Quick start guide

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

Manual Revision: 10/16/2015

For the latest information, technical specications, and support for

this product, please visit www.startech.com/PEX433WAC11.

Packaging contents

• 1 x PCI Express® AC600 Wireless-AC network adapter

• 1 x driver CD

• 1 x mounting bracket

• 1 x quick start guide

System requirements

• Available PCI Express slot

• A computer running any of the following:

• Windows® 7 (32-bit and 64-bit)

• Windows 8 (32-bit and 64-bit)

• Windows 8.1 (32-bit and 64-bit)

• Windows 10 (64-bit)

• Windows Server® 2008 R2

• Windows Server 2012

Operating system requirements are subject to change. For the latest

requirements, please visit www.startech.com/PEX433WAC11.

PEX433WAC11

PCI Express AC600 Wireless-AC Network Adapter - 802.11ac

*actual product may vary from photos

Product diagram

Install the hardware

Warning! PCI Express cards should be handled carefully, especially

when they’re transported. If you’re not careful with your cards, you

may lose data as a result. Always handle cards with caution. Make

sure that you’re properly grounded by wearing an anti-static strap

when you install any computer component. If an anti-static strap

isn’t available, touch a large grounded metal surface for several

seconds to discharge any built-up static electricity.

1. Turn o your computer and any devices or peripherals that are

connected to it (for example, printers, external hard drives, and so

on).

2. Unplug the power cable from the back of your computer.

3. Disconnect any peripheral devices that are connected to your

computer.

4. Remove the cover from your computer case. Consult the

documentation that came with your computer for details about

how to do this safely.

5. Locate an open PCI Express slot and remove the corresponding

metal cover plate from the back of your computer case. Consult

the documentation that came with your computer for details

about how to do this safely. This card works in PCI Express slots of

additional lanes (x4, x8, or x16 slots).

6. Gently insert the card into the open PCI Express slot and fasten

the bracket to the back of the case.

Note: If you install the card into a small form factor or a low-prole

desktop system, it may be necessary to replace the preinstalled

standard-prole bracket with the included low-prole (half-height)

installation bracket.

7. Place the cover back onto your computer case.

8. Attach antennas directly to the connectors on the card.

9. Reconnect the power cable to the back of your computer.

10. Reconnect all of the peripheral devices that you disconnected in

step 3.

11. Turn on your computer.

Install the software

To install the software on a computer running a version of Windows

7 or Windows 8, complete the following:

1. Insert the provided CD into the DVD/CD-ROM drive on your

computer.

2. If the Found New Hardware dialog box appears on your screen,

close the dialog box or click Cancel.

3. Do one of the following:

• On the Adapter PCI-E Card Driver menu screen, click

Installation.

• If the menu screen doesn’t appear, navigate to the CD/DVD

drive and double-click the autorun.exe le.

4. Follow the on-screen instructions to complete the installation.

Note: You may be prompted to restart your computer when the

installation is complete.

Activity LED

Antenna connectors

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

IC Radiation Exposure Statement

This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0.5cm between the radiator and

your body.

Déclaration d’exposition à la radiation

Cet équipement respecte les limites d’exposition aux rayonnements IC dénies pour un environnement non contrôlé. Cet équipement doit être installé et mis en marche à une distance minimale de 0.5 cm qui sépare

l’élément rayonnant de votre corps.

L’émetteur ne doit ni être utilisé avec une autre antenne ou un autre émetteur ni se trouver à leur proximité.

FCC ID: VYTLP-8014

IC: 11232A-PEX433WAC11

The Country Code Selection feature is disabled for products marketed in the US/Canada

The device, for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this

manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access our

comprehensive selection of online tools, documentation, and downloads. For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two-year warranty. StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the

products may be returned for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Verify the software installation

To verify that the software was installed correctly on a computer

running a version of Windows, complete the following:

1. Depending on the version of software that you’re running, do one

of the following to open the Device Manager:

• Click > Start Control Panel System and Security Device > >

Manager.

• Click the icon in the taskbar and type in Start device manager

the eld. In the search results, click . Search Device Manager

You may be asked for an admin password or to conrm your

choice.

2. Expand .Network adapters

3. Right-click Realtek 8812AE Wireless LAN 802.11ac PCI-E NIC and

click .Properties

4. On the tab, review the General Device status and make sure that

the device is working properly.

Connect to a Wi-Fi network

Connecting to a wireless network is done through either the

Windows wireless conguration utilities or through the Realtek

utility. To connect to a wireless network, you need to know the name

of the wireless network (SSID), the type of security it’s using (if any),

and the associated password. For more information, consult the

documentation for your wireless access point (AP) or contact your

network administrator.

1. To display a list of the available networks, depending on the

version of Windows OS that you’re running, do one of the

following:

• Navigate to the Network Settings screen.

• In the system tray, click the icon.network adapter

2. Click Connect next to the SSID for the Wi-Fi network that you

want to connect to.

3. If necessary, enter the password for the network.

About the LED indicator

The PEX433WAC11 includes a green activity LED located next to the

antenna connectors. The LED blinks when there is activity on a 2.4 or

5 GHz connection.
