SC745TQ-R1200B SC745TQ-920B

SC745TQ-R800(B) SC745S2-R800(B)

SC745TQ-800(B) SC745S2-800(B)

USER’S MANUAL

1.0a

SC745 CHASSIS

Series

SUPER ®

SC745 Chassis Manual

Manual Revision 1.0a

Release Date: December 1, 2010

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and

documentation, is the property of Supermicro and/or its licensors, and is supplied only under a

license. Any use or reproduction of this product is not allowed, except as expressly permitted by

the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

iii

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the SC745 4U chassis. Installa-

tion and maintenance should be performed by experienced technicians only.

Supermicro's SC745 chassis series is optimized for the latest Intel® Xeon® pro-

cessor 5500 series (Nehalem) and is also compatible with previous generation

Intel and AMD dual processor-based motherboards. Utilizing redundant, high-

efciency power supplies (85% and up) with the Gold Level 1200W option, and

eight hot-swappable 3.5" drive bays, this chassis offers reliable performance with

problem-free maintenance. Designed with 100% cooling redundancy via a combina-

tion of high-performance fans and an adjustable air-shroud capable of tting any

generation of motherboard, the SC745 minimizes the probability of system downtime

or performance degradation from thermal-related issues.

The SC745 features a ninety degree rotatable drive bay module, seven tool-less

expansion slots, and 6-pin power connectors supporting high-end graphics cards

and GPU cards. The SC745 is quick to congure and easy to operate.

For compatible backplane information, refer to the Supermicro Web site at www.

supermicro.com. For information on SCSI backplanes, contact the technical support

department of Supermicro computer.
