200 New Highway, Amityville, NY 11701
800 645- -5516 / www.specotech.com
DIMENSIONS
FEATURES
Intensifier T® Series HD-TVI 1080p 2MP Outdoor Dome Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
2.8mm fixed lens, Waterproof
HT724ST8 (IP68 Stainless Steel) –
SPECIFICATIONS
Image Sensor.................. 1/3” Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.001 lux ( -up X32) Sens
Eective Pixels................ 1984 (H) x 1105 (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 1/30,000 sec.) –
Day / Night....................... Auto / Color / BW
Test Monitor Output......... CVBS (BNC out in Yellow)
Communication............... UTC (up the coax)
Power............................. 12VDC / 24VAC
Power Consumption........ 150mA (DC), 200mA (AC)
Operating Temperature.... -4 °F –140°F
Unit Dimensions.............. 3.46” (H) x (Dia.) 5.1”
Unit Weight...................... 4lbs
Certications.................... FCC, RoHS, IP68, UL(le no. E355310)
Submergible depth.......... 3.29 feet
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Superior low-light performance
• Amplify existing light with no distance limitation
• PRESET (Indoor/Outdoor/Lowlight/Hallway/Lobby/Elevator)
• 3-axis for wall and ceiling mounting
• Full OSD operation thru on-board control and UTC (up the coax)
• Additional 960H analog output (BNC out in Yellow)
• Signal distance up to 1600 feet
• Submergible depth up to 3.29 feet
• 12VDC/24VAC dual voltage operation
• 5 year warranty
• Vandalproof / Tamperproof
• IP68 Waterproof - Stainless Steel
OSD MENU TREE
EXPOSURE
• • B/W EXTERN
• • • LOW MIDDLE HIGH
• • • SHARPNESS GAMMA MIRROR • FLIP
DAY / NIGHT
WHITE BAL.
SPECO DNR
EXIT
• BRIGHTNESS • SHUTTER
BACKLIGHT
• HLC • BLC • WDR
• AUTO
• • AWB COLOR GAIN
• • ACE DEFOG
SYSTEM
• • COM. IMAGE RANGE
• COLOR SPACE
• FRAME RATE
• • INTENSIFY AGC
• COLOR
• PRIVACY
LENS
MOTION
• OUTPUT
• LANGUAGE
• • COLOR BAR RESET • CAMERA TITLE
• FREQ
LENS : as this item uses xed lens, please stay with ‘Manual’ mode.
EXPOSURE : Adjusts exposure sengs.
BRIGHTNESS : Adjusts image brightness. (0~ 20)
SHUTTER : Auto / Manual Shuer can be selectable
- AUTO : Shuer can be selectable automacally.
- FLICKER(Flicker Less) : Selects this when picture ickering.
- Manual : Controls the shuer speed manually from 1/30 ~1/30000
INTENSIFY : Sets the desired mulple of the digital exposure length.
(OFF/x2 ~ x32)
AGC(Auto Gain Control): Adjusts the AGC level. (0~10)
OSD MENU Details
Side View Bottom View
PRESET MODE
• INDOOR • OUTDOOR • LOW LIGHT LOBBY •• • HALLWAY ELEVATOR
MAIN SETUP
Unit : inch
1 Wrench
1 Power lead
1 Video Test Cable
3 Mounting screws
Accessories
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specicaons without
noce and without incurring any obligaon. Rev. 170105
200 New Highway, Amityville, NY 11701
800 645- -5516 / www.specotech.com
OSD MENU Details
DAY / NIGHT : Adjust Day / Night opons.
COLOR : Always Color mode.
B/W : Always B/W mode.
- ANTI-SAT. : Adjusts the An Saturation level (0~ ) 20
EXT : please do not use this mode for this item
AUTO : Day / Night is switching automacally by AGC level.
- ANTI-SAT. : Adjusts the An Saturation level (0~ ) 20
- AGC THRES : Adjusts AGC THRES (0~ ) 20
- AGC MARGIN : Adjusts AGC margin (0~ ) 20
- DELAY : Adjusts the changing delay me (LOW/MIDDLE/HIGH)
WHITE BAL. : Adjusts white balancing opons.
AWB : it goes to opmized color level automacally.
COLOR GAIN : Sets the desired Color Gain value (0~ ) 20
SPECO DNR : Uses to reduce the background noise in a low luminance
environment with 2D + 3D ltering system.
BACKLIGHT : Adjusts backlight opons.
WDR : WDR illuminates darker areas of an image while retaining the
same light level for brighter areas to even out the overall brightness
of images with high contrast between bright and dark area
- Adjusts the WDR Weight (LOW/MIDDLE/HIGH)
* CVBS out cannot adjust this funcon.
BLC : Produces a clearer image of an object darkened by strong backlighng.
- H-POS : Adjusts the horizontal posion(0~20)
- V-POS : Adjusts the Vercal posion(0~20)
- H-SIZE : Adjusts the horizontal block size (0~20)
- V-SIZE : Adjusts the vercal block size (0~20)
HLC : Uses to contain extremely bright areas such as from car headlight,
the light can be masked out much of the on-screen details.
IMAGE : Adjusts various image opons.
SHARPNESS: Adjusts sharpness level. Increasing this value, the picture
outline becomes stronger and clear. (0~10)
GAMMA : Sets the desired Gamma value. (0.45 ~ 0.75)
MIRROR : Change the video direcon horizontally.
FLIP: Change the video direcon perpendicularly.
ACE (D-WDR) : Uses a digital wide dynamic range to balance dark and over
saturated areas within the image.
DEFOG : Acvated this mode when the video or the weather is foggy.
PRIVACY : Used to hide regions of the image.
- ZONE NUM : Selects the zone number up 15.
- ZONE DISP : Selects desired zone with ON or OFF
- H-POS : Adjusts the horizontal posion(0~60)
- V-POS : Adjusts the vercal posion(0~40)
- H-SIZE : Adjusts the horizontal size(0~40)
- V-SIZE : Adjusts the vercal size(0~40)
- Y-LEVEL : Adjusts the yellow color level (0~20)
- CB LEVEL : Adjusts the blue color level (0~20)
- CR LEVEL : Adjusts the red color level (0~20)
SYSTEM : Adjusts various camera system opons.
OUTPUT
FRAME RATE: Select the frame rate 30fps/60fps according to the video
output mode.
FREQ
COM.
- CAM ID : Sets the camera ID for the RS-485 (0~255)
- BAUD RATE : Sets the baud rate for the RS-485 (2400~115200).
IMAGE RANGE
COLOR SPACE
COLOR BAR : Manufacturer’s opon
LANGUAGE : Sets the desired OSD language
CAMERA TITLE
RESET: Press with long to reset all sengs to factory defaults.
MOTION : Adjust moon detecon sengs.
- SENSITIVITY : Sets the desired of “Moon” (0~20)
- WINDOW TONE : Adjusts the window tone value (0~60)
- WINDOW USE : Adjusts the window seng size (0~3)
- WINDOW ZONE : acvate or deacvate moon window
- DET H-POS :Adjusts the horizontal posion(0~60)
- DET V-POS : Adjusts the vercal posion(0~40)
- DET H-SIZE : Adjusts the horizontal size(0~60)
- DET V-SIZE : Adjusts the vercal size(0~40)
- ALARM : Select Alarm between ON of OFF
