Sida 1/107

C7SIM-Q

USER’S MANUAL

Revision 1.0c

Manual Revision: Revision 1.0c

Printed Date: March 11, 2011

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document. Information in this document is subject to change without notice.

Other products and companies referred to herein are trademarks or registered trademarks of their

respective companies or mark holders.

Printed in the United States of America

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and

documentation, is the property of Supermicro and/or its licensors, and is supplied only under a

license. Any use or reproduction of this product is not allowed, except as expressly permitted by

the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for

all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class B

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

manufacturer’s instruction manual, may cause interference with radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, you are encouraged to try to correct the interference by one or more

of the following measures: Reorient or relocate the receiving antenna. Increase the separation

between the equipment and the receiver. Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected. Consult the dealer or an experienced radio/television

technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Preface

iii

Manual Organization

Chapter 1 describes the features, specications and performance of the mainboard

and provides detailed information about the chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when

installing the processor, memory modules and other hardware components into

the system.

If you encounter any problems, see , which describes troubleshooting Chapter 3

procedures for the video, the memory and the system setup stored in CMOS.

Chapter 4 includes an introduction to BIOS and provides detailed information on

running the CMOS Setup utility.

Appendix A Appendix B provides BIOS POST Messages. provides Driver soft-

ware installation instructions. Appendix C are setup instructions for the Intel Active

Management Techology (AMT), and Appendix D describes the BIOS Recovery

instructions.

Conventions Used in the Manual:

Special attention should be given to the following symbols for proper installation and

to prevent damage done to the components or injury to yourself:

Warning: Important information given to ensure proper system installation,

to prevent bodily injury or damage to the components.

Note: Additional Information given to differentiate various models or to ensure

correct system setup.

Preface

This manual is written for system integrators, PC technicians and knowledgable

PC users. It provides information for the installation and use of the

C7SIM-Q motherboard. The C7SIM-Q supports a single Intel® Core

TM i7, Core i5,

Core i3 and Pentium® processor series in an LGA1156 socket. Featuring the In-

tel Q57 Express, the C7SIM-Q also offers substantial enhancement in price/sys-

tem performance ratio in a cost-effective, small form-factor package. Please refer

to our web site (http://www.supermicro.com/products/) for updates on supported

processors. This product is intended to be installed and serviced by professional

technicians.
