Pole Mount
Quick Start Guide
Thank you for purchasing our product All examples and pictures used in the .
manual are only for reference purpose .
Installation
Pole mounting examples
Here we only take some camera models for example to introduce their pole
mounting with the junction box and other brackets.
Pole Mounting of Dome Camera with Wall Mount
1 Loosen the lock screw to remove .
the mounting base.
2 Fix the wall mount to the pole mount.
with the bolts and nuts provided .
Lock screw Wall mount
3 Install the pole mount to the.
pillar.
4. Screw the mounting base of the dome
camera onto the wall mount.
5 Route and connect cables. Then .
mount the camera to the mounting
base.
6 Fix the camera with lock screw. .
Pole Mounting of Bullet Camera with Junction Box
Pole Mounting of Bullet Camera
1. Open the covers of the junction box. 2 Screw the camera to the upper cover .
of the junction box .
3. Fix the lower cover of the junction
box to the pole mount with the
provided.
bolts
and nuts
1. Fix the bullet camera to the pole
mount with screws provided.
2. Connect cables and then fasten the
the pole mount to the .pillar
4. Install the pole mount to the pillar .
Then connect cables and fasten the
upper cover with the camera to the
junction box.
Upper cover
Lower cover
