USER’S MANUAL
Revision 1.1
SuperWorkstation
7049GP-TRT
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in an industral environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical
systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.1
Release Date: February 02, 2021
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
document. Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2021 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
3
Preface
3
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the SuperWorkstation. Installation and maintenance
should be performed by experienced technicians only.
Please refer to the server specications page on our website for updates on supported
memory, processors and operating systems (http://www.supermicro.com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: https://www.supermicro.com/wdl/driver
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
support@supermicro.com.
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
Secure Data Deletion
A secure data deletion tool designed to fully erase all data from storage devices can be found
on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/
Lot9_Secure_Data_Deletion_Utility
Warnings
Special attention should be given to the following symbols used in this manual.
4
SuperWorkstation 7049GP-TRT User's Manual
Contents
Chapter 1 Introduction
1.1 Overview ...............................................................................................................................8
1.2 Unpacking the System .........................................................................................................8
1.3 System Features ..................................................................................................................9
1.4 Server Chassis Features ....................................................................................................10
Control Panel ....................................................................................................................10
Front Features ...................................................................................................................12
Rear Features ...................................................................................................................13
1.5 Motherboard Layout ...........................................................................................................14
Quick Reference Table ......................................................................................................15
Chapter 2 Workstation Setup
2.1 Overview .............................................................................................................................18
2.2 Preparing for Setup ............................................................................................................18
General Precautions .........................................................................................................18
Choosing a Setup Location ...............................................................................................18
Workstation Precautions ...................................................................................................19
Rack Precautions ..............................................................................................................19
Ambient Operating Temperature ....................................................................................19
Airow ............................................................................................................................19
Mechanical Loading .......................................................................................................19
Circuit Overloading ........................................................................................................19
Reliable Ground .............................................................................................................20
2.3 Preparing the Chassis for Rack Mounting ..........................................................................21
Removing the Top Tower Cover ........................................................................................21
Removing the Chassis Feet ..............................................................................................21
2.4 Installing the Rails ..............................................................................................................22
Identifying the Sections of the Rack Rails ........................................................................22
Installing the Inner Rails to the Chassis ...........................................................................23
Installing the Outer Rails to the Rack ...............................................................................24
2.5 Installing the Chassis into the Rack ....................................................................................25
Removing the Chassis from the Rack ..............................................................................26
Chapter 3 Maintenance and Component Installation
5
Preface
3.1 Removing Power ................................................................................................................27
3.2 Accessing the System ........................................................................................................27
3.3 Motherboard Components ..................................................................................................28
Processor and Heatsink Installation ..................................................................................28
Overview of the Processor Socket Assembly ...................................................................29
Overview of the Processor Heatsink Module (PHM) ........................................................30
Attaching the Non-F Model Processor to the Narrow Processor Clip to Create the
Processor Package Assembly ...........................................................................................31
Removing the FAN Module ..............................................................................................32
Attaching the Non-F Model Processor Package Assembly to the Heatsink to Form the
Processor Heatsink Module (PHM) ...................................................................................33
Preparing the CPU Socket for Installation ........................................................................34
Removing the Dust Cover from the CPU Socket .............................................................34
Installing the Processor Heatsink Module (PHM) ............................................................35
Removing the Processor Heatsink Module (PHM) from the Motherboard .......................36
Air Shroud .........................................................................................................................37
System Cooling .................................................................................................................38
System Fan Failure ...........................................................................................................38
Replacing System Fans ....................................................................................................38
Drive Carrier Indicators ....................................................................................................40
3.4 Memory Support and Installation .......................................................................................41
DDR4 Memory Support for Intel Xeon Scalable-SP Processors ......................................42
DDR4 Memory Support for 2nd Gen Intel Xeon Scalable-SP Processors .......................42
DIMM Population Guidelines for Optimal Performance ....................................................43
Key Parameters for DIMM Conguration ......................................................................43
DIMM Population Table .....................................................................................................44
Memory Population Table for the Motherboard Using Intel Xeon Scalable-SP and 2nd
Gen Intel Xeon Scalable-SP Processors .......................................................................44
DIMM Population Table .....................................................................................................44
Memory Population Table for the Motherboard Using Intel Xeon Scalable-SP and 2nd
Gen Intel Xeon Scalable-SP Processors .......................................................................44
Installing Memory ..............................................................................................................45
Motherboard Battery .........................................................................................................46
6
SuperWorkstation 7049GP-TRT User's Manual
Chapter 4 Motherboard Connections
4.1 Power Connections ............................................................................................................47
4.2 Headers and Connectors ...................................................................................................48
4.3 Ports ...................................................................................................................................54
Rear I/O Ports ................................................................................................................54
4.4 Jumpers ..............................................................................................................................57
Explanation of Jumpers .................................................................................................57
4.5 LED Indicators ....................................................................................................................60
Chapter 5 Software
5.1 Microsoft Windows OS Installation .....................................................................................61
5.2 Driver Installation ................................................................................................................63
5.3 SuperDoctor ® 5 ...................................................................................................................64
5.4 IPMI ....................................................................................................................................65
BMC ADMIN User Password ............................................................................................65
Chapter 6 UEFI BIOS
6.1 Introduction .........................................................................................................................66
Starting the Setup Utility ...................................................................................................66
6.2 Main Setup .........................................................................................................................67
6.3 Advanced Setup Congurations .........................................................................................68
6.4 Event Logs .......................................................................................................................102
6.5 IPMI ..................................................................................................................................104
6.6 Security .............................................................................................................................107
6.7 Boot ..................................................................................................................................110
6.8 Save & Exit .......................................................................................................................113
Appendix A BIOS Error Codes
Appendix B Standardized Warning Statements for AC Systems
Appendix C System Specications
Appendix D UEFI BIOS Recovery
Appendix E BSMI RoHS
7
Contacting Supermicro
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: marketing@supermicro.com (General Information)
support@supermicro.com (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: sales@supermicro.nl (General Information)
support@supermicro.nl (Technical Support)
rma@supermicro.nl (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3992
Email: support@supermicro.com.tw
Website: www.supermicro.com.tw
8
SuperWorkstation 7049GP-TRT User's Manual
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the 7049GP-TRT. The
7049GP-TRT is based on the X11DPG-QT motherboard and the SC-747BTS-R2K20BP
chassis.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
1.2 Unpacking the System
Inspect the box the SuperServer 7049GP-TRT was shipped in and note if it was damaged
in any way. If any equipment appears damaged, please le a damage claim with the carrier
who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
electromagnetic elds are generated. It will also require a grounded AC power outlet nearby.
Be sure to read the precautions and considerations noted in Appendix B.
Main Parts List
Description QuantityPart Number
Hybrid backplane BPN-SAS3-747TQ-N4 1
iPASS to 2 SATA cable CBL-0188L-02 2
Active CPU heatsink SNK-P0070APS4 2
4-pin PWM fan Fan-0114L4 2
Middle fan FAN-0138L4 2
4-pin PWM fan assembly FAN-0082L4 2
9
Chapter 1: Introduction
1.3 System Features
The following table provides you with an overview of the main features of the 7049GP-TRT.
Please refer to Appendix C for additional specications.
System Features
Motherboard
X11DPG-QT
Chassis
SC-747BTS-R2K20BP
CPU
Dual Intel Xeon Scalable-SP and 2nd Gen Intel Xeon Scalable-SP processors (Socket P) with three Intel®
UltraPath Interconnect (UPI) links of up to 10.4 GT/s
Socket Type
Dual Socket P (LGA 3647)
Memory
Integrated memory controller embedded in the processor supports up to 4TB of 3DS Load Reduced DIMM (3DS
LRDIMM), 3DS Registered DIMM (3DS RDIMM), or up to 2TB of Load Registered DIMM (LRDIMM), with speeds
of 2933*/2666/2400/2133/1866/1600/1333 MHz modules in 16 memory slots.
Note: 2933 MHz memory is supported by 2nd Gen Intel Scalable-SP (82xx/62xx series) processors only.
Chipset
Intel® C621 chipset
Expansion Slots
Four PCI Express 3.0 x16
Two PCI Express 3.0 x16 or HSSI (High Speed Serial Interface)
One PCI Express 3.0 p9-x4 in x8 slot
Hard Drives
Eight hot-swap 3.5" drives
Power
1+1 redundant and hot-swappable 2200W power supplies with PMBus
Form Factor
4U Rackmount/Tower
Dimensions
7.0 x 18.2 x 26.5 in. / 178 x 462 x 673 mm. (W x H x D)
10
SuperWorkstation 7049GP-TRT User's Manual
Figure 1-1. Control Panel View
1.4 Server Chassis Features
Control Panel
The switches and LEDs located on the control panel are described below. See Chapter 4 for
details on the control panel connections.
198
7
6
543
2
11
Chapter 1: Introduction
Control Panel Features
Item Feature Description
1 Power Button
The main power switch is used to apply or remove power from the
power supply to the server. Turning o system power with this button
removes the main power but maintains standby power. To perform
many maintenance tasks, you must unplug system before servicing.
2 Reset Button The reset button is used to reboot the system.
3 HDD LED Indicates hard drive activity on the hard drive when ashing.
4 NIC LED Indicates network activity on LAN when ashing.
5 Information LED Alerts operator of several states. See table below for details.
6 Power Fail Indicates a power failure to the system's power supply units.
7 USB3.0 Two USB 3.0 ports.
8 Line out Line out port.
9 Mic Mic port.
Information LED
Status Description
Continuously on and red An overheat condition has occurred.
(This may be caused by cable congestion.)
Blinking red (1 Hz) Fan failure, check for an inoperative fan.
Blinking red (0.25 Hz) Power failure, check for a non-operational power supply.
Solid blue Local UID has been activated. Use this function to locate the server in
a rack mount environment.
Blinking blue Remote UID is on. Use this function to identify the server from a
remote location.
12
SuperWorkstation 7049GP-TRT User's Manual
Front Chassis Features
Item Feature Description
1 Control Panel Front control panel (see preceding page).
2 Bezel Lock (Optional) Locks the bezel for secure access.
3 Hot-swap Drive Bays Eight 3.5'' drive bays.
Figure 1-2. Chassis Front View
Front Features
The SC-747BTS-R2K20BP is 4U rackmount/tower chassis See the illustration below for the
features included on the front of the chassis.
1
2
3
13
Chapter 1: Introduction
Rear Chassis Features
Item Feature Description
1 Power Two 2200W redundant power supplies with PMBus
2 COM Serial Port
3 USB Two USB 3.0 ports and two USB 2.0 ports
4 LAN Two RJ45 10GBase-T ports
5 IPMI RJ45 Dedicated IPMI LAN port
6 FAN Two rear fans
7 Video VGA port
8 PCIe Four PCIe 3.0 x16 (double-width) slots
9 PCIe Two PCIe 3.0 x16 (single-width) slots and one PCIe 3.0 p13-x4 (in x8) slot
Figure 1-3. Chassis Rear View
Rear Features
The illustration below shows the features included on the rear of the chassis.
1
9
8
7
6
5
432
14
SuperWorkstation 7049GP-TRT User's Manual
Figure 1-4. Motherboard Layout
1.5 Motherboard Layout
Below is a layout of the X11DPG-QT with jumper, connector and LED locations shown. See
the table on the following page for descriptions. For detailed descriptions, pinout information
and jumper settings, refer to Chapter 4.
X11DPG-QT
DESIGNED IN USA
REV:1.02
IPMI CODEMAC CODE
SAN MAC BAR CODE
BIOS
LICENSE
CPU1
CPU2
JBT1
PCH
BT1
BMC
VGA COM1
USB 0/1
IPMI_LAN
USB 4/5 (3.0)
LAN 1LAN 2
FAN 3
FAN 4
FAN 6
FAN 1FAN 5
FAN 2
FAN A
FAN B
JHFI1
P2-DIMMD2
P2-DIMMD1
P2-DIMME1
P2-DIMMF1
P1-DIMMA2
P1-DIMMA1
P1-DIMMB1
P1-DIMMC1
JUIDB1
(UID)
LED2
(UID-LED)
LEDM1
JSDCARD1
JPWR1
JPWR2
JPWR3
LAN
CTRL
P1-DIMMF1
P1-DIMME1
P1-DIMMD1
P1-DIMMD2
P2-DIMMC1
P2-DIMMB1
P2-DIMMA1
P2-DIMMA2
JNCSI1
JHFI2
JTBT1
JPCIE11
JPCIE10
(CPU2 SLOT11 PCI-E 3.0 p14-x4 (IN x8))
(CPU2 SLOT10 PCI-E 3.0 x16)
JPCIE8
JPCIE9
(CPU2 SLOT8 PCI-E 3.0 x16)
JNVI2C2
JNVI2C1
(CPU1 SLOT9 PCI-E 3.0 x16)
JPCIE6
JPCIE4
(CPU2 SLOT6 PCI-E 3.0 x16)
(CPU1 SLOT4 PCI-E 3.0 x16)
JPCIE2
(CPU1 SLOT2 PCI-E 3.0 x16)
S-UM12
JPI2C1
JPWR4
LEDPWR
JF1
JHD_AC1
AUDIO_FP
JSPDIF_IN1
JPAC1
JPME2
JTAG_HFI1
JTPM1
COM2
JPTG1
JRK1
JIPMB1
JVRM_SEL1
JWD1
JSEN1
JSTBY1
I-SATA0~3I-SATA4~7
USB 6/7 (3.0)
USB 2/3
S-SATA4
S-SATA5 USB 8 (3.0)
SP1
M.2 CONNECOR
JSD1JSD2
S-SGPIO
JL1
FAN C FAN D
15
Chapter 1: Introduction
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JHD_AC1 AC97/High Denition Audio Enable O (HD Enabled)
JPAC1 Audio Enable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JPTG1 Onboard 10Gb LAN1/2 Enable/Disable Pins 1-2 (Enabled)
JVRM_SEL1 VRM_I2C Jumper Pins 1-2 (Normal)
JWD1 Watch Dog Timer Reset Pins 1-2 (Reset)
Connector Description
AUDIO_FP Front Panel Audio Header
BT1 Onboard Battery
COM1 COM Port (COM1) on the I/O Backplane
COM2 COM Header
FAN1 ~ FAN6, FANA,
FANB, FANC, FAND System/CPU Fan Headers (FAN5: CPU1 Fan, FAN6: CPU2 Fan)
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0~3, I-SATA4~7 Intel® PCH SATA 3.0 Ports (0-3, 4-7)
JF1 Front Control Panel Header
JIPMB1 4-pin BMC External IC Header (for an IPMI card)
JL1 Chassis Intrusion Header
JNCSI1 NC-SI Header for IPMI Support
JNVI2C1 VPP Header for the NVMe Add-on Card on PCIe Slot 9
JNVI2C2 VPP Header for the NVMe Add-on Card on PCIe Slot 10
JPI2C1 Power Supply SMBus I 2C Header
JPWR1 24-pin ATX Power Connector
JPWR2/JPWR3 12V 8-pin CPU Power Connector (To provide alternative power for special enclosure when the 24-
pin ATX power is not in use.)
JPWR4 12V 4-pin Power Connectors
JRK1 RAID_Key for Onboard SATA Devices
JSD1/JSD2 SATA DOM Power Connectors 1/2
JSDCARD1 Micro SD Card Slot
JSEN1 Inlet Sensor Header
JSPDIF_IN1 Sony/Philips Digital Interface Audio Input Header
16
SuperWorkstation 7049GP-TRT User's Manual
Connector Description
JSTBY1 Standby Power Connector
JTAG_HFI1 HFI Debug Port for Fabric CPU
JTBT1 General Purpose Header for Thunderbolt Add-on Card
JTPM1 Trusted Platform Module/Port 80 connector
JUIDB1 UID (Unit Identier) Switch
LAN1/2 LAN Ports
M.2 CONNECTOR PCIe M.2 Connector, small form factor devices and other portable devices for High speed NVMe
SSDs
S-SATA4/S-SATA5 SATA 3.0 Ports with Power-pin Built-in w/support of SuperDOM (Device-On Module)
S-SGPIO Serial Link General Purpose I/O Header
SP1 Internal Speaker/Buzzer
USB 0/1 Back Panel USB 2.0 Ports
USB 2/3 Front Access USB 2.0 Header
USB 4/5 Back Panel USB 3.0 Ports
USB 6/7 Front Access USB 3.0 Header
USB 8 USB 3.0 Type A Header
VGA VGA Port (Back Panel)
LED Description Status
LED2 UID (Unit Identier) LED Solid Blue: Unit Identied
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
LEDPWR Onboard Power LED Solid Green: Power On
17
Chapter 1: Introduction
JPCIE8
PCIE 3.0 x16
Slot 8
32GB/s
32GB/s x 16
x 4
Slot 6
JPCIE6
PCIE 3.0 x16
UL1
JPCIE9
PCIE 3.0 x16
Slot 9
JPCIE4
PCIE 3.0 x16
Slot 4
JPCIE2
PCIE 3.0 x16
port 1,2(USB3.0)
+
port 11,12(USB2.0)
M.2 CONN
PCIE 3.0 x4
HDR 2x5
x4
VR13
6+1 PHASE
205W
port 8,9(USB2.0)
port 3,4(USB3.0)
+
port 2,3(USB2.0)
TYPE A(USB3.0)
port 5(USB3.0)
+
port 10(USB2.0)
P2
x16
P0
DMIPE3 PE2 PE1
PE2 PE1 DMIPE3
DDR4 DIMM
REAR (USB2.0)
port 4,5(USB2.0)
DDR4 DIMM
#1
B
DDR4 DIMM
x16
x16
DMI
PET [4,5,6,7]
PHY
RTL8211E
USB2.0 [7] ESPI
PET9
#1
DDR4 DIMM
DDR4 DIMMDDR4 DIMM
sSATA Gen3 [4..5]
BMC
REAR(USB3.0)
AST2500
DDR4 DIMM
A
DDR4 DIMM
D
E
#1
#1 #1
#1#1
#1
Slot 10
x16
PCIE 3.0 x16
JPCIE10
BMC SPI
SPI
PCH
SPI FLASH
32MB BMC
DDR4
VGA
IPMI LAN
RJ45
S-SATA4
SATA Gen3 [0..3]
S-SATA5
HDR 2x10
HWM COM1
NC-SI(RMII)
USB3.0 [1..5]
USB2.0 [7..12]
x16
EXT CONN
JNCSI1
VCCP1&2
32GB/s
Slot 11
JPCIE11
PCIE 3.0 x4
DDR4 DIMM
#2
#1
DDR4 DIMM
#2
#1
F
#1
#2
DDR4 DIMM
C
#2
#1
DDR4 DIMM
To BMC RMII port
NC-SI
JLAN1
RJ45
JLAN2
RJ45
Slot 2
I-SATA-0~3
IPASS CONN
SATA Gen3 [4..7] I-SATA-4~7
IPASS CONN
PET [0,1,2,3]
x4
X550
10G
10G
USB2.0 [2..5]
P2 P1
UPI
UPI
UPI
P0
P0
COM2
MUX
PCH SPI
SPI FLASH
32MB BIOS
TPM Header
HD LINK ALC888 AUDIO FP
B
A
C
D
EF
(USB3.0) (USB2.0)
CPU 2
CPU 1
Figure 1-5. Intel® C621 Chipset: System Block Diagram
Note: This is a general block diagram and may not exactly represent the features on your
motherboard. See the System Specications appendix for the actual specications of your
motherboard.
SuperWorkstation 7049GP-TRT User's Manual
18
Chapter 2
Workstation Setup
2.1 Overview
This chapter provides advice setting up your system. If your system is not already fully
integrated with processors, system memory etc., refer to Chapter 3 for details on installing
those specic components.
Caution: Electrostatic Discharge (ESD) can damage electronic components. To prevent such
damage to PCBs (printed circuit boards), it is important to use a grounded wrist strap, handle
all PCBs by their edges and keep them in anti-static bags when not in use.
2.2 Preparing for Setup
Please read this section in its entirety before you begin the installation.
General Precautions
• Review the electrical and general safety precautions in Appendix B.
• Use a regulating uninterruptible power supply (UPS) to protect the server from power
surges and voltage spikes and to keep your system operating in case of a power failure.
• Allow any drives and power supply modules to cool before touching them.
• To maintain proper cooling, always keep all chassis panels closed and all SATA carriers
installed when not being serviced.
Choosing a Setup Location
• The system should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic elds are generated.
• Leave enough clearance in front and back of the system to allow sucient airow and
access when servicing.
• This product should be installed only in a Restricted Access Location (dedicated equipment
rooms, service closets, etc.).
Chapter 2: Server Installation
19
• This product is not suitable for use with visual display workplace devices according to §2
of the German Ordinance for Work with Visual Display Units.
Workstation Precautions
• Ensure that the caster wheels on the workstation are locked.
Rack Precautions
• Ensure that the leveling jacks on the bottom of the rack are extended to the oor so that
the full weight of the rack rests on them.
• In single rack installations, stabilizers should be attached to the rack. In multiple rack in-
stallations, the racks should be coupled together.
• Always make sure the rack is stable before extending a server or other component from
the rack.
• You should extend only one server or component at a time - extending two or more simul-
taneously may cause the rack to become unstable.
• Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating temperature of
the rack environment may be greater than the room's ambient temperature. Therefore,
consideration should be given to installing the equipment in an environment compatible with
the manufacturer’s maximum rated ambient temperature (TMRA).
Airow
Equipment should be mounted into a rack so that the amount of airow required for safe
operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not arise due
to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power supply circuitry
and the eect that any possible overloading of circuits might have on overcurrent protection
SuperWorkstation 7049GP-TRT User's Manual
20
To prevent bodily injury when mounting or servicing this unit in a rack, you must take
special precautions to ensure that the system remains stable. The following guidelines
are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially lled rack, load the rack from the bottom to the top
with the heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or
servicing the unit in the rack.
Slide rail mounted equipment is not to be used as a shelf or a work space.
Warning: Do not pick up the server with the front handles. They are designed to
pull the system from a rack only.
and power supply wiring. Appropriate consideration of equipment nameplate ratings should
be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself should be
grounded. Particular attention should be given to power supply connections other than the
direct connections to the branch circuit (i.e. the use of power strips, etc.).
Chapter 2: Server Installation
21
2.3 Preparing the Chassis for Rack Mounting
The chassis top tower cover and feet must be removed before rack installation.
Removing the Top Tower Cover
1. Locate the blue cover lock at the rear of the cover.
2. Slide the lock to the right and push the cover forward.
3. Lift the top cover o the chassis.
Figure 2-1. Removing the Top Tower Cover and Feet
Removing the Chassis Feet
1. Lay the chassis on its side.
2. Remove the screws holding the chassis feet in place.
3. Each foot has a foot lock tab at the center. Use a at head screwdriver to gently lift the
foot lock upward. Slide the foot toward the rear of the chassis.
Top Cover
Chassis Feet
Cover Lock
SuperWorkstation 7049GP-TRT User's Manual
22
2.4 Installing the Rails
This section provides a guideline for installing the rails to the chassis and to the rack with
the optional rack mount kit.
Identifying the Sections of the Rack Rails
The chassis package includes two optional rack rail assemblies in the rack mounting kit.
Each assembly consists of two sections: An inner xed chassis rail that secures directly to
the server chassis and an outer xed rack rail that secures directly to the rack itself.
Inner Rails
Figure 2-2. Identifying the Inner Rails and Chassis Handles
Chapter 2: Server Installation
23
Figure 2-3. Installing the Handles and Inner Rails to the Chassis
Installing the Inner Rails to the Chassis
1. Attach the handles to the front of the chassis with three screws each.
2. Identify the left and right inner rails. They are labeled on the rails and in the gure
below.
3. Align each rail with the screw holes along the side of the chassis.
4. Screw the rails securely to the side of the chassis.
R
1
1
L
SuperWorkstation 7049GP-TRT User's Manual
24
Installing the Outer Rails to the Rack
Installing the Outer Rails
1. Attach the rear rail to the middle rail.
2. Adjust both to the proper distance so that the rails t snugly into the rack.
3. Secure the rear rail with two M5 screws at the rear of the rack.
4. Repeat steps 1-3 for the left outer rail.
Figure 2-4. Inner and Outer Rack Rail Sections
Rear Rail
Middle Rail
Secure to the Rear of
the Rack Rail
Attach to the Middle Rail
Slide into the Inner Rail
Chapter 2: Server Installation
25
Note: The gure is for illustrative purposes only. Always install servers to the bottom of a
rack rst.
Figure 2-5. Installing the Server into the Rack
2.5 Installing the Chassis into the Rack
With rails attached to both the chassis and the rack, install the system into the rack.
1. Conrm that the chassis includes the inner rails and the outer rails.
2. Align the inner chassis rails with the front of the outer rack rails.
3. Slide the inner rails into the outer rails, keeping the pressure even on both sides (you
may have to depress the locking tabs when inserting). When the chassis has been
pushed completely into the rack, you should hear the locking tabs "click" into the locked
position.
Warning: Stability hazard. The rack stabilizing mechanism must be in place, or the
rack must be bolted to the oor before you slide the unit out for servicing. Failure to
stabilize the rack can cause the rack to tip over.
When initially installing the system to a rack, test that the rail locking tabs engage to
prevent the system from being overextended. Have a rack lift in place as a precaution
in case the test fails.
SuperWorkstation 7049GP-TRT User's Manual
26
Removing the Chassis from the Rack
Caution! It is dangerous for a single person to o-load the heavy chassis from the rack without
assistance. Be sure to have sucient assistance supporting the chassis when removing it
from the rack. Use a lift.
1. Remove the screws that hold the front of the server to the rack.
2. Pull the chassis forward out the front of the rack until it stops.
3. Find the quick-release tab on each side of the chassis on the inner rails. Press down on
the quick-release tab and continue to pull the chassis out of the rack.
Warning: In any instance of pulling the system from the rack, always use a rack lift
and follow all associated safety precautions.
Slide rail mounted equipment is not to be used as a shelf or a work space.
27
Chapter 3: Maintenance and Component Installation
Chapter 3
Maintenance and Component Installation
This chapter provides instructions on installing and replacing main system components. To
prevent compatibility issues, only use components that match the specications and/or part
numbers given.
Installation or replacement of most components require that power rst be removed from the
system. Please follow the procedures given in each section.
3.1 Removing Power
Use the following procedure to ensure that power has been removed from the system. This
step is necessary when removing or installing non hot-swap components or when replacing
a non-redundant power supply.
1. Use the operating system to power down the system.
2. After the system has completely shut-down, disconnect the AC power cords from the
power strip or outlet.
3. Disconnect the power cords from the power supply modules.
3.2 Accessing the System
The SC747BTS-R2K20BP chassis features two removable side covers, allowing access to
the interior.
Removing the Side Covers
1. Remove the two screws securing the left side cover to the chassis.
2. Slide the left cover toward the rear of the chassis.
3. Lift the left cover from the chassis.
4. Remove the three screws securing the right side cover to the chassis.
5. Slide the right cover toward the rear of the chassis.
6. Insert the expansion (add-on) card into the riser card.
Caution: Except for short periods of time, do not operate the server without the cover in place.
The chassis cover must be in place to allow for proper airow and to prevent overheating.
SuperWorkstation 7049GP-TRT User's Manual
28
3.3 Motherboard Components
Processor and Heatsink Installation
Follow the procedures in this section to install a processor (CPU) and heatsink onto the
motherboard mounted in the chassis.
Warning: When handling the processor package, avoid placing direct pressure on the label
area of the CPU or CPU socket. Also, improper CPU installation or socket misalignment can
cause serious damage to the CPU or motherboard which may result in RMA repairs. Please
read and follow all instructions thoroughly before installing your CPU and heatsink.
Notes:
• When receiving a motherboard without a processor pre-installed, make sure that the plastic
protective socket cover is in place and none of the socket pins are bent; otherwise, contact
your retailer immediately.
• Use an Intel-certied multi-directional heatsink.
• Refer to the Supermicro website for updates on CPU support.
• Always connect the power cord last, and always remove it before adding, removing, or
changing any hardware components. Please note that the processor and heatsink should
be assembled together rst to form the Processor Heatsink Module (PHM), and then install
the entire PHM into the CPU socket.
Note: All graphics, drawings, and pictures shown in this manual are for illustration only.
The components that came with your machine may or may not look exactly the same
as those shown in this manual.
29
Chapter 3: Maintenance and Component Installation
Overview of the Processor Socket Assembly
The processor socket assembly contains 1) the Intel 82xx/62xx/52xx/42xx/32xx or
81xx/61xx/51xx/41xx/31xx processor, 2) the narrow processor clip, 3) the dust cover, and 4)
the CPU socket.
3. Dust Cover
4. CPU Socket
1. The Processor
Note: Be sure to cover the CPU socket with the dust cover when the CPU is not in-
stalled.
2. Narrow Processor Clip (the plastic processor package carrier used for the CPU)
(for the non-F Model)
SuperWorkstation 7049GP-TRT User's Manual
30
Overview of the Processor Heatsink Module (PHM)
The Processor Heatsink Module (PHM) contains 1) a heatsink, 2) a narrow processor clip,
and 3) the Intel 82xx/62xx/52xx/42xx or 81xx/61xx/51xx/41xx/31xx processor.
1. Heatsink
2. Narrow Processor Clip
3. Intel Processor
31
Chapter 3: Maintenance and Component Installation
Attaching the Non-F Model Processor to the Narrow Processor
Clip to Create the Processor Package Assembly
To properly install the CPU into the narrow processor clip, please follow the steps below.
1. Locate pin 1 (notch A), which is the triangle located on the top of the narrow processor
clip. Also locate notch B and notch C on the processor clip.
2. Locate pin 1 (notch A), which is the triangle on the substrate of the CPU. Also, locate
notch B and notch C on the CPU as shown below.
3. Align pin 1 (the triangle on the substrate) of the CPU with pin 1 (the triangle) of
the narrow processor clip. Once they are aligned, carefully insert the CPU into the
processor clip by sliding notch B of the CPU into notch B of the processor clip, and
sliding notch C of the CPU into notch C of the processor clip.
4. Examine all corners of the CPU to ensure that it is properly seated on the processor
clip. Once the CPU is securely attached to the processor clip, the processor package
assembly is created.
Note: Please exercise extreme caution when handling the CPU. Do not touch the
CPU LGA-lands to avoid damaging the LGA-lands or the CPU. Be sure to wear ESD
gloves when handling components.
Processor Package Carrier (w/CPU mounted
on the Processor Clip)
A
B
C
Allow Notch C to
latch on to CPU
Allow Notch B to
latch on to CPU
A
A
B
B
C
C
Pin 1
Align CPU Pin 1
CPU (Upside Down)
w/CPU LGA Lands up
CPU/Heatsink Package
(Upside Down)
Align Notch C of the CPU
and Notch C of the Processor Clip
Align Notch B of the CPU
and Notch B of the Processor Clip
SuperWorkstation 7049GP-TRT User's Manual
32
Removing the FAN Module
1. Unplug the fan module connector from the motherboard fan connector.
2. Remove the screw on the fan module to release it from the heatsink.
33
Chapter 3: Maintenance and Component Installation
Attaching the Non-F Model Processor Package Assembly to the
Heatsink to Form the Processor Heatsink Module (PHM)
After you have made a processor package assembly by following the instructions on the
previous page, please follow the steps below to mount the processor package assembly onto
the heatsink to create the Processor Heatsink Module (PHM).
1. Locate "CPU 1" on the heatsink label and the triangular corner next to it on the heatsink.
With your index nger pressing against the screw at this triangular corner, carefully hold
and turn the heatsink upside down with the thermal-grease side facing up. Remove the
protective thermal lm if present, and apply the proper amount of the thermal grease
as needed. (Skip this step if you have a new heatsink because the necessary thermal
grease is pre-applied in the factory.)
2. Holding the processor package assembly at the center edge, turn it upside down. With
the thermal-grease side facing up, locate the hollow triangle located at the corner of the
processor carrier assembly ("a" in the graphic). Note a larger hole and plastic mounting
clicks located next to the hollow triangle. Also locate another set of mounting clicks and
Heatsink
(Upside Down)
Non-Fabric CPU and Processor Clip
(Upside Down)
C
D
dc
a
b
A
B
On Locations of (C, D),
the notches
snap ont
o the heat sink’s
mounting holes
On Locations (A, B),
the notchessnap onto the
heatsink’s sides
A
B
DC
Triangle on the CPU
Triangle on the
Processor Clip
Make sure Mounting
Notches snap into place
a larger hole at the diagonal corner
of the same (reverse) side of the
processor carrier assembly ("b" in
the graphic).
3. With the back of heatsink and
the reverse side of the processor
package assembly facing up, align
the triangular corner on the heatsink
("A" in the graphic) against the
mounting clips next to the hollow
triangle ("a") on the processor
package assembly.
4. Also align the triangular corner ("B")
at the diagonal side of the heatsink
with the corresponding clips on the
processor package assembly ("b").
5. Once the mounting clips on the
processor package assembly
are properly aligned with the
corresponding holes on the back
of heatsink, securely attach the
heatsink to the processor package
assembly by snapping the mounting
clips at the proper places on the
heatsink to create the processor
heatsink module (PHM).
SuperWorkstation 7049GP-TRT User's Manual
34
Preparing the CPU Socket for Installation
This motherboard comes with the CPU socket pre-assembled in the factory. The CPU socket
contains 1) a dust cover, 2) a socket bracket, 3) the CPU (P0) socket, and 4) a back plate.
These components are pre-installed on the motherboard before shipping.
CPU Socket w/Dust Cover On
Dusk Cover
Removing the Dust Cover from the CPU Socket
Remove the dust cover from the CPU socket, exposing the CPU socket and socket pins as
shown on the illustration below.
Note: Do not touch the socket pins to avoid damaging them, causing the CPU to
malfunction.
So Pincket s
Remove he du cove t st r from
the CPU socket. Do not
touch the socket pins!
35
Chapter 3: Maintenance and Component Installation
Installing the Processor Heatsink Module (PHM)
1. Once you have assembled the processor heatsink module (PHM) by following the
instructions listed on page 29 or page 30, you are ready to install the processor heatsink
module (PHM) into the CPU socket on the motherboard. To install the PHM into the
CPU socket, follow the instructions below.
2. Locate the triangle (pin 1) on the CPU socket, and locate the triangle (pin 1) at the
corner of the PHM that is closest to "1." (If you have diculty locating pin 1 of the PHM,
turn the PHM upside down. With the LGA-lands side facing up, you will note the hollow
triangle located next to a screw at the corner. Turn the PHM right side up, and you will
see a triangle marked on the processor clip at the same corner of hollow triangle.)
3. Carefully align pin 1 (the triangle) on the PHM against pin 1 (the triangle) on the CPU
socket.
4. Once they are properly aligned, insert the two diagonal oval holes on the heatsink into
the guiding posts.
5. Using a T30 Torx-bit screwdriver, install four screws into the mounting holes on the
socket to securely attach the PHM onto the motherboard starting with the screw marked
"1" (in the sequence of 1, 2, 3, and 4).
Note: Do not use excessive force when tightening the screws to avoid damaging the
LGA-lands and the processor.
#1 #2
#3
#4
Small Guide Post
Large
Guide
Post
Oval D
T30 Torx Driver
Use a torque
of 12 lbf
Oval C
Printed Triangle
Mounting the Processor Heatsink Module
into the CPU socket (on the motherboard)
T e screws in theighten th
sequence of 1, 2, 3, 4 (top 3 quarter view)
SuperWorkstation 7049GP-TRT User's Manual
36
Printed Triangle on Motherboard
Removing the screws in
the sequence of 4, 3, 2, 1
#1 #2
#3
#4
After removing the screws,
lift the Processor Heatsink
Module off the CPU socket.
CPU Socket
Removing the Processor Heatsink Module (PHM) from the
Motherboard
Before removing the processor heatsink module (PHM), unplug power cord from the power
outlet.
1. Using a T30 Torx-bit screwdriver, turn the screws on the PHM counterclockwise to
loosen them from the socket, starting with screw marked #4 (in the sequence of 4, 3, 2,
1).
2. After all four screws are removed, wiggle the PHM gently and pull it up to remove it from
the socket.
Note: To properly remove the processor heatsink module, be sure to loosen and remove
the screws on the PHM in the sequence of 4, 3, 2, 1 as shown below.
37
Chapter 3: Maintenance and Component Installation
Figure 3-1. Installing the Air Shroud
Air Shroud
The air shroud is used to concentrate airow to maximize fan eciency. The air shroud does
not require screws to set up.
Installing the Air Shroud
1. Lay the chassis on a at, stable surface and remove the chassis cover.
2. If necessary, move any cables that interfere with the air shroud placement.
3. Place the air shroud in the chassis. The air shroud ts just behind the three fans in the
fan rack. Slide the air shroud into the grooves just behind the fan rack.
4. Reroute any cables that were moved and replace the chassis cover.
39
Chapter 3: Maintenance and Component Installation
Figure 3-3. Rear System Chassis Fans
Figure 3-2. Mid-System Chassis Fans
Rear Fan Release Tab
FAN-0082L4
Mid Fan
Release Tab
FAN-0138L4
FAN-0114L4
SuperWorkstation 7049GP-TRT User's Manual
40
Drive Carrier Indicators
Each drive carrier has two LED indicators: an activity indicator and a status indicator. For RAID
congurations using a controller, the meaning of the status indicator is described in the table
below. For OS RAID or non-RAID congurations, some LED indications are not supported,
such as hot spare. For VROC congurations, refer to the VROC appendix in this manual.
Drive Carrier LED Indicators
Color Blinking Pattern Behavior for Device
Activity
LED
Blue Solid On SAS/NVMe drive installed
Blue Blinking I/O activity
Status
LED
Red Solid On Failure of drive with RSTe support
Red Blinking at 1 Hz Rebuilding drive with RSTe support
Red Blinking with two blinks
and one stop at 1 Hz Hot spare for drive with RSTe support
(not supported in VMD mode)
Red On for ve seconds,
then o Power on for drive with RSTe support
Red Blinking at 4 Hz Identify drive with RSTe support
Green Solid On Safe to remove NVMe device
(not supported in VMD mode)
Amber Blinking at 1 Hz Attention state—do not remove NVMe device
(not supported in VMD mode)
Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and
servers. For information on recommended HDDs, visit the Supermicro website at https://www.
supermicro.com/products/nfo/Ultra.cfm.
41
Chapter 3: Maintenance and Component Installation
3.4 Memory Support and Installation
The X11DPG-QT supports up to 4TB of 3DS Load Reduced DIMM (3DS LRDIMM), 3DS
Registered DIMM (3DS RDIMM), or up to 2TB of Load Registered DIMM (LRDIMM), with
speeds of 2933*/2666/2400/2133/1866/1600/1333 MHz modules in 16 memory slots (*Notes
below). Populating the DDR4 memory module in 2DPC system conguration on this MBD
will aect memory bandwidth performance. Populating these DIMM modules with a pair of
emory modules of the same type and size will result in interleaved memory, which will improve
memory performance.
Notes:
• Be sure to use the memory modules of the same type and speed on the motherboard.
Mixing of memory modules of dierent types and speeds is not allowed.
• When installing memory modules, be sure to populate the rst DIMM module on the blue
memory slot, which is the rst memory slot of a memory channel, and then populate the
second DIMM in the black slot if 2DPC memory conguration is used.
• Memory speed is dependent on the type of processors used in your system.
• Populating DDR4 memory modules in a two-DIMMs per-channel (2DPC) conguration on
this motherboard will aect memory bandwidth and performance.
• Unbalanced memory conguration is not recommended.
• 2933 MHz memory is supported by 2nd Generation Intel Xeon Scalable-SP (82xx/62xx
series) processors only.
• The memory capacity support will dier according to the processor SKUs.
SuperWorkstation 7049GP-TRT User's Manual
42
DDR4 Memory Support for Intel Xeon Scalable-SP Processors
DDR4 Memory Support
Type
Ranks
Per
DIMM
and
Data
Width
DIMM Capacity (GB)
Speed (MT/s)
One Slot
per Channel Two Slots
per Channel
DRAM Density One DIMM per
Channel One DIMM per
Channel Two DIMMs
per Channel
4Gb 8Gb 1.2 Volts 1.2 Volts 1.2 Volts
RDIMM
SRx4 4GB 8GB
2666 2666 2666
SRx8 8GB 16GB
DRx8 8GB 16GB
DRx4 16GB 32GB
RDIMM 3Ds QRX4 N/A 2H-64GB
8RX4 N/A 4H-128GB
LRDIMM QRx4 32GB 64GB
LRDIMM 3Ds QRx4 N/A 2H-64GB
8Rx4 N/A 4H-128 GB
DDR4 Memory Support
Type
Ranks
Per
DIMM
and
Data
Width
DIMM Capacity (GB)
Speed (MT/s)
One Slot
per Channel Two Slots per
Channel
DRAM Density One DIMM
per Channel One DIMM
per Channel
Two
DIMMs per
Channel
4 Gb* 8 Gb 16 Gb 1.2 Volts 1.2 Volts 1.2 Volts
RDIMM
SRx4 4 GB 8 GB 16 GB
2933** 2933** 2933**
SRx8 8 GB 16 GB 32 GB
DRx8 8 GB 16 GB 32 GB
DRx4 16 GB 32 GB 64 GB
RDIMM 3Ds QRX4 N/A 2H-64GB 2H-128GB
8RX4 N/A 4H-128GB 4H-256GB
LRDIMM QRx4 32 GB 64 GB 128 GB
LRDIMM 3Ds QRx4 N/A 2H-64GB 2H-64GB
8Rx4 N/A 4H-128 GB 4H-256 GB
DDR4 Memory Support for 2nd Gen Intel Xeon Scalable-SP Processors
Notes:
• 2933 MHz memory support in two-DIMMs per-channel (2DPC) conguration can be
achieved by using memory purchased from Supermicro.
• 2933 MHz memory is supported by 2nd Generation Intel Xeon Scalable-SP processors only.
43
Chapter 3: Maintenance and Component Installation
DIMM Population Guidelines for Optimal Performance
For optimal memory performance, follow the instructions listed in the tables below when
populating memory modules.
Key Parameters for DIMM Conguration
Key Parameters for DIMM Congurations
Parameters Possible Values
Number of Channels 1, 2, 3, 4, 5, or 6
Number of DIMMs per Channel 1DPC (1 DIMM Per Channel) or 2DPC (2 DIMMs Per Channel)
DIMM Type RDIMM (w/ECC), 3DS RDIMM, LRDIMM, 3DS LRDIMM
DIMM Construction
non-3DS RDIMM Raw Cards: A/B (2Rx4), C (1Rx4), D (1Rx8), E (2Rx8)
3DS RDIMM Raw Cards: A/B (4Rx4)
non-3DS LRDIMM Raw Cards: D/E (4Rx4)
3DS LRDIMM Raw Cards: A/B (8Rx4)
General DIMM Mixing Guidelines
• All DIMMs must be all DDR4 DIMMs.
• x4 and p43-x8 DIMMs can be mixed in the same channel.
• Mixing of LRDIMMs and RDIMMs is not allowed in the same channel, across dierent
channels, and across dierent sockets.
• Mixing of non-3DS and 3DS LRDIMM is not allowed in the same channel, across dier-
ent channels, and across dierent sockets.
Mixing of DIMM Types within a Channel
DIMM Types RDIMM LRDIMM 3DS LRDIMM
RDIMM Allowed Not Allowed Not Allowed
LRDIMM Not Allowed Not Allowed Allowed
3DS LRDIMM Not Allowed Not Allowed Allowed
SuperWorkstation 7049GP-TRT User's Manual
44
DIMM Population Table
Note: Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Memory Population Table for the Motherboard Using Intel Xeon Scalable-SP and 2nd Gen Intel Xeon
Scalable-SP Processors
Memory Population Table for the X11DP Motherboard w/16 DIMM Slots Onboard
When 1 CPU is used: Memory Population Sequence
1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
1 CPU & 4 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 6 DIMM CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 8 DIMMs
Unbalanced: not
recommended)
(CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-
DIMME1/P1-DIMMF1
2 CPUs & 2 DIMMs CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1
2 CPUs & 10 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 14 DIMMs
(Unbalanced: not
recommended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-
DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMA2/P2-DIMMD1/P2-DIMME1/P2-
DIMMF1
DIMM Population Table
Note: Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Memory Population Table for the Motherboard Using Intel Xeon Scalable-SP and 2nd Gen Intel Xeon
Scalable-SP Processors
Memory Population Table for the X11DP Motherboard w/16 DIMM Slots Onboard
When 1 CPU is used: Memory Population Sequence
1 CPU & 1 DIMM CPU1: P1-DIMMA1
1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
1 CPU & 4 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 5 DIMMs
(Unbalanced: not
recommended) CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 6 DIMM CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 7 DIMMs
(Unbalanced: not
recommended)
CPU1:P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-
DIMMF1
1 CPU & 8 DIMMs
Unbalanced: not
recommended)
(CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-
DIMME1/P1-DIMMF1
When 2 CPUs are
used: Memory Population Sequence
2 CPUs & 2 DIMMs CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 4 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
CPU2: P2-DIMMA1/P2-DIMMD1
2 CPUs & 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1
2 CPUs & 8 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 10 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 12 DIMM CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 14 DIMMs
(Unbalanced: not
recommended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-
DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMA2/P2-DIMMD1/P2-DIMME1/P2-
DIMMF1
2 CPUs & 16 DIMMs
(Unbalanced: not
recommended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-
DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/P2-
DIMME1/P2-DIMMF1
45
Chapter 3: Maintenance and Component Installation
Release Tab
Notch
Press both ends straight
down into the memory slot.
Installing Memory
1. Remove power from the system as described in Section 3.1.
2. Starting with the slot in the order described previously, push the release tab outward to
unlock it.
3. Align the key of the DIMM with the receptive point on the memory slot and with your
thumbs on both ends of the module, press it straight down into the slot until the module
snaps into place.
4. Press the release tab to the locked position to secure the DIMM module into the slot.
5. Repeat the procedure for the remaining DIMM modules in the order detailed in the
previous section.
To remove a DIMM module, unlock the release tabs then pull the module from the slot.
SuperWorkstation 7049GP-TRT User's Manual
46
Warning: There is a danger of explosion if the onboard battery is installed upside down (which
reverses its polarities). This battery must be replaced only with the same or an equivalent type
recommended by the manufacturer (CR2032).
Figure 3-4. Installing the Onboard Battery
Motherboard Battery
The motherboard uses non-volatile memory to retain system information when system power
is removed. This memory is powered by a lithium battery residing on the motherboard.
Replacing the Battery
1. Remove power from the system as described in section 3.1 and remove the node from
the chassis.
2. Push aside the small clamp that covers the edge of the battery. When the battery is
released, lift it out of the holder.
3. To insert a new battery, slide one edge under the lip of the holder with the positive (+)
side facing up. Then push the other side down until the clamp snaps over it.
Note: Handle used batteries carefully. Do not damage the battery in any way; a damaged
battery may release hazardous materials into the environment. Do not discard a used battery
in the garbage or a public landll. Please comply with the regulations set up by your local
hazardous waste management agency to dispose of your used battery properly.
47
Chapter 4: Motherboard Connections
Chapter 4
Motherboard Connections
This section describes the connections on the motherboard and provides pinout denitions.
Note that depending on how the system is congured, not all connections are required. The
LEDs on the motherboard are also described here. A serverboard layout indicating component
locations may be found in Chapter 1.
Please review the Safety Precautions in Appendix B before installing or removing components.
4.1 Power Connections
Two power connections on the 7049GP-TRT must be connected to the power supply. The
wiring is included with the power supply.
• 24-pin Primary ATX Power (JPWR1)
• 8-pin Processor Power (JPWR2)
Warning: To provide adequate power to your system and to avoid damaging the power sup-
ply or the motherboard, be sure to connect all power connectors mentioned above to the
power supply. Failure in doing so may void the manufacturer warranty on your power supply
and motherboard.
Main ATX Power Supply Connector
The primary power supply connector (JPWR1) meets the ATX SSI EPS 24-pin specication.
ATX Power 24-pin Connector
Pin Denitions
Pin# Pin#Denition Denition
13 +3.3V +3.3V1
14 NC +3.3V2
15 Ground Ground3
16 PS_ON +5V4
17 Ground Ground5
18 Ground +5V6
19 Ground Ground7
20 PWR_OKRes (NC) 8
21 +5V 5VSB9
22 +5V 10 +12V
23 +5V +12V11
24 Ground 12 +3.3V
12V 8-pin PWR Connector
Pin Denitions
Pins Denition
1 through 4 Ground
5 through 8 +12V
48
SuperWorkstation 7049GP-TRT User's Manual
4.2 Headers and Connectors
Fan Headers
There are eight fan headers on the motherboard. These are 4-pin fan headers; pins 1-3
are backward compatible with traditional 3-pin fans. The onboard fan speeds are controlled
by Thermal Management (via Hardware Monitoring) in the BIOS. When using Thermal
Management setting, please use all 3-pin fans or all 4-pin fans.
Fan Header
Pin Denitions
Pin# Denition
1 Ground (Black)
2 +12V (Red)
3 Tachometer
4 PWM Control
Internal Speaker/Buzzer
The Internal Speaker/Buzzer (SP1) is used to provide audible indications for various beep
codes. See the table below for pin denitions.
Internal Buzzer
Pin Denitions
Pin# Denition
1 Pos (+) Beep In
2 Neg (-) Alarm Speaker
S-SGPIO Header
A Serial General Purpose Input/Output header (S-SGPIO) is located on the motherboard.
This header is used to communicate with the enclosure management chip on the backplane.
See the table below for pin denitions.
SGPIO Header
Pin Denitions
Pin# Pin#Denition Denition
1 2NC NC
3 4Ground DATA Out
5 6Load Ground
7 8Clock NC
NC = No Connection
49
Chapter 4: Motherboard Connections
Disk-On-Module Power Connector
The Disk-On-Module (DOM) power connectors at JSD1 and JSD2 provide 5V power to a
solid-state DOM storage devices connected to one of the SATA ports. See the table below
for pin denitions.
DOM Power
Pin Denitions
Pin# Denition
1 5V
2 Ground
3 Ground
Trusted Platform Module/Port 80 Header
Pin Denitions
Pin# Pin#Denition Denition
1 2P3V3 SPI_TPM_CS_N
3 4PCIE_RESET_N# SPI_PCH_MISO
5 6SPI_PCH_CLK# Ground
7 8SPI_PCH_MOSI N/A
9 JTPM1_P3V3A 10 IRQ_TPM_SPIN_N
TPM Header
The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is
available from a third-party vendor. A TPM/Port 80 connector is a security device that supports
encryption and authentication in hard drives. It allows the motherboard to deny access if the
TPM associated with the hard drive is not installed in the system. See the table below for
pin denitions.
Chassis Intrusion
A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable
from the chassis to the header to inform you when the chassis is opened.
Chassis Intrusion
Pin Denitions
Pins Denition
1 Intrusion Input
2 Ground
50
SuperWorkstation 7049GP-TRT User's Manual
4-pin BMC External I 2C Header
A System Management Bus header for IPMI 2.0 is located at JIPMB1. Connect a cable to this
header to use the IPMB I 2C connection on your system. See the table below for pin denitions.
External I 2C Header
Pin Denitions
Pin# Denition
1 Data
2 Ground
3 Clock
4 No Connection
Power SMB (I 2C) Header
Power System Management Bus (I 2C) header at JPI 2C1 monitors the power supply, fan and
system temperatures. Refer to the table below for pin denitions.
Power SMB Header
Pin Denitions
Pin# Denition
1 Clock
2 Data
3 Power Fail
4 Ground
5 +3.3V
I-SATA 3.0 and S-SATA 3.0 Ports
The X11DPG-QT has eight I-SATA 3.0 ports (I-SATA0~3, I-SATA4~7) which are supported by
the Intel® C621 chipset. In addition, it also has two S-SATA 3.0 ports (S-SATA4/ S-SATA5)
that are supported by the Intel® SCU. S-SATA4/5 can be used with Supermicro SuperDOMs
which are yellow SATA DOM connectors with power pins built in, and do not require external
power cables. Supermicro SuperDOMs are backward-compatible with regular SATA HDDs or
SATA DOMs that need external power cables. All these SATA ports provide serial-link signal
connections, which are faster than the connections of Parallel ATA.
SATA 3.0 Port
Pin Denitions
Pin# Signal
1 Ground
2 SATA_TXP
3 SATA_TXN
4 Ground
5 SATA_RXN
6 SATA_RXP
7 Ground
51
Chapter 4: Motherboard Connections
RAID Key Header
A RAID_Key header is located at JRK1 on the motherboard. RAID key is used to support
onboard NVMe connections.
RAID Key Header
Pin Denitions
Pin# Denition
1 Ground
2 RAID_KEY_PU
3 Ground
4 PCH_RAID_KEY
Audio Front Panel Header
A 10-pin audio header (AUDIO_FP) located on the motherboard allows you to use the onboard
sound chip (ALC888S) for audio functions. Connect an audio cable to the this header to use
this feature. See the table below for pin denitions.
Audio Header
Pin Denitions
Pin# Pin#Denition Denition
1 2Microphone_Left Audio_Ground
3 4Microphone_Right Audio_Detect
5 6Line_2_Right Ground
7 8Jack_Detect Key
9 Line_2_Left 10 Ground
SPDIF_IN Header
The Sony/Philips Digital Interface (JSPDIF_IN1) header is used for digital audio. Place a cap
on each header for audio support. You will also need to have a cable to use the connection.
SPDIF_In
Pin Denitions
Pin# Denition
1 S/PDIF_In
2 Ground
Micro SD Card Slot
Insert a Micro SD memory card into the expansion slot at JSDCARD1 for additional memory
or OS image.
52
SuperWorkstation 7049GP-TRT User's Manual
NVMe I2C Header
JNVI2C1 and JNVI2C2 are management headers for the Supermicro AOC NVMe PCIe
peripheral cards. Please connect the I2C cable to the connector. Also, JNVI2C1 and JNVI2C2
are VPP headers for NVMe add-on cards on PCIe slots 9 and 10 respectively.
Standby Power
The standby power header is located at JSTBY1 on the motherboard. Refer to the table
below for pin denitions.
Standby Power
Pin Denitions
Pin# Denition
1 +5V Standby
2 Ground
3 No Connection
I/O Header for Thunderbolt
The JTBT1 header is a general purpose I/O header for a Thunderbolt add-on card.
PCIe M.2 Connector (M.2 Connector)
The PCIe M.2 connector is for devices such as memory cards, wireless adapters, etc. These
devices must conform to the PCIe M.2 specications (formerly known as NGFF). Also, the
M.2 socket on the motherboard supports PCIe 3.0 p52-x4 (32 Gb/s) SSD cards in the 2280 and
22110 form factors.
NC-SI Header for IPMI Support
A Network-Controller Sideband Interface (NC-SI) header is located at JNCSI1 on the
motherboard. Connect an appropriate cable from this header to an add-on card to provide the
out-of-band (sideband) connection between the onboard Baseboard Management Controller
(BMC) and a Network Interface Controller (NIC) for remote management. For the network
sideband interface to work properly, you will need to use a motherboard that supports NC-SI
and also need to have a special cable. Please contact Supermicro at www.supermicro.com
to purchase the cable for this header. Refer to the table below for pin denitions.
53
Chapter 4: Motherboard Connections
NC-SI Header for IPMI Support
Pin Denitions
Pin# Pin#Denition Denition
1 2CLK_50MHz Ground
3 4NCSI_CRS_DV Ground
5 6NCSI_RXD0 Ground
7 8NCSI_RXD1 Ground
9 NCSI_TXD0 10 Ground
11 NCSI_TXD1 12 Ground
13 NCSI_TX_EX 14 NCSI_PRESENT_N
15 NC 16 NC
17 185V STBY 5V STBY
19 205V STBY 5V STBY
21 22 NC5V STBY
Inlet Sensor Header
This header (JSEN1) allows BMC to monitor thermal inlet temperature. A special module is
required. Please contact Supermicro at www.supermicro.com to purchase the module for this
header. Refer to the table below for pin denitions.
HFI Debug Port for Fabric CPU (JTAG_HFI1)
This connector (JTAG_HFI1) is the JTAG port and provides miscellaneous signals connectivity
requirements of the Fabric CPU debug port. Refer to the table below for pin denitions.
Inlet Sensor Header
Pin Denitions
Pin# Denition
1 SMBDAT
2 Ground
3 SMBCLK
4 3.3V STBY
HFI Debug Port for Fabric CPU
Pin Denitions
Pin# Pin#Denition Denition
1 2CD_TCK Ground
3 4CD_TDO VCCH
5 6CD_TMS CD_TRST_N
7 8CPU_PWRGD NC
9 CD_TDI 10 Ground
54
SuperWorkstation 7049GP-TRT User's Manual
4.3 Ports
Figure 4-2. Rear I/O Ports
Rear I/O Ports
See the gure below for the locations and descriptions of the various I/O ports on the rear
of the motherboard.
Rear I/O Ports
# #Description Description
1. 6.COM Port 1 USB Port 1
2. 7.Dedicated IPMI LAN Port LAN Port 1
3. 8.USB 3.0 Port 4 LAN Port 2
4. 9.USB 3.0 Port 5 VGA Port
5. USB Port 0
1
5
4
3
2
6 7 8 9
VGA Port
One VGA port is located next to LAN Port 2 on the I/O back panel. Use this connection for
VGA display.
Serial Port
There is one COM port (COM1) on the I/O back panel and one COM header (COM2) on the
motherboard. This COM ports provide serial communication support. See the table below
for pin denitions.
COM Port
Pin Denitions
Pin# Pin#Denition Denition
1 6DCD DSR
2 7RXD RTS
3 8TXD CTS
4 9DTR RI
5 Ground 10 N/A
55
Chapter 4: Motherboard Connections
LAN Ports
Two LAN ports (LAN1, LAN2) are located on the I/O back panel. These ports accept RJ45
type cables.
LAN Port
Pin Denition
Pin# Pin#Denition Denition
1 5TX_D1+ BI_D3-
2 6TX_D1- RX_D2-
3 7RX_D2+ BI_D4+
4 8BI_D3+ BI_D4-
Front Panel USB 3.0
Header Pin Denitions
Pin# Pin#Denition Denition
1 2+5V +5V
3 4USB_PN2 USB_PN3
5 6USB_PP2 USB_PP3
7 8Ground Ground
9 Key 10 Ground
Back Panel USB (3.0)
Pin Denitions
Pin# Pin#Denition Denition
1 VBUS 10 Power
2 D- 11 USB 2.0 Di󰀨erential Pair
3 D+ 12
4 Ground 13 Ground of PWR Return
5 StdA_SSRX- 14 SuperSpeed Receiver
6 StdA_SSRX+ 15 Di󰀨erential Pair
7 GND_DRAIN 16 Ground for Signal Return
8 StdA_SSTX- 17 SuperSpeed Transmitter
9 StdA_SSTX+ 18 Di󰀨erential Pair
Universal Serial Bus (USB) Ports
There are two USB 3.0 ports (USB 4/5) located on the I/O back panel. The motherboard also
has a front access USB 3.0 header that supports two USB connections (USB 6/7). A USB
Type A header, USB 8, also provides USB 3.0 support. The onboard headers can be used
to provide front side USB access with a cable (not included).
56
SuperWorkstation 7049GP-TRT User's Manual
Unit Identier Switch/UID LED Indicator
A rear Unit Identier (UID) switch (JUIDB1) and an rear LED Indicator (LED2) are located
on the rear side of the system. The front UID LED is located on Pin 7 of the Front Control
Panel (JF1). When you press the UID switch, both front and rear UID LED indicators will be
turned on. Press the UID switch again to turn o󰀨 the LEDs. The UID Indicators provide easy
identication of a system unit that may be in need of service.
Note: UID can also be triggered via IPMI on the motherboard. For more information
on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.
supermicro.com.
UID Switch
Pin Denitions
Pin# Denition
1 Ground
2 Ground
3 Button In
4 Button In
UID LED
Pin Denitions
Color Status
Blue: On Unit Identied
IPMI LAN Port
A dedicated IPMI LAN port that supports Gigabit LAN is located next to USB 0/1 ports on
the back panel. This LAN port is supported by the onboard AST 2500 BMC and accepts an
RJ45 type cable. Refer to the LED Indicator Section for LAN LED information.
LAN Ports
Pin Denitions
Pin# Pin#Denition Denition
1 P2V5SB 10 SGND
2 TD0+ 11 Act LED
3 P3V3SBTD0- 12
4 Link 100 LED (Yellow, +3V3SB)TD1+ 13
5 Link 1000 LED (Yellow, +3V3SB)TD1- 14
6 GroundTD2+ 15
7 GroundTD2- 16
8 GroundTD3+ 17
9 GroundTD3- 18
57
Chapter 4: Motherboard Connections
4.4 Jumpers
Explanation of Jumpers
To modify the operation of the motherboard, jumpers are used to choose between optional
settings. Jumpers create shorts between two pins to change the function associated with it.
Pin 1 is identied with a square solder pad on the printed circuit board. See the motherboard
layout page for jumper locations.
Note: On a two-pin jumper, "Closed" means the jumper is on both pins and "Open" indicates
the jumper is either on only one pin or has been completely removed.
Connector
Pins
Jumper
Setting
3 2 1
3 2 1
CMOS Clear
JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper
consists of contact pads to prevent accidentally clearing the contents of CMOS.
To Clear CMOS
1. First power down the system and unplug the power cord(s).
2. Remove the cover of the chassis to access the motherboard.
3. Remove the onboard battery from the motherboard.
4. Short the CMOS pads with a metal object such as a small screwdriver for at least four
seconds.
5. Remove the screwdriver (or shorting device).
6. Replace the cover, reconnect the power cord(s) and power on the system.
Notes: Clearing CMOS will also clear all passwords.
Do not use the PW_ON connector to clear CMOS.
JBT1 contact pads
58
SuperWorkstation 7049GP-TRT User's Manual
HD Audio Enable
JHD_AC1 allows you to enable or disable the onboard high denition audio support. See the
table below for jumper settings
HD Audio Enable/Disable
Jumper Settings
Jumper Setting Denition
Open Enabled (Default)
Short Disabled
Onboard Audio Enable
JPAC1 allows you to enable or disable the onboard audio support. The default position is on
pins 1-2 to enable onboard audio connections. Refer to the table below for jumper settings.
Audio Enable/Disable
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
Watch Dog
JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system
when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the
system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt
signal for the application that hangs. Watch Dog must also be enabled in BIOS. The default
setting is Reset.
Note: When Watch Dog is enabled, the user needs to write their own application
software to disable it.
Watch Dog
Jumper Settings
Jumper Setting Denition
Pins 1-2 Reset
Pins 2-3 NMI
Open Disabled
Manufacturing Mode Select
Close JPME2 to bypass SPI ash security and force the system to use the Manufacturing
Mode, which will allow you to ash the system rmware from a host server to modify system
settings. See the table below for jumper settings.
Manufacturing Mode Select
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 Manufacturing Mode
59
Chapter 4: Motherboard Connections
VRM_I2C Jumper
Set this jumper (JVRM_SEL1) to Normal (Default) to allow BMC to access VRM controllers.
Set this jumper to short pins 2-3 to have VRM code updated by PCH. See the table below
for jumper settings.
VRM_I2C
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 VRM Program
10Gb LAN1/2 Enable/Disable
JPTG1 allows you to enable or disable the 10Gb LAN1/2. The default setting is Enabled.
10Gb LAN Enable/Disable
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled
Pins 2-3 Disabled
60
SuperWorkstation 7049GP-TRT User's Manual
4.5 LED Indicators
Dedicated IPMI LAN LEDs
A dedicated IPMI LAN port is also included on the motherboard. The amber LED on the right
of the IPMI LAN port indicates activity, while the green LED on the left indicates the speed
of the connection. See the table below for more information.
IPMI LAN Link LEDs
Color Status Denition
O󰀨 O󰀨 No Connection
Green: Solid Link/Speed (Left) 100 Mb/s
Amber Blinking Activity (Right) Active
IPMI LAN
Activity LEDLink LED
UID LED
LED Indicator
LED Color Denition
Blue: On Unit Identied
Unit ID LED
A rear UID LED indicator at LED2 is located near the UID switch on the I/O back panel. This
UID indicator provides easy identication of a system unit that may need service.
Onboard Power LED
LEDPWR is an Onboard Power LED. When this LED is lit, it means that power is present
on the motherboard. In suspend mode, this LED will blink on and o󰀨. Be sure to turn o󰀨 the
system and unplug the power cord(s) before removing or installing components.
Onboard Power LED Indicator
LED Color Denition
O󰀨
System O󰀨
(power cable not
connected)
Green System On
BMC Heartbeat LED
LEDM1 is the BMC heartbeat LED. When the LED is blinking green, BMC is functioning
normally. See the table below for the LED status.
Onboard Power LED Indicator
LED Color Denition
Green:
Blinking BMC Normal
Chapter 5: Software
61
Chapter 5
Software
After the hardware has been installed, you can install the Operating System (OS), congure
RAID settings and install the drivers.
5.1 Microsoft Windows OS Installation
If you will be using RAID, you must congure RAID settings before installing the Windows
OS and the RAID driver. Refer to the RAID Conguration User Guides posted on our website
at www.supermicro.com/support/manuals.
Installing the OS
1. Create a method to access the MS Windows installation ISO le. That might be a DVD,
perhaps using an external USB/SATA DVD drive, or a USB ash drive, or the IPMI KVM
console.
2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your
motherboard and click on "Download the Latest Drivers and Utilities", select the proper
driver, and copy it to a USB ash drive.
3. Boot from a bootable device with Windows OS installation. You can see a bootable
device list by pressing during the system startup.F11
Figure 5-1. Select Boot Device
SuperServer 7049GP-TRT User's Manual
62
4. During Windows Setup, continue to the dialog where you select the drives on which to
install Windows. If the disk you want to use is not listed, click on “Load driver” link at the
bottom left corner.
Figure 5-2. Load Driver Link
To load the driver, browse the USB ash drive for the proper driver les.
• For RAID, choose the SATA/sSATA RAID driver indicated then choose the storage drive
on which you want to install it.
• For non-RAID, choose the SATA/sSATA AHCI driver indicated then choose the storage
drive on which you want to install it.
5. Once all devices are specied, continue with the installation.
6. After the Windows OS installation has completed, the system will automatically reboot
multiple times.
Chapter 5: Software
63
5.2 Driver Installation
The Supermicro website contains drivers and utilities for your system at https://www.
supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver.
After accessing the website, go into the CDR_Images (in the parent directory of the above
link) and locate the ISO le for your motherboard. Download this le to to a USB ash drive
or a DVD. (You may also use a utility to extract the ISO le if preferred.)
Another option is to go to the Supermicro website at http://www.supermicro.com/products/.
Find the product page for your motherboard, and "Download the Latest Drivers and Utilities".
Insert the ash drive or disk and the screenshot shown below should appear.
Figure 5-3. Driver & Tool Installation Screen
Note: Click the icons showing a hand writing on paper to view the readme les for each
item. Click the computer icons to the right of these items to install each item (from top to the
bottom) one at a time. After installing each item, you must re-boot the system before
moving on to the next item on the list. The bottom icon with a CD on it allows you to view
the entire contents.
SuperServer 7049GP-TRT User's Manual
64
5.3 SuperDoctor® 5
The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based
interface for Windows and Linux operating systems. The program monitors such system health
information as CPU temperature, system voltages, system power consumption, fan speed,
and provides alerts via email or Simple Network Management Protocol (SNMP).
SuperDoctor 5 comes in local and remote management versions and can be used with Nagios
to maximize your system monitoring needs. With SuperDoctor 5 Management Server (SSM
Server), you can remotely control power on/o󰀨 and reset chassis intrusion for multiple systems
with SuperDoctor 5 or IPMI. SuperDoctor 5 Management Server monitors HTTP, FTP, and
SMTP services to optimize the e󰀩ciency of your operation.
Note: The default User Name and Password for SuperDoctor 5 is ADMIN / ADMIN.
Figure 5-4. SuperDoctor 5 Interface Display Screen (Health Information)
Chapter 5: Software
65
5.4 IPMI
The X11DPG-QT supports the Intelligent Platform Management Interface (IPMI).
IPMI provides remote access, monitoring and management through the baseboard
management controller (BMC) and other management controllers distributed
among different system modules.There are several BIOS settings that are related
to IPMI. For general documentation and information on IPMI, visit our website at:
http://www.supermicro.com/products/nfo/IPMI.cfm.
BMC ADMIN User Password
For security, each system is assigned a unique default BMC password for the ADMIN user.
This can be found on a sticker on the chassis and a sticker on the motherboard. The sticker
also displays the BMC MAC address.
Figure 5-5. BMC Password Label
See Chapter 1 for the locations of the labels.
SuperWorkstation 7049GP-TRT User's Manual
66
Chapter 6
UEFI BIOS
6.1 Introduction
This chapter describes the AMIBIOS™ Setup utility for the X11DPG-QT motherboard. The is
stored on a chip and can be easily upgraded using a ash program.
Note: Due to periodic changes to the BIOS, some settings may have been added or deleted
and might not yet be recorded in this manual. Please refer to the Manual Download area of
our website for any changes to BIOS that may not be reected in this manual.
Starting the Setup Utility
To enter the BIOS Setup Utility, hit the <Delete> key while the system is booting up. (In
most cases, the <Delete> key is used to invoke the BIOS setup screen. There are a few
cases when other keys are used, such as <F1>, <F2>, etc.) Each main BIOS menu option
is described in this manual.
The Main BIOS screen has two main frames. The left frame displays all the options that can
be congured. “Grayed-out” options cannot be congured. The right frame displays the key
legend. Above the key legend is an area reserved for a text message. When an option is
selected in the left frame, it is highlighted in white. Often a text message will accompany it.
(Note that BIOS has default text messages built in. We retain the option to include, omit, or
change any of these text messages.) Settings printed in are the default values.Bold
A " " indicates a submenu. Highlighting such an item and pressing the <Enter> key will
open the list of settings within that submenu.
The BIOS setup utility uses a key-based navigation system called hot keys. Most of these
hot keys (<F1>, <F10>, <Enter>, <ESC>, <Arrow> keys, etc.) can be used at any time during
the setup navigation process.
Chapter 6: UEFI BIOS
67
6.2 Main Setup
When you rst enter the AMI BIOS setup utility, you will enter the Main setup screen. You can
always return to the Main setup screen by selecting the Main tab on the top of the screen. The
Main BIOS setup screen is shown below. The following Main menu items will be displayed:
System Date/System Time
Use this option to change the system date and time. Highlight System Date or System Time
using the arrow keys. Enter new values using the keyboard. Press the <Tab> key or the arrow
keys to move between elds. The date must be entered in MM/DD/YYYY format. The time
is entered in HH:MM:SS format.
Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.
The date's default value is 01/01/2015 after RTC reset.
Supermicro X11DPG-QT
BIOS Version
This item displays the version of the BIOS ROM used in the system.
Build Date
This item displays the date when the version of the BIOS ROM used in the system was built.
CPLD Version
This item displays the Complex Programmable Logic Device version. Memory Information
Memory Information
Total Memory
This item displays the total size of memory available in the system.
SuperWorkstation 7049GP-TRT User's Manual
68
6.3 Advanced Setup Congurations
Use the arrow keys to select Boot Setup and press <Enter> to access the submenu items.
Warning: Take caution when changing the Advanced settings. An incorrect value, a very high
DRAM frequency, or an incorrect DRAM timing setting may make the system unstable. When
this occurs, revert to the default to the manufacture default settings.
Boot Feature
Quiet Boot
Use this feature to select the screen display between the POST messages and the OEM logo
upon bootup. Select Disabled to display the POST messages. Select Enabled to display the
OEM logo instead of the normal POST messages. The options are Disabled and Enabled.
Option ROM Messages
Use this feature to set the display mode for the Option ROM. Select Keep Current to display
the current AddOn ROM setting. Select Force BIOS to use the Option ROM display set by
the system BIOS. The options are Force BIOS and Keep Current.
Bootup NumLock State
Use this feature to set the Power-on state for the <Numlock> key. The options are On and O󰀨.
Wait For "F1" If Error
Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs.
The options are Disabled and Enabled.
Chapter 6: UEFI BIOS
69
INT19 Trap Response
Interrupt 19 is the software interrupt that handles the boot disk function. When this item is
set to Immediate, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup
immediately and allow the drives that are attached to these host adaptors to function as
bootable disks. If this item is set to Postponed, the ROM BIOS of the host adaptors will not
capture Interrupt 19 immediately and allow the drives attached to these adaptors to function
as bootable devices at bootup. The options are Immediate and Postponed.
Re-try Boot
If this item is enabled, the BIOS will automatically reboot the system from a specied boot
device after its initial boot failure. The options are Disabled, Legacy Boot, and EFI Boot.
Install Windows 7 USB support
Enable this feature to use the USB keyboard and mouse during the Windows 7 installation,
since the native XHCI driver support is unavailable. Use a SATA optical drive as a USB drive.
USB CD/DVD drives are not supported. Disable this feature after the XHCI driver has been
installed in Windows. The options are and Enabled.Disabled
Port 61h Bit-4 Emulation
Select Enabled to support the emulation of Port 61h bit-4 toggling in SMM (System
Management Mode). The options are Disabled and Enabled.
Power Conguration
Watch Dog Function
If enabled, the Watch Dog Timer will allow the system to reset or generate NMI based on
jumper settings when it is expired for more than 5 minutes. The options are Disabled and
Enabled.
Restore on AC Power Loss
Use this feature to set the power state after a power outage. Select Stay-Off for
the system power to remain o after a power loss. Select Power-On for the system
power to be turned on after a power loss. Select Last State to allow the system to
resume its last power state before a power loss. The options are Stay O, Power On,
and Last State.
Power Button Function
This feature controls how the system shuts down when the power button is pressed. Select 4
Seconds Override for the user to power o the system after pressing and holding the power
button for 4 seconds or longer. Select Instant O to instantly power o the system as soon
as the user presses the power button. The options are and 4 Seconds Override.Instant O
SuperWorkstation 7049GP-TRT User's Manual
70
Throttle on Power Fail
Throttling improves reliability and reduces power consumption in the processor via automatic
voltage control during processor idle states. Select Enabled to decrease the system power
by throttling CPU frequency when one power supply is failed. The options are Disabled and
Enabled.
CPU Conguration
This submenu displays the information of the CPU as detected by the BIOS. It also allows
the user to conguration CPU settings:
• Processor BSP Revision
• Processor Socket
• Processor ID
• Processor Frequency
• Processor Max Ration
• Processor Min Ration
• Microcode Revision
• L1 Cache RAM
• L2 Cache RAM
• L3 Cache RAM
• Processor 0 Version
• Processor 1 Version
Hyper-Threading [All] (Available when supported by the CPU)
Select Enabled to support Intel® Hyper-threading Technology to enhance CPU performance.
The options are Disable and Enable.
Execute Disable Bit (Available if supported by the OS & the CPU)
Select Enable to enable the Execute-Disable Bit which will allow the processor to designate
areas in the system memory where an application code can execute and where it cannot,
thus preventing a worm or a virus from ooding illegal codes to overwhelm the processor or
damage the system during an attack. (Please refer to Intel's website for more information.)
The options are Disable and Enable.
Chapter 6: UEFI BIOS
71
Intel Virtualization Technology (Available when supported by the CPU)
Select Enable to use Intel® Virtualization Technology so that I/O device assignments will be
reported directly to the VMM (Virtual Memory Management) through the DMAR ACPI Tables.
This feature o󰀨ers fully-protected I/O resource-sharing across the Intel® platforms, providing
the user with greater reliability, security and availability in networking and data-sharing. The
options are Disable and Enable.
Note: If a change is made to this setting, you will need to reboot the system for the
change to take e󰀨ect. Refer to Intel’s website for detailed information.
PPIN Control
Select Unlock/Enable to use the Protected-Processor Inventory Number (PPIN) in the system.
The options are Unlock/Disable and Unlock/Enable.
Hardware Prefetcher (Available when supported by the CPU)
If this item is set to Enable, the hardware prefetcher will prefetch streams of data and
instructions from the main memory to the L2 cache to improve CPU performance. The options
are Enable and Disable.
Adjacent Cache Prefetch (Available when supported by the CPU)
The CPU prefetches the cache line for 64 bytes if this feature is set to Disable. The CPU
prefetches both cache lines for 128 bytes as comprised if this feature is set to Enable. The
options are and Disable. Enable
DCU Streamer Prefetcher (Available when supported by the CPU)
Select Enabled to enable Intel® CPU Advanced Encryption Standard (AES) Instructions for
CPU to enhance data integrity. The options are and Disable. Enable
DCU IP Prefetcher (Available when supported by the CPU)
If this feature is set to Enable, the DCU (Data Cache Unit) IP prefetcher will prefetch IP
addresses in advance to improve network connectivity and system performance. The options
are Enable and Disable.
LLC Prefetch
Select Enable to support the LLC prefetch on all threads. The options are and Enable. Disable
Extended APIC
Select Enable to use the extended APIC (Advanced Programmable Interrupt Control) support
to enhance power management. The options are Disable and Enable.
AES-NI
Select Enable to use the Intel® Advanced Encryption Standard (AES) New Instructions (NI)
to ensure data security. The options are Disable and Enable.
SuperWorkstation 7049GP-TRT User's Manual
72
Advanced Power Management Conguration
Power Technology
Use this item to enable power management features. The options are Disable, Energy
Ecient, and Custom. Select Energy Ecient to support power-saving mode. Select
Custom to customize system power settings. Select Disable to disable power-saving
settings.
Power Performance Tuning (Available when Power Technology is set to Custom)
This feature allows the user to set whether the operating system or the BIOS controls the
Energy Performance BIAS (EPB). The options are OS Controls EPB and BIOS Controls
EPB.
ENERGY_PERF_BIAS_CFG Mode (Available when Power Performance Tuning is
set to BIOS Controls EPB)
The Energy Performance BIAS (EPB) feature allows the user to congure CPU power and
performance settings. Select Maximum Performance to set the highest performance. Select
Performance to optimize performance over energy eciency. Select Balanced Performance
to prioritize performance optimization while conserving energy. Select Balanced Power
to prioritize energy conservation while maintaining good performance. Select Power to
optimize energy eciency over performance. The options are Maximum Performance,
Performance, Balanced Performance, Balanced Power, and Power.
CPU P State Control (Available when Power Technology is set to
Custom)
SpeedStep (Pstates)
EIST (Enhanced Intel® SpeedStep™ Technology) allows the system to automatically
adjust processor voltage and core frequency to reduce power consumption and heat
dissipation. The options are Disable and Enable.
EIST PSD Function
This feature allows the user to change the P-State (Power-Performance State) coordina-
tion type. P-State is also known as "SpeedStep" for Intel® processors. Select HW_ALL to
change the P-State coordination type for all hardware components only. Select SW_ALL
to change the P-State coordination type for all software installed in the system. Select
SW_ANY to change the P-State coordination type for a particular software program
specied by the user in the system. The options are HW_ALL, SW_ALL, and SW_ANY.
Turbo Mode (Available when Intel® EIST Technology is enabled)
Select Enable to use the Turbo Mode to boost system performance. The options are
Disable and Enable.
SuperWorkstation 7049GP-TRT User's Manual
74
Chipset Conguration
Warning: Setting the wrong values in the following features may cause the system to malfunc-
tion.
North Bridge
This feature allows the user to congure the following North Bridge settings.
UPI Conguration
UPI Conguration
The following information will be displayed:
• Number of CPU
• Number of IIO
• Current UPI Link Speed
• Current UPI Link Frequency
• UPI Global MMIO Low Base/Limit
• UPI Global MMIO High Base/Limit
• UPI Pci-e Conguration Base/Size
Degrade Precedence
Select Topology Precedence to degrade features if system options are in conict. Select
Feature Precedence to degrade topology if system options are in conict. The options
are Topology Precedence and Feature Precedence.
Link L0p Enable
Select Enable for the QPI to enter the L0p state for power saving. The options are Dis-
able, Enable, and Auto.
Link L1 Enable
Select Enable for the QPI to enter the L1 state for power saving. The options are Dis-
able, Enable, and Auto.
IO Directory Cache (IODC)
Use this feature to enable the IO Directory Cache (IODC) support. The options are Dis-
able, Auto, Enable for Remote InvItoM Hybrid Push, InvItoM AllocFlow, Enable for Re-
mote InvItoM Hybrid AllocNonAlloc, and Enable for Remote InvItoM and Remote WViLF.
Chapter 6: UEFI BIOS
75
SNC
Sub NUMA Clustering (SNC) is a feature that breaks up the Last Level Cache (LLC) into
clusters based on address range. Each cluster is connected to a subset of the memory
controller. Enabling SNC improves average latency and reduces memory access conges-
tion to achieve higher performance. Select Auto for 1-cluster or 2-clusters depending on
IMC interleave. Select Enable for Full SNC (2-clusters and 1-way IMC interleave). The
options are , Enable, and AutoDisable .
XPT Prefetch
XPT Prefetch is a feature that speculatively makes a copy to the memory controller of
a read request being sent to the LLC. If the read request maps to the local memory ad-
dress and the recent memory reads are likely to miss the LLC, a speculative read is sent
to the local memory controller. The options are Disable and Enable.
KTI Prefetch
KTI Prefetch is a feature that enables memory read to start early on a DDR bus, where
the KTI Rx path will directly create a Memory Speculative Read command to the memory
controller. The options are Disable and Enable.
Local/Remote Threshold
This feature allows the user to set the threshold for the Interrupt Request (IRQ) signal,
which handles hardware interruptions. The options are Disable, Auto, Low, Medium,
and High.
Stale AtoS
This feature optimizes A to S directory. When all snoop responses found in directory A
are found to be Rspl, then all data is moved to directory S and is returned in S-state.
The options are , Enable, and AutoDisable .
LLC Dead Line Alloc
Select Enable to optimally ll dead lines in LLC. Select Disable to never ll dead lines in
LLC. The options are Disable, Enable, and Auto.
Isoc Mode
Select Enable to enable Isochronous support to meet QoS (Quality of Service) require-
ments. This feature is especially important for Virtualization Technology. The options are
Disable, Enable, and Auto.
SuperWorkstation 7049GP-TRT User's Manual
76
Memory Conguration
Integrated Memory Controller (iMC)
Enforce POR
Select Enable to enforce POR restrictions on DDR4 frequency and voltage programming.
The options are and Disable.POR
Memory Frequency
Use this feature to set the maximum memory frequency for onboard memory modules.
The options are 1866, 2000, 2133, 2200, 2400, 2600, and 2666.Auto,
Data Scrambling for NVMDIMM
Select Enable to enable data scrambling to enhance system performance and data in-
tegrity. The options are , Disable, and Enable.Auto
Data Scrambling for DDR4
Use this feature to enable data scrambling for DDR4. The options are , Disable, Auto
and Enable.
tCCD_L Relaxation
Select Auto to get TCDD settings from SPD (Serial Presence Detect) and implement into
memory RC code to improve system reliability. Select Disable for TCCD to follow Intel
POR. The options are Disable and Auto.
Enable ADR
Select Enable for ADR (Automatic Diagnostic Repository) support to enhance memory
performance. The options are and Enable.Disable
2X Refresh Options
Use this item to select the 2X refresh mode. The options are Auto and Enable.
Page Policy
This feature allows the user to determine the desired page mode for IMC. When Auto is
selected, the memory controller will close or open pages based on the current operation.
Closed policy closes that page after reading or writing. Adaptive is similar to open page
policy, but can be dynamically modied. The options are Auto, Closed, and Adaptive..
IMC Interleaving
This feature allows the user to congure Integrated Memory Controller (IMC) Interleaving
settings. The options are , 1-way Interleave, and 2-way Interleave.Auto
Chapter 6: UEFI BIOS
77
Memory Topology
The item displays the information of onboard memory modules as detected by the
BIOS.
Memory RAS (Reliability_Availability_Serviceability) Conguration
Memory RAS Conguration Setup
Use this submenu to congure the following Memory RAS settings.
Static Virtual Lockstep Mode
Select Enable to support the static virtual lockstep mode. The options are Disable
and Enable.
Mirror Mode
Use this item to select the mirror mode. The options are , Mirror Mode 1LM, Disable
and Mirror Mode 2LM. If this item is set to Mirror Mode 1LM or Mirror Mode 2LM, the
available memory capacity will be reduced by 50 percent.
UEFI ARM Mirror
Select Enable to support the UEFI-based address range mirroring with setup option.
The options are and Enable.Disable
Memory Rank Sparing
Select Enable to enable memory-sparing support for memory ranks to improve memory
performance. The options are and Enable.Disable
*If the item above "Memory Rank Sparing" is set to Enable, the following item,
"Multi Rank Sparing", will be available:
Multi Rank Sparing
Use this feature to set the multiple rank sparing number. The default setting and the
maximum is two ranks per channel. The options are One Rank and Two Rank.
Correctable Error Threshold
Use this item to enter the threshold value for correctable memory errors. The default
setting is 10.
SDDC Plus One
Single Device Data Correction (SDDC) allows data to be reconstructed when one of
the memory devices fails on a DIMM. Use this feature to enable the SDDC support.
The options are and Enable.Disable
