Quick-start guide

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 11/30/2017

For the latest information, technical specications, and support for

this product, please visit www.StarTech.com/US100A20SFP

Package contents

• 1 x network adapter

• 1 x quick-start guide

Requirements

• USB-enabled computer with an available USB 2.0 port

• Any of the following operating systems:

• Microsoft Windows® 10, 8/8.1, 7

• Microsoft Windows Server® 2012, 2008, 2003

• macOS El Capitan (10.11), Yosemite (10.10), Mavericks (10.9),

Mountain Lion (10.8)

• Linux® kernel 3.5 to 4.11.x, LTS versions only

• 100Mbps SFP transceiver with your desired network connection

Operating system requirements are subject to change. For the latest

requirements, please visit www.StarTech.com/US100A20SFP.

US100A20SFP

USB 2.0 to 100Mbps Ethernet Network Adapter - Open SFP

*actual product may vary from photos

Product diagram

Link and activity LED

SFP slot

Built-in USB 2.0

cable

Installation

Notes:

• You may need to restart your computer during the software

installation process. Be sure to save any unsaved material before

you install the software.

• If you’re running Windows 7 (or lower), macOS or Linux, ensure

the network adapter is not connected to your computer until after

driver installation.

1. If you’re running Windows 7 (or lower), macOS or Linux, download

the latest software from the StarTech.com website:

http://www.StarTech.com/US100A20SFP.

Note: If you’re running Windows 8 (or later) proceed to step 5.

2. The software that corresponds with your operating system will be

compressed in a .zip folder. Download and extract the contents

of that folder to a location on your computer that’s easy to access,

such as your or folder. Desktop Downloads

3. Open the folder that corresponds with your specic operating

system and launch the installer le.

4. Follow the on-screen prompts to complete the installation, and if

instructed to do so, restart your computer.

5. Insert your 100Mbps SFP transceiver into the SFP slot on the card.

6. Connect a network interface cable to the SFP transceiver and to

your network.

7. Connect the built-in USB 2.0 cable to a USB port on your

computer.

About the LED indicators

The network adapter features two LED indicators:

• The Power LED illuminates to indicate that the adapter is receiving

power from the computer that it’s connected to.

• The Link and activity LED illuminates solid to indicate a network

connection link and blinks to indicate that data is being sent or

received.

Power LED

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the

equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders. Linux® is the

registered trademark of Linus Torvalds in the U.S. and other countries. Windows® is a registered trademark of Microsoft Corporation in the United States and/or other countries. macOS and FireWire are

trademarks of Apple Inc., registered in the U.S. and other countries.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for

repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not

allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
