SecureGuard Server®

About this Quick Setup Guide

Before operating the unit, plesae read this user’s guide thoroughly and

retain it for future reference.

Product Components

Internal Connections continued

Quick Setup Guide (Ver.1.0)

Speco Technologies SecureGuard® Server

Model: SG115

1510-042

The following components are included:

QT: 1

Power Cable

QT: 1

Internal Connections

Front View

1USB 2.0 x2; Microphone Input (Pink); Line Output (Green) (Not shown

in front view image)

Power on the Server

• Please follow the proper power ON procedures to avoid damaging the server.

• Connect all necessary components, e.g. power cable(s), network cable(s), monitor

and cameras, before powering the server.

• Power ON the server by depressing the Power Switch ( ) to boot up the server.

• After boot up, at the Windows login screen, you will see that the default user

account is “Speco Technologies”. There is no password associated with the

default account. It is to set a password after logging into the highly advisable

Windows home screen for the rst time. See Image 1.

Note: The server comes pre-loaded with SecureGuard Server software.®

• At the Windows Desktop home screen, run the SecureGuard®

Conguration Tool to setup the server by double clicking on

the SecureGuard® Conguration Tool icon. See Image 2.

Image 2

• If prompted to select or create a System Recordings folder, point to the storage

drive where the recordings will be stored. Otherwise, move on to the next step.

See Image 3.

Note: DO NOT store recordings on the hard drive dedicated for the operating

system.

Run SecureGuard® Conguration Tool

Rear View

456

7 8

2Power Switch

3PS/2 Ports: Mouse (Green); Keyboard (Purple)

4VGA Output

5HDMI Output

6USB 3.0

7USB 2.0 x4

8Microphone Input (Pink); Line Output (Green); Line Input (Blue)

9Gigabit Ethernet LAN port

10 115 or 230 VAC Input Switch

11 AC Input

Image 3

Quick Setup Guide

Image 1

WARNING: Please store your password

in a safe location. Speco Technologies will

not be able to assist you in recovering a

lost password.

Note: The default timezone on the servers is set

to (UTC-05:00) Eastern Time (US & Canada).

Rev. 10/19/15

Run SecureGuard® Conguration Tool continued

• When prompted, enter the

default username admin

and default password

to access the admin

SecureGuard® Conguration

Tool. See Image 4.

• At the “System” tab, ensure

“System Recordings” le

path is pointing to the

storage drives. See Image 5.

Image 4

Image 5

Setting up Network

Note: For servers with Dual Network Interface Cards, it is HIGHLY ADVISABLE

that the camera and the client connection network trafc be kept seperate.

• In the “Network” tab, for

“Client Interface” select the

network adapter that remote

client(s) will connect to.

For “Video Interface” select

the network adapter that the

camera(s) will connect to.

See Image 6.

Adding Sites (IP cameras, DVRs, NVRs)

Image 6

• To register the server with Speco’s Free DDNS, ensure the “Enable Speco DDNS”

checkbox is selected, and enter a name for the server in the “Host Name” eld

then click on “Submit/Update”. See Image 7.

Image 7

• If the server name isn’t currently

registered with Speco’s DDNS

server, then the registration will be

successful. If it fails, use a different

name for the “Host Name”. See

Image 8.

Image 8

• By default, the server uses ports for network communication.7312 7313&

Note: To avoid network conicts with devices that also use the server default ports

7312 7313 and , the option of changing the port numbers is available through the

Conguration Tool. The servers come shipped with an inbound rule for Window’s

rewall that allows for communication on the server’s default ports. If the server’s

default ports are changed, please ensure the existing inbound rule is updated, or

create a new inbound rule permitting communication on the new port values.

• The “Sites” tab is where sites (IP cameras, DVRs, and NVRs) can be added,

deleted or updated. There are two methods of adding sites to the server. The rst

method Site Locate uses “ ” which automatically scans the Local Area Network

for only IP cameras. See Image 9.

Method 1: Auto Detect

Method 2: Manual

→

Image 9

• Clicking on “Site Locate”,

will open the “Site Locate”

window and start scanning

the local area network for

IP cameras. You can rescan

the network by clicking on

“Refresh”. See Image 10.

Image 10

• To add an IP camera to the server, double

click on the IP camera to bring up the “Site

Settings” windows for the IP camera.

Ensure the values for all the elds are

accurate and then click “OK”. See

Image 11.

• The IP cameras will now be listed under

“Sites to add” list.

Image 11

• Continue to repeat this process for the remaining IP cameras that must be added

to the server. Once complete, click on “OK” to exit the “Site Locate” window. The

cameras that were added to the “Sites to add” list will now be made available in

the “Sites” tab. Click on “Apply” to complete adding the sites to the server. See

Image 14.

Image 12

• The second method of adding sites to

the server is by manually entering the site

information. This method be used must

when adding and DVRs NVRs. To enter

site information manually, click on “New”

in the “Sites” tab to bring up the “Site

Settings” window. See Image 12.

• Fill in the values for all the elds, and

verify the accuracy of the information by

clicking on “ ”. The server will Check Site

run a quick test to conrm if the

connection to the site is successful. If

successful, click on “OK” to exit the “Site

Settings” window. See Image 13.

Image 13

Quick Setup Guide (Ver.1.0)

Speco Technologies SecureGuard® Server Model: SG115

Adding Sites (IP cameras, DVRs, NVRs) continued Installing SecureGuard on Client PCs ®continued

Adding Users continued

200 New Highway

Amityville, NY 11701

1-800-645-5516

www.specotech.com

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specications without

notice and without incurring any obligation. Rev. 10/19/15

• Finally, click on “Apply” to add the site(s) to the server. See Image 14.

Image 14

• To set up a recording schedule, click on the “Schedules” tab.

• Next to “Action:” select the type of recording (Continuous, Motion, or Sensor)

by clicking on the button (radio button) next to it.

• The schedule grid is made up of rows and columns. The rows pertain to the

days of the week (Mon-Sun), and the columns pertain to the hours of a day

(00HR-23HR).

• The cells inside the schedule grid can be colored in based on the type of

recording selected. The color representation is as follows: Green for

, for , for , and for Continuous Blue Motion Orange Sensor White No

Recording. To color in the grid, hold down the mouse button and drag the

mouse cursor over the grid. See Image 15.

Green

Blue Orange White

Image 15

• To set the entire schedule to

a single recording type,

click on the white box

located in the top-left most

corner of the grid. See

Image 16.

Image 16

• Once the schedule and recording type has been set, associate the schedule with

individual sites (IP cameras, DVRs, NVRs) by moving over the sites listed under

“Available Site…” to “Sites using schedule …” by clicking on .

• Click on “Apply” to save the schedule.

Adding Users

Note: By default, the server

comes loaded with 3 user

accounts: Admin, User, &

Guest.

• Go to the “Users” tab, here

you can add, edit, or delete

users, and manage user access

control through roles and

permission.

• To add users, click on “Add

User”. See Image 17. Image 17

• The “Add User” window will pop up.

See Image 18.

Image 18

• Enter the new user credentials, and select a “User Role” based on the level of access

you wish the user to have. An “Administrator” role has full access to the system and

the permissions associated with this role cannot be modied. The “User” and

“Guest” roles have limited access, but the permissions can be modied. See Image 19.

Note: A customized role can be created to meet varying levels of access control.

Image 19

• The name and email eld are not

mandatory.

• Click on “OK” to exit the “Add User”

window, and click on “Apply” in the

“Users” tab to add the user(s) to the

system.

Installing SecureGuard on Client PCs®

Note: Download SecureGuard® Client from Speco Technologies website at

www.specotech.com.

• Once the client software has been obtained, start the installation by running the

executable le.

• Uncheck the components you don’t wish to install on the client computer.

This option is limited to the following components:

• SecureGuard® Player

• Start Menu Shortcuts

• Desktop Icon

Components deemed necessary for the operation of SecureGuard Client cannot ®

be unchecked. Click on “Next” to proceed. See Image 20.

Image 20

• Select the destination folder where SecureGuard Client will be installed by ®

clicking on “Browse”, or use the suggested destination folder which SecureGuard ®

Client will create. Click on “Install” to proceed. See . Image 21

Startup & Live View continued

Image 21

• The installer will attempt to install

Microsoft Visual C++ 2010 x86

Redistributable. Check that you have

read and accepted the license terms and

then click on “Install”. See Image 22.

• Once the installation is complete, click on

“Finish” to end the process. See Image 23.

Image 22

Image 23

Startup & Live View

Setting up Recording Schedules

• Once the installation is complete, the SecureGuard Client user login window will ®

open. If not, run the application by double clicking on the SecureGuard Client ®

desktop icon.

• At the user login window, enter the server address. The server address can be the

IP address of the server or the DDNS name. If using the latter, please make sure

“Use DDNS” checkbox is checked and then click on “OK”. See Image 24.

Drop-down contains

previously entered

Server Addresses.

→

Check the box to

connect to server using

DDNS name

→

Enter the Server

Address (DDNS or IP

address) here.

→

Enter username for

→

Enter password

associated with the

username.

→

Image 24

• Once logged in, the SecureGuard Client ®

Welcome window will pop up. Click

“OK” to proceed. See .Image 25

Image 25

• Next, the User Settings window will pop up. Here the sites that were added to the

server will be listed under Saved Sites. See .Image 26

Image 26

• In order to view the sites, they need to be placed in a group. To start off, a default

group has already been created named . To add sites to the , click Group Group

on the . After adding the sites, click on “Apply”. The “Apply” button will be

grayed out, indicating the sites have been added to the . Click on “Close” to Group

exit the User Settings window. See .Image 27

Image 29

Image 27

• The Open Group window will pop up listing

all the groups and sites. Select and Group

click on “OK” to begin viewing the sites

added to . See and .Group Image 28 Image 29

Image 28

Produktspecifikationer

Varumärke:	Speco Technologies
Kategori:	övervakningskamera
Modell:	SecureGuard SG115

Behöver du hjälp?

Om du behöver hjälp med Speco Technologies SecureGuard SG115 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

övervakningskamera Speco Technologies Manualer

Speco Technologies O5LB1 Bruksanvisning

8 Januari 2025

Speco Technologies O2P30X Bruksanvisning

8 Januari 2025

Speco Technologies WDRB11H Bruksanvisning

27 Oktober 2024

Speco Technologies O8B7M Bruksanvisning

27 Oktober 2024

Speco Technologies O2VLB7 Bruksanvisning

23 September 2024

Speco Technologies VLDT3GM Bruksanvisning

9 September 2024

Speco Technologies CVC624WDR Bruksanvisning

7 September 2024

Speco Technologies O4iB2M Bruksanvisning

7 September 2024

Speco Technologies ZIPTW4B1 Bruksanvisning

6 September 2024

Speco Technologies O2ID21M Bruksanvisning

6 September 2024

övervakningskamera Manualer

Nyaste övervakningskamera Manualer

Philips B120E Bruksanvisning

16 Januari 2025

Dahua Technology Pro IPC-HDPW5442G-Z Bruksanvisning

10 Januari 2025

Hikvision DS-2CE59U1T-AVPIT3ZF Bruksanvisning

8 Januari 2025

Hikvision IDS-2CD7526G0-IZHSY Bruksanvisning

8 Januari 2025

Hikvision DS-2CD2163G0-I(S) Bruksanvisning

8 Januari 2025

Hikvision DS-2CD2H83G1-IZS Bruksanvisning

8 Januari 2025

ZKTeco AntarVis 2.0 Bruksanvisning

8 Januari 2025

TP Link InSight S345ZI Bruksanvisning

8 Januari 2025

Lorex LNZ43P4A Bruksanvisning

8 Januari 2025

Lorex C221NA Bruksanvisning

8 Januari 2025
