HD1B316

High Definition Weatherproof Bullet Camera

200 New Highway, Amityville, NY 11701

800-645-5516 / www.specotech.com

1. Package Contents

1 HD1B316 camera

4 Mounting Screws

1 Wrench

2. Features

4. OSD Menu

3. Controller

①

①①

②

②②

③

③③

Main Menu

Lens ▷

▷

▷▷

Shutter ▷

▷

▷▷

BLC ON

AGC MID

White Balance ▷

▷

▷▷

Adjust ▷

▷

▷▷

Reset ▷

▷

▷▷

Return

* 1/3” Sony 720P HD CMOS Sensor (Megapixel Resolution)

* 3.5~16mm Auto Iris Lens

* HDcctv 720p30 Video Output (1.5Gb/S Digital over coax)

* Video Output for Test Monitor

* True Mechanical Day / Night (ICR)

* Min. Illumination – Color : 0.2Lux, F1.2 / B/W : 0.01Lux, F.1.2

* External Controls for Zoom and Focus

* Easy mount system simplifies installation

* Weatherproof Operation (IP-67 Rated)

* Indoor / Outdoor : meets all your surveillance needs

* Install using RG 59cable & BNC connectors

* 5 year warranty

* Lens

-DC : DC Lens Type Setting

IRIS ADJ [ Value] : IRIS Open Level Control

- Return : Function Back

*Shutter

-Flicker : This function triggers the screen in the 50Hz power range, preventing the

screen flicker that can result from the dissonance of vertical

synchronization frequency and blink frequency.

- Auto : Only Operate when Manuals Lens is active

- Manual : 1/30, 1/60, 1/600, 1/1200, 1/6000, 1/12000

- Return : Function Back

* BLC

- Provides light level control to overcome severe back light condition

* AGC

- OFF / LOW / MID / HIGH

* White Balance

- AWB : Auto White Balance Mode Setting

- Fixed[Value] : 2300,3100,5000,6800

- Manual : White Balance Mode Manual Setting

R-Gain [Value] : R-Gain Value Control

B-Gain [Value] : B-Gain Value Control

-Return : Function Back

* Adjust

- Sharpness [Value] : Sharpness Control

- Brightness : Adjust a brightness setting of monitoring status

- Contrast : Adjust a contrast of monitoring status

- Day / Night : [Auto]

[Color]

[B/W]

- Return : Function Back

* Reset

- Would you like to reset? Yes or No

4. OSD Menu Details

①Switch for Selection of Video out / SDI out

②Video output for Test Monitor

③OSD Button (UP/DOWN/LEFT/RIGHT/SET)

HD1B316

High Definition Weatherproof Bullet Camera

200 New Highway, Amityville, NY 11701

800-645-5516 / www.specotech.com

6. SPECIFICATIONS 7.DIMENSIONS

Item 　

HD1B316

Image Sensor 　

1/3" Sony Progressive Scan

Total Pixels 　

1384(H)x1076(V) approx. 1.49M Pixel

Effective Pixels 　

1329(H)x1049(V) approx.1.39M Pixel

Recommended Pixel 　

1280(H)x1024(V) approx.1.31MPixel

Video Format 　

Progressive Scan

Sync Format 　

Internal Sync

Recommended Lens 　

F Number: 2.8 or More

S/N Ratio 　

50dB or More

BLC OSD support

AGC 　

OSD support

Day/Night 　

OSD support

Application Lens 　

DC IRIS 3.5~16mm

Video Output 　

720P 30HZ

Video Output Format 　

1.5G/s Digital over Coax

Power Source 　

12Volts DC

Power Consumption 　

300mA / 12Volts DC

Operational Temperature 　

-20℉

℉

℉℉ to 122℉

℉

℉℉

Control 　

Key Button

Weight 　

1.16KG

Dimension 　

85mm(H)x136mm(W)x264mm(L)

Front View

Unit : mm

264

154

136

Side View

Rev.101020

Speco Technologies is constantly developing product

improvements. We reserve the right to modify product

design and specifications without notice and without

incurring any obligation.
