Sida 1/8
Write Serial Number here:
_______________ _______ __
WINE C LAR EL
Model SWC530BLBIST
Owner’s Manual
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS
Felix Storch, Inc.
An ISO 9001:20 registered company 15
Summit Appliance Division
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
2
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electrical shock or injury when using your
appliance, follow these basic precautions
Read all instructions before using the appliance.
Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter, and do not
use an extension cord.
It is recommended that a separate circuit, serving only your appliance, be provided. Use receptacles that
cannot be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is
disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect the power before cleaning or servicing. Failure to do so can result in
electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any other
appliance. The fumes can create a fire hazard or explosion.
Use two or more people to move/install the appliance. Failure to do so can result in back or other injur y.
To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 61°F (16°C) and below 95°F (35°C). This unit
must be installed in an area protected from the elements, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high heat.
The appliance must be installed with all electrical connections in accordance with state and local codes.
A standard electrical supply (115V AC only, 60 Hz), properly grounded in accordance with the National
Electrical Code and local codes and ordinances, is required.
Do not kink or pinch the power supply cord of the appliance.
The fuse (or circuit breaker) size should be 15 amps.
It is important for the appliance to be leveled in order to work properly. You may need to make several
adjustments to level it.
Although the unit has been tested at the factory, due to transit and storage, you should clean the
appliance before use.
Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage or
discolor the interior.
Do not use this apparatus for other than residential purposes.
This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the
greenhouse effect. Care must be taken during transportation and setting up of the appliance that no
parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.
In the event of any damage:
- Avoid open flames and anything that creates a spark,
- Disconnect from the electrical power line,
- Air the room in which the appliance is located for several minutes, and
- Contact the Service Department for advice.
The more coolant there is in an appliance, the larger the room it should be installed in. In the event of a
leakage, if the appliance is in a small room, there is the danger of combustible gases building up. For
every ounce of coolant, at least 325 cubic feet of room space is required. The amount of coolant in the
appliance is stated on the data plate on the back of the appliance. It is hazardous for anyone other than
an authorized Service Person to carry out servicing or repairs to this appliance.
Take serious care when handling, moving, and using the appliance to avoid either damaging the
refrigerant tubing or increasing the risk of a leak.
Replacing component parts and servicing shall be done by factory authorized service personnel so as to
minimize the risk of possible ignition due to incorrect parts or improper service.
3
DANGER! Risk of child entrapment
Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are
still dangerous, even if they will “just sit in the garage a few days”.
Remove the door. Leave Before you throw away your old wine cooler or any appliance:
the shelves in place so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the appliance.
- SAVE THESE INSTRUCTIONS -
INSTALLATION INSTRUCTIONS
Before Using Your Appliance
Remove the exterior and interior packing.
Before connecting the appliance to the power source, let it stand upright for approximately 2 hours.
This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
Clean the interior surface with lukewarm water using a soft cloth.
Install the handle.
Installation of Your Appliance
This appliance is designed for free standing or built-in (fully recessed) installation. If free standing,
the unit should have at least 4” of clearance at both sides, at the top and at the back to allow for
adequate ventilation. If it is built-in, leave 3/16” at both sides, 1/16” at the top and 2” at the rear. Be
sure that airflow under the appliance is not blocked.
Place your appliance on a floor that is strong enough to support it when it is fully loaded. To level
your appliance, adjust the front leveling legs at the bottom.
Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.
Extremely cold ambient temperatures may also cause the unit not to perform properly.
Avoid locating the unit in moist areas.
Plug the appliance into an exclusive, properly installed and grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified and authorized products
service center.
T handle stored inside the unit. Install using the screws (supplied). he is
Reversing the Door Swing
This appliance has the capability of the door opening from either the left or right side. The unit is
delivered to you with the door opening from the left side. Should you desire to reverse the opening
direction, please follow the instructions below. To make the reversal, you will find two hardware pieces
in a plastic bag inside the appliance: the top left hinge and the bottom left hinge. The bottom support
bracket is used for both sides.
1. Carefully lay the appliance on its back. Use cushioning to protect the floor and appliance.
