Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: April 28, 2020 8:24 AM

Product Diagram (USB2004EXT2NA)

Front

Rear

Component Function

1USB-A Ports • Used to connect (mouse, keyboard, USB Devices

etc.) to the .Remote Extender

2LEDs (Local/Remote)

Power:

• Solid Blue: Extenders The are receiving power.

Link:

• Solid Green: Extenders The are linked.

• O: Extenders The are not linked.

Host:

• Solid: Extender Host Computer is linked to the .

• Flashing: Extenders are in suspend mode.

Activity:

• Flashing: Extenders Data is transmitted between .

• O: Extenders are in a suspended mode.

4 Port USB 2.0 Extender over Cat5e, Cat6, or Cat7 | Up to 330 ft (100 m)

3Power Port 24V 1A

(Local/Remote)

• Used to connect the to Remote Extender AC

Electrical Outlets, Power Adapter using the

(included).

4Cong Port • Used for rmware management/updates.

5Mode Button • Used for rmware management/updates.

6RJ45 Port - Link (Local/

Remote)

• Used to connect the to the Local Extender Remote

Extender.

• Max. data transfer rate = 480Mbps

7USB-B Host Port • Used to connect the to a Local Extender Host

Computer USB Cable, using the (included).

Requirements

For the latest requirements, please visit www.startech.com/USB2004EXT2NA

• USB Enabled Host Computer

• Solid Core Cat5e unshielded twisted pair (UTP) or greater

Installation

1. Position the near the .Local Extender Host Computer

2. Position the near an .Remote Extender AC Electrical Outlet

3. Connect a (or better) to the on the and the Cat5e Cable RJ45 Port Local Extender

other end to the on the .RJ45 Port Remote Extender

Note: The cannot go through any networking equipment (router, Cat5e Cabling

switch, etc.).

4. Connect the (included) to the on the USB Cable USB-B Host Port Local Extender

and the other end to a USB port on the .Host Computer

5. Connect the (included) to the on the Power Adapter Power Port Remote Extender

and the other end to an .AC Electrical Outlet

6. Connect to the on the .USB Devices USB-A Ports Remote Extender

1 2

3 5 6 74

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

EU Declaration of Conformity

We, StarTech.com, declare under our sole responsibility that the USB2004EXT2NA to which this declaration relates, is in

conformity with European Standards EN 55024, EN 55032, EN 61000, and RoHS Directive 2011/65/EU + 2015/863/EU.

WEEE Statement

The European Union has established regulations for the collection and recycling of all waste electrical and electronic equipment

(WEEE). Implementation of WEEE regulations may vary slightly by individual EU member states. Please check with your local and

state government guidelines for safe disposal and rec.

Warranty Information

This product is backed by a three-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

•  製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
