The STRONG SRT 8520 is a high-tech HD receiver for
Free-to-Air and Irdeto encrypted channels via terrestrial
antenna. The USB connector allows you to play video,
music and photo les from external USB devices. Easy
setup and use, excellent picture and audio quality, an
Electronic Programme Guide (EPG), favourite lists,
teletext and subtitles support make this model an
excellent choice.
Digital HDTV receiver for DVB-T2 Free-to-Air TV and
radio programmes*
Cardless embedded Conditional Access System for
watching programmes encrypted by Irdeto
USB port: play video***, music and photo les, update
receiver software via USB storage device
400 channels memory capacity
Channel numbering as given by the operator
Extremely bright and clear picture and excellent sound
quality
Exciting and convenient
HDTV receiver
*Depending on local signal conditions; **Availability depending on broadcaster; ***STRONG cannot guarantee the playback of video files although
extensions are listed, as it depends on codec used, data bit rate and resolution.
Picture similar
Digital Terrestrial High Denition
Receiver SRT 8520
Digital
Audio 30 Timers
Favourite
lists
4
Man./
Auto
Search MPEG 0.70 Watt
Stand-byTV Info MP3/JPGSubtitles
400
Channels
1 6 7
2 4 8
3 5
22 Dec 2017 13:25
EAN SRT 8520: 8717185446913
Electronic TV Programme Guide (EPG) for on screen
programme information of present/following event
information up to 7 days**
Booking of events directly from EPG
Energy saving: automatic standby function and low
power consumption in standby
Teletext, full multi-lingual DVB subtitling and audio
track support**
4 favourite lists for TV and radio programmes
30 event timers with 3 modes (once, daily, weekly)
Parental lock function for menu and rating control for
channel**
Multi-lingual support on screen menu (OSD)
Aspect ratio adjustment 4:3, 16:9, Pan & Scan,
Letterbox
1. Antenna
2. TV set/extra receiver
(analogue signal)
3. TV/HI-FI/Amplifier
4. Digital audio amplifier
5. External USB device
6. TV (HDMI)
7. Power cable
STRONG declares that this item complies with the basic requirements and other relevant regulations of
directives CE 2004/108/EC and 73/23/EC, RoHS 2002/95/EC
Subject to alterations. In consequence of continuous research and development technical specifications,
design and appearance of products may change. Irdeto is a registered trademark of Irdeto Access BV. All
other product names are trademarks or registered trademarks of their respective owners.
© STRONG 2018. All rights reserved.
Tuner:
Input connector: IEC60169-2, female,
75 Ohm nominal
Input frequency range: VHF: 177.5 ~ 226.5 MHz
UHF: 474 ~ 858 MHz
Input signal level: -82 ~ -25 dBm
Antenna power: 5 V DC (+/-5), max. 50 mA,
short cut protected
Demodulation DVB-T/T2:
Demodulation: Compliant to DVB-T2 (EN 302 755)
Demodulation modes: QPSK, 16/64/256 QAM
Bandwidth: 7 or 8 MHz
Guard interval: DVB-T2: 1/128, 1/32, 1/16,
19/256, 1/8, 19/128, 1/4 FFT mode: 1K, 2K, 4K;
8K, 16K, 32K and extended normal
Forward Error Corrections: DVB-T2: 1/2, 3/5, 2/3,
3/4, 4/5 5/6
Video decoder:
Profile: MP @ HL, MPEG-4 H.264/AVC
Input bit rate: Up to 30 Mbit/s
Aspect ratio: 4:3 and 16:9, Letterbox, Pan &
Scan, Auto
Frame rate: 25 Hz for PAL
Video resolution: 576p, 720p, 1080i, 1080p
Audio decoder:
Audio support: MPEG-1 Layer 1 & 2
Audio mode: Mono L/R, Stereo
Frequency response: 20 Hz ~ 20 kHz, unevenness
in the frequency range 60 Hz ~ 18 kHz + / - 0.5 dB
Sampling rate: 32, 44.1, 48 kHz
Conditional Access System:
System: Irdeto CCA
Card reader: 1 slot, conforming to ISO 7816
System and Memory:
Processor: MSD5043
Flash memory: 8 MB
System Memory: 128 MB
Multimedia:
Video playback: Various file formats (MPG,
MPEG, TS, VOB, MP4, AVI, MKV) *
Audio playback: MP3, WMA
Picture view: JPG, PNG, BMP
Connectors:
Antenna Input
Antenna output
3 RCA (Composite Video, Audio Left and Right)
S/PDIF (coaxial)
USB 2.0, Type A connector
HDMI Type A, Version 1.3 with HDCP
General data:
Power Supply: AC 100 – 240 V ~ 50/60 Hz
Power consumption: 10 W max. (with USB device
connected)
Power consumption in standby: 0.70 W (without
USB device connected)
Operating temperature range: 0 ~ +40° C
Storage temperature: -10 ~ +50° C
Operating humidity range: 10 ~ 85% RH, non-
condensing
Dimensions (W x D x H) in mm: 210 x 145 x 49
Weight: 0.59 kg
Technical aterations reserved
Picture similar
Picture similar
Software update via terrestrial antenna (OTA) and
external USB storage device
Automatic and manual channel scan for TV and/or
radio programmes
Many channel handling options: sorting, moving,
locking, deleting and searching
Automatic channel list update
Power on with last viewed channel
Video outputs: HDMI, 3 RCA (Video, Audio L/R), TV
SCART
Digital sound through coaxial output (S/PDIF) by
connecting to digital amplier
VHF/UHF tuner with loop-through
Support of active antenna by 5 V output
Selectable resolution 1080p, 1080i, 720p and 576p
Supports MPEG-4 and H.264
Connectors: ANT IN, TO TV, HDMI, 3 RCA, TV SCART,
S/PDIF coaxial, USB
*Depending on local signal conditions; **Availability depending on broadcaster; ***STRONG cannot guarantee the playback of video files although
extensions are listed, as it depends on codec used, data bit rate and resolution.
*STRONG cannot guarantee the playback of video files although extensions are listed, as it depends on codec used, data bit rate and resolution.
Digital Terrestrial High Denition
Receiver SRT 8520
