TM1500 Telemetry Module
Telemetry Instruction Manual
Telemetrie-Modul Bedienungsanleitung
Mode d‘emploi du module de télémesure
Manuale di istruzioni Modulo per telemetria
EN
2
The following terms are used throughout the product literature to indicate
various levels of potential harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of
physical property damage AND a little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability
of physical property damage AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability
of property damage, collateral damage, and serious injury OR create a high
probability of superficial injury.
NOTICE
All instructions, warranties and other collateral documents are subject to
change at the sole discretion of Horizon Hobby, LLC. For up-to-date product
literature, visit horizonhobby.com and click on the support tab for this
product.
Meaning of Special Language
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING: Read the ENTIRE instruction manual to become familiar
with the features of the product before operating. Failure to operate the
product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution
and common sense and requires some basic mechanical ability. Failure to
operate this Product in a safe and responsible manner could result in injury
or damage to the product or other property. This product is not intended for
use by children without direct adult supervision. Do not attempt disassembly,
use with Incompatible components or augment product in any way without
the approval of Horizon Hobby, LLC. This manual contains instructions for
safety, operation and maintenance. It is essential to read and follow all the
instructions and warnings in the manual, prior to assembly, setup or use, in
order to operate correctly and avoid damage or serious injury.
WARNING AGAINST COUNTERFEIT PRODUCTS: Always purchase
from a Horizon Hobby, LLC authorized dealer to ensure authentic
high-quality Spektrum product. Horizon Hobby, LLC disclaims all support
and warranty with regards, but not limited to, compatibility and performance
of counterfeit products or products claiming compatibility with DSM or
Spektrum technology.
NOTICE: This product is only intended for use with unmanned, hobby-grade,
remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability
outside of the intended purpose and will not provide warranty service related
thereto.
WARRANTY REGISTRATION
Visit www.community.spektrumrc.com today to register your product.
EN
3
A: Voltage sensor port
B: Temperature sensor port
C: Bind Button
D: XBUS Port 1
E: XBUS Port 2
F: RPM sensor port
G: Input Port
Spektrum TM1500 Telemetry Module (SPM6742)
The Spektrum™ TM1500 Telemetry Module sends valuable data, such as
RPM, temperature, and voltage straight to your telemetry compatible DSMR
®
Spektrum Radio System.
Installation
1. Use servo tape to mount the TM1500 Telemetry Module near the receiver
in a position that allows the included 2.5-inch data lead to extend from the
receiver to the INPUT port on the telemetry module.
2. Plug the Data lead into the TM1500 port marked INPUT and plug the other
end into the BIND port on the receiver.
3. Install any telemetry sensors.
IMPORTANT: The TM1500 antenna’s position significantly affects telemetry
range. For improved telemetry range, mount the antenna as high as practical
(an antenna tube works well) with the 31 mm exposed tip in a vertical position.
SPECIFICATIONS TM1500
Type DSMR Full Range Telemetry Module
Compatibility DX6R, DX5R and DX4R Pro
Dimensions (LxWxH) 37.6 x 27.4 x 16.9mm
Weight 9.7g
Voltage Range 3.5–9V
Internal Sensor Receiver pack voltage
Included Sensors Voltage and Temperature
A
G
F
B
C
D
E
