Thank you for purchasing our product. Speco Technologies is constantly developing and

improving products. We reserve the right to modify product design and specifications

without notice and without incurring any obligation.

VLB5 / 7V B V V VL 6/ LD5/ LD6M/ LT

U e us r Man al

Warnings

■ If the product does not work properly, please contact the dealer or where the product was purchased. Speco

Technologies is not responsible for any problems caused by improper operation or repair.

■ Do not expose the unit to heavy stress, violent vibration or long-term exposure to water and humidity during

transportation, storage, and/or installation.

■ Do not install near sources of heat.

■ Only install the product in environments inside the specification operating temperature and humidity range.

■ Do not install the camera near power lines, radar equipment or other electromagnetic radiation.

■ Do not block any ventilation openings if any.

■ Use all the weatherproofing hardware requirement to minimize weather intrusion.

sensitivity, low noise and distortion and supports HD video transmission with the common coaxial cable,

ensuring the requirement of the HD monitoring in the traditional surveillance system.

This camera series is the latest technology and advanced circuit design, which features high definition and

Introduction

● High Resolution

Adopt high performance sensor, providing high definition and clear image.

● High Transmission Performance

Real time transmission with high speed and long distance- .

● DNR

Reduce noise from brightness and color signal .

● OSD

Access the camera settings which can be clearly displayed through the main menu.

● White Balance

Adjust the color temperature according to the environment automatically.

● ICR Auto Switch

The filter will filter infrared light during the daytime and change to normal at night to

ensure a high sensitivity and clear image .

● AGC

Adjust the gain of amplifier, enabling the camera to output the standard video signal in different

lighting condition.

● Wide Dynamic Range (WDR)

When there are both very bright and very dark areas simultaneously in the field of view, this function

will balance the brightness level and provide clear images.

● Backlight Compensation BLC ( )

When the back of the captured object is too much bright, you can set BLC for the captured object to

make it clearer.

Cables

Power Cable

Video Output

Video Switch Cable

Video Switch: F our video output modes can be optional--AHD, TVI, CVI and CVBS

(a) remove the cover of the video switch cable; (b) hold and press the button in the video

switch cable for 5 seconds to switch the current video output.

Before you start, please make sure that the wall or ceiling is s tro ng e nou gh to wit hst and t hree ti mes

th e w eig ht o f t he camera. Please install and use the camera in the dry environment.

You’d better install back the lens cover or lower dome less than 4 hours after removing it.

The mounting types of cameras are only for reference.

Installation

►Mounting for VLB5/VLB6

1. Drill the screw holes and the cable hole on the wall according to the drill template.

VLB6

48mm

48mm ∅4.5

VLB5

∅4.6

48mm
