Board Layout

SuperServer F648G2-FC0+/FC0PT+ Quick Reference Guide

CPU Installation Front View & Interface

Heatsink Installation

1. Place the heatsink on top of the installed CPU.

2. Align the four screws to the socket.

3. Holding the heatsink in place, screw down as shown

(cross pattern, in order: A, C, B, D).

4. Note: Only use 6-8 lb/f of torque; otherwise, hand-tighten

each screw to avoid damaging the CPU.

Memory

Caution

SAFETY INFORMATION

IMPORTANT: See installation instructions and safety warning

before connecting system to power supply.

http://www.supermicro.com/about/policies/safety_information.cfm

WARNING:

To reduce risk of electric shock/damage to equipment,

disconnect power from server by disconnecting all power

cords from electrical outlets.

If any CPU socket empty, install protective plastic CPU cap

CAUTION:

Always be sure all power supplies for this system have

the same power output. If mixed power supplies are

installed, the system will not operate.



Rear View

Descrip iot n

No.

Full-height & half-length PCI-E Expansion Slot

UID Button

Power Button

VGA Port

GbE LAN1/LAN2 Ports

Dedicated LAN for IPMI

USB 0/1 Ports

Nodes and Corresponding Hard Drives

1 2

Descrip iot nNo.

Power Supply Module

Rear Fan

46 57 3 1

Pro ors and their Co g ory M escess rrespondin Mem odul

seludoM MMID gnidnopserroC#UPC

CPU 1 P1-

DIMMA1

P1-

DIMMB1

P1-

DIMMC1

P1-

DIMMD1

P1-

DIMMA2

P1-

DIMMB2

P1-

DIMMC2

P1-

DIMMD2

CPU2 P2-

DIMME1

P2-

DIMMF1

P2-

DIMMG1

P2-

DIMMH1

P2-

DIMME2

P2-

DIMMF2

P2-

DIMMG2

P2-

DIMMH2

Pro or and ory M e n for ti l P o ncecess Mem odul Popul ioat Op ma erf rma

Number of

CPUs+DIMMs

CPU and Memory Population Conﬁ guration Table

(For memory to work properly, please follow the instructions below.)

1 CPU &

2 DIMMs

CPU1

P1-DIMMA1/P1-DIMMB1

1 CPU &

4 DIMMs

CPU1

P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1

1 CPU &

5~8 DIMMs

CPU1

P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1 + any pair of P1-DIMMA2/P1-

DIMMB2/P1-DIMMC2/P1-DIMMD2 slots

2 CPUs &

4 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1

2 CPUs &

6 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1

2 CPUs &

8 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-

DIMMG1/P2-DIMMH1

2 CPUs &

9~16 DIMMs

CPU1 + CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-

DIMMG1/P2-DIMMH1 + any pair of P1, P2 DIMM slots

2 CPUs &

16 DIMMs

CPU1+ CPU2

P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-

DIMMG1/P2-DIMMH1, P1-DIMMA2/P1-DIMMB2/P1-DIMMC2/P1-DIMMD2, P2-DIMME2/

P2-DIMMF2/P2-DIMMG2/P2-DIMMH2

F G N e s in the Ch is442B od Lo ioncat ass

Node 1

Controls eight 2.5" HDDs, A1-A8

Node 2

Controls eight 2.5" HDDs, B1-B8

http://www.supermicro.com MNL-1756-QRG

Screw #D

Screw #A

Screw #B

Screw #C

For more information go to :

http://www.supermicro.com/support



Align CPU to socket;

install CPU straight down

NOTE:

1. Do not bend pin inside socket.

2. Please contact Technical Support for additional information

about frequency optimized CPUs and specialized system

optimization.



JSD1 & JSD2: I-SATA4 & I-SATA5

Power Connector

I-SATA4~5: Support SMCI SuperDOM

T-SGPIO 1/2: Intel SATA SGPIO

I-SATA0~3: Internal SATA 3.0 Ports

P2-DIMME1 / P2-DIMME2

P2-DIMMF1 / P2-DIMMF2

CPU2 Socket

SXB2: CPU2 PCI-E p1-x32

Proprietary Slot

P2-DIMMH1 / P2-DIMMH2

P2-DIMMG1 / P2-DIMMG2

P1-DIMMD1 / P1-DIMMD2

P1-DIMMC1 / P1-DIMMC2

DescriptionNo.

SXB1: CPU1 Slot1 PCI-E 3.0 p1-x16

CPU1 Slot2 PCI-E 3.0 x8

CPU2 Slot3 PCI-E 3.0 x8

CPU1 Socket

PCH Slot4 PCIE-E 2.0 x4

JBT1: CMOS Clear

1G_bit LAN Ports 1/2 (X10DRFF-iG/CG)

10G_bit LAN Ports 1/2 (X10DRFF-iTG/CTG)

IPMI_LAN1: IPMI dedicated LAN Support

JTPM1: Trusted Platform Module Header

S-SATA 0~3: SATA 3.0 connectors

P1-DIMMB1 / P1-DIMMB2

P1-DIMMA1 / P1-DIMMA2

Proprietary Slot

DescriptionNo.

J23

JVRM1

JVRM2

JWD1

JPME2

UID_LED1

COM1

JSD2

JUIDB1

FAN7

FAN6

FAN1

FAN4

FAN5

FAN3

FAN2

FAN8

JBT1

I-SATA5

I-SATA3

I-SATA2

I-SATA1

I-SATA0

S-SATA2

S-SATA3

S-SATA0

S-SATA

I-SATA4

SXB1

HDD_LED1

LEDBMC

USB1

JPW1

HDD_PWR2

HDD_PWR1

JPW3

LEDS2

J22

BT1

S-SGPIO1

T-SGPIO2

JIPMB1

REAR_FAN1

REAR_FAN2

SAS4-7

SAS0-3

PCH SLOT4 PCIE-E 2.0 X4

CPU2 SLOT3 PCI-E 3.0 X8

CPU1 SLOT2 PCI-E 3.0 X8

SXB1: CPU1 SLOT1 PCI-E X16 PROPRIETARY SLOT

P1-DIMMA2

P1-DIMMB1

P1-DIMMB2

P1-DIMMA1

P2-DIMME1

P2-DIMME2

P2-DIMMF1

P2-DIMMF2

P2-DIMMG1

SXB2:CPU2 PCI-E X32 PROPRIETARY SLOT

P2-DIMMG2

P2-DIMMH1

P2-DIMMH2

JPW2

P1-DIMMC2

P1-DIMMC1

P1-DIMMD2

P1-DIMMD1

JNVI2C1

T-SGPIO1

CPU2

CPU1

X10DRFF-CG/CTG

JNVI2C2

BIOS

PCH

Battery

USB0

JSD1

JPS1

23 22 21

5 6 7

1920 18

25 24

1 2 3 4

JTPM1

mini-SAS HD Connectors:

SAS0-3: LSI SAS Port 0-3

SAS4-7: LSI SAS Port 4-7

Rev. 1.0a

Populating RDIMM/LRDIMM DDR4 Memory Modules

Type

Ranks

Per DIMM

and Data

Width

DIMM Capacity

(GB)

Speed (MT/s); Voltage (V); Slots per Channel (SPC) and

DIMMs per Channel (DPC)

2 Slots per Channel

1 DPC 2 DPC

E5-2600 V3 E5-2600 V4 E5-2600 V3 E5-2600 V4

4 GB 8 GB 1.2 V 1.2 V 1.2 V 1.2 V

RDIMM SRx4 8 GB 16 GB 2133 2400 1866 2133

RDIMM SRx8 4 GB 8 GB 2133 2400 1866 2133

RDIMM DRx8 8 GB 16 GB 2133 2400 1866 2133

RDIMM DRx4 16 GB 32 GB 2133 2400 1866 2133

LRDIMM QRx4 32 GB 64 GB 2133 2400 2133 2400

LRDIMM 3DS 8Rx4 64 GB 128 GB 2133 2400 2133 2400
