Information for Lot 9 of ErP (Ecodesign)

This addendum addresses European Union (EU) Ecodesign requirements for servers and storage

products. All data and ratings within this addendum are in reference only to the Supermicro product(s) in

the manual. The below information conforms requirements laid down in Annex II of the Commission to

Regulation 2019/424.

3(1)(a): See Section 1.1 of the system manual for the product type.

3(1)(b): See the title page and preface of the system manual for the trademark and

manufacturer’s address.

3(1)(c): See the title page of the system manual for product model number(s).

3(1)(d): See the serial number the physical system to determine the year of manufacture. on

3(1)(e-j): PSU Efficiency and Power Factor Value able) (From 80 Plus report) (T

PSU Model #: PWS-350-

Watts: 350W

PSU Efficiency

Power Factor

% of Rated Load

10 %

20 %

50 %

100 %

50 %

Single Output (AC-DC)

86.10%

91.00%

92.51%

90.18%

0.99

System (EUT) Efficiency in Idle State Power (Table)

Representative

Configurations

Measured Idle State

Power (W)

Calculated Idle Power

Allowance (W)

High-End Performance

Configuration

41.6

189.51

Typical Configuration

N/A

Low-End Performance

Configuration

29.3

163.73

System (EUT) Efficiency in Active State Power (Table)

Representative

Configurations

Active State

Efficiency Score

(Effserver)

Minimum Active State

Efficiency

High-End Performance

Configuration

14.3

Typical Configuration

N/A

Low-End Performance

Configuration

13.3

3(1)(k): The operating condition class is A2.

Dry bulb temp C°

Humidity range, non-condensing

Operating

condition

class

Allowable

range

Recom

mended

range

Allowable range

Recommended range

Max dew

point (°C)

Maximum

rate of

change (°

C/hr)

15 32-

18-27

–

12 C Dew Point (DP) and°

8 % relative humidity (RH) to

17 C DP and % RH°80

–

9 C °DP to

15 C and °DP

60 % RH

5/20

10-35

18-27

–

12 C and 8 % °DP RH to

21 C and % °DP 80 RH

Same as A1

5/20

5-40

18-27

–

12 C and 8 % °DP RH to

24 C and % °DP 85 RH

Same as A1

5/20

5-45

18-27

–

12 C and 8 % °DP RH to

24 C and % °DP 90 RH

Same as A1

5/20

3(1)(l): The idle state power at the higher boundary temperature of the operating conditions

class is 49.10W.

3(1)(m): The active state efficiency and performance a minimum of 13.3. is

3(1)(n): There are two methods by which a user can securely delete data from this system. The

user performing secure data deletion should be an IT professional.

The first is with a Unified Extensible Firmware Interface (UEFI) shell utility. This utility

works on X10/X11/H11/H12/M11 motherboard series with onboard SATA/NVMe devices.

Any user may access and download this utility through following link:

https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/Lot9_Secure

_Data_Deletion_Utility/

Download the shell utility package and extract it to a USB flash drive, then plug the drive

into the server for which secure data deletion is necessary. Then turn the system on.

Navigate to the BIOS setup menu, then place the server system into the UEFI shell

environment. Follow the instructions in the README file to invoke the utility and

complete the deletion.

The second method is through the secure data deletion tool provided by the original

manufacturer of the hard drive. This should be used in a scenario where the shell utility

is not applicable. Each manufacturer should have the tool available on their website. If

needed, please look on the hard drive label for the name of the manufacturer and model

information.

3(1)(o): List of recommended combinations of blade servers with chassis: N/A.

3(1)(p) List of all current SKUs within this product family: N/A.

3(3)(a): There is no use of cobalt in batteries in this product.

The indicative weight range of neodymium in the HDD is 0.0 if manufactured by Western

Digital, and is between 5-25 grams if manufactured by Seagate.

3(3)(b): Please see the disassembly instructions on the next page.
