone number up 15.
- ZONE DISP : Selects desired zone with ON or OFF
- H-POS : Adjusts the horizontal position(0~60)
- V-POS : Adjusts the vertical position(0~40)
- H-SIZE : Adjusts the horizontal size(0~40)
- V-SIZE : Adjusts the vertical size(0~40)
- Y-LEVEL : Adjusts the yellow color level (0~20)
- CB LEVEL : Adjusts the blue color level (0~20)
- CR LEVEL : Adjusts the red color level (0~20)
SYSTEM : Adjusts various camera system options.
OUTPUT
FRAME RATE: Select the frame rate 30fps/60fps according to the video
output mode.
FREQ
COM.
- CAM ID : Sets the camera ID for the RS-485 (0~255)
- BAUD RATE : Sets the baud rate for the RS-485 (2400~115200).
IMAGE RANGE
COLOR SPACE
COLOR BAR : Manufacturer’s option
LANGUAGE : Sets the desired OSD language
CAMERA TITLE
RESET: Press with long to reset all settings to factory defaults.
Intensifier T® Series HD-TVI 1080p 2MP Indoor Dome Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
CVC6246T – 2.8~12mm auto iris varifocal lens, black housing
CVC6246TW – 2.8~12mm auto iris varifocal lens, white housing
MOTION : Adjust motion detection settings.
- SENSITIVITY : Sets the desired of “Motion” (0~20)
- WINDOW TONE : Adjusts the window tone value (0~60)
- WINDOW USE : Adjusts the window setting size (0~3)
- WINDOW ZONE : activate or deactivate motion window
- DET H-POS :Adjusts the horizontal position(0~60)
- DET V-POS : Adjusts the vertical position(0~40)
- DET H-SIZE : Adjusts the horizontal size(0~60)
- DET V-SIZE : Adjusts the vertical size(0~40)
- ALARM : Select Alarm between ON of OFF
