StarTech.com MCM1110MMLC Bruksanvisning

StarTech.com Nätverkskort/adapter MCM1110MMLC

Läs nedan 📖 manual på svenska för StarTech.com MCM1110MMLC (4 sidor) i kategorin Nätverkskort/adapter. Denna guide var användbar för 14 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/4
Gigabit Ethernet Fiber Media Converter - Compact - 850nm MM LC - 550m
StarTech ID: MCM1110MMLC
This fiber media converter offers an easy, cost-effective way to extend your network over Gigabit fiber. It is
equipped with a multi-mode transceiver which converts a copper RJ45 Ethernet connection to Gigabit fiber to
extend your network over longer distances or connect workstations to switches. The converter provides a
powerful extended networking solution for campuses, businesses, government facilities, stadiums, or other
areas requiring network access.
Cost-effective extension and dependable performance
The Gigabit Fiber Media Converter provides a cost-effective and dependable solution for shorter range network
extensions. It connects an Ethernet network to remote devices over a fiber backbone, with a 550m range on the
fiber optic interface. The media converter has a durable metal housing, engineered to deliver long-lasting
performance.
Versatile connections for broad compatibility
Fully compatible with 10/100/1000Base-T Ethernet networks, the fiber media converter supports auto
negotiation to bridge different speed networks and devices to a Gigabit fiber network. It provides versatile
connectivity to your existing networks and devices, allowing you to maximize the usage and performance of
legacy equipment.
The multi-mode transceiver is removable, giving you the flexibility to change your transceiver in the future to
meet your networking needs.
Easy installation and compact convenience
The unmanaged fiber media converter has a standalone design with simple plug-and-play set-up to ensure fast
and easy installation. Compact in size, the converter gives you flexible installation options - including a wall
mounting option to save space.
www.startech.com
1 800 265 1844
The MCM1110MMLC is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Extend or bridge networks using fiber cable
Provide connectivity to users in an isolated area of a large complex or in a separate building
Ideal for secure connections required by government or corporations where EMI is not acceptable
Features
Convert between an RJ45 copper Ethernet connection and a fiber optic connection to extend your
network cost-effectively
10/100/1000 Mbps RJ45 port supports auto negotiation to bridge different network speeds and devices to
a Gigabit fiber network
Compact standalone design and wall mounting option for easy and convenient installation
850nm LC multimode Gigabit fiber connection using the included SFP transceiver
550m range on fiber optic interface
Link Fault Pass (LFP) supported
Durable metal housing
Auto MDIX
9K Jumbo Frame supported
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Industry Standards IEEE 802.3 10BASE-T
Industry Standards IEEE 802.3u 100BASE-TX
Industry Standards IEEE 802.3ab 1000BASE-T
Industry Standards IEEE 802.3z 1000BASE-SX
Industry Standards IEEE 802.3z 1000BASE-LX
PoE No
WDM No
Auto MDIX Yes
Compatible Networks 10/100/1000 Mbps
Fiber Operating Mode Full-Duplex
Fiber Type Multi Mode
Max Transfer Distance 550 m (1804 ft)
Maximum Data Transfer Rate 1 Gbps
MTBF > 50,000 hours at 25°C
Wavelength 850nm
Local Unit Connectors 1 - RJ-45 Female
Local Unit Connectors 1 - Fiber Optic LC Duplex Female
Color Brown
Enclosure Type Steel
Product Height 1 in [26 mm]
Product Length 3.8 in [97 mm]
Product Weight 7.1 oz [200 g]
Product Width 2.8 in [70 mm]
LED Indicators 1 - Power
LED Indicators 1 - Fiber Port Link/Act
LED Indicators 1 - Copper Port Link/Act
LED Indicators 1 - 1000 Mbps
Center Tip Polarity Positive
Input Current 1 A
Input Voltage 100 ~ 240 AC
Output Current 2 A
Output Voltage 5 DC
www.startech.com
1 800 265 1844

Produktspecifikationer

Varumärke: StarTech.com
Kategori: Nätverkskort/adapter
Modell: MCM1110MMLC
